YiRage - Yield Revolutionary AGile Engine

Multi-Backend LLM Inference Optimization

🎯 About YiRage

YiRage (Yield Revolutionary AGile Engine) provides comprehensive multi-backend support for LLM inference optimization across diverse hardware platforms.

Multi-Backend Optimization Focus

Unified optimization workflow across CUDA, ROCm, CPU, MPS, Ascend, MACA, TPU, XPU, FPGA, Triton, NKI, and MLIR backends
Hardware-aware search, profiling, and kernel generation for deployment-focused LLM inference
Extensible backend architecture for adding new hardware targets and compiler integrations

🏗️ Architecture

Five-Layer Backend Architecture

┌─────────────────────────────────────────────────────────────────────────────────────────┐
│                              YiRage Backend Architecture                                │
├─────────────────────────────────────────────────────────────────────────────────────────┤
│                                                                                         │
│  ┌─────────────────────────────────────────────────────────────────────────────────┐    │
│  │                         Layer 1: Python API                                     │    │
│  │  yirage.new_kernel_graph() → UnifiedCompiler → CoreBridge → superoptimize()     │    │
│  │  HardwareRegistry.instance() → ChipArchitecture → detect_current_chip()         │    │
│  └─────────────────────────────────────────────────────────────────────────────────┘    │
│                                        │                                                │
│  ┌─────────────────────────────────────▼───────────────────────────────────────────┐    │
│  │                         Layer 2: Backend Manager (C++)                          │    │
│  │  BackendRegistry (thread-safe) ← BackendFactory ← StrategyFactory               │    │
│  └─────────────────────────────────────────────────────────────────────────────────┘    │
│                                        │                                                │
│  ┌─────────────────────────────────────▼───────────────────────────────────────────┐    │
│  │                         Layer 3: Search & Strategy                              │    │
│  │  Hardware-aware Search │ Fingerprint Verification │ Performance Profiling       │    │
│  └─────────────────────────────────────────────────────────────────────────────────┘    │
│                                        │                                                │
│  ┌─────────────────────────────────────▼───────────────────────────────────────────┐    │
│  │                         Layer 4: Threadblock Operations                         │    │
│  │  MatMul │ Attention │ RMSNorm │ SwiGLU │ Softmax │ Reduce │ Elementwise         │    │
│  └─────────────────────────────────────────────────────────────────────────────────┘    │
│                                        │                                                │
│  ┌─────────────────────────────────────▼───────────────────────────────────────────┐    │
│  │                         Layer 5: Persistent Kernel Runtime                      │    │
│  │  Memory Management │ Kernel Launch │ Synchronization │ JIT Compilation          │    │
│  └─────────────────────────────────────────────────────────────────────────────────┘    │
│                                        │                                                │
│  ┌─────────────────────────────────────▼───────────────────────────────────────────┐    │
│  │                              Hardware Layer                                     │    │
│  │  ┌─────┐ ┌─────┐ ┌─────┐ ┌───────┐ ┌──────┐ ┌──────┐ ┌─────┐ ┌─────┐ ┌──────┐   │    │
│  │  │CUDA │ │ROCm │ │ MPS │ │Ascend │ │ MACA │ │ TPU  │ │ XPU │ │FPGA │ │ CPU  │   │    │
│  │  │NVIDA│ │ AMD │ │Apple│ │Huawei │ │MetaX │ │Google│ │Intel│ │Xilinx││x86/ARM│  │    │
│  │  └─────┘ └─────┘ └─────┘ └───────┘ └──────┘ └──────┘ └─────┘ └─────┘ └──────┘   │    │
│  │  ┌───────┐ ┌─────┐ ┌──────┐                                                     │    │
│  │  │Triton │ │ NKI │ │ MLIR │  ← Compiler Backends                                │    │
│  │  │OpenAI │ │ AWS │ │ LLVM │                                                     │    │
│  │  └───────┘ └─────┘ └──────┘                                                     │    │
│  └─────────────────────────────────────────────────────────────────────────────────┘    │
│                                                                                         │
└─────────────────────────────────────────────────────────────────────────────────────────┘

Backend Support Matrix (12 Backends × 5 Layers)

Backend	Hardware	Backend API	Strategy	Kernel	Threadblock	PK Runtime
CUDA	NVIDIA GPU	✅	✅	✅	✅	✅
ROCm	AMD GPU	✅	✅	✅	✅	✅
CPU	x86/ARM	✅	✅	✅	✅	✅
MPS	Apple Silicon	✅	✅	✅	✅	✅
Ascend	Huawei NPU	✅	✅	✅	✅	✅
MACA	MetaX GPU	✅	✅	✅	✅	✅
TPU	Google Cloud	✅	✅	✅	✅	✅
XPU	Intel GPU	✅	✅	✅	✅	✅
FPGA	Intel/Xilinx	✅	✅	✅	✅	✅
Triton	Compiler	✅	✅	✅	✅	✅
NKI	AWS Neuron	✅	✅	🚧	🚧	🚧
MLIR	Multi-target	✅	✅	✅	✅	✅

Status note: ✅ means the YiRage interface and modeling path exist; 🚧 means the backend is limited to modeling/code-generation paths and is not yet available through the runtime execution API. Some vendor-specific threadblock and persistent-kernel implementations remain experimental and are excluded from the default CMake build until their vendor toolchains and interfaces are complete.

