Introduction

Proton is a tool for use with the Steam client which allows games which are exclusive to Windows to run on the Linux operating system. It uses Wine to facilitate this.

Proton-CachyOS is a tool for use with the Steam client and umu-launcher which builds on Proton introducing experimental features, third-party tools and more. You can find binary packages for use with Steam Linux Runtime in this repository's releases.

Most users should use Proton provided by the Steam Client itself. See this Steam Community post for more details. This custom Proton distributions is provided for users who want to test bleeding-edge features, community modifications and stores other than Steam.

The changelog is available in CHANGELOG.md.

Build instructions are available in BUILDING.md.

Runtime Config Options

Proton can be tuned at runtime to help certain games run. The Steam client sets some options for known games using the STEAM_COMPAT_CONFIG variable. You can override these options using the environment variables described below.

The best way to set these environment overrides for all games is by renaming user_settings.sample.py to user_settings.py and modifying it appropriately. This file is located in the Proton installation directory in your Steam library (often ~/.steam/steam/steamapps/common/Proton #.#).

If you want to change the runtime configuration for a specific game, you can use the Set Launch Options setting in the game's Properties dialog in the Steam client. Set the variable, followed by %command%. For example, input "PROTON_USE_WINED3D=1 %command%" to use the OpenGL-based wined3d renderer instead of the Vulkan-based DXVK renderer.

To enable an option, set the variable to a non-0 value. To disable an option, set the variable to 0. To use Steam's default configuration, do not specify the variable at all.

All of the below are runtime options. They do not effect permanent changes to the Wine prefix. Removing the option will revert to the previous behavior.

Compat config string	Environment Variable	Description
	PROTON_LOG	Convenience method for dumping a useful debug log to $PROTON_LOG_DIR/steam-$APPID.log. Set to 1 to enable default logging, or set to a string to be appended to the default WINEDEBUG channels.
	PROTON_LOG_DIR	Output log files into the directory specified. Defaults to your home directory.
	PROTON_WAIT_ATTACH	Wait for a debugger to attach to steam.exe before launching the game process. To attach to the game process at startup, debuggers should be set to follow child processes.
	PROTON_CRASH_REPORT_DIR	Write crash logs into this directory. Does not clean up old logs, so may eat all your disk space eventually.
wined3d	PROTON_USE_WINED3D	Use OpenGL-based wined3d instead of Vulkan-based DXVK for d3d11, d3d10, and d3d9.
nod3d11	PROTON_NO_D3D11	Disable d3d11.dll, for d3d11 games which can fall back to and run better with d3d9.
nod3d10	PROTON_NO_D3D10	Disable d3d10.dll and dxgi.dll, for d3d10 games which can fall back to and run better with d3d9.
dxvkd3d8	PROTON_DXVK_D3D8	Use DXVK's d3d8.dll.
nofsync	PROTON_NO_FSYNC	Do not use futex-based in-process synchronization primitives. (Automatically disabled on systems with no FUTEX_WAIT_MULTIPLE support.)
	HOST_LC_ALL	Set value to a locale to override all other system locale settings for a game. This variable should be used instead of LC_ALL.
disablenvapi	PROTON_DISABLE_NVAPI	Disable NVIDIA's NVAPI GPU support library.
nativevulkanloader		Use the Vulkan loader shipped with the game instead of Proton's built-in Vulkan loader. This breaks VR support, but is required by a few games.
forcelgadd	PROTON_FORCE_LARGE_ADDRESS_AWARE	Force Wine to enable the LARGE_ADDRESS_AWARE flag for all executables. Enabled by default.
heapdelayfree	PROTON_HEAP_DELAY_FREE	Delay freeing some memory, to work around application use-after-free bugs.
gamedrive	PROTON_SET_GAME_DRIVE	Create an S: drive which points to the Steam Library which contains the game.
noforcelgadd		Disable forcelgadd. If both this and forcelgadd are set, enabled wins.
oldglstr	PROTON_OLD_GL_STRING	Set some driver overrides to limit the length of the GL extension string, for old games that crash on very long extension strings.
vkd3dfl12		Force the Direct3D 12 feature level to 12, regardless of driver support.
vkd3dbindlesstb		Put force_bindless_texel_buffer into VKD3D_CONFIG.
nomfdxgiman	WINE_DO_NOT_CREATE_DXGI_DEVICE_MANAGER	Enable hack to work around video issues in some games due to incomplete IMFDXGIDeviceManager support.
noopwr	WINE_DISABLE_VULKAN_OPWR	Enable hack to disable Vulkan other process window rendering which sometimes causes issues on Wayland due to blit being one frame behind.
hidenvgpu	PROTON_HIDE_NVIDIA_GPU	Force Nvidia GPUs to always be reported as AMD GPUs. Some games require this if they depend on Windows-only Nvidia driver functionality. See also DXVK's nvapiHack config, which only affects reporting from Direct3D.
	WINE_FULLSCREEN_INTEGER_SCALING	Enable integer scaling mode, to give sharp pixels when upscaling.
	WINE_USE_KWIN_HACKS	Enable KDE-specific windowing hacks that may improve experience with KDE older than 6.4 on Wayland and KDE older than 6.6 on X11.
cmdlineappend:		Append the string after the colon as an argument to the game command. May be specified more than once. Escape commas and backslashes with a backslash.
xalia or noxalia	PROTON_USE_XALIA	Enable Xalia, a program that can add a gamepad UI for some keyboard/mouse interfaces, or set to 0 to disable. The default is to enable it dynamically based on window contents.
fnad3d11	FNA3D_FORCE_DRIVER=D3D11	Force FNA to use D3D11 for rendering.
seccomp	PROTON_USE_SECCOMP	Note: Obsoleted in Proton 5.13. In older versions, enable seccomp-bpf filter to emulate native syscalls, required for some DRM protections to work.
d9vk	PROTON_USE_D9VK	Note: Obsoleted in Proton 5.0. In older versions, use Vulkan-based DXVK instead of OpenGL-based wined3d for d3d9.

