Agentic Mobile Protocol (AMP)

Quick start

Prerequisites:

• Python 3.10+: A virtual environment is created automatically on first run.
• Node.js and npm: Frontend dependencies are installed automatically on first run.
• bash and standard CLI tools (curl, lsof) on macOS or Linux.

AMP provides the following sample scenarios. Each script provisions a fresh virtual environment, installs dependencies, launches all the role services, and starts the web frontend.

Sample scenario	Launch script
Human Not Present	bash ./samples/python/scenarios/human_not_present/start.sh
Human Present	bash ./samples/python/scenarios/human_present/start.sh

Note: These scripts are bash-specific. Invoke them with bash, not sh.

1. Run one of the sample scenarios. Once the startup completes, the script prints the URL for each service.
2. Open the printed Web Frontend URL in your browser to interact with the Shopping Agent.
3. Press Ctrl+C to stop all services.

Note: Structured logs and the temporary databases for each run are written under the scenario's .logs/ and .temp-db/ folders.

Project structure

amp/
├── docs/                       # Protocol specification and glossary
├── src/python/                 # Reusable, framework-agnostic libraries
│   ├── common/                 # Shared kernel, including events, evidence logging, HTTP client, SQLite store, and money utils
│   ├── mandate_chain/          # Three-layer SD-JWT generation, validation, and mandate service
│   └── schemas/                # Pydantic models for checkout and mandate objects
├── samples/python/             # Runnable role services with scenario launchers
│   ├── acquirer/               # Acquirer service with CGCP routing
│   ├── alipayplus/             # Alipay+ network and mandate services
│   ├── credential_provider/    # Credential Provider service
│   ├── merchant/               # Merchant service
│   ├── mpp/                    # Mobile Payment Provider service
│   ├── shopping_agent/         # Shopping Agent and Web Frontend (Vite/React SPA)
│   └── scenarios/              # Launch scripts for human-present or human-not-present scenarios
├── tests/python/               # Unit tests and mandate_chain examples
└── requirements.txt            # Python dependencies

Shared libraries

Module	Path	Purpose
common	src/python/common	Shared kernel, including events, evidence logging, HTTP client, SQLite store, and money utils
mandate_chain	src/python/mandate_chain	Three-layer SD-JWT generation, validation, and mandate service
schemas	src/python/schemas	Pydantic models for checkout and mandate objects

Sample architecture

Service	URL
Shopping Agent	http://localhost:8080
Merchant	http://localhost:8081
Credential Provider	http://localhost:8082
Alipay+ Network	http://localhost:8083
Alipay+ Mandate	http://localhost:8084
Acquirer	http://localhost:8085
Mobile Payment Provider (MPP)	http://localhost:8086
Web Frontend	http://localhost:8088

Roles at a glance

Role	Directory	Responsibility
Shopping Agent	samples/python/shopping_agent	Parses user intent, plans and drives the shopping steps under the AMP protocol (search → checkout → mandate → credential → pay). Holds an EC P-256 key and signs L3. Serves /task SSE endpoints consumed by the web frontend.
Merchant	samples/python/merchant	Provides product catalog, creates checkout, and initiates payments towards the acquirer.
Credential Provider	samples/python/credential_provider	Enrolls payment methods, creates and inquires mandate sessions.
Alipay+ Network	samples/python/alipayplus	Serves as the payment network orchestration and routing layer.
Alipay+ Mandate	samples/python/alipayplus	Manages the mandate lifecycle: creates mandates, applies budget deductions, advances mandate status, and validates mandates against constraints.
Acquirer	samples/python/acquirer	Recognizes CGCP tokens, routes requests by token prefix, and forwards them to the Alipay+ Network.
Mobile Payment Provider (MPP)	samples/python/mpp	Responsible for user authorization, IDV completion, and payment.
Web Frontend	samples/python/shopping_agent/web_frontend	Vite + React + TypeScript SPA that consumes agent SSE events and renders the protocol chain, IDV confirmation, and receipt cards.

Tech stack

• Backend: Python 3.10+, FastAPI, Starlette, Uvicorn, Pydantic v2
• Cryptography/tokens: cryptography, jwcrypto, sd-jwt (SD-JWT per RFC 9901, ES256 signatures)
• HTTP: httpx for inter-service calls
• Frontend: Vite + React 18 + TypeScript + SCSS (lucide-react icons)
• Persistence (demo): per-run SQLite / JSON stores under .temp-db/

Contact

For security issues, please reach out to alipayplus_amp@ant-intl.com.

License

See LICENSE.