Five-Layer Design

Layer 1: Python API

Backend query and selection (get_available_backends())
Hardware Device Registry (HardwareRegistry — register/query chip architectures at runtime)
Unified compiler interface (UnifiedCompiler)
Core bridge to C++ (CoreBridge)
Hardware-specific optimizers

Layer 2: Backend Manager (C++)

BackendRegistry (singleton, thread-safe)
Factory patterns for backends and strategies
Automatic initialization on import

Layer 3: Search & Strategy

Hardware-aware kernel search
Fingerprint-based verification
Performance profiling and modeling

Layer 4: Threadblock Operations

Optimized LLM operators (MatMul, Attention, RMSNorm, SwiGLU)
Hardware-specific implementations
Code generation for Triton/NKI/MLIR

Layer 5: Persistent Kernel Runtime

Device memory management
Kernel launch and synchronization
JIT compilation support

✨ Key Features

🚀 12 Backend Targets (Core + Experimental)

Backend	Hardware	Key Features	Architecture
CUDA	NVIDIA GPU	Tensor Core, 32-thread Warp, cuBLAS	SM, Shared Memory
ROCm	AMD GPU	Matrix Core, 64-thread Wavefront, rocBLAS	GCN/CDNA, LDS
CPU	x86/ARM	AVX512/NEON SIMD, Cache Blocking, OpenMP	Multi-core, L1/L2/L3
MPS	Apple Silicon	Metal, Threadgroup, Unified Memory	M1/M2/M3/M4
Ascend	Huawei NPU	Cube Unit 16×16, AI Core, L1 Buffer	Ascend 910/310
MACA	MetaX GPU	64-thread Warp, CUDA-compat, Tensor Core	C500 Series
TPU	Google Cloud	MXU 128×128, BF16 Native, PJRT	TPU v2/v3/v4/v5
XPU	Intel GPU	XMX 8×8, SYCL/oneAPI, SLM	Arc/Max/Gaudi
FPGA	Intel/Xilinx	DSP Blocks, Pipeline, BRAM/HBM	OpenCL Kernel
Triton	Compiler	Auto-tuning, Tile Fusion, MMA	PTX/HSACO
NKI	AWS Neuron	Tensor Engine 128×128, SBUF 24MB	Trainium/Inferentia
MLIR	Multi-target	JIT, Linalg, Pass Pipeline	LLVM/NVVM/SPIRV

🔧 Hardware Architecture Differences

┌────────────────────────────────────────────────────────────────────────────────────┐
│                        Hardware Architecture Comparison                            │
├────────────┬─────────────────┬─────────────────┬───────────────────────────────────┤
│ Backend    │ Thread Model    │ Matrix Unit     │ Memory Hierarchy                  │
├────────────┼─────────────────┼─────────────────┼───────────────────────────────────┤
│ CUDA       │ 32-thread Warp  │ Tensor Core     │ Registers → Shared → L2 → HBM     │
│ ROCm       │ 64-thread Wave  │ Matrix Core     │ VGPR → LDS → L2 → HBM             │
│ MPS        │ SIMD Group      │ Apple GPU       │ Threadgroup → Device → Unified    │
│ Ascend     │ AI Core         │ Cube 16×16      │ L0 → L1 → L2 → HBM                │
│ MACA       │ 64-thread Warp  │ Tensor Core     │ Shared → L2 → HBM                 │
│ TPU        │ MXU Systolic    │ MXU 128×128     │ VMEM → HBM                        │
│ XPU        │ Xe Subgroup     │ XMX 8×8         │ SLM → L3 → HBM                    │
│ FPGA       │ Pipeline        │ DSP Block       │ BRAM/URAM → DDR/HBM               │
└────────────┴─────────────────┴─────────────────┴───────────────────────────────────┘

🎯 Hardware-Aware Kernel Optimizers

60+ Optimization Methods across all 12 backends
Automatic Configuration based on hardware capabilities
Performance Modeling for each backend
Code Generation for Triton/NKI/MLIR

Example: CUDA Optimizer

from yirage.backends.cuda.config import CUDAArch, get_cuda_search_config

config = get_cuda_search_config(CUDAArch.AMPERE)
print(config["arch"], config["warp_size"], config["has_tensor_cores"])
# Auto-configured: Tensor Core, warps, shared memory, search space

Example: MPS Optimizer (Apple Silicon)

from yirage.backends.mps.config import AppleChipFamily, get_mps_search_config

config = get_mps_search_config(AppleChipFamily.M3_MAX)
print(config["chip_family"], config["gpu_cores"], config["max_threads_per_threadgroup"])
# Auto-configures: M-series family, GPU cores, threadgroup size

Example: Ascend Optimizer (Huawei NPU)

import yirage as yr

# Create and optimize for Ascend NPU
graph = yr.new_kernel_graph()
X = graph.new_input(dims=(8, 4096), dtype=yr.float16)
W = graph.new_input(dims=(4096, 4096), dtype=yr.float16)
O = graph.matmul(X, W)
graph.mark_output(O)

# Optimize using Ascend backend (via BiSheng + Triton)
optimized = graph.superoptimize(backend='ascend')
# Auto-configures: AI Core blocks, Cube unit tiles, L1 buffer

Example: MACA Optimizer (MetaX GPU)

import yirage as yr

# Create and optimize for MetaX MACA GPU
graph = yr.new_kernel_graph()
X = graph.new_input(dims=(8, 4096), dtype=yr.float16)
W = graph.new_input(dims=(4096, 4096), dtype=yr.float16)
O = graph.matmul(X, W)
graph.mark_output(O)

# Optimize using MACA backend (64-thread warps!)
optimized = graph.superoptimize(backend='maca')
# Auto-configures: 64-thread warps, tile sizes, shared memory

# Environment: export MACA_HOME=/opt/maca

Example: ROCm Optimizer (AMD GPU) 🆕

import yirage as yr

# Create and optimize for AMD GPU
graph = yr.new_kernel_graph()
X = graph.new_input(dims=(8, 4096), dtype=yr.float16)
W = graph.new_input(dims=(4096, 4096), dtype=yr.float16)
O = graph.matmul(X, W)
graph.mark_output(O)

# Optimize using ROCm backend
optimized = graph.superoptimize(backend='rocm')
# Auto-configures: 64-thread wavefronts, LDS, Matrix Cores (MI200/MI300)

