Radish

A Redis-compatible server that runs inside a Cloudflare Durable Object

Radish began in 2024 as a Go reimplementation of Redis, written when Redis changed to a source-available license. This is its second life, and a different bet: the original escaped the license, this escapes the operations, by putting Redis semantics on a substrate that already solves durability and failover.

SQLite is the store, a Durable Object is the process, and R2 is the cold tier. No cluster to shard, no failover to configure, no AOF policy to tune — those are properties of the platform rather than things to operate.

The Go implementation is preserved at tag go-implementation and remains MIT-licensed. Nothing about it was wrong; it just needed a machine to run on.

Status: not production ready. See Limits and Not implemented before considering it for data you care about. It does run on Cloudflare — redis-cli drives a deployed Durable Object unmodified — but it has no production miles.

  YOUR MACHINE                    │            CLOUDFLARE
                                  │
  ┌───────────┐                   │
  │ redis-cli │                   │
  │ ioredis   │                   │
  │ redis-py  │                   │
  └─────┬─────┘                   │
        │ TCP :6379               │
        │ raw RESP bytes          │
        ▼                         │
  ┌───────────┐                   │
  │ Bun shim  │  translates only  │      ┌──────────┐
  │           │──────────────────────────│  Worker  │  authenticates the
  └───────────┘  wss + x-radish-auth│      │  router  │  upgrade, then exits
                                  │      └────┬─────┘  the data path
        ▲                         │           │
        │                         │           │ ?db=cli
        └─ deleted when connect() │           ▼
           lands; client then     │   ┌───────────────────┐
           reaches the DO direct  │   │     RedisDO       │
                                  │   │  ◀── socket lives │  hibernatable
                                  │   │      HERE         │  evicts between
                                  │   │                   │  commands
                                  │   │  ┌─────────────┐  │
                                  │   │  │   SQLite    │  │  hot + warm
                                  │   │  │  meta       │  │  meta never
                                  │   │  │  str hash   │  │  leaves
                                  │   │  │  list sett  │  │
                                  │   │  │  zset       │  │
                                  │   │  └──────┬──────┘  │
                                  │   └─────────┼─────────┘
                                  │             │ evict ▼  ▲ fault in
                                  │        ┌────┴─────────────┐
                                  │        │  R2  ColdTier    │  cold
                                  │        └──────────────────┘  unbounded
                                  │
                                  │   ?db=sessions ──▶ a DIFFERENT DO
                                  │   ?db=tenant-7 ──▶ another one
                                  │   each: own SQLite, own lease,
                                  │         own failover, 10 GB each

The Worker is not in the data path. It authenticates the upgrade, calls redis.getByName(name).fetch(request), and steps out. Cloudflare.upgrade() runs inside the Durable Object and calls ctx.acceptWebSocket(...) on the DurableObjectState, so the socket terminates there. Every RESP frame after the handshake reaches the DO's webSocketMessage handler with no per-message Worker invocation. Because it is acceptWebSocket rather than accept, the socket is hibernatable — the object can be evicted between commands while the connection stays open, which is why connection state rides in the socket attachment.

The shim is the only piece that is not real. It exists because redis-cli speaks TCP and a Durable Object cannot accept TCP. It has no protocol knowledge — bytes in, bytes out — and it is temporary: Cloudflare's connect() handler is in private beta, and on celld the handler does not exist and would have to be added. When either lands the shim is deleted and clients reach the DO with nothing in between.

One name is one instance. ?db=cli and ?db=sessions are different Durable Objects with different SQLite databases, migrating between machines independently. No cluster, no resharding, no failover to operate.

What this is


Commands	136 of Redis 7.4.11's 250 — 124 in the dispatch table, 12 connection-scoped
Tests	624, ~159,700 assertions
Differential	10 seeds × ~2,025 commands vs `redis:7.4.11`, byte-identical
Source	7,980 lines

Compatibility contract

Pinned to Redis 7.4.11. Reply shapes verified for RESP2 and RESP3 separately; they differ per command and are tested per command.

Correctness is established by differential testing, not by assertion: the same seeded command stream runs against a real redis-server and against radish, and the raw RESP bytes are compared. Any difference is a bug unless it is listed below. Unit tests can only assert what their author believed Redis does; four times during development that belief was wrong and the harness caught it.

Deliberate deviations

Each of these is a difference we chose, with a test pinning it.

