git clone https://github.com/XimilalaXiang/DeLive.git
cd DeLive
npm run install:all
npm run dev

graph TB
    subgraph "Desktop Shell"
        EM[Electron Main Process]
        WIN[Main Window]
        CAP[Caption Overlay Window]
        DESK[Tray / Shortcut / Auto Launch / Updater]
        SEC[IPC Security / SafeStorage / Diagnostics]
    end

    subgraph "Renderer"
        UI[React App]
        STORES[Zustand Stores]
        CFG[Provider and Runtime Setup]
        PREV[History / Preview / AI Workspace]
    end

    subgraph "Orchestration"
        ASR[useASR]
        CAPMGR[CaptureManager]
        PROVSESS[ProviderSessionManager]
        CAPBR[CaptionBridge]
    end

    subgraph "Capture Pipeline"
        GDM[getDisplayMedia]
        MR[MediaRecorder<br/>WebM / Opus]
        AP[AudioWorklet<br/>PCM16 16kHz]
    end

    subgraph "Provider Layer"
        REG[Provider Registry]
        SON[Soniox]
        VOL[Volcengine]
        ELB[ElevenLabs]
        MIS[Mistral AI]
        GLA[Gladia]
        DPG[Deepgram]
        AAI[AssemblyAI]
        CFL[Cloudflare Workers AI]
        SIL[SiliconFlow]
        GRQ[Groq]
        LOA[Local OpenAI-compatible]
        WCP[whisper.cpp Runtime]
    end

    subgraph "Electron Services"
        PROXY[Embedded Multi-Provider Proxy]
        RTM[Local Runtime Controller]
    end

    subgraph "Persistence"
        REPO[Session Repository]
        IDB[IndexedDB]
        LS[localStorage]
        SAFE[safeStorage]
    end

    UI --> STORES
    UI --> CFG
    UI --> PREV
    UI --> ASR

    ASR --> CAPMGR
    ASR --> PROVSESS
    ASR --> CAPBR

    CAPMGR --> GDM
    GDM --> MR
    GDM --> AP

    PROVSESS --> REG
    REG --> SON
    REG --> VOL
    REG --> ELB
    REG --> MIS
    REG --> GLA
    REG --> DPG
    REG --> AAI
    REG --> CFL
    REG --> SIL
    REG --> GRQ
    REG --> LOA
    REG --> WCP

    MR --> SON
    MR --> LOA
    AP --> VOL
    AP --> ELB
    AP --> MIS
    AP --> GLA
    AP --> DPG
    AP --> AAI
    AP --> CFL
    AP --> SIL
    AP --> GRQ
    AP --> WCP

    VOL --> PROXY
    MIS --> PROXY
    DPG --> PROXY
    AAI --> PROXY
    ELB --> PROXY
    GLA --> PROXY
    WCP --> RTM

    STORES --> REPO
    REPO --> IDB
    REPO --> LS
    CFG --> SAFE

    UI --> EM
    EM --> WIN
    EM --> CAP
    EM --> DESK
    EM --> SEC
    EM --> PROXY
    EM --> RTM
    CAPBR --> CAP

    style UI fill:#61dafb,color:#000
    style EM fill:#334155,color:#fff
    style CAP fill:#f472b6,color:#000
    style REG fill:#f59e0b,color:#000
    style PROXY fill:#10b981,color:#fff
    style RTM fill:#0f766e,color:#fff
    style SEC fill:#ef4444,color:#fff
    style SAFE fill:#a855f7,color:#fff
    style IDB fill:#3b82f6,color:#fff

DeLive/
├── electron/          # Electron main process, windows, tray, IPC, updater, runtime, Open API server
├── frontend/          # React renderer app, providers, stores, UI components, tests
├── shared/            # Shared TypeScript contracts and provider proxy helpers
├── server/            # Standalone proxy server for debugging
├── mcp/               # MCP server for AI agents (Claude, Cursor, etc.)
├── skills/            # Agent skill definitions
├── scripts/           # Icon generation, runtime staging, release notes
├── docs/              # VitePress documentation site source
├── landing/           # Landing page source
└── package.json