# Environment: export ROCM_PATH=/opt/rocm

Example: TPU Optimizer (Google Cloud) 🆕

import yirage as yr

# Create and optimize for Google TPU
graph = yr.new_kernel_graph()
X = graph.new_input(dims=(8, 4096), dtype=yr.bfloat16)
W = graph.new_input(dims=(4096, 4096), dtype=yr.bfloat16)
O = graph.matmul(X, W)
graph.mark_output(O)

# Optimize using TPU backend
optimized = graph.superoptimize(backend='tpu')
# Auto-configures: 128x128 MXU, BF16 native, VMEM tiling

Example: MLIR JIT Compiler 🆕

from yirage.pk import MLIRPKBackend
from yirage.threadblock.mlir_ops import MLIRCodeGenerator, MLIRTileConfig

# Generate MLIR for MatMul
config = MLIRTileConfig(tile_sizes=[32, 32, 32], vectorize=True)
mlir_code = MLIRCodeGenerator.generate_matmul(1024, 1024, 1024,
                                               dtype=yr.float16, config=config)

# JIT compile and execute
backend = MLIRPKBackend(target=MLIRPKBackend.JIT_TARGET_CPU)
backend.initialize()
backend.jit_compile(mlir_code)
backend.execute("matmul", [A_ptr, B_ptr, C_ptr], 3)

🔍 Backend-Specific Search Strategies

┌──────────────────────────────────────────────────────────────────────────────────────┐
│                              Search & Optimization Flow                              │
├──────────────────────────────────────────────────────────────────────────────────────┤
│                                                                                      │
│  ┌──────────────┐     ┌──────────────────────────────────────────────────────────┐   │
│  │ Kernel Graph │────▶│                  Search Engine                           │   │
│  └──────────────┘     │  ┌────────────────┐  ┌───────────────┐  ┌─────────────┐  │   │
│                       │  │ Candidate Gen  │──│ Fingerprint   │──│ Performance │  │   │
│                       │  │ (µGraph Space) │  │ Verification  │  │  Profiler   │  │   │
│                       │  └────────────────┘  └───────────────┘  └─────────────┘  │   │
│                       └─────────────────────────────┬────────────────────────────┘   │
│                                                     │                                │
│  ┌──────────────────────────────────────────────────▼───────────────────────────┐    │
│  │                       Backend-Specific Strategies                            │    │
│  ├────────────┬────────────┬────────────┬────────────┬────────────┬─────────────┤    │
│  │   CUDA     │   ROCm     │   MPS      │  Ascend    │   MACA     │    TPU      │    │
│  │ TensorCore │ MatrixCore │ ThreadGrp  │  CubeUnit  │  64-Warp   │    MXU      │    │
│  │  32-Warp   │  64-Wave   │   SIMD     │  AI Core   │ TensorCore │  128×128    │    │
│  ├────────────┼────────────┼────────────┼────────────┼────────────┼─────────────┤    │
│  │    XPU     │   FPGA     │  Triton    │    NKI     │   MLIR     │    CPU      │    │
│  │    XMX     │  Pipeline  │ AutoTune   │ TensorEng  │ LinalgOpt  │  SIMD/OMP   │    │
│  │   SYCL     │    DSP     │ TileFuse   │   SBUF     │ JIT/AOT    │ CacheBlock  │    │
│  └────────────┴────────────┴────────────┴────────────┴────────────┴─────────────┘    │
│                                       │                                              │
│                         ┌─────────────▼─────────────┐                                │
│                         │    Optimized Kernel       │                                │
│                         │  (Best Configuration)     │                                │
│                         └───────────────────────────┘                                │
└──────────────────────────────────────────────────────────────────────────────────────┘

12 Independent Search Strategies with hardware-specific optimization
20+ Candidate Generation Dimensions
15 Performance Evaluation Metrics
Auto-tuning and performance modeling
Code generation for compiler backends (Triton, NKI, MLIR)

🔌 Hardware Device Management (New!)

YiRage provides a unified hardware registry that allows new chip architectures to be registered at runtime — no code changes required. This is the highest level of hardware adaptation: any new chip can be plugged into the system by describing its architecture once.

Architecture

┌──────────────────────────────────────────────────────────────────────────┐
│                     Hardware Device Management                           │
├──────────────────────────────────────────────────────────────────────────┤
│                                                                          │
│  ┌─────────────────────┐     ┌──────────────────────────────────────┐    │
│  │  HardwareRegistry   │     │  ChipArchitecture Dataclass          │    │
│  │  (Thread-safe       │────▶│  ┌──────────┐ ┌───────────┐          │    │
│  │   Singleton)        │     │  │MemorySpec│ │ComputeSpec│          │    │
│  │                     │     │  └──────────┘ └───────────┘          │    │
│  │  • register()       │     │  ┌────────────┐ ┌────────┐           │    │
│  │  • get()            │     │  │FeatureFlags│ │Metadata│           │    │
│  │  • list_by_vendor() │     │  └────────────┘ └────────┘           │    │
│  │  • list_by_backend()│     └──────────────────────────────────────┘    │
│  │  • import_json()    │                                                 │
│  │  • export_json()    │     ┌──────────────────────────────────────┐    │
│  │  • on_register()    │     │  Built-in: 20+ Chips Pre-registered  │    │
│  └─────────────────────┘     │  NVIDIA V100→B200 │ AMD MI250X/MI300X│    │
│                              │  Ascend 910/910B  │ MetaX C500       │    │
│  ┌─────────────────────┐     │  Apple M2–M4      │ Google TPU v4/v5e│    │
│  │  Auto-Detection     │     │  Intel PVC │ Xilinx Alveo │ AWS Trn2 │    │
│  │  nvidia-smi/rocm-smi│     └──────────────────────────────────────┘    │
│  │  npu-smi/mx-smi/MPS │                                                 │
│  └─────────────────────┘                                                 │
│                                                                          │
└──────────────────────────────────────────────────────────────────────────┘