Deviation	Reason
`SELECT` accepts only index 0	One named Durable Object is one instance. A second database does not exist; `CONFIG GET databases` reports `1` consistently.
`ERR scan cursor expired`	Our SCAN cursors are server-side and evictable after 60s idle. Redis's are stateless and cannot expire, so this reply has no upstream equivalent. It is an explicit error rather than a successful-looking empty result, which would silently violate the full-iteration guarantee.
List position space exhaustion refuses	Lists use fractional indices. Exhausting the float space at one end returns an error rather than drifting toward `-Infinity`. Requires ~2^53 pushes at one end, which the 10 GB cap makes unreachable.
`EXEC` rolls back on infrastructure failure	An ordinary command error inside `MULTI` still preserves successful siblings, as Redis does. A storage failure rolls the whole transaction back rather than committing a half-applied mutation. Redis has no equivalent because it has no storage layer that can fail this way.
Values capped at 1 MiB	Cloudflare caps a SQLite row/BLOB at 2 MB. Advertising Redis's 512 MiB would be a limit no row can hold.
`SCAN MATCH *` matches the empty string	Literal `stringmatchlen` returns false there, a quirk masked in Redis by `KEYS`' allkeys short-circuit. We keep sane glob semantics.
`ZSCAN` score spelling does not depend on size	Upstream re-spells `ZSCAN` scores with `%.17Lg` once a sorted set exceeds `zset-max-listpack-entries` (default 128), so above that size Redis disagrees with its own `ZSCORE` on the same key. Measured: 0 of 114 scores differ at listpack size, 145 of 194 at skiplist size. We have one representation and keep the `d2string` spelling at every size, which agrees with `ZSCORE` and every other double reply.

Platform-dependent behavior

INCRBYFLOAT and HINCRBYFLOAT reproduce IEEE binary128 (long double on aarch64 and every other quad-precision target) with correct round-to-nearest-even and Redis's %.17Lf human form, bit-for-bit, across the full representable range including subnormals, overflow and underflow. Verified byte-identical against redis 7.4.11 over 1,821 randomized cases.

On x86-64, where long double is x87 80-bit, upstream Redis prints fewer significant digits for values above ~2^56. We match the quad-precision platform, not the x87 one. The regression test asserts this mechanically: the reply must equal the binary128 expansion and must not equal the x87 expansion, so a future run against an x86-64 reference names its own cause.

Double formatting

double replies reproduce Redis's fpconv_dtoa (Grisu2), not JavaScript's shortest round-trip form. The two disagree on exponent-form thresholds, and Grisu2 is not always shortest — Redis prints -678346351760656.7 where the shortest round-tripping decimal is -678346351760656.8. We print what Redis prints, verified byte-identical against the reference.

Limits

Platform limits, enforced rather than advertised:


Storage per instance	10 GB of SQLite per named instance; beyond that, values tier to R2. Instances are unlimited.
Value size	1 MiB (2 MB platform row cap, less key and column overhead)
Bound parameters	100 per statement — set algebra is folded rather than expanded
Statement length	100 KB
Connection attachment	16,384 bytes; larger session state spills to a SQL row
Queued `MULTI`	512 KiB / 1024 commands, charged before acknowledgement
Subscriptions	64 KiB / 1024, charged before acknowledgement

Tiering

SQLite is capped at 10 GB per Durable Object and writes fail at the ceiling rather than degrading, so values tier out to R2. meta never leaves SQLite, so TYPE, TTL, EXISTS, SCAN and DEL never touch R2 at any dataset size.

tier	SQLite rows	R2 object
`hot`	yes	absent or stale	written since last upload
`warm`	yes	present, identical	eviction costs zero uploads
`cold`	no	present, authoritative	faulted in before dispatch

A key that cycles in and out without being written uploads exactly once.

The two stores share no transaction, so meta is the single authority and every sequence fails toward "upload again", never toward losing data. hot → warm uploads, re-reads and byte-compares before marking — a write can land during the await, and the key is already hot so no trigger fires. warm → cold is one SQLite transaction. cold → warm restores rows and marks warm together; a missing object raises rather than returning an empty key.

Mutations invalidate the R2 copy via SQLite triggers on all five value tables, so a command author cannot forget — including authors of commands that do not exist yet.

Keys are extracted from argv before dispatch, so cold values are restored while command handlers stay synchronous. A keyspace that has never evicted pays no SQL, no allocation and no microtask on that path.

What gets evicted

The planner is a pure function returning a plan, not an action, and every eviction carries a reason. Free evictions (warm → cold) are a separate pool that is always drained before any upload is planned — an asymmetry no score can invert.

score = bytes / (readProbability · readAmplification · churnPenalty)

Fault-in is whole-key, so read amplification is type-dependent and dominates: a string is amplification 1, while restoring a 10,000-member hash to serve one HGET is not. It spans 1–57× against recency's 10.7×, deliberately.

Hard exclusions: a key expiring within 5 minutes (it frees its own bytes; an upload buys nothing and leaves an orphan), and anything under 4096 bytes — SQLite's page size, below which eviction may release no pages at all while still costing an object, a Class A operation and a future round trip.

churnPenalty is inert: nothing records a last-write time, and adding one would mean an unconditional meta write per command across all 136 commands. Named WRITE_CLOCK_NOT_RECORDED at its use site.

Not implemented

Absent, not partially working:

Blocking — BLPOP BRPOP BLMOVE BLMPOP
Streams — XADD XRANGE XREAD and consumer groups
Scripting — EVAL EVALSHA FUNCTION
Zset set-ops — ZUNION ZINTER ZDIFF and their *STORE forms
Multi-key pop — LMPOP ZMPOP
Introspection — OBJECT DUMP RESTORE
Cluster, replication, ACL

WATCH/UNWATCH are implemented, so MULTI is not structurally incomplete.