Proton-CachyOS Config Options

Compat config string	Environment Variable	Description
	PROTON_LOG	In case of videos/audio not playing or being replaced by the SMPTE color bars, use"+mfplat,+quartz,+wmvcore,+wmadec,+dmo" instead of 1.
dxvksarek	PROTON_DXVK_SAREK	Use the dxvk-sarek fork as DXVK replacement for older GPUs that don't properly support Vulkan 1.3 (supported Vulkan 1.1.x to 1.2.x). It is using the async branch, so it SHOULD NOT to be used with games using anti-cheat or multiplayer games in general. You have been warned.
dxvklowlatency	PROTON_DXVK_LOWLATENCY	Enable the alternative dxvk-low-latency fork, which enhances the original dxvk with low-latency frame pacing capabilities to improve game responsiveness and input lag. It also improves latency stability over time, usually resulting in a more accurate playback speed of the generated video. Refer to the project's documentation for in-depth configuration.
d7vkddraw	PROTON_D7VK_DDRAW	Use ddraw.dll from the D7VK project for DirectX 7-or-lower games.
fsr4	PROTON_FSR4_UPGRADE	Automatically download amdxcffx64.dll and upgrade games with FSR 3.1 to use FSR 4. Version to download can be specified by supplying it as a value, like so PROTON_FSR4_UPGRADE="4.0.1", instead of 1. Downloads the latest available and known-good version of the required DLL by default.
fsr4hud	PROTON_FSR4_INDICATOR	Enable the FSR4 watermark at the top left portion of the screen. This is a shorthand option for setting FSR_WATERMARK=1 and FSR_FG_WATERMARK=1.
mlfg	PROTON_MLFG_UPGRADE	Enables the use of MLFG with FSR4 >= 4.0.3.
dlss	PROTON_DLSS_UPGRADE	Automatically download and use newer versions of nvngx_dlss(d|g).dll DLLs. Version to download can be specified by supplying it as a value, like so PROTON_DLSS_UPGRADE="310.2", instead of 1, to download version 310.2.1.0. This option also sets DXVK_NVAPI_DRS_SETTINGS to use the latest preset. If you provide your own configuration through this environment variable, your configuration will override the defaults.
dlsshud	PROTON_DLSS_INDICATOR	Enable the DLSS overlay at the bottom left portion of the screen.
xess	PROTON_XESS_UPGRADE
ffx3	PROTON_FFX3_UPGRADE
ffx4	PROTON_FFX4_UPGRADE
nvidialibs	PROTON_NVIDIA_LIBS	Enable alternative implementations of Nvidia libraries missing from Proton. Allows things like hardware-accelerated PhysX to function and should be use only when needed. This option enables all of nvcuda, nvenc, nvml and nvoptix. These are incompatible with wow64 and thus disabled when PROTON_USE_WOW64=1 is set.
nvidialibsno32	PROTON_NVIDIA_LIBS_NO_32BIT	Use with the previous option, to enable only the 64bit nvidia libraries. Useful if you are using RTX series 4000 or 5000 GPUs and you had bad performance or crashes when enabling these with 32bit games.
nvcuda	PROTON_NVIDIA_NVCUDA	Enable alternative nvcuda.dll from nvidia-libs only.
nvenc	PROTON_NVIDIA_NVENC	Enable alternative nvcencodeapi(64).dll from nvidia-libs only.
nvml	PROTON_NVIDIA_NVML	Enable alternative nvml.dll from nvidia-libs only. This option is enabled by default.
nvoptix	PROTON_NVIDIA_NVOPTIX	Enable alternative nvoptix.dll from nvidia-libs only.
nowmdecoration	PROTON_NO_WM_DECORATION	Disable window decorations by the the window manager, use wine's own window decorations.
wayland	PROTON_ENABLE_WAYLAND	Enable Wayland support. winewayland is experimental and work-in-progress, expect issues. When reporting issues ALWAYS mention if you using this environment variable, and make sure the issue still happens without it. Valve's Protons do not include winewayland.drv, they always use winex11.drv. For more information refer to this section
wayland	PROTON_USE_WAYLAND	Alias of PROTON_ENABLE_WAYLAND
pipewire	PROTON_USE_PIPEWIRE	Enable the winepipewire.drv audio driver. This audio driver is enabled by default and can be disabled with PROTON_USE_PIPEWIRE=0. For more information and further configuration refer to this section
