SmartPerfetto

AI-powered Android performance analysis built on Perfetto.

SmartPerfetto adds an AI analysis layer on top of Perfetto traces. Load a trace, ask a natural-language question, and get an evidence-backed answer with SQL results, skill outputs, root-cause reasoning, and optimization suggestions.

The project is open source and in active development. The UI, backend runtime, and skill system are usable today, but public APIs and internal contracts may still change.

Configure Your AI Provider First

SmartPerfetto uses the Claude Agent SDK. If you run it locally on a machine where Claude Code already works, the SDK can reuse Claude Code's local auth/config and you do not need to put an API key in .env. This covers both Claude Code subscription login and Claude Code setups that already point to a third-party model through a base URL plus API key.

For everyone else, the file location depends on how you run SmartPerfetto:

Run mode	Recommended credential path	Notes
Local source checkout with working Claude Code	No `.env` required	If `claude` can already code in this terminal, run `./start.sh`
Local source checkout with API key/proxy	`backend/.env`	Create with `cp backend/.env.example backend/.env`
Docker Hub image	`.env` in the repository root	Create with `cp backend/.env.example .env`; Docker does not see your host Claude Code login
Source Docker build	`backend/.env`	Used by `docker-compose.yml`

The AI Assistant settings panel in the Perfetto UI has a Backend API Key field. That field is only for SMARTPERFETTO_API_KEY, which protects the SmartPerfetto backend. It is not a place to enter Anthropic, OpenAI, DeepSeek, Kimi, MiMo, Qwen, GLM, Ollama, or other model-provider keys.

For direct Anthropic API access, set:

ANTHROPIC_API_KEY=sk-ant-your-key

For OpenAI, Gemini, DeepSeek, Kimi, MiMo, Qwen, GLM, Ollama, or other third-party providers, expose an Anthropic-compatible endpoint through one-api/new-api/LiteLLM or your own gateway, then set:

ANTHROPIC_BASE_URL=http://localhost:3000
ANTHROPIC_API_KEY=sk-proxy-or-provider-token
CLAUDE_MODEL=your-main-model
CLAUDE_LIGHT_MODEL=your-light-model

SmartPerfetto defaults to Simplified Chinese for AI answers, streamed progress, and generated reports. Set this if the primary users prefer English:

SMARTPERFETTO_OUTPUT_LANGUAGE=en

After editing env files, start or restart the backend. For Docker, run docker compose -f docker-compose.hub.yml up -d or docker compose -f docker-compose.hub.yml restart. For local source runs, use ./start.sh, or ./scripts/restart-backend.sh if the backend is already running. For explicit SmartPerfetto env/proxy credentials, verify the active provider with http://localhost:3000/health. For the local Claude Code path, verify by running a normal claude request in the same terminal; the first AI analysis call will use the SDK's Claude Code auth/config path.

Perfetto Resources

Resource	English	Chinese
Android Performance Blog	androidperformance.com/en	androidperformance.com
Perfetto official docs	perfetto.dev/docs	gugu-perf.github.io/perfetto-docs-zh-cn

What It Does

Analyzes Android Perfetto traces for scrolling jank, startup, ANR, interaction latency, memory, game, and rendering-pipeline issues.
Keeps Perfetto's timeline and SQL power, then adds an AI assistant panel inside the Perfetto UI.
Uses a TypeScript backend to run agent workflows, query trace_processor_shell, invoke YAML analysis skills, and stream results to the browser.
Supports Anthropic directly and other tool-calling LLMs through an Anthropic-compatible API proxy, including providers that expose OpenAI-compatible or Anthropic-compatible endpoints such as Xiaomi MiMo.
Ships with 160+ YAML skill/config files and scene strategies for Android performance investigation.

Tech Stack

Area	Technology
Frontend	Forked Perfetto UI with the `com.smartperfetto.AIAssistant` plugin
Backend	Node.js 24 LTS, TypeScript strict mode, Express
Agent runtime	Claude Agent SDK, MCP tools, scene strategies, verifier, SSE streaming
Trace engine	Perfetto `trace_processor_shell` over HTTP RPC
Analysis logic	YAML skills under `backend/skills/` plus Markdown strategies under `backend/strategies/`
Storage	Local uploads, session logs, reports, and runtime learning files
Testing	Jest, skill validation, strategy validation, 6-trace scene regression gate
Deployment	Docker Compose or local dev scripts

For Users

Docker (Recommended)

Use this path if you only want to run SmartPerfetto. You need Docker Desktop/Engine and LLM provider credentials in .env; you do not need Node.js, a C++ toolchain, or the perfetto/ submodule. The Docker Hub image is published nightly from main and includes the backend, the pre-built Perfetto UI, and the pinned trace_processor_shell, so it also avoids first-run access to Google's artifact bucket on the host.

