MiniCPM-o 4.5 PyTorch Simple Demo System

中文简介 | Detailed Documentation

Ready-to-use Demo Website | Discord | Feishu Group

This demo system is officially provided by the MiniCPM-o 4.5 model training team. It uses a PyTorch + CUDA inference backend, combined with a lightweight frontend-backend design, aiming to demonstrate the full audio-video omnimodal full-duplex capabilities of MiniCPM-o 4.5 in a transparent, concise, and lossless manner.

About MiniCPM-o 4.5

MiniCPM-o 4.5 is the latest and most capable model in the MiniCPM-o series. The model is built in an end-to-end fashion based on SigLip2, Whisper-medium, CosyVoice2, and Qwen3-8B with a total of 9B parameters. It exhibits a significant performance improvement, and introduces new features for full-duplex multimodal live streaming. Notable features of MiniCPM-o 4.5 include:

• 🔥 Leading Visual Capability. MiniCPM-o 4.5 achieves an average score of 77.6 on OpenCompass, a comprehensive evaluation of 8 popular benchmarks. With only 9B parameters, it surpasses widely used proprietary models like GPT-4o, Gemini 2.0 Pro, and approaches Gemini 2.5 Flash for vision-language capabilities. It supports instruct and thinking modes in a single model, better covering efficiency and performance trade-offs in different user scenarios.

• 🎙 Strong Speech Capability. MiniCPM-o 4.5 supports bilingual real-time speech conversation with configurable voices in English and Chinese. It features more natural, expressive and stable speech conversation. The model also allows for fun features such as voice cloning and role play via a simple reference audio clip, where the cloning performance surpasses strong TTS tools such as CosyVoice2.

• 🎬 New Full-Duplex and Proactive Multimodal Live Streaming Capability. As a new feature, MiniCPM-o 4.5 can process real-time, continuous video and audio input streams simultaneously while generating concurrent text and speech output streams in an end-to-end fashion, without mutual blocking. This allows MiniCPM-o 4.5 to see, listen, and speak simultaneously, creating a fluid, real-time omnimodal conversation experience. Beyond reactive responses, the model can also perform proactive interaction, such as initiating reminders or comments based on its continuous understanding of the live scene.

• 💪 Strong OCR Capability, Efficiency and Others. Advancing popular visual capabilities from MiniCPM-V series, MiniCPM-o 4.5 can process high-resolution images (up to 1.8 million pixels) and high-FPS videos (up to 10fps) in any aspect ratio efficiently. It achieves state-of-the-art performance for end-to-end English document parsing on OmniDocBench, outperforming proprietary models such as Gemini-3 Flash and GPT-5, and specialized tools such as DeepSeek-OCR 2. It also features trustworthy behaviors, matching Gemini 2.5 Flash on MMHal-Bench, and supports multilingual capabilities on more than 30 languages.

• 💫 Easy Usage. MiniCPM-o 4.5 can be easily used in various ways: Basic usage, recommended for 100% precision: PyTorch inference with Nvidia GPU. Other end-side adaptation includes (1) llama.cpp and Ollama support for efficient CPU inference on local devices, (2) int4 and GGUF format quantized models in 16 sizes, (3) vLLM and SGLang support for high-throughput and memory-efficient inference, (4) FlagOS support for the unified multi-chip backend plugin. We also open-sourced web demos which enable the full-duplex multimodal live streaming experience on local devices such as GPUs, PCs (e.g., on a MacBook).

The 4 currently supported modes share a single model instance with millisecond-level hot-switching (< 0.1ms).

Additional features:

• Customizable system prompts
• Customizable reference audio
• Simple and readable codebase for continual development
• Serve as API backend for third-party applications

Architecture

Frontend (HTML/JS)
    |  HTTPS / WSS
Gateway (:8006, HTTPS)
    |  HTTP / WS (internal)
Worker Pool (:22400+)
    +-- Worker 0 (GPU 0)
    +-- Worker 1 (GPU 1)
    +-- ...

• Frontend — Mode selection homepage, Turn-based Chat, Omni / Audio Duplex full-duplex interaction, Admin Dashboard
• Gateway — Request routing and dispatching, WebSocket proxy, request queuing and session affinity
• Worker — Each Worker occupies one GPU exclusively, supports Turn-based Chat / Duplex protocols, Duplex supports pause/resume (auto-release on timeout)

Quick Start

Check System Requirements

1. Make sure you have an NVIDIA GPU with more than 28GB of VRAM.
2. Make sure your machine is running a Linux operating system.

