Paper | Blog Post | Demo | Models | Data

MolmoWeb is an open multimodal web agent built by Ai2. Given a natural-language task, MolmoWeb autonomously controls a web browser -- clicking, typing, scrolling, and navigating -- to complete the task. This repository contains the agent code, inference client, evaluation benchmarks, and everything needed to reproduce the results from the paper.

Models
Installation
Quick Start
Inference Client
Benchmarks
Annotation Tool
Training
Grounding Evaluation
Citation
License

Models

Model	Parameters	HuggingFace
MolmoWeb-8B	8B	allenai/MolmoWeb-8B
MolmoWeb-4B	4B	allenai/MolmoWeb-4B
MolmoWeb-8B-Native	8B	allenai/MolmoWeb-8B-Native
MolmoWeb-4B-Native	4B	allenai/MolmoWeb-4B-Native

The first two models (MolmoWeb-8B and MolmoWeb-4B) are Huggingface/transformers-compatible (see example usage on Huggingface); and the last two (MolmoWeb-8B-Native and MolmoWeb-4B-Native) are molmo-native checkpoints.

Collections:

Installation

Requires Python >=3.10,<3.13. We use uv for dependency management.

# Install uv if you don't have it
curl -LsSf https://astral.sh/uv/install.sh | sh

# Clone and install
git clone git@github.com:allenai/molmoweb.git
cd molmoweb
uv venv --python ">=3.10,<3.13"
uv sync

# Install Playwright browsers (needed for local browser control)
uv run playwright install
uv run playwright install --with-deps chromium

Environment Variables

# Browserbase (required when --env_type browserbase)
export BROWSERBASE_API_KEY="your-browserbase-api-key"
export BROWSERBASE_PROJECT_ID="your-browserbase-project-id"

# Google Gemini (required for gemini_cua, gemini_axtree, and Gemini-based judges)
export GOOGLE_API_KEY="your-google-api-key"

# OpenAI (required for gpt_axtree and GPT-based judges like webvoyager)
export OPENAI_API_KEY="your-openai-api-key"

Quick Start

Three helper scripts in scripts/ let you download weights, start the server, and test it end-to-end.

1. Download the Model

bash scripts/download_weights.sh                                  # MolmoWeb-8B (default)
bash scripts/download_weights.sh allenai/MolmoWeb-4B-Native       # MolmoWeb-4B Native

This downloads the weights to ./checkpoints/<model-name>.

2. Start the Model Server

# default predictor type is native
bash scripts/start_server.sh ./checkpoints/MolmoWeb-4B-Native       # MolmoWeb-4B-Native
# change to HF-compatible
export PREDICTOR_TYPE="hf"
bash scripts/start_server.sh ./checkpoints/MolmoWeb-8B              # MolmoWeb-8B, port 8001
bash scripts/start_server.sh ./checkpoints/MolmoWeb-8B 8002         # custom port

Or configure via environment variables:

export CKPT="./checkpoints/MolmoWeb-4B-Native"   # local path to downloaded weights
export PREDICTOR_TYPE="native"             # "native" or "hf"
export NUM_PREDICTORS=1                    # number of GPU workers

bash scripts/start_server.sh

The server exposes a single endpoint:

POST http://127.0.0.1:8001/predict
{
  "prompt": "...",
  "image_base64": "..."
}

Wait for the server to print that the model is loaded, then test it.

3. Test the Model

Once the server is running, send it a screenshot of the Ai2 careers page (included in assets/test_screenshot.png) and ask it to read the job titles:

uv run python scripts/test_server.py                        # default: localhost:8001
uv run python scripts/test_server.py http://myhost:8002     # custom endpoint

The test script sends this prompt to the model:

Read the text on this page. What are the first four job titles listed under 'Open roles'?

You can also do it manually in a few lines of Python:

import base64, requests

with open("assets/test_screenshot.png", "rb") as f:
    image_b64 = base64.b64encode(f.read()).decode()

resp = requests.post("http://127.0.0.1:8001/predict", json={
    "prompt": "What are the first four job titles listed under 'Open roles'?",
    "image_base64": image_b64,
})
print(resp.json())

Inference Client

The inference package provides a high-level Python client that manages a browser session and runs the agent end-to-end. The client communicates with a running model server endpoint.