	DXVK_HDR	Enables HDR when set to DXVK_HDR=1, optionally combined with ENABLE_HDR_WSI=1 if required, on Nvidia driver versions older than 595.x.x.
	DXVK_NO_HDR	The opposite of DXVK_HDR=1, forcefully disables HDR if it is automatically enabled. NOTE: Presently Gnome does not support enough color management features to expose HDR automatically.
sdlinput	PROTON_PREFER_SDL	Uses SDL input instead of HIDRAW/Steam Input
sdlinput	PROTON_USE_SDL	Alias of PROTON_PREFER_SDL
	PROTON_NO_STEAMINPUT
localshadercache	PROTON_LOCAL_SHADER_CACHE	Enable per-game shader cache even if "Shader Pre-caching" is disabled. Any configuration set by this option can be overriden, i.e. if one of the environment variables is already set, the user-set value will be used. The default configuration is set up to mimic Steam's "Shader Pre-Caching", with shaders being cached under <steamlibrary>/shadercache/<appid> for each game.
mediaconv	PROTON_ENABLE_MEDIACONV	For debugging purposes, do not use.
	PROTON_MEDIA_FORCE_GST	Fixes video/audio playback in cutscenes in some cases.
	PROTON_GST_VIDEO_ORIENTATION	Change the orientation (rotation) of videos rendered using gstreamer. The accepted values are the same as gstreamer's videoflip plugin
vkreflex	DXVK_NVAPI_VKREFLEX	Enables DXVK-NVAPI's Vulkan Reflex layer to support Reflex in Vulkan games. It's meant to enable Reflex in games such as Portal RTX, Path of Exile 1 and 2 and Doom TDA, etc.
lowlatencylayer	LOW_LATENCY_LAYER	Enables low_latency_layer, for more information and and configuration options refer to the projects README.
	PROTON_USE_OPTISCALER	Enables automatic OptiScaler injection. For more information refer to this section
	PROTON_DISCORD_BRIDGE	Enables rpc-bridge to allow games running in Proton to set Discord's Rich Presence.

Other Useful Config Options

Compat config string	Environment Variable	Description
	WINE_BLOCK_HOSTS	Provides a list of hosts for Wine to not connect to. The list can be either comma (,) or semicolon (;) separated, i.e WINE_BLOCK_HOSTS=host1.org,host2.net. The maximum number of hosts is 16 and the maximum length of each host is 256 characters.
	WINEALSA_CHANNELS	Allows to select more than two channels with the winealsa driver as well as force disable spatial audio in games. Can be useful with surround setups or when the sounds come out wrong positionally (like dialogue coming out only from the left speaker). Possible values is the number of speakers, such as 2 (to disable spatial audio), such as 4 (2 front, 2 rear), 6 (5.1) or 8 (7.1).
	WINEALSA_SPATIAL	Properly downmixes spatial with winealsa and includes the height channels. Use 1 to enable, 0 to disable (default). Recommended only if there are spatial audio errors with the WINEALSA_CHANNELS variable
	WINE_AUDIO_DRIVER	Comma-separated list of audio drivers for wine to choose from. The default list is pipewire,pulse,alsa. For example WINE_AUDIO_DRIVER=pulse will use winepulse.drv exclusively.
	GST_GL_WINDOW

Proton wayland quirks

If something that uses Electron/CEF (launchers like Battle.net, Ubisoft Connect, EA App, Rockstar Launcher) doesn't work (displays as white window) after enabling native Wayland support, try adding --in-process-gpu to the command arguments. If you encounter controller issues with winewayland.drv, try using PROTON_USE_SDL=1, or running Steam with -steamos3 which might allow Steam Input to work. For other options relating to winewayland.drv refer to Proton-EM documentation

NOTE: The automated wayland hacks that were included in Proton 10 have been removed on purpose pending a proper implementation. This is the reason previous versions seemed to work but in Proton 11 some launchers display as a white window.