20+ Built-in Chip Architectures

Vendor	Chips	Backend	Category
NVIDIA	V100, T4, A100, RTX 3090, RTX 4090, H100, B200	`cuda`	GPU
AMD	MI250X, MI300X	`rocm`	GPU
Intel	Data Center GPU Max 1550 (PVC)	`xpu`	GPU
Huawei	Ascend 910, 910B, 310P	`ascend`	NPU
MetaX	C500, C500 Pro	`maca`	GPU
Apple	M2 Ultra, M3 Max, M4 Max	`mps`	GPU
Google	TPU v4, TPU v5e	`tpu`	TPU
Xilinx	Alveo U250	`fpga`	FPGA
AWS	Trainium2	`nki`	DSA

Quick Start — Query Built-in Chips

from yirage.hardware import HardwareRegistry

reg = HardwareRegistry.instance()

# Look up a chip
h100 = reg.get("nvidia_h100")
print(h100.summary())
# NVIDIA H100 SXM5 | 132 CUs | 80GB HBM3 | 989 TFLOPS FP16

# List chips by vendor / backend / category
nvidia_chips = reg.list_by_vendor("nvidia")   # 7 chips
cuda_chips   = reg.list_by_backend("cuda")    # all CUDA-mapped chips
gpu_chips    = reg.list_by_category("gpu")    # all GPUs across vendors

Register a New Chip at Runtime

from yirage.hardware import (
    HardwareRegistry, ChipArchitecture,
    ChipVendor, ChipCategory,
    ComputeSpec, MemorySpec, MemoryType, FeatureFlags,
)

reg = HardwareRegistry.instance()

# Define the new chip
new_chip = ChipArchitecture(
    chip_id="myvendor_x1",
    chip_name="MyVendor X1 Accelerator",
    vendor=ChipVendor.OTHER,
    category=ChipCategory.DSA,
    arch_name="X1",
    arch_code="x1_v1",
    backend="cuda",                          # maps to YiRage backend
    memory=MemorySpec(
        capacity_gb=128,
        bandwidth_gbps=6000,
        memory_type=MemoryType.HBM3E,
    ),
    compute=ComputeSpec(
        warp_size=32,
        num_compute_units=256,
        peak_tflops_fp16=2000,
    ),
    features=FeatureFlags(
        tensor_cores=True,
        fp8=True,
        bf16=True,
    ),
)

reg.register(new_chip)
print(f"Registry now has {reg.size} chips")

Bulk Import / Export (JSON)

# Export entire registry to a file
reg.export_json("/path/to/chips.json")

# Import chips from a JSON file (e.g. from a partner's chip catalog)
count = reg.import_json("/path/to/new_chips.json")
print(f"Imported {count} new chips")

Auto-detect Current Hardware

from yirage.hardware import detect_current_chip

chip = detect_current_chip()
if chip:
    print(f"Detected: {chip.summary()}")
    print(f"Backend:  {chip.backend}")
    print(f"Memory:   {chip.memory.capacity_gb} GB {chip.memory.memory_type.value}")
    print(f"FP16:     {chip.compute.peak_tflops_fp16} TFLOPS")

React to New Registrations (Callback)

from yirage.hardware import ChipArchitecture, HardwareRegistry

reg = HardwareRegistry.instance()

def on_new_chip(chip):
    print(f"🆕 New chip registered: {chip.chip_name} ({chip.chip_id})")

another_chip = ChipArchitecture(
    chip_id="callback_demo",
    chip_name="Callback Demo",
    backend="cpu",
)

reg.on_register(on_new_chip)
reg.register(another_chip, overwrite=True)   # triggers callback

Module Structure

python/yirage/hardware/
├── __init__.py          # Public API — auto-populates built-in chips on import
├── chip_arch.py         # ChipArchitecture, MemorySpec, ComputeSpec, FeatureFlags
├── registry.py          # HardwareRegistry (thread-safe singleton)
├── builtin_chips.py     # 20+ pre-registered chip definitions
└── detector.py          # Runtime auto-detection (nvidia-smi, npu-smi, etc.)

🚀 Quick Start

Installation

Native runtime: import yirage requires yirage.core (Cython) linked against libyirage_runtime. Build from source with pip install -e . (see AGENTS.md) or use a wheel that includes the extension. Optional PyPI extras only add Python dependencies; they do not remove the need for native code.

Quick Install (Auto-detect Hardware)

git clone https://github.com/chenxingqiang/YiRage.git
cd YiRage
pip install -e .   # Auto-detects CUDA/MPS/CPU

Specify Backend

# Using environment variable
YIRAGE_BACKEND=cuda pip install -e .     # NVIDIA GPU
YIRAGE_BACKEND=rocm pip install -e .     # AMD GPU
YIRAGE_BACKEND=mps pip install -e .      # Apple Silicon
YIRAGE_BACKEND=ascend pip install -e .   # Huawei NPU
YIRAGE_BACKEND=maca pip install -e .     # MetaX GPU
YIRAGE_BACKEND=cpu pip install -e .      # CPU backend (still full native build)

# Multiple backends
YIRAGE_BACKEND=cuda,cpu pip install -e .

Huawei Ascend NPU

📖 Full Ascend Guide

# Load environment
source /usr/local/Ascend/ascend-toolkit/set_env.sh
pip install torch_npu

# Install
YIRAGE_BACKEND=ascend pip install -e .

📖 Full Installation Guide - All backends and options

Basic Usage

import yirage as yr

# Query available backends
backends = yr.get_available_backends()
print(f"Available backends: {backends}")
# Output: ['cuda', 'cpu', 'mps']  # depends on your hardware

# Check specific backend
if yr.is_backend_available('mps'):
    print("Apple Silicon GPU ready!")

# Create kernel with backend selection
mpk = yr.PersistentKernel(
    mode="decode",
    backend="mps",              # Specify backend
    fallback_backends=["cpu"],  # Auto fallback
    world_size=1,
    mpi_rank=0,
    # ... other parameters
)

Using Hardware-Specific Optimizers

# CUDA optimization
from yirage.backends.cuda.config import CUDAArch, get_cuda_search_config

cuda_config = get_cuda_search_config(CUDAArch.AMPERE)
print(f"CUDA tile candidates: {cuda_config['block_dims_to_explore'][:3]}")