Single Query

from inference import MolmoWeb

client = MolmoWeb(
    endpoint="SET_UP_YOUR_ENDPOINT",
    local=True,         # True = local Chromium, False = Browserbase cloud browser
    headless=True,
)

query = "Go to arxiv.org and find out the paper about Molmo and Pixmo."
traj = client.run(query=query, max_steps=10)

output_path = traj.save_html(query=query)
print(f"Saved to {output_path}")

Follow-up Query

followup_query = "Find the full author list of the paper."
traj2 = client.continue_run(query=followup_query, max_steps=10)

Batch Queries

queries = [
    "Go to allenai.org and find the latest research papers on top of the homepage",
    "Search for 'OLMo' on Wikipedia",
    "What is the weather in Seattle today?",
]

trajectories = client.run_batch(
    queries=queries,
    max_steps=10,
    max_workers=3,
) # Inspect the trajectory .html files default saved under inference/htmls

Inference Backends

Supported backends: fastapi (remote HTTP endpoint), modal (serverless), native (native molmo/olmo-compatible checkpoint), hf (HuggingFace Transformers-compatible checkpoint).

vLLM support: We leave vLLM integration to users. Please be cautious, as vLLM does not support the exact attention backend used in OLMo, which may lead to unexpected behavior or reduced accuracy.

Extract Accessibility Tree

from inference.client import MolmoWeb

client = MolmoWeb()
axtree_str = client.get_axtree("https://allenai.org/")
print(axtree_str)
client.close()

Benchmarks

The benchmarks/ directory contains the unified evaluation framework. It supports six benchmarks out of the box: WebVoyager, Online Mind2Web, Odysseys, DeepShop, WebTailBench, and Custom (bring your own tasks).

The evaluation pipeline has two stages:

Run -- the agent executes tasks in a browser, producing trajectory logs.
Judge -- an LLM judge scores each trajectory for success.

Running Evaluations

The entry point is benchmarks/benchmarks.py, a Fire CLI with two commands: run and judge.

uv run python -m benchmarks.benchmarks run \
    --benchmark custom \
    --data_path ./demo_task.json \
    --results_dir ./results \
    --agent_type molmoweb \
    --inference_mode fastapi \
    --endpoint_or_checkpoint http://127.0.0.1:8001 \
    --max_steps 30 \
    --num_workers 1 \
    --env_type simple

Judging Results

After trajectories are collected, run the judge. The webvoyager judge requires OPENAI_API_KEY to be set.

uv run python -m benchmarks.benchmarks judge \
    --benchmark custom \
    --data_path ./demo_task.json \
    --results_dir ./results \
    --judge_type webvoyager \
    --num_workers 1

Synthetic Data Generation

The same evaluation framework can be used to generate synthetic training data by running other agents on tasks. Collect trajectories with any supported agent and use the resulting logs for training.

Agents

Agent	Description	Required Environment Variables
`molmoweb`	MolmoWeb multimodal agent (local model server)	None (uses `--endpoint_or_checkpoint`)
`gemini_cua`	Gemini computer-use agent	`GOOGLE_API_KEY`
`gemini_axtree`	Gemini with accessibility tree	`GOOGLE_API_KEY`
`gpt_axtree`	GPT with accessibility tree	`OPENAI_API_KEY`

We welcome contributions of custom agents. To add your own, implement the agent interface in agent/ and register the agent type in benchmarks/evaluate.py.

Evaluating Other Agents on Benchmarks

You can evaluate any supported agent on any benchmark using the same code. For example, to evaluate gemini_axtree on Online Mind2Web with Browserbase:

uv run python -m benchmarks.benchmarks run \
    --benchmark online_mind2web \
    --results_dir ./results/om2w_gemini_axtree \
    --agent_type gemini_axtree \
    --max_steps 30 \
    --num_workers 5 \
    --env_type browserbase