The container starts without a local .env file for health/UI smoke checks, but AI analysis needs ANTHROPIC_API_KEY or ANTHROPIC_BASE_URL plus ANTHROPIC_API_KEY.

Windows users should use Docker Desktop with the WSL2 backend. The published image is a Linux container image and runs through Docker Desktop; no separate Windows build is required.

git clone https://github.com/Gracker/SmartPerfetto.git
cd SmartPerfetto
cp backend/.env.example .env
# Edit .env — set ANTHROPIC_API_KEY, or ANTHROPIC_BASE_URL + ANTHROPIC_API_KEY for a proxy
docker compose -f docker-compose.hub.yml pull
docker compose -f docker-compose.hub.yml up -d

Frontend: http://localhost:10000
Backend health: http://localhost:3000/health

Stop the container with:

docker compose -f docker-compose.hub.yml down

Uploads and logs are stored in Docker volumes, so they survive container restarts.

Local Script

Use this path if you prefer running from a source checkout on macOS or Linux. Prerequisites: Node.js 24 LTS, curl, lsof, pkill, and either Claude Code login or LLM provider credentials. For Windows source development, use WSL2, not native Windows shell.

The repository includes .nvmrc and .node-version, and npm is configured with engine-strict=true. ./start.sh, ./scripts/start-dev.sh, and ./scripts/restart-backend.sh will try to activate Node 24 through nvm or fnm. If backend dependencies were installed under another Node ABI, the scripts reinstall backend/node_modules automatically before starting the server. This prevents native modules such as better-sqlite3 from being reused across Node 20/24/25.

On macOS, if trace_processor_shell fails the --version smoke test, macOS says the developer cannot be verified, or the terminal only prints killed, Gatekeeper may have blocked the downloaded binary. Open System Settings → Privacy & Security → Security, click Allow Anyway for trace_processor_shell, then re-run ./start.sh and choose Open if macOS asks again. For a binary you trust, you can also remove the quarantine attribute:

xattr -dr com.apple.quarantine /absolute/path/to/trace_processor_shell
chmod +x /absolute/path/to/trace_processor_shell

git clone https://github.com/Gracker/SmartPerfetto.git
cd SmartPerfetto

# Option A: if Claude Code already works in this terminal, no .env is required.
claude

# Option B: explicit API key or Anthropic-compatible proxy.
cp backend/.env.example backend/.env
# Edit backend/.env — set ANTHROPIC_API_KEY (direct) or
# ANTHROPIC_BASE_URL + ANTHROPIC_API_KEY (API proxy)

./start.sh

The repo ships with a pre-built Perfetto UI in frontend/, so the local script also avoids submodule initialization and the long Perfetto UI compile.

For Developers

Runtime Scripts

Script	Use when
`./start.sh`	✅ Default — regular use, backend changes, strategy/skill edits
`./scripts/start-dev.sh`	Only when modifying the AI plugin UI (`ai_panel.ts`, `styles.scss` etc.) — requires `perfetto/` submodule

Source Docker Build

Use this only when testing Docker changes or building an unreleased local checkout:

cp backend/.env.example backend/.env
docker compose up --build

The source build uses the committed frontend/ bundle and does not rebuild the perfetto/ submodule.

Frontend Development (modifying AI plugin code)

When you need to edit the AI Assistant plugin UI:

# One-time: initialize the perfetto submodule
git submodule update --init --recursive

# Start with hot reload (rebuilds frontend on save)
./scripts/start-dev.sh

After verifying your changes in the browser, update the pre-built frontend and commit:

./scripts/update-frontend.sh
git add frontend/
git commit -m "chore(frontend): update prebuilt"

Advanced Provider Options

The quick setup above covers where credentials live. Local users whose Claude Code already works can usually skip SmartPerfetto env files entirely, even when Claude Code itself is backed by a third-party provider. Direct Anthropic API usage requires only:

ANTHROPIC_API_KEY=your_anthropic_api_key_here

Third-party providers can be used through an API proxy that accepts Anthropic Messages requests and forwards them to a provider backend:

ANTHROPIC_BASE_URL=http://localhost:3000
ANTHROPIC_API_KEY=sk-proxy-xxx
CLAUDE_MODEL=your-main-model
CLAUDE_LIGHT_MODEL=your-light-model

Known proxy options include one-api, new-api, and LiteLLM. The selected model must support streaming and tool/function calling reliably. This is also the recommended path for providers like Xiaomi MiMo when your account exposes an OpenAI-compatible endpoint: connect the provider in the proxy, then point ANTHROPIC_BASE_URL at the proxy's Anthropic-compatible endpoint and set CLAUDE_MODEL to the mapped MiMo model ID. If your MiMo gateway already exposes an Anthropic-compatible Messages endpoint directly, you can point ANTHROPIC_BASE_URL there without an extra proxy. See backend/.env.example for provider examples and tuning options.

Note: Claude Code's own local auth/config is the native auth path for the Claude Agent SDK, whether it uses an Anthropic subscription or a Claude Code-configured third-party endpoint. Separate tools such as Codex CLI, Gemini CLI, and OpenCode manage their own configuration files and login state; SmartPerfetto does not automatically read those credentials. Use ANTHROPIC_BASE_URL only when the provider is not already available through Claude Code and you want SmartPerfetto to own the proxy config explicitly.

The frontend settings dialog only stores the backend URL and optional SMARTPERFETTO_API_KEY for SmartPerfetto backend auth. LLM provider credentials must come from Claude Code local auth/config or from the backend/Docker env file above.

If the local Claude Code path is unavailable, its quota is exhausted, or you want SmartPerfetto to use a different provider than Claude Code, use the explicit proxy path:

ANTHROPIC_BASE_URL=http://localhost:3000
ANTHROPIC_API_KEY=sk-proxy-xxx
CLAUDE_MODEL=your-provider-main-model
CLAUDE_LIGHT_MODEL=your-provider-light-model

Restart the backend after changing provider settings. GET /health returns aiEngine.providerMode and aiEngine.diagnostics so you can confirm whether the runtime is using Anthropic direct access, AWS Bedrock, or an Anthropic-compatible proxy.

Output Language

User-facing output defaults to Simplified Chinese. To make AI answers, streamed progress text, and generated Agent-Driven reports English, set:

SMARTPERFETTO_OUTPUT_LANGUAGE=en

Accepted values include zh-CN and en. Restart the backend after changing .env.

Turn Budgets

SmartPerfetto has separate turn budgets for fast and full analysis:

CLAUDE_QUICK_MAX_TURNS=10  # fast mode default
CLAUDE_MAX_TURNS=60        # full mode default

Raise these values for slower models or traces that need more tool iterations. The total safety timeout scales with the turn budget: full mode uses CLAUDE_FULL_PER_TURN_MS per turn, and fast mode uses CLAUDE_QUICK_PER_TURN_MS per turn. Restart the backend after changing .env.

Basic Usage

Open http://localhost:10000.
Load a Perfetto trace file (.pftrace or .perfetto-trace).
Open the AI Assistant panel.
Ask a question, for example:
- 分析滑动卡顿
- Why is startup slow?
- CPU 调度有没有问题？
- Analyze the ANR in this trace

SmartPerfetto works best with Android 12+ traces that include FrameTimeline data. Recommended atrace categories:

Scene	Minimum categories	Useful extras
Scrolling	`gfx`, `view`, `input`, `sched`	`binder_driver`, `freq`, `disk`
Startup	`am`, `dalvik`, `wm`, `sched`	`binder_driver`, `freq`, `disk`
ANR	`am`, `wm`, `sched`, `binder_driver`	`dalvik`, `disk`

CLI Usage

SmartPerfetto also ships a terminal CLI for trace analysis without opening the browser UI. It uses the same agentv3 runtime as the web experience and writes local sessions, transcripts, and reports under ~/.smartperfetto/.

# Requires Node.js 24 LTS
npm install -g @gracker/smartperfetto

# Analyze a trace, then continue the conversation or open the report.
smp -f trace.pftrace -p "Analyze scrolling jank"
smp resume <sessionId> --query "Why is RenderThread slow?"
smp list
smp report <sessionId> --open

# Or run an interactive Claude-Code-style REPL.
smp

The first analysis downloads the pinned trace_processor_shell binary automatically if it is not already available. If your network cannot reach Google's artifact bucket, set TRACE_PROCESSOR_PATH=/path/to/trace_processor_shell to use a local binary, or set TRACE_PROCESSOR_DOWNLOAD_BASE / TRACE_PROCESSOR_DOWNLOAD_URL to a trusted mirror; downloaded binaries are still checked against the pinned SHA256. smartperfetto remains available as the long command name; source checkout scripts are only for maintainers debugging the CLI. See CLI Reference for all commands, REPL slash commands, storage layout, and resume behavior.