Complexity

SQLite is a B-tree, not a quicklist. Where that costs something, it is named:

Operation	Redis	radish
`LPUSH` / `RPUSH`	O(1)	O(log n) — index seek on one endpoint
`LLEN` `HLEN` `SCARD` `ZCARD`	O(1)	O(1) — maintained cardinality
`ZRANK` / `ZREVRANK`	O(log n)	O(rank) — row-value range scan, not rank metadata
`LINSERT` worst case	O(n)	O(dense run adjacent to insertion), bounded and resumable

Cardinality is stored nullable, where NULL means not yet counted. A path that mutates rows without updating the counter can only make the count unknown, never wrong; the next read repairs it with one COUNT(*) and memoises.

Durability

A reply is held until the writes behind it are durable — Cloudflare's output gate. Redis defaults to appendfsync everysec and can lose up to a second of acknowledged writes; radish loses none.

This is not a backup story. Durable storage does not specify export, retention, restore, corruption recovery, or accidental-deletion recovery. There is no tested runbook for any of them. R2 holds evicted values (see Tiering); it is not a backup, and there is no export or point-in-time restore.

Running

Locally

bun install
bun test                                            # 624 tests

echo "RADISH_AUTH_TOKEN=$(openssl rand -hex 24)" > .env

bun run dev                                         # worker on :1337
RADISH_AUTH_TOKEN=$(grep -oE '[0-9a-f]{48}' .env) bun run shim
redis-cli -p 6379 ping

A token is required even locally — the worker fails closed rather than serving anyone who reaches it.

Deployed

bun run deploy

RADISH_AUTH_TOKEN=$(cat .radish-token) \
UPSTREAM="wss://<worker>.workers.dev/connect?db=cli" \
  bun run shim

redis-cli -p 6379 set greeting "hello from cloudflare"

Creates a Worker, a SQLite-backed Durable Object namespace, and the ColdTier R2 bucket. The shim sends x-radish-auth whenever RADISH_AUTH_TOKEN is set in its environment.

The Worker refuses to serve without a token. RADISH_AUTH_TOKEN is read from .env at deploy time (the Effect-native path registers the binding implicitly from the yield* Config in the Init phase, so no env prop is needed). Without it /connect returns 503 rather than serving anonymously; set RADISH_ALLOW_UNAUTHENTICATED=true to opt out deliberately. A changed secret is not detected as a diff, so redeploying a new token needs --force.

Toolchain constraints

The Alchemy CLI must run under Node, not Bun — alchemy 2.0.0-beta.77 assumes Node's CJS interop (Workerd.default.default). Use the local install, never bunx alchemy, which fetches an unpinned copy into a temp directory and ignores everything below. effect is pinned to 4.0.0-rc.112 via overrides; rc.113+ renamed Config.string and alchemy has not followed. patches/ carries ESM shims for fast-glob and picomatch, which ship no default export.

alchemy profile refresh needs a real TTY for its OAuth scope picker, so it cannot run inside a non-interactive shell. profile edit --method stored --set apiToken=env:VAR is the non-interactive alternative.

Differential harness

docker run --rm -p 6380:6379 redis:7 redis-server --databases 1
SEED=1234 bun test/differential.ts --ref localhost:6380 --sut localhost:6379

It begins with FLUSHALL. Never point it at an instance holding real data.

Layout

src/types.ts        Reply algebra + byte helpers
src/errors.ts       Redis error strings, verbatim; bounded binary-safe diagnostics
src/resp.ts         RESP2/RESP3 codec; incremental, chunk-boundary safe
src/schema.ts       SQLite DDL
src/store.ts        Keyspace: types, lazy expiry, SCAN cursors, byte glob
src/commands/       Synchronous command handlers, (Ctx, argv) => Reply
src/session.ts      SessionExecutor: decode, dispatch, MULTI, WATCH, pub/sub
src/do.ts           Durable Object wiring only
src/worker.ts       Router. One name = one instance.
shim/tcp-shim.ts    TCP:6379 ↔ WebSocket
test/differential.ts  Diffs raw RESP bytes against a real redis-server

Command handlers are synchronous, not pure — they read and write SQL and may mutate connection state. What they do not touch is the socket or the protocol version, which is what lets one table serve RESP2, RESP3 and queued transactions.

Design invariants

Bytes stay bytes on the storage path. Keys, values, fields, members, channels and patterns are BLOB end to end. Text conversion is limited to ASCII syntax parsing and escaped diagnostics.
Lazy expiry has one enforcement point. Every existence check routes through Store.typeOf, which purges an expired key before answering.
Connection state is reconstructible. A hibernating socket can outlive its isolate, so even the decoder's partial buffer is bounded and persisted.
Unsupported means an error, never a plausible reply. CONFIG SET rejects parameters it cannot apply; INFO omits fields it cannot measure rather than reporting zero.