Then judge the results:

uv run python -m benchmarks.benchmarks judge \
    --benchmark online_mind2web \
    --results_dir ./results/om2w_gemini_axtree \
    --judge_type webjudge_online_mind2web \
    --num_workers 5

benchmarks.py Reference

`run` command

Argument	Type	Default	Description
`results_dir`	`str`	(required)	Output directory for trajectory logs.
`agent_type`	`str`	(required)	Agent to use: `molmoweb`, `gemini_cua`, `gemini_axtree`, or `gpt_axtree`.
`benchmark`	`str`	`"custom"`	Benchmark name: `custom`, `deepshop`, `webvoyager`, `online_mind2web`, `odysseys`, or `webtailbench`.
`data_path`	`str`	`None`	Override the default data file path for the chosen benchmark.
`inference_mode`	`str`	`None`	How to connect to the model: `fastapi` (HTTP endpoint), `local` (in-process HF), `modal` (Modal serverless), or `native` (in-process OLMo).
`endpoint_or_checkpoint`	`str`	`None`	Either an HTTP URL (for `fastapi`/`modal`) or a local path / HF model ID (for `local`/`native`).
`device`	`str`	`None`	CUDA device for local inference, e.g. `cuda:0`.
`api_key`	`str`	`None`	API key for API-based agents (Gemini, GPT).
`num_workers`	`int`	`5`	Number of parallel evaluation workers.
`max_steps`	`int`	`30`	Maximum agent steps per episode.
`env_type`	`str`	`"simple"`	Browser environment: `browserbase` (requires `BROWSERBASE_API_KEY` and `BROWSERBASE_PROJECT_ID`) or `simple` (local Chromium).

`judge` command

Argument	Type	Default	Description
`results_dir`	`str`	(required)	Directory containing trajectory logs to judge.
`benchmark`	`str`	`"custom"`	Benchmark name (must match what was used during `run`).
`data_path`	`str`	`None`	Override data file path.
`judge_type`	`str`	`None`	Judge implementation. Defaults to the benchmark's default judge. Options: `webvoyager` (GPT-4o), `deepshop_judge`, `webjudge_online_mind2web`, `odysseys_rubric` (Gemini rubric judge).
`num_workers`	`int`	`30`	Number of parallel judging workers.

See benchmarks/README.md for full documentation.

Training

Training code lives in the train/ directory. MolmoWeb training is a single-stage SFT on top of a Molmo2 pretrained checkpoint.

Setup

Install dependencies inside the train/ directory:

cd train
uv sync

Set the following environment variables (used by training, eval, and data scripts):

export WEBOLMO_DATA_DIR=/path/to/datasets   # MolmoWeb training data

Downloading Data

MolmoWeb training data is hosted on HuggingFace under the MolmoWeb Data collection. With WEBOLMO_DATA_DIR set, download all datasets with:

uv run python olmo/data/download_datasets.py

Dataset	HuggingFace Repo	Description
SyntheticGround	`allenai/MolmoWeb-SyntheticGround`	Synthetic web grounding (click targets)
SyntheticQA	`allenai/MolmoWeb-SyntheticQA`	Synthetic screenshot QA
SyntheticTrajs	`allenai/MolmoWeb-SyntheticTrajs`	Gemini-generated agent trajectories
HumanTrajs	`allenai/MolmoWeb-HumanTrajs`	Human-annotated trajectories
SyntheticSkills	`allenai/MolmoWeb-SyntheticSkills`	Synthetic atomic skill demonstrations
HumanSkills	`allenai/MolmoWeb-HumanSkills`	Human atomic skill demonstrations
PixMoPoints	`allenai/pixmo-points`	Point annotations for visual grounding
ScreenSpot	`rootsautomation/ScreenSpot`	UI grounding benchmark
ScreenSpotV2	`likaixin/ScreenSpot-v2-variants`	UI grounding benchmark v2

Visualizing Data

To inspect dataset examples as an HTML file, run dataset_visualize.py from inside the train/ directory:

uv run python dataset_visualize.py <task> <output_dir>

For example, to visualize 50 shuffled training examples from molmoweb_synthetic_trajs:

uv run python dataset_visualize.py molmoweb_synthetic_trajs ./viz --split train --num_examples 50 --shuffle

This saves ./viz/molmoweb_synthetic_trajs.html with rendered examples (images, tokenized text, and ground-truth annotations).

Downloading Pretrained Checkpoints

SFT training starts from a Molmo2 pretrained checkpoint. Download one of the pretrained base checkpoints from HuggingFace:

bash scripts/download_weights.sh allenai/MolmoWeb-Pretrained-8B   # 8B base
bash scripts/download_weights.sh allenai/MolmoWeb-Pretrained-4B   # 4B base

This saves the checkpoint to ./checkpoints/MolmoWeb-Pretrained-8B (or -4B). Set CHECKPOINT_PATH in train/run_train.sh to this path before launching training.

