talos-pilot

A terminal UI (TUI) for managing and monitoring Talos Linux Kubernetes clusters.

talos-pilot provides real-time cluster visibility, diagnostics, log streaming, network analysis, and production-ready node operations - all from your terminal.

https://github.com/user-attachments/assets/4c946c32-1f7e-4ab8-9d88-9937516015d1

Why talos-pilot?

Talos Linux removes SSH access for security, replacing it with an API-driven management model. While talosctl is powerful, it requires memorizing many subcommands. talos-pilot provides:

• Interactive cluster overview - See all nodes, services, and health at a glance
• Real-time monitoring - CPU, memory, network stats with auto-refresh
• Unified log viewer - Stream logs from multiple services simultaneously (Stern-style)
• Production operations - Drain, reboot, rolling upgrades with safety checks
• Diagnostics - Automated health checks with actionable fix suggestions

Relationship to k9s

talos-pilot is complementary to k9s, not a replacement. They operate at different layers:

Use k9s for "why won't my pod start?" Use talos-pilot for "why won't my node join the cluster?"

Features

Cluster Management

Monitoring

Diagnostics & Security

Operations

Installation

From Releases (Recommended)

Download the latest release for your platform from the Releases page.

Install prebuilt binaries via shell script:

curl --proto '=https' --tlsv1.2 -LsSf https://github.com/Handfish/talos-pilot/releases/download/<version>/talos-pilot-installer.sh | sh

Install prebuilt binaries via powershell script:

powershell -ExecutionPolicy Bypass -c "irm https://github.com/Handfish/talos-pilot/releases/download/<version>/talos-pilot-installer.ps1 | iex"

Install prebuilt binaries via Homebrew

brew install Handfish/tap/talos-pilot

From Source

git clone https://github.com/Handfish/talos-pilot
cd talos-pilot
cargo build --release
./target/release/talos-pilot

NixOS

Talos pilot is available as a Nix flake but can also be run without installing.

Run talos-pilot without installing

You can test the app directly by using a nix shell

nix shell github:Handfish/talos-pilot

Or run it directly

nix run github:Handfish/talos-pilot

Usage in flakes

# flake.nix
{
  inputs = {
    # ...
    talos-pilot.url = "github:Handfish/talos-pilot";
  };
  outputs =
    {
      self,
      nixpkgs,
      talos-pilot,
      # ...
    }:
    {
      nixosConfigurations.mymachine = nixpkgs.lib.nixosSystem {
        system = "x86_64-linux";
        modules = [
          {
            # provides `pkgs.talos-pilot`
            nixpkgs.overlays = [ talos-pilot.overlays.default ];
          }
          (
            { pkgs, ... }:
            {
              # install talos-pilot
              environment.systemPackages = [ pkgs.talos-pilot ];
            }
          )
        ];
      };
    };
}

Requirements

• Valid ~/.talos/config (talosconfig)
• Network access to Talos nodes on port 50000
• (Building from source) Rust 2024 edition (1.85+)

Usage

# Use default context from talosconfig
talos-pilot

# Use specific context
talos-pilot --context homelab

# Set log tail limit
talos-pilot --tail 1000

# Enable debug logging
talos-pilot --debug --log-file ~/talos-pilot.log

Bootstrap Wizard (Insecure Mode)

For bootstrapping new clusters on bare metal or VMs in maintenance mode, talos-pilot provides an interactive wizard:

https://github.com/user-attachments/assets/0955b5a9-e35d-4fc6-a53d-db16e4558fc9

# Connect to a node in maintenance mode
talos-pilot --insecure --endpoint <node-ip>

The wizard guides you through:

1. Generate Config - Creates talosconfig, controlplane.yaml, and worker.yaml
2. Apply Config - Applies configuration to the node, triggering installation
3. Bootstrap - Initializes etcd and starts the Kubernetes cluster

Once complete, you can manage the cluster using standard talos-pilot commands.

Keyboard Navigation

View Shortcuts

Architecture

crates/
├── talos-rs/           # Talos gRPC client library
├── talos-pilot-core/   # Shared business logic
└── talos-pilot-tui/    # Terminal UI (ratatui)

Core Modules

Key Technologies

• Rust 2024 edition with async/await
• tokio - Async runtime
• ratatui + crossterm - TUI framework
• tonic + prost - gRPC client
• kube-rs - Kubernetes client
• color-eyre - Error handling

Development

# Run all tests
cargo test --all

# Run with debug output
RUST_LOG=debug cargo run

# Watch logs in another terminal
tail -f /tmp/talos-pilot.log

# Check for warnings
cargo clippy --all --all-targets -- -D warnings

Local Testing with Docker

See docs/local-talos-setup.md for setting up a local Talos cluster.

Current Stats

• Core library: ~1,760 lines across 8 modules
• Tests: 98 total (47 core + 8 TUI + 32 talos-rs + 11 doc)
• Components: 12 TUI components
• Build warnings: 0

Contributing

Key Principles

1. State over logs - Check actual system state, not log messages
2. Graceful degradation - Show "unknown" rather than crash
3. No false positives - When in doubt, show unknown not failed

Roadmap

License

MIT License - see LICENSE for details.

Acknowledgments

• Talos Linux by Sidero Labs
• k9s for TUI inspiration
• ratatui for the TUI framework