# CPU optimization
from yirage.backends.cpu.config import get_cpu_search_config

cpu_config = get_cpu_search_config()
print(f"CPU SIMD: {cpu_config['simd_type']} across {cpu_config['num_cores']} cores")
# Auto-detects: SIMD type, CPU cores, cache-aware search space

# MPS optimization (Apple Silicon)
from yirage.backends.mps.config import AppleChipFamily, get_mps_search_config

mps_config = get_mps_search_config(AppleChipFamily.M3_MAX)
print(f"MPS chip: {mps_config['chip_family']} with {mps_config['gpu_cores']} GPU cores")
# Auto-configures: GPU family, cores, memory/search limits

📊 Performance

M3 Mac Benchmarks

Benchmark	MPS (ms)	CPU (ms)
gated_mlp	0.677	1.268
rms_norm	0.463	0.115
lora	0.637	0.590
gqa	0.554	-
norm_transformer	1.195	-

All benchmarks support CUDA, MPS, and CPU backends

🤖 RL-Guided Kernel Search

YiRage now supports RL-guided kernel search using Ray/RLlib, enabling intelligent exploration of the kernel configuration space.

Hierarchical Closed-Loop Architecture

┌─────────────────────────────────────────────────────────────────────┐
│                  RL-YiRage Hierarchical Closed Loop                 │
│                                                                     │
│  Level 1: Config Policy                                             │
│  ┌─────────────────────────────────────────────────────────────┐    │
│  │ HardwareConfig (grid_dim, block_dim, forloop) ────────────┐ │    │
│  └─────────────────────────────────────────────────────────┐ │ │    │
│                                                            │ │ │    │
│  Level 2: Graph Policy (constrained by Level 1)            │ │ │    │
│  ┌─────────────────────────────────────────────────────┐   │ │ │    │
│  │ µGraph actions ─▶ C++ Search ─▶ GPU Verify ─▶ reward│◀──┘ │ │    │
│  └─────────────────────────────────────────────────────┘     │ │    │
│         ▲                                                    │ │    │
│         └──── µGraph features (from C++) ◀───────────────────┘ │    │
│                                                                │    │
│                      policy update (RLlib)  ◀──────────────────┘    │
└─────────────────────────────────────────────────────────────────────┘

Quick Start

# Run integration tests (no GPU required)
python scripts/test_rl_integration.py

# Test locally (no GPU required)
python scripts/train_rl_kernel_search.py --mode local --test-episodes 10

# Train with Ray/RLlib (requires GPU for verification)
python scripts/train_rl_kernel_search.py --mode train \
    --algorithm PPO \
    --num-workers 8 \
    --max-iterations 1000

# Search with trained policy
python scripts/train_rl_kernel_search.py --mode search \
    --checkpoint /path/to/checkpoint \
    --target-graph examples/matmul.json

Python API

from yirage.rl import YiRageSearchEnv, EnvConfig, train_rl_search

# Create environment
env_config = EnvConfig(
    target_graph_json=target_graph,
    backend="cuda",
    num_gpus=4,
)

# Option 1: Use as Gymnasium environment
env = YiRageSearchEnv(vars(env_config))
obs, info = env.reset()
action = env.action_space.sample()
obs, reward, done, truncated, info = env.step(action)

# Option 2: Train with RLlib
from yirage.rl import TrainingConfig

config = TrainingConfig(
    algorithm="PPO",
    num_workers=8,
    max_iterations=500,
)
results = train_rl_search(config)

Hierarchical Search

from yirage.rl.search import (
    HardwareConfig, SearchSpaceConstraints,
    ConstrainedGraphActionSpace, HierarchicalSearchEnv
)

# Level 1: Configure hardware parameters
config = HardwareConfig(
    grid_dim_x=4, grid_dim_y=2, grid_dim_z=1,
    block_dim_x=128, block_dim_y=1, block_dim_z=1,
    forloop_range=16,
    shared_memory_size=49152
)

# Level 2: Get constraints for graph search
constraints = SearchSpaceConstraints(config)
print(f"Valid imaps: {len(constraints.valid_imaps)}")
print(f"Max operators: {constraints.max_operators}")

# Create constrained graph action space
graph_space = ConstrainedGraphActionSpace(constraints)

µGraph Feature Extraction

from yirage.rl.features import MuGraphFeature, FeatureProcessor

# Features extracted from C++ layer (or simulated JSON)
features = MuGraphFeature.from_json(features_json)
print(f"Operators: {len(features.operators)}")
print(f"Graph depth: {features.graph_depth}")

# Process for neural network input
processor = FeatureProcessor()
processed = processor.process(features)
# node_features: (num_nodes, 16)
# edge_index: (2, num_edges)
# global_features: (48,)

Key Features

Hierarchical Search: Level 1 (config) constrains Level 2 (µGraph)
Complete Closed Loop: RL decisions → C++ search → GPU verification → reward
AccelForge Pre-screening: virtual-hardware latency/energy/area/power modeling before physical profiling
µGraph Feature Extraction: Rich features from C++ layer for RL model input
Multi-objective Reward: Balances validity, performance, efficiency, exploration
Ray Integration: Distributed CPU workers + GPU verification
Action Masking: Prevents invalid actions based on search state
Model Persistence: Save/load trained policies, export to ONNX

Hardware-Aware Training

from yirage.rl.hardware import detect_hardware, get_optimal_config
from yirage.rl.training import GRPOConfig, GRPOTrainer

# Auto-detect hardware
hardware = detect_hardware()
print(f"Detected: {hardware.backend} - {hardware.device_name}")
print(f"Peak FP16: {hardware.peak_tflops_fp16} TFLOPS")

# Get optimal config for workload
config = get_optimal_config(hardware, workload)

# Train with GRPO (supports LoRA fine-tuning)
grpo_config = GRPOConfig(
    group_size=8,
    learning_rate=1e-4,
    use_lora=True,
    lora_rank=16,
)

AccelForge Hardware Co-design

YiRage can use AccelForge as a virtual hardware oracle for accelerator design-space exploration and kernel candidate pre-screening:

pip install "yirage[accelforge]"

See YiRage × AccelForge Quick Start for availability diagnostics, µGraph workload conversion, multi-objective metrics, pre-screening, and Pareto-front examples.