Install FFmpeg

FFmpeg is required for video frame extraction and inference result visualization. For more information, visit the official FFmpeg website.

macOS (Homebrew):

brew install ffmpeg

Ubuntu/Debian:

sudo apt update && sudo apt install ffmpeg

Verify installation:

ffmpeg -version

Deployment Steps

1. Install Python 3.10

We recommend using miniconda to install Python 3.10.

mkdir -p ./miniconda3_install_tmp

# Download the miniconda3 installation script
wget https://repo.anaconda.com/miniconda/Miniconda3-py310_25.11.1-1-Linux-x86_64.sh -O ./miniconda3_install_tmp/miniconda.sh

# Install miniconda3 into the project directory
bash ./miniconda3_install_tmp/miniconda.sh -b -u -p ./miniconda3

After installation, you will have an empty base environment. Activate this base environment, which uses Python 3.10 by default.

source ./miniconda3/bin/activate
python --version # Should display 3.10.x

2. Install Dependencies for MiniCPM-o 4.5

Using the install.sh script in the project directory is the fastest way. It creates a venv virtual environment named base under .venv in the project directory and installs all dependencies.

source ./miniconda3/bin/activate
bash ./install.sh

If you have a good network connection, the entire installation process takes about 5 minutes. If you are in China, consider using a third-party PyPI mirror such as the Tsinghua mirror.

# First, prepare an empty Python 3.10 environment
source ./miniconda3/bin/activate
python -m venv .venv/base
source .venv/base/bin/activate

# Install PyTorch
pip install "torch==2.8.0" "torchaudio==2.8.0"

# Install the remaining dependencies
pip install -r requirements.txt

3. Create Configuration File

Copy config.example.json to config.json in the project directory.

cp config.example.json config.json

The model path (model_path) defaults to openbmb/MiniCPM-o-4_5. If you have access to Hugging Face, no modification is needed — the model will be automatically pulled from Hugging Face.

# Install huggingface cli
pip install -U huggingface_hub

# Download the model
huggingface-cli download openbmb/MiniCPM-o-4_5 --local-dir /path/to/your/MiniCPM-o-4_5

pip install -U huggingface_hub

export HF_ENDPOINT=https://hf-mirror.com

huggingface-cli download openbmb/MiniCPM-o-4_5 --local-dir /path/to/your/MiniCPM-o-4_5

pip install modelscope

modelscope download --model OpenBMB/MiniCPM-o-4_5 --local_dir /path/to/your/MiniCPM-o-4_5

Modify "gateway_port": 8006 to change the deployment port. The default is 8006.

4. Start the Service

CUDA_VISIBLE_DEVICES=0,1,2,3 bash start_all.sh

After the service starts, visit https://localhost:8006. The self-signed certificate will trigger a browser warning — click "Advanced" → "Proceed" to continue.

5. torch.compile Acceleration

On older-generation GPUs such as A100 and RTX 4090, the per-unit computation time in Omni Full-Duplex mode is approximately 0.9s, approaching the 1-second real-time threshold and causing noticeable stuttering. torch.compile uses Triton to compile core sub-modules into optimized GPU kernels, reducing computation time to approximately 0.5s — meeting real-time requirements for smooth, stutter-free interaction.

Three steps to enable:

5a. Enable compilation in config.json:

{ "service": { "compile": true } }

5b. Run the pre-compilation script (one-time, ~15 min):

CUDA_VISIBLE_DEVICES=0 TORCHINDUCTOR_CACHE_DIR=./torch_compile_cache .venv/base/bin/python precompile.py

Pre-compilation generates optimized Triton kernels and saves them to the ./torch_compile_cache directory (start_all.sh reads the compilation cache from TORCHINDUCTOR_CACHE_DIR). The cache persists on disk and is automatically loaded on all subsequent starts (including process restarts), with no need to recompile.

5c. Start the service:

CUDA_VISIBLE_DEVICES=0,1,2,3 bash start_all.sh

Workers automatically load the cached kernels from ./torch_compile_cache. Loading takes approximately 5 minutes when the cache is available.

