Battle Art Voxel Fork

Battle Art Voxel Fork turns the overworld of the Pokémon Gen 1 Recompilation Project into a 3D voxel diorama and stages battles inside that world. It also provides configurable static and animated battle sprites, arena backdrops, trainer art, first-person exploration, water reflections, lighting, and compatibility hooks for other presentation mods.

Version 1.9.0 supports Pokémon Red, Blue, and Yellow on Gen1Recomp 0.1.69 through current pre-2.0 releases. It is intentionally declared as a Gen 1 mod; Pokémon Gold uses different engine modules and needs a real port rather than a manifest change. See the Gen 1 and Gen 2 differences and porting guide.

Highlights

• Extruded terrain, buildings, foliage, figures, depth-buffered occlusion, cast shadows, and optional tilt-shift and world curvature.
• Voxel water with waves and sky reflections; FULL reflections also include visible shoreline, trees, buildings, and characters.
• First-person free look and analog movement while retaining the engine's collision, encounter, warp, ledge, and script behavior.
• Battles staged over the current map with an over-the-shoulder camera, parallax, depth of field, configurable HUDs, and optional Gen 6-style backdrops.
• Static or animated Pokémon art from Gen 1 through Gen 5 collections, trainer portraits, player intro art, native shiny detection, and safe ROM fallback.
• Compatibility with Stadium Battle FX attack effects, Gen 3 Battle UI, the Stadium 2 Importer, and Kanto First Person.
• Two performance paths: persistent disk precaching on legacy engines and sandbox-safe bounded mesh streaming on current engines.

Engine compatibility

The 0.1.83 boundary is inclusive: persistent BAVC precaching works through 0.1.83. Starting with 0.1.84, the mod hides the PRECACHE and CACHE actions and uses the newer sandbox-compatible path automatically. This is expected behavior, not an incomplete installation.

Some older engine builds exposed enough filesystem functionality for the cache backend itself, but Battle Art 1.9.0 as a whole requires APIs introduced in 0.1.69. Those older builds are therefore not advertised as supported merely because they can write a cache file.

On recent engines, R.DIST: MEDIUM is the default. It bounds connected-map work to 32 Gen 1 cells (512 world pixels) while the current map remains complete. SHORT, FAR, and FULL are available for lower-end hardware, wider views, or comparison.

The manifest accepts the development build identifier and stable versions in the range >=0.1.69 <2.0.0.

Installation

1. Install a supported Gen1Recomp build and import Pokémon Red, Blue, or Yellow.
2. Download a package from Releases, or clone this repository.
3. Put the mod folder in the game's mods directory. A normal Windows installation uses %APPDATA%\pokemon-love2d\mods\BATTLE_ART_VOXEL_FORK.
4. Enable BATTLE ART VOXEL FORK in the Mod Manager or in a profile.
5. Optionally import or add battle-art PNGs as described below. Missing art always falls back to the ROM.

The mod conflicts with the original Dramatic Shape, Dramaless Shape, and Potato Voxel renderers because they compete for the same world presentation.

Feature sets

Voxel overworld

The renderer turns map blocks into a perspective diorama instead of flattening them into a single plane. Terrain, water, structures, grass, flowers, authored figures, NPCs, and overworld Pokémon retain their normal game state while the mod changes how they are presented.

Key visual controls include:

WORLD FILL controls empty space below and outside the world:

• CYAN is the default classic underlay.
• BLACK uses the dark #181818 underlay.
• OFF/KFP draws no underlay, allowing Kanto First Person to own that space.

Water and sky

WATER has three levels:

• OFF disables the voxel water pass.
• SKY draws pixel-height waves reflecting the current sky, sun or moon, and staged battlers.
• FULL adds screen-space reflections of visible shoreline, trees, and buildings.

The outdoor sky, shadows, flat-world tint, and water share the same clock. Gen 6 battle backdrops snapshot the current dawn/day/dusk/night period when a battle starts, so a time change cannot abruptly replace the backdrop during that battle.