LLM Fine-tuning with TRL

from yirage.rl.training import FineTuningConfig, MuGraphPolicyTrainer

# Configure fine-tuning with TRL
config = FineTuningConfig(
    strategy="dpo",  # sft, dpo, grpo, ppo
    model_name_or_path="meta-llama/Llama-2-7b-hf",
    use_lora=True,
    use_4bit=True,  # QLoRA
    lora_r=16,
)

# Train policy model
trainer = MuGraphPolicyTrainer(config)
trainer.train(train_data)

# Generate optimal configs
configs = trainer.generate_config(target_graph, hardware)

Universal Compute Optimization

Optimize any compute task on any hardware at any cluster scale with a single function call:

from yirage.rl.cluster import optimize_any_task

# Optimize with one line
result = optimize_any_task(
    {"type": "attention", "batch": 32, "seq_len": 2048, "num_heads": 32},
    cluster_spec={"type": "multi_node", "num_nodes": 4, "gpus_per_node": 8}
)

print(f"Strategy: {result.result.parallelism_strategy}")  # e.g., "tensor_parallel_8"
print(f"Latency: {result.result.estimated_latency_ms:.2f} ms")
print(f"Throughput: {result.result.estimated_throughput_tps:.1f} samples/sec")

# Get kernel configs for YiRage search
for op_id, config in result.kernel_configs.items():
    print(f"{op_id}: {config}")

Device Registry (25+ Pre-defined Devices):

from yirage.rl.cluster import (
    ClusterTopology, DeviceRegistry, get_device_spec, register_custom_device
)

# Create heterogeneous cluster from registry
cluster = ClusterTopology.create_from_registry([
    "H100_SXM:4",      # 4x NVIDIA H100
    "MI300X:2",        # 2x AMD MI300X
    "TPUv4:2",         # 2x Google TPU v4
    "Ascend910B:2",    # 2x Huawei Ascend
])

# Register custom hardware
register_custom_device("MyAccelerator", {
    "device_type": "custom",
    "compute_units": 128,
    "peak_tflops_fp16": 500.0,
    "memory_gb": 64.0,
    "memory_bandwidth_gbps": 2000.0,
})

Supported Device Types:

Category	Devices
NVIDIA GPU	H100, A100, V100, RTX 4090, RTX 3090
AMD GPU	MI300X, MI250X
Intel	Max 1550 (XPU)
Google	TPU v4, TPU v5e
Huawei	Ascend 910B, Ascend 910, Ascend 310
AWS	Trainium2, Inferentia2
Apple	M2 Ultra, M3 Max (MPS)
MetaX	C500 (MACA)
CPU	EPYC 9654, Xeon 8480
FPGA	Alveo U280
Custom	User-defined devices

Key features:

Any Task: MatMul, Attention, MLP, Transformer, or custom graphs
Any Hardware: CPU, GPU, NPU, TPU, FPGA, or custom accelerators
Any Scale: Single device to multi-node clusters
Simulation-based: Accurate communication modeling without real cluster
µGraph Integration: Generates search space for YiRage kernel optimization
Device Registry: 25+ pre-defined devices with full specs

Design Documents

🔥 COMET: Compound Operations with Explicit Collectives

YiRage integrates the COMET framework for modeling and optimizing compound operation dataflows with explicit collective communication, based on the research paper:

"COMET: A Framework for Modeling Compound Operation Dataflows with Explicit Collectives" (Negi et al.)

Key Features

Compound Operations: Fused execution of GEMM-Softmax, GEMM-LayerNorm, Self-Attention, Gated MLP
Explicit Collectives: AllReduce, AllGather, ReduceScatter, Broadcast with accurate cost modeling
Data Staging Model: Ramp-up/steady-state/ramp-down phases for memory hierarchy
Scheduling Strategies: Sequential, Pipelined, Parallel execution modes
Energy & Latency Estimation: Detailed breakdown for optimization decisions

Compound Operations API

import yirage as yr

# Create kernel graph
graph = yr.new_kernel_graph()

# GEMM-Softmax fusion (reduces DRAM traffic by keeping intermediate on-chip)
A = graph.new_input(dims=(1024, 512), dtype=yr.float16)
B = graph.new_input(dims=(512, 1024), dtype=yr.float16)
result = graph.gemm_softmax(A, B, dim=-1)

# GEMM-LayerNorm fusion
result_ln = graph.gemm_layernorm(A, B, normalized_shape=(1024,))

# Self-Attention (FlashAttention-style fusion)
Q = graph.new_input(dims=(8, 1024, 64), dtype=yr.float16)  # [H, S, D]
K = graph.new_input(dims=(8, 64, 1024), dtype=yr.float16)  # [H, D, S] (transposed)
V = graph.new_input(dims=(8, 1024, 64), dtype=yr.float16)  # [H, S, D]
attn_out = graph.self_attention(Q, K, V)

# Gated MLP (LLM-style with SiLU activation)
X = graph.new_input(dims=(8, 1024, 4096), dtype=yr.float16)
W_gate = graph.new_input(dims=(4096, 11008), dtype=yr.float16)
W_up = graph.new_input(dims=(4096, 11008), dtype=yr.float16)
W_down = graph.new_input(dims=(11008, 4096), dtype=yr.float16)
mlp_out = graph.gated_mlp(X, W_gate, W_up, W_down, activation="silu")

# RMSNorm + Linear (common in attention QKV projection)
norm_out = graph.rms_norm_linear(X, W_gate, normalized_shape=(4096,))

graph.mark_output(result)
optimized = graph.superoptimize(backend="cuda")