CUDA_VISIBLE_DEVICES=0,1 bash start_all.sh          # Specify GPUs
bash start_all.sh --http                             # Downgrade to HTTP (not recommended, mic/camera APIs require HTTPS)

# Worker (one per GPU)
CUDA_VISIBLE_DEVICES=0 PYTHONPATH=. .venv/base/bin/python worker.py --worker-index 0 --gpu-id 0

# Gateway
PYTHONPATH=. .venv/base/bin/python gateway.py --port 10024 --workers localhost:22400

5. Stop the Service:

pkill -f "gateway.py|worker.py"

Docker Deployment

You can also run the service inside Docker. This approach packages all dependencies into a single image — just mount one workspace directory and you're good to go.

Prerequisites:

• Docker Engine 19.03+
• NVIDIA Container Toolkit (nvidia-docker)
• NVIDIA GPU with > 28 GB VRAM

1. Build the image:

docker build -t minicpm-o-demo .

2. Prepare the workspace directory:

Create a single workspace directory with your model weights and optional config:

mkdir -p my-workspace/models

# Copy or symlink model weights
ln -s /path/to/MiniCPM-o-4_5 my-workspace/models/MiniCPM-o-4_5

# (Optional) Custom config — model_path should point to /workspace/models/MiniCPM-o-4_5
cp config.example.json my-workspace/config.json

The workspace directory layout:

my-workspace/
├── models/MiniCPM-o-4_5/   # Model weights (required)
├── config.json              # Custom config (optional, fallback to defaults)
├── certs/                   # TLS certs (optional, for HTTPS)
├── data/                    # Auto-created: persistent session data
└── torch_compile_cache/     # Auto-created: compilation cache

3. Run with docker run:

docker run --gpus all -p 8006:8006 \
    -v $(pwd)/my-workspace:/workspace \
    minicpm-o-demo

3 (alternative). Run with Docker Compose:

Edit docker-compose.yml to set the workspace volume path, then:

docker compose up -d

Environment variables supported by the container:

Known Issues and Improvement Plans

• In Turn-based Chat mode, image input is temporarily unavailable — only audio and text input are supported. An image Q&A mode will be split out soon.
• Half-duplex voice call (no button required to trigger responses) is under development and will be merged soon.
• In Audio Full-Duplex mode, echo cancellation currently has issues affecting interruption success rate. Using headphones is recommended. A fix is coming soon.
• In voice mode, due to the model's training strategy, Chinese and English calls require corresponding language system prompts.

Project Structure

Project Code Structure

minicpmo45_service/
├── config.json               # Service config (copied from config.example.json, gitignored)
├── config.example.json       # Config example (full fields + defaults)
├── config.py                 # Config loading logic (Pydantic definition + JSON loading)
├── requirements.txt          # Python dependencies
├── start_all.sh              # One-click startup script
│
├── gateway.py                # Gateway (routing, queuing, WS proxy)
├── worker.py                 # Worker (inference service)
├── gateway_modules/          # Gateway business modules
│
├── core/                     # Core encapsulation
│   ├── schemas/              # Pydantic schemas (request/response)
│   └── processors/           # Inference processors (UnifiedProcessor)
│
├── MiniCPMO45/               # Model core inference code
├── static/                   # Frontend pages
├── resources/                # Resource files (reference audio, etc.)
├── tests/                    # Tests
└── tmp/                      # Runtime logs and PID files

Frontend Routes

Configuration

config.json — Unified Configuration File

All configurations are centralized in config.json (copied from config.example.json). config.json is gitignored and will not be committed.

Configuration Priority: CLI arguments > config.json > Pydantic defaults

Minimal Configuration (only model path required):

{"model": {"model_path": "/path/to/model"}}

CLI Argument Overrides

# Worker
python worker.py --model-path /alt/model --pt-path /alt/weights.pt --ref-audio-path /alt/ref.wav

# Gateway
python gateway.py --port 10025 --workers localhost:22400,localhost:22401 --http

Resource Consumption

Testing

# Schema unit tests (no GPU required)
PYTHONPATH=. .venv/base/bin/python -m pytest tests/test_schemas.py -v

# Processor tests (GPU required)
CUDA_VISIBLE_DEVICES=0 PYTHONPATH=. .venv/base/bin/python -m pytest tests/test_chat.py tests/test_streaming.py tests/test_duplex.py -v -s

# API integration tests (service must be running)
PYTHONPATH=. .venv/base/bin/python -m pytest tests/test_api.py -v -s