First- and third-person modes

Choose VOXEL: 1ST to enter the player's viewpoint. Look with the mouse, right stick, or a touch drag; move with WASD, the left stick, or the touch D-pad. Mouse left click acts as A and right click as B while pointer capture is active.

VOXEL: 3RD (EXPERIMENTAL) uses the same free-look and free-movement rig with the camera pulled back behind the player. Moving between 1ST and 3RD slides the eye along that camera boom instead of cutting between unrelated views.

Both free-camera modes still ask the Gen 1 engine about collision and run its landing pipeline for every crossed cell. Warps, encounters, ledges, gates, and scripts therefore remain engine-owned. Selecting an orbit or flat VOXEL mode restores ordinary grid movement.

Staged battles and arenas

3D-BTL stages battles on nearby clear ground in the current map. It is enabled by default and does not require the free-roam VOXEL camera to be pitched.

Presentation controls include:

ARENA FILL: GEN6 selects backgrounds using map location, encounter type, surfing/fishing state, boss state, and the time captured at battle entry.

Battle art

BATTLE ART controls Pokémon sprite ownership:

• STATIC reads ordinary species PNGs.
• ANIMATED reads the selected animated front set and compatible animated/static back set.
• ROM bypasses imported Pokémon art.

Front collections can be selected from Gen 1 through Gen 5. Gen 1 animated-mode fronts are single-frame compatibility PNGs; Gen 2–5 fronts are atlases. Back collections also expose Gen 1 through Gen 5: Gen 3 and Gen 5 can animate, while Gen 1, Gen 2, and Gen 4 use static PNGs.

Additional controls choose player front/back presentation, player-card mirroring, automatic/world/original-UI back placement, opponent trainer generations, and static or five-pose player trainer introductions.

DUPLICATE FIX separates sprite ownership from other mods:

• BATTLE ART makes this mod own normal and shiny battle sprites. It evaluates the Gen 2 DV shiny formula itself and routes qualifying Pokémon to matching shiny assets without relying on Crystal or another shiny mod's API.
• MODDED yields Pokémon battler-picture ownership to another Pokémon sprite provider or the ROM while retaining Battle Art's arena and camera features. It does not control move or attack-effect sprites.

Ditto Transform is tracked independently, so transformed art follows the species currently being presented. Missing, malformed, or unreadable assets fail open to the original ROM sprite instead of aborting the battle.

UI and mod compatibility

• Gen 3 Battle UI automatically receives the HUD, text/menu, and panel surfaces when its revamped battle UI option is enabled. Unsupported scripted phases retain the native presentation.
• The older Gen 1 Modern UI adapter is recognized when its experimental battle UI option is enabled.
• Stadium Battle FX can retain its Stadium move effects and announcer while Battle Art owns the staged arena, cards, and camera. Keep 3D-BTL: ON; no DUPLICATE FIX setting is required because its attack-effect sprites are not Pokémon battler pictures.
• The Stadium 2 Importer can provide Stadium 3D models through the staged-battle compatibility interface. This is the supported Stadium model path; it is separate from Stadium Battle FX, which supplies attack-effect sprites.
• Effects mods can inspect the same read-only staged-battle descriptor rather than importing Battle Art internals.
• OFF/KFP leaves the world underlay to Kanto First Person.
• MODDED leaves Pokémon battler-picture drawing to another Pokémon sprite provider or the ROM.

Persistent precache on 0.1.69–0.1.83

On legacy engines, the title menu's PRECACHE action opens a cancellable GENERATE PRECACHE task. It creates reusable terrain, water, connected-map body, and auxiliary geometry after content mods have patched maps and tilesets. Running it again resumes from valid records instead of rebuilding them.

The files are written only below:

mod-derived/BATTLE_ART_VOXEL_FORK/static-mesh-cache-v2

The cache does not store runtime NPCs, spawned overworld Pokémon, or temporary script changes. Live map changes are meshed in RAM; returning to the canonical layout reuses the disk record. A human-readable static-cache-exclusions.tsv records intentionally excluded runtime objects and noncanonical geometry.

