Flash-Sparse-Attention is a high-performance trainable sparse attention implementation that combines Flash Attention's memory efficiency with sparse computation for handling extremely long sequences in Transformer models.

[!NOTE] The CuTe backend (flash_sparse_attn.ops.cute) currently delivers the best performance. A Gluon backend targeting performance parity with CuTe is still a work in progress.

Key Features

[!NOTE] Support for arbitrary mask and bias shapes is available in this branch. The current main branch no longer maintains that feature set.

Supported Features

Forward and backward passes for dense attention, sparse attention, and gated attention
Regular batched inputs and varlen inputs
Causal attention and local window attention
Arbitrary combinations of Q and KV sequence lengths, with head dimensions up to 256
Grouped Query Attention and Multi Query Attention
Sparse softmax threshold control
Gated attention with gate inputs and configurable gating sparsity
Flex Local Window Attention with per-head arbitrary window sizes and local ranges
Split-KV for workload balancing in forward and decode workloads
Split-QO for workload balancing in backward workloads
Fused Quant for low-precision computation on hardware without native FP8 support
Top-k gather KV-cache decode
Paged Attention

For complete API documentation, please refer to here

Features We Aim to Support

KV-Cache Manager
TLE backend support
Gluon backend targeting performance parity with CuTe [WIP]

Installation

Requirements

Linux: Ubuntu 22.04 or later
Device: GPU, XPU, NPU, or PPU
Python: 3.9 or later
PyTorch: 2.5.1 or later
Triton: 3.6.0 or later
Triton Kernels: 3.6.0 or later

Install

Install from PyPI:

pip install flash-sparse-attn

To install from source:

git clone https://github.com/HKUSTDial/flash-sparse-attention.git
cd flash-sparse-attention
pip install .

Quick Start

Basic Usage

Below are examples for forward, backward, and decode.

import torch
from flash_sparse_attn.ops.triton.interface import (
    flash_sparse_attn_func,
    flash_sparse_attn_with_kvcache_func,
)

dtype = torch.bfloat16
device = torch.device("cuda")
batch_size, seqlen, num_heads, num_kv_heads, head_dim = 2, 4096, 32, 8, 128

Forward

Combine flex window, split-KV, fused quant, and sparse softmax for maximum performance.

query = torch.randn(batch_size, seqlen, num_heads, head_dim, dtype=dtype, device=device)
key = torch.randn(batch_size, seqlen, num_kv_heads, head_dim, dtype=dtype, device=device)
value = torch.randn(batch_size, seqlen, num_kv_heads, head_dim, dtype=dtype, device=device)

output = flash_sparse_attn_func(
    query, key, value,
    is_causal=True,
    softmax_threshold=1.0,
    is_local=True,
    is_quant=True,
    is_split_kv=True,
)

Backward

Combine flex window, split-QO, fused quant, and low-contribution skipping for maximum backward performance.

query = torch.randn(batch_size, seqlen, num_heads, head_dim, dtype=dtype, device=device, requires_grad=True)
key = torch.randn(batch_size, seqlen, num_kv_heads, head_dim, dtype=dtype, device=device, requires_grad=True)
value = torch.randn(batch_size, seqlen, num_kv_heads, head_dim, dtype=dtype, device=device, requires_grad=True)

output = flash_sparse_attn_func(
    query, key, value,
    is_causal=True,
    softmax_threshold=1.0,
    is_local=True,
    is_quant=True,
    is_split_kv=True,
    is_split_qo=True,
)

output.sum().backward()

Decode

Combine flex window, split-KV, fused quant, sparse softmax, packed GQA, and Graph for maximum decode performance.

query = torch.randn(batch_size, num_heads, head_dim, dtype=dtype, device=device)
key = torch.randn(batch_size, seqlen, num_kv_heads, head_dim, dtype=dtype, device=device)
value = torch.randn(batch_size, seqlen, num_kv_heads, head_dim, dtype=dtype, device=device)

def fsa_decode_fn():
    return flash_sparse_attn_with_kvcache_func(
        query, key, value,
        softmax_threshold=1.0,
        is_local=True,
        is_quant=True,
    )

# Warmup
for _ in range(3):
    fsa_decode_fn()
torch.cuda.synchronize()

# Capture Graph
graph = torch.cuda.CUDAGraph()
with torch.cuda.graph(graph):
    output = fsa_decode_fn()

# Replay
graph.replay()

Benchmarking

Benchmark scripts are located under tests, covering forward, backward, and decoding performance.

Forward Performance

# Triton backend
python tests/benchmark_forward.py

# CuTe backend
python tests/benchmark_forward_cute.py

# Gluon backend
# WIP

Backward Performance

# Triton backend
python tests/benchmark_backward.py

# CuTe backend
python tests/benchmark_backward_cute.py

# Gluon backend
# WIP

Decode Performance

# Triton backend
python tests/benchmark_decode.py

# CuTe backend
# WIP

# Gluon backend
# WIP

Citation

If you use FSA in your research, please cite:

@misc{shi2026cowindowattentioncausalcoverage,
      title={CoWindow Attention: Full Causal Coverage Is a Collective Property},
      author={Jingze Shi and Zhangyang Peng and Xianduo Li and Yanlin Qi and Xiaotian Lin and Haoxian Chen and Liangdong Wang and Guang Liu and Yuyu Luo},
      year={2026},
      eprint={2609.32704},
      archivePrefix={arXiv},
      primaryClass={cs.AI},
      url={https://arxiv.org/abs/2609.32704},
}

@misc{shi2026massallocattentionletattention,
      title={MassAlloc Attention: Let Attention Allocate Its Own Compute},
      author={Jingze Shi and Zhangyang Peng and Xianduo Li and Yanlin Qi and Xiaotian Lin and Haoxian Chen and Liangdong Wang and Guang Liu and Yuyu Luo},
      year={2026},
      eprint={2609.32712},
      archivePrefix={arXiv},
      primaryClass={cs.AI},
      url={https://arxiv.org/abs/2609.32712},
}

@misc{shi2025trainabledynamicmasksparse,
      title={Trainable Dynamic Mask Sparse Attention},
      author={Jingze Shi and Yifan Wu and Bingheng Wu and Yiran Peng and Liangdong Wang and Guang Liu and Yuyu Luo},
      year={2025},
      eprint={2508.02124},
      archivePrefix={arXiv},
      primaryClass={cs.AI},
      url={https://arxiv.org/abs/2508.02124},
}

Acknowledgments

This project builds upon and integrates several excellent works:

OpenSeek - Kernel development support
Flash-Attention - Memory-efficient attention computation
NVIDIA CUTLASS - High-performance matrix operations library

We thank the open-source community for its contributions to efficient Transformer implementations. 🤗