Pipewire audio driver

• The driver is enabled by default. To disable it and use winepulse.drv set PROTON_USE_PIPEWIRE=0.
• You can also use WINE_AUDIO_DRIVER to set the list of audio drivers for wine to choose from. The default list is pipewire,pulse,alsa. For example WINE_AUDIO_DRIVER=pulse will use winepulse.drv exclusively.
• When reporting issues with winepipewire.drv remember to use PROTON_LOG=warn+pipewire,warn+mmdevapi %command% to create meaningful logs. Make sure to leep the logging level at warn+ as shown. Full tracing (+pipewire,+mmdevapi) floods the log and perturbs audio timing enough to cause crackling, so only use it for a short capture and remove it for normal play.
• Lower latency (system-wide; smaller = lower latency, more CPU; 0 = auto)

  pw-metadata -n settings 0 clock.force-quantum 256


  To make it permanent edit ~/.config/pipewire/pipewire.conf.d/99-lowlatency.conf:

  context.properties = { default.clock.min-quantum = 256 }


  Setting PIPEWIRE_LATENCY does nothing here, use the quantum above.
• Choose output device - games follow your PipeWire default sink. Change it in your sound settings, pavucontrol (Playback tab), or wpctl set-default <id>. The game shows up named after itself or as winepipewire.
• You can make sure the game uses winepipewire.drv either through pw-top or by looking at the audio device names in the game itself which should include (Pipewire) in their name.

Optiscaler integration

• Other than PROTON_USE_OPTISCALER=1 to enable it, you might need to use PROTON_OPTISCALER_NAME=<name.dll> to control the DLL that should be injected. Three names are supported for PROTON_OPTISCALER_NAME, dxgi.dll, d3d12.dll and dbghelp.dll and defaults to dxgi.dll unless explictly set.
• You can use PROTON_OPTISCALER_CONFIG write arbitrary configuration in OptiScaler.ini. The config is a semicolon ( ;) separated string of individual options. The template for each option is {section}.{option}={value}, for example PROTON_OPTISCALER_CONFIG="Upscalers.Dx11Upscaler=fsr31;Upscalers.Dx12Upscaler=dlss". To avoid mistakes, only config options that already exist in Optiscaler.ini can be modified.
• The changes to the config are permanent until OptiScaler is upgraded or downgraded to a different version. To modify a setting it has to either be manually edited or altered by applying a different config through the environment variable. Be careful, using this will also remove any comments from the OptiScaler.ini file. Keep a backup or refer to the repo for documentation of the various settings.
• When enabled, the PROTON_<UPSCALER>_UPGRADE options can be used to dictate the versions of the upscaler DLLs to download and use, so PROTON_FSR4_UPGRADE=4.0.2 will download the FidelityFX DLLs for version 4.0.2.
• The configuration files are placed with the DLLs in <prefix>/drive_c/windows/system32/umu/ in case you need to edit them. Further configuration options exposed through environment variables are not planned, and likely to not be implemented.
• Right now drop-in DLL replacements are not possible, since the files are validated on each startup. If you need more fine-grained control than what is offered by the in-game menu, it's probably better to manually set up OptiScaler.
• I consider this work-in-progress, and it will certainly not work with all games. Do not report issues to OptiScaler when using this, always try their own manual installation first (and of course disable this feature when doing so).

Retired environment variables

The following environment variables have been removed or replaced

Old Environment Variable	New Environment Variable	Description
WINEPULSE_FAST_POLLING	N/A	Can help eliminate crackling with the default audio driver. Use 1 to enable, 0 to disable (default). Can cause rare crackling in God of War Ragnarok with the power of two quants (e.g. 512/768/1024)
PROTON_ENABLE_HDR	DXVK_HDR
PROTON_VKREFLEX	DXVK_NVAPI_VKREFLEX	Enables DXVK-NVAPI's Vulkan Reflex layer to support Reflex in Vulkan games. It's meant to enable Reflex in games such as Portal RTX, Path of Exile 1 and 2 and Doom TDA, etc.
PROTON_MEDIA_USE_GST	PROTON_MEDIA_FORCE_GST	Fixes video/audio playback in cutscenes in some cases.
PROTON_VKD3D_HEAP	N/A