BAVC is a versioned, fingerprinted, LZ4-compressed geometry container. Corrupt or truncated records safely fall back to cooperative mesh generation. Cache size depends on the imported ROM and installed content and can reach hundreds of MiB. The directory is disposable: deleting it only makes the mod regenerate those meshes. The pause-menu CACHE action can save or drop accumulated legacy-engine RAM cache work.

Sandboxed mesh streaming on 0.1.84+

Current engines do not grant content mods the raw filesystem and FFI access used by the persistent cache. Battle Art instead packs mesh vertices into bounded ByteData buffers, uploads them through the supported API, keeps only the current session's useful meshes in memory, and releases map meshes as they become unnecessary.

There is no precache button in this mode. Use R.DIST to trade connected-world breadth for loading time and memory use; MEDIUM is the recommended default. All supported voxel, camera, battle, battle-art, backdrop, and compatibility features remain available.

Controls

The hotkeys work in free roam and mirror rows in the Options menu:

Battle Art suppresses the engine's flat TILT and full-screen GBC FX while installed because those passes conflict with the 3D renderer. Uninstalling the mod restores their normal rows and saved values.

Bring your own battle art

Local battle PNGs are ignored by Git. The repository supplies folder contracts and importer tools, while a missing file always falls back to ROM art.

Use lowercase species filenames such as pikachu.png, caterpie.png, farfetchd.png, and mr-mime.png. The Nidoran files are nidoran-f.png and nidoran-m.png. Place shiny variants in the corresponding documented shiny folder. Each battle-art directory contains a README describing its exact file and atlas contract.

Static PNGs are used at native resolution. Existing alpha is preserved. For an opaque source image, the border-connected corner color is keyed transparent while enclosed matching pixels remain intact. Enemy fronts face left; player fronts can be mirrored by the mod; authored back art should face right.

The tools directory includes importers for Crystal, Emerald, Platinum, Black/White, extended Gen 2–5 species sets, shiny collections, static illustrations, and animated atlases. These scripts prepare local art without committing it.

• tools/package_mod.ps1 creates a local test package including your ignored battle PNGs.
• tools/package_clean_mod.ps1 creates a shareable package that preserves the folder contracts and tools but excludes local battle PNGs.

Integration API for mod authors

Replacement UIs can wrap battle.presentation.suppress_native.v1. A consumer receives the API version, source ID, requested hud, text, or panels surface, and the current battle when available. Return exactly true only when the consumer draws the complete requested surface; absent, failing, or false consumers leave Battle Art's native surface enabled.

The exported descriptor is available at:

mod.find("BATTLE_ART_VOXEL_FORK").exports.battlePresentation

Effects and presentation mods can inspect staged battle placement through:

local stage = mod.find("BATTLE_ART_VOXEL_FORK").exports.battleStage
local state = stage and stage.state(battle)

API version 1 is observational and read-only. A staged session reports staged = true; ready becomes true when the first projected shot exists. Ready state includes copied player/enemy anchors, sprite placement, animation scale, layer transform, and ownership declarations for the arena, battlers, trainers, camera, HUD, transitions, and animation projection. Consumers can align effects or yield competing presentation without retaining live internal tables.

For Stadium 3D models, use the Stadium 2 Importer, which integrates through this staged-battle interface. Stadium Battle FX replaces attack effects instead of Pokémon battler pictures, so it does not require DUPLICATE FIX: MODDED.

Gen 2 status

Battle Art 1.9.0 is Gen 1 only. The renderer, shaders, asset resolvers, shiny predicate, battle-art formats, and presentation API are reusable, but the current boot sequence directly wraps Gen 1 world, map, battle, UI, script, and input modules. Gold exposes separate stacks that must be mapped and tested deliberately.

The Gen 1 and Gen 2 differences and porting guide lists the confirmed blockers, reusable portions, and a staged porting plan for anyone working on Gen 2 support.
