MLOps Development Kit (MDK) - Lightweight

This is a lightweight version of the MLOps Development Kit (MDK) designed to streamline machine learning workflows on Google Cloud Platform, particularly with Vertex AI.

This document contains an overview of how to get started using the MDK, including environment setup, infrastructure deployment, and instructions for both standard and "Lite" modes.

📋 Prerequisites

Before running the Terraform configuration or executing pipelines, ensure you have completed the following setup:

1. Authentication & Permissions

Authenticated with Google Cloud: Run the following commands to set up Application Default Credentials (ADC) which Terraform and MDK will use:
```
gcloud auth login
gcloud auth application-default login
```
Configured Docker for Artifact Registry:
```
gcloud auth configure-docker ${REGION}-docker.pkg.dev
```
(Replace ${REGION} with the region you will use, e.g., us)
Required Permissions: Your account needs sufficient permissions in the target GCP project.
- roles/serviceusage.serviceUsageAdmin (Enable APIs)
- roles/resourcemanager.projectIamAdmin (Manage IAM bindings)
- roles/storage.admin (Manage GCS)
- roles/artifactregistry.admin (Manage Artifact Registry)
- roles/bigquery.admin (Manage BigQuery)
Network: Depending on your networking setup, you might need to be on a VPN for this.

🛠 Setup

Local Environment Setup

To use and develop this code, you will need a Python virtual environment. We recommend using uv.

Install uv: Ensure uv is installed on your system. (Unlike many Python development tools, it is not recommended to install uv in a virtual environment). See Astral Docs for instructions.

Create and activate a virtual environment: In the top-level directory of the source code, run the following:

# Create a virtual environment:
uv venv
uv sync

# Give your virtual environment access to this source code, in editable mode:
uv pip install -e .

Activate the environment:
- For Linux/Mac:
```
source .venv/bin/activate
```
- For Windows:
```
.venv\Scripts\activate
```

🌍 Terraform Lite Setup

Deployment Steps

Follow these steps to deploy the infrastructure:

Navigate to the Terraform directory:
```
cd terraform-lite
```
Configure Variables: Open lite.tfvars and update the following variables to match your environment:
- project_id: The GCP project ID where resources will be deployed.
- user_group_ids: A list of user emails or Google Group IDs that will access the demo. Each must be prefixed with user: or group: (e.g., ["user:your-name@example.com"]).
Deploy: Run the following commands to initialize and apply the configuration:
```
terraform init
terraform apply -var-file=lite.tfvars
```

Troubleshooting: Artifact Registry Permission Issues

If you run mdk run and encounter a permission error reading from the Artifact Registry (e.g., Vertex AI cannot pull your Docker image), this may be due to the Vertex AI Custom Container service account not having roles granted yet.

By default, first_time = true is set to avoid Terraform failures if the service account is not yet created by Google Cloud.

To resolve a permission issue:

Update lite.tfvars: Set first_time to false.
Apply Terraform again: terraform apply -var-file=lite.tfvars
Retry: Run your mdk run command again.

💡 MDK Lite Mode Guide

Lite Mode is designed for rapid local testing or initial prototyping on Vertex AI with lowered setup overhead.

Its primary function is to bypass operations targeting the Expanded Model Registry (EMR) while keeping all Vertex AI Native components (Vertex AI Pipeline submittals, Vertex Model Registry uploads) fully operational.

Initializing an App Repo

To scaffold a new workspace or application repository inside Lite Mode, first change directories to where you want you new workspace/app repository to be located.

cd ..

Then run mdk init and optionally pass the --lite flag during your initial setup initialization:

# Run initialization (Defaults to Lite Mode)
mdk init
# or
mdk init --lite

To initialize in Standard Mode (with Expanded Model Registry support), pass --lite=False:

mdk init --lite=False

Running Your Pipeline

On Vertex AI remote (Standard submission): When lite: true is set inside your pipeline_config.yml, no special flags are needed.
```
mdk run xgb_training_pipeline
```
On Local Machine Layout (--local): To execute the pipeline locally inside Lite mode, include both flags:
```
mdk run --local --lite xgb_training_pipeline
```

🚀 Running an Example

(Note: The following instructions apply to projects initialized from templates or containing the example structures.)

To run an example pipeline, follow these steps:

Upload Data: Run the data upload script to make the example BigQuery tables available:

# For Linux/Mac
cd examples/scripts
chmod +x load-dry-beans-data-to-bq.sh
./load-dry-beans-data-to-bq.sh

# For Windows
dir examples/scripts
bash load-dry-beans-data-to-bq.sh

List Pipelines:
```
cd ../..
mdk list
```
Submit a pipeline for execution:
```
mdk run xgb_training_pipeline
```

🛠 Iterative Development

(Note: The following instructions apply to projects initialized from templates.)

In the src/model_workflow directory, there are several files that correspond to different steps in an ML pipeline (train, evaluate, batch_predict, etc). These files can be updated with your specific workloads.

Any external variables that are necessary for your workloads (e.g. hyperparameters, GCS file URIs, dataset paths, etc) can be placed in the general config file model_products/main_product/config/config.yml.

Adding Components, Images, or Pipelines

New Component: Go into model_products/main_product/components, copy an existing component, rename the directory, and update component.py.
New Image: Go into model_products/main_product/images. You can edit files under byoc or copy and rename it.
New Pipeline: Go into model_products/main_product/pipelines, copy an existing pipeline, rename the directory, and update pipeline.py.
Registration: You must register any new components, images, or pipelines within the pipeline config file model_products/main_product/config/pipeline_config.yml.

👥 Contributors

Juan David Vargas-Lopez

🤝 Contributing

Contributions are welcome! See the Contributing Guide.

📣 Feedback

We value your input! Your feedback helps us improve MDK and make it more useful for the community.

🙋 Getting Help

If you encounter any issues or have specific suggestions, please first consider raising an issue on our GitHub repository.