COMET Cost Model

from yirage.rl.cluster.simulator import (
    COMETCostModel, COMETHardwareConfig,
    SchedulingStrategy, MemoryLevel, CommunicationType
)

# Create cost model with hardware config
hw_config = COMETHardwareConfig(
    dram_bandwidth_gbps=900.0,      # HBM2e
    global_buffer_bandwidth_gbps=3000.0,  # On-chip L2
    num_compute_units=108,          # SMs on A100
    peak_tflops_fp16=312.0,
)
cost_model = COMETCostModel(hw_config=hw_config)

# Estimate compound operation latency and energy
latency, energy = cost_model.estimate_compound_operation(
    op_name="gemm_softmax",
    input_shapes=[(2048, 1024), (1024, 2048)],
    dtype_bytes=2,  # FP16
    num_devices=4,
    strategy=SchedulingStrategy.PIPELINED,
)

print(f"Total latency: {latency.total_latency_ms:.3f} ms")
print(f"  - Compute: {latency.compute_latency_ms:.3f} ms")
print(f"  - Memory: {latency.total_memory_latency_ms:.3f} ms")
print(f"  - Collective: {latency.collective_latency_ms:.3f} ms")
print(f"Total energy: {energy.total_energy_mj:.3f} mJ")

# Compare distributed variants (local vs distributed execution)
results = cost_model.compare_distributed_variants(
    op_name="gemm_softmax",
    input_shapes=[(4096, 2048), (2048, 4096)],
    num_devices=8,
)
print(f"Speedup with distribution: {results['speedup']:.2f}x")

Collective Communication Cost Model

from yirage.rl.cluster.simulator import CommunicationModel, CommunicationType

comm_model = CommunicationModel()

# Ring AllReduce latency (Eq. 3-4 from COMET paper)
latency_ms = comm_model.all_reduce_time_ms(
    size_bytes=100 * 1024 * 1024,  # 100 MB
    num_devices=8,
    bandwidth_gbps=200.0,  # NVLink
    latency_us=1.0,
    algorithm="ring",
)
print(f"AllReduce latency: {latency_ms:.3f} ms")

# AllGather and ReduceScatter
gather_time = comm_model.all_gather_time_ms(
    size_bytes=50 * 1024 * 1024,
    num_devices=8,
    bandwidth_gbps=200.0,
    latency_us=1.0,
)
print(f"AllGather latency: {gather_time:.3f} ms")

Latency Breakdown (COMET Equations)

The cost model implements the COMET paper equations:

Equation	Description	Formula
Eq. 1	Memory Transaction	`MemLat(T) = DV / BW`
Eq. 2	Data Staging	`TotalMem = RampUp + Steady + RampDown`
Eq. 3-4	Ring Collective	`CollLat = 2(n-1)/n × size / bw`
Eq. 5-7	Scheduling	`Stall = CS + OS + CF`

Where:

DV: Data Volume, BW: Bandwidth
CS: Compulsory Stall (data dependency)
OS: Optional Stall (resource blocking)
CF: Conflict Stall (resource contention)

COMET Search Strategy

YiRage provides a complete search strategy for COMET compound operations:

from yirage.search import (
    COMETSearchStrategy,
    get_backend_config,
    detect_compound_patterns,
    optimize_compound_graph,
)

# Auto-detect compound patterns in a graph
op_types = ["matmul", "exp", "reduction", "div", "matmul"]  # Self-attention
patterns = detect_compound_patterns(op_types)
print(f"Found {len(patterns)} compound patterns: {[p.op_type.name for p in patterns]}")

# Get backend-specific configuration (15 hardware profiles)
config = get_backend_config("cuda", "a100")  # NVIDIA A100
# Or: get_backend_config("rocm", "mi300x")   # AMD MI300X
# Or: get_backend_config("tpu", "v5e")       # Google TPU v5e
# Or: get_backend_config("ascend", "910b")   # Huawei Ascend

# Run COMET search to find optimal configuration
strategy = COMETSearchStrategy(config)
result = strategy.search(
    op_types=op_types,
    problem_dims={"M": 4096, "K": 4096, "N": 4096}
)

print(f"Best tile config: M={result.tile_config.tile_m}, N={result.tile_config.tile_n}")
print(f"Scheduling: {result.scheduling.name}")
print(f"Estimated latency: {result.latency_ns:.2f} ns")

Backend Hardware Profiles

Backend	Variant	DRAM BW (GB/s)	Peak TFLOPS	Tile Sizes
CUDA	H100	3350	989	64, 128, 256
CUDA	A100	2039	312	64, 128, 256
CUDA	V100	900	125	32, 64, 128
ROCm	MI300X	5300	1307	64, 128, 256
ROCm	MI250X	3200	383	64, 128, 256
XPU	Ponte Vecchio	3200	420	32, 64, 128, 256
Ascend	910B	1600	320	64, 128, 256
TPU	v5e	1600	197	128, 256, 512
TPU	v4	1200	275	128, 256, 512
MACA	MXC500	2000	256	64, 128, 256
MPS	M3 Max	400	14.2	32, 64, 128
MPS	M2 Ultra	800	27.2	32, 64, 128
CPU	Xeon	200	4.0	32, 64, 128, 256
CPU	EPYC	460	5.0	32, 64, 128, 256
FPGA	Alveo	77	4.0	16, 32, 64, 128

🚀 Deep Ray Integration

YiRage provides production-grade distributed optimization with deep Ray integration:

Features

Feature	Description
C++ Binding	Direct `search_partition()` API via Cython for native performance
Object Store	`ray.put()` for efficient large graph data sharing
Placement Groups	GPU affinity with PACK/SPREAD strategies for NVLink
Fault Tolerance	Exponential backoff retry + checkpoint/restore
Collective Ops	Efficient all-reduce for gradient synchronization