API Integration

The browser UI talks to the backend through REST and SSE. If you want to build your own UI or automation, start with these endpoints:

Method	Path	Purpose
`POST`	`/api/agent/v1/analyze`	Start an analysis
`GET`	`/api/agent/v1/:sessionId/stream`	Subscribe to SSE progress and answer tokens
`GET`	`/api/agent/v1/:sessionId/status`	Poll analysis status
`POST`	`/api/agent/v1/:sessionId/respond`	Continue a multi-turn session
`POST`	`/api/agent/v1/resume`	Resume SDK context for an existing session
`POST`	`/api/agent/v1/scene-reconstruct`	Start scene reconstruction
`GET`	`/api/agent/v1/:sessionId/report`	Fetch the generated report

Set SMARTPERFETTO_API_KEY in backend/.env if you expose the backend beyond your local machine. Protected APIs then require Authorization: Bearer <token>.

Architecture

Frontend (Perfetto UI @ :10000)
  └─ SmartPerfetto AI Assistant plugin
       └─ SSE / HTTP
Backend (Express @ :3000)
  ├─ agentv3 runtime: scene routing, prompts, MCP tools, verifier
  ├─ Skill engine: YAML analysis pipelines
  ├─ Session/report/log services
  └─ trace_processor_shell pool (HTTP RPC, 9100-9900)

Repository layout:

SmartPerfetto/
├── backend/
│   ├── src/agentv3/        # Primary AI runtime
│   ├── src/services/       # Trace processor, skills, reports, sessions
│   ├── skills/             # YAML analysis skills and configs
│   ├── strategies/         # Scene strategies and prompt templates
│   └── tests/              # Skill-eval and regression tests
├── docs/                   # Architecture, MCP, skills, rendering references
├── scripts/                # Development and restart scripts
└── perfetto/               # Forked Perfetto UI submodule

Development

Common commands:

./scripts/start-dev.sh
./scripts/restart-backend.sh

# Before opening a PR: runs quality, build/type checks, skill/strategy
# validation, core tests, and the 6 canonical trace regression.
npm run verify:pr

cd backend
npm run build
npm run cli:build-run -- --help
npm run test:scene-trace-regression
npm run validate:skills
npm run validate:strategies
npm run test:core

Required checks:

Before opening a PR: npm run verify:pr from the repository root
Any code change: cd backend && npm run test:scene-trace-regression
Skill YAML change: npm run validate:skills plus scene regression
Strategy/template Markdown change: npm run validate:strategies plus scene regression
Type/build fix: cd backend && npm run typecheck

Do not hardcode prompt content in TypeScript. Put scene logic in backend/strategies/*.strategy.md or reusable *.template.md files.

Documentation

Contributing

Contributions are welcome. Good first contributions include:

Reproducing a performance case with a small trace and clear question
Adding or improving YAML skills
Improving scene strategies and output templates
Fixing UI issues in the Perfetto plugin
Adding regression coverage for known trace scenarios

Before opening a PR:

Read CONTRIBUTING.md.
Fork the repo and create a branch from main.
Keep changes scoped and include a clear test plan.
Run the required checks listed above.
Follow the Code of Conduct.

Contact

Bugs and feature requests: GitHub Issues
Security reports: GitHub private advisory or smartperfetto@gracker.dev
Collaboration, commercial support, and sponsorship: WeChat 553000664

Sponsor

Common sponsorship channels for open-source projects include GitHub Sponsors, OpenCollective, Buy Me a Coffee, Afdian, WeChat/Alipay QR codes, and commercial support or licensing.

SmartPerfetto does not publish a public payment page yet. For sponsorship, donation, enterprise trial, or commercial licensing, contact the maintainer on WeChat: 553000664.

License

AGPL-3.0-or-later for SmartPerfetto core code.

The perfetto/ submodule is a fork of Google Perfetto and remains under Apache-2.0.

For commercial licensing without AGPL obligations, contact the maintainer on WeChat: 553000664.