Model	HuggingFace Repo
MolmoWeb-Pretrained-8B	allenai/MolmoWeb-Pretrained-8B
MolmoWeb-Pretrained-4B	allenai/MolmoWeb-Pretrained-4B

SFT Training

Configure the variables at the top of train/run_train.sh, then run:

cd train
bash run_train.sh

Variable	Default	Description
`CHECKPOINT_PATH`	MolmoWeb-Pretrained-4B	Path to pretrained starting checkpoint
`MIXTURE`	`molmoweb`	Data mixture (`molmoweb` or `debug`)
`NUM_GPUS`	`8`	GPUs per node
`GLOBAL_BATCH_SIZE`	`64`	Total batch size across all GPUs
`DEVICE_BATCH_SIZE`	`2`	Per-GPU batch size
`SEQ_LEN`	`10240`	Sequence length
`DURATION`	`500`	Number of training steps
`SAVE_INTERVAL`	`100`	Checkpoint save frequency (steps)

To launch a debug run directly:

uv run torchrun -m --nproc-per-node 1 \
  launch_scripts.train debug debug \
  --save_folder=dbg \
  --device_batch_size 1 \
  --duration 10 \
  --global_batch_size 2

Grounding Evaluation

MolmoWeb can be evaluated on grounding benchmarks to measure how accurately the model predicts click coordinates for UI elements.

Benchmark	Task name
ScreenSpot	`screenspot`
ScreenSpot-v2	`screenspot_v2`

Configure the variables at the top of train/run_ground_eval.sh, then run:

cd train
bash run_ground_eval.sh

Variable	Default	Description
`CHECKPOINT_PATH`	MolmoWeb-4B-Native	Path to the NATIVE model checkpoint to evaluate
`MIXTURE`	`screenspot:test,screenspot_v2:test`	Comma-separated `task:split` pairs
`NUM_GPUS`	`1`	Number of GPUs
`DEVICE_BATCH_SIZE`	`2`	Per-GPU batch size
`SAVE_FOLDER`	results	Output directory for results

Citation

@misc{gupta2026molmowebopenvisualweb,
      title={MolmoWeb: Open Visual Web Agent and Open Data for the Open Web},
      author={Tanmay Gupta and Piper Wolters and Zixian Ma and Peter Sushko and Rock Yuren Pang and Diego Llanes and Yue Yang and Taira Anderson and Boyuan Zheng and Zhongzheng Ren and Harsh Trivedi and Taylor Blanton and Caleb Ouellette and Winson Han and Ali Farhadi and Ranjay Krishna},
      year={2026},
      eprint={2604.08516},
      archivePrefix={arXiv},
      primaryClass={cs.CV},
      url={https://arxiv.org/abs/2604.08516},
}

License

Apache 2.0. See LICENSE for details.

Table of Contents

Models

Installation

Environment Variables

Quick Start

1. Download the Model

2. Start the Model Server

3. Test the Model

Inference Client

Single Query

Follow-up Query

Batch Queries

Inference Backends

Extract Accessibility Tree

Benchmarks

Running Evaluations

Judging Results

Synthetic Data Generation

Agents

Evaluating Other Agents on Benchmarks

benchmarks.py Reference

`run` command

`judge` command

Training

Setup

Downloading Data

Visualizing Data

Downloading Pretrained Checkpoints

SFT Training

Grounding Evaluation

Citation

License

关于 About

语言 Languages

提交活跃度 Commit Activity

核心贡献者 Contributors

Table of Contents

Models

Installation

Environment Variables

Quick Start

1. Download the Model

2. Start the Model Server

3. Test the Model

Inference Client

Single Query

Follow-up Query

Batch Queries

Inference Backends

Extract Accessibility Tree

Benchmarks

Running Evaluations

Judging Results

Synthetic Data Generation

Agents

Evaluating Other Agents on Benchmarks

benchmarks.py Reference

run command

judge command

Training

Setup

Downloading Data

Visualizing Data

Downloading Pretrained Checkpoints

SFT Training

Grounding Evaluation

Citation

License

关于 About

语言 Languages

提交活跃度 Commit Activity

核心贡献者 Contributors

`run` command

`judge` command