Quick Start

from yirage.distributed import (
    RayDeepIntegration,
    DeepIntegrationConfig,
    GPUPlacementConfig,
    RetryConfig,
    RetryStrategy,
)

# Configure distributed optimization
config = DeepIntegrationConfig(
    num_workers=8,
    gpu_placement=GPUPlacementConfig(
        gpus_per_worker=1,
        strategy="PACK",  # NVLink locality
    ),
    retry=RetryConfig(
        strategy=RetryStrategy.EXPONENTIAL,
        max_retries=5,
    ),
    use_object_store=True,
)

# Create engine and optimize
engine = RayDeepIntegration(config)
result = engine.optimize(
    graph={"type": "matmul", "input_shapes": [[1024, 2048], [2048, 4096]]},
    search_space={"grid_dims": [(1,1,1), (2,1,1), (4,1,1)], "block_dims": [(128,1,1), (256,1,1)]},
)

print(f"Best latency: {result['best_latency_ms']:.3f} ms")
print(f"Workers used: {result['num_workers']}")

All-Reduce for Gradients

# Distributed gradient synchronization
gradients = [{"layer1": 0.1}, {"layer1": 0.3}, {"layer1": 0.2}, {"layer1": 0.4}]
reduced = engine.all_reduce_gradients(gradients, reduce_op="mean")
# reduced["layer1"] = 0.25

Run Demo

python examples/cluster/deep_ray_integration_demo.py

📚 Documentation

Quick Start - Get started in 5 minutes
API Reference - Complete API documentation
Backend Guide - Backend usage and configuration
Architecture Design - System design

Hardware Device Management

Module	Description
`yirage.hardware`	Hardware Registry — register, query, and auto-detect chip architectures at runtime
`yirage.hardware.ChipArchitecture`	Unified dataclass for chip specs (memory, compute, features)
`yirage.hardware.HardwareRegistry`	Thread-safe singleton with register/query/import/export
`yirage.hardware.detect_current_chip()`	Auto-detect NVIDIA/AMD/Ascend/MetaX/Apple hardware

Hardware-Specific Guides

Platform	Guide	Description
Huawei Ascend NPU	Installation Guide	Complete setup, build, and test instructions
Huawei Ascend NPU	Quick Start	Quick API usage examples
MetaX MACA GPU	Quick Start	MetaX GPU integration 🆕

Contributing - Contribution guidelines

🎓 Examples

Run Benchmarks

# MPS backend (Apple Silicon)
python benchmark/baselines/pytorch/gated_mlp.py -b 8 --backend mps

# CUDA backend (NVIDIA GPU)
python benchmark/baselines/pytorch/gated_mlp.py -b 8 --backend cuda

# CPU backend
python benchmark/baselines/pytorch/gated_mlp.py -b 8 --backend cpu

# Ascend backend (Huawei NPU) - requires CANN + torch_npu
python benchmark/baselines/pytorch/gated_mlp.py -b 8 --backend ascend

# MACA backend (MetaX GPU) - requires MACA SDK
python benchmark/baselines/pytorch/gated_mlp.py -b 8 --backend maca

Backend Selection

import yirage as yr

# Method 1: Direct specification
mpk = yr.PersistentKernel(
    backend="cpu",
    mode="decode",
    world_size=1,
    mpi_rank=0,
)

# Method 2: With fallback
mpk = yr.PersistentKernel(
    backend="cuda",
    fallback_backends=["mps", "cpu"],  # Auto fallback
    mode="decode",
    world_size=1,
    mpi_rank=0,
)

# Method 3: Query and select
backends = yr.get_available_backends()
best_backend = backends[0]  # Use first available

🏆 Submit Your First Kernel

YiRage lets you validate optimization results quickly and then submit kernels to the gpu-mode leaderboard via popcorn-cli for community benchmarking on real hardware (A100, H100, etc.).

Quick Validation Workflow

# 1. Validate your kernel locally (no GPU required)
python examples/submission.py --validate

# Expected output:
# ✅  NumPy kernel: shape=(256, 256), dtype=uint8
# ⏱   NumPy throughput: 0.312 ms/frame  (0.21 Gpix/s)
# ✅  Torch kernel: shape=(4, 1, 256, 256), device=cpu
# ⏱   Torch throughput: 1.234 ms/batch
# ✅  All validation steps completed.

Submit to Leaderboard (4 steps)

1. Install popcorn-cli

curl -fsSL https://raw.githubusercontent.com/gpu-mode/popcorn-cli/main/install.sh | bash

2. Register your account

popcorn-cli register discord

3. Set up your project

# Configure your project with a working example and optional agent skills
popcorn-cli setup

4. Submit your kernel

# Submit the included grayscale example to the grayscale_v2 leaderboard on an A100
popcorn-cli submit --gpu A100 --leaderboard grayscale_v2 --mode leaderboard examples/submission.py

Tip: Replace examples/submission.py with any file that exports a solution(input_tensor) function.
See the popcorn-cli repo for the full list of available leaderboards and GPUs.

Writing Your Own Submission

A valid submission.py must export a solution function with the leaderboard's expected signature:

import torch

def solution(input_tensor: torch.Tensor) -> torch.Tensor:
    """Your optimized kernel implementation."""
    # Example: YiRage-optimized grayscale conversion
    coeffs = torch.tensor([0.299, 0.587, 0.114], device=input_tensor.device)
    return (input_tensor * coeffs[None, :, None, None]).sum(dim=1, keepdim=True)

For a complete example with local validation, benchmarking, and YiRage superoptimizer integration, see examples/submission.py.

🤝 Contributing

We welcome contributions! Please see CONTRIBUTING.md for guidelines.

Adding a New Backend

Implement BackendInterface
Create {Backend}KernelConfig
Implement {Backend}Optimizer
Create {Backend}SearchStrategy (optional)
Update CMake configuration

See Ascend Implementation Guide for a complete example.

📄 License

YiRage is licensed under the Apache License 2.0.

Copyright:

See LICENSE and NOTICE for details.

📚 Citation

@software{yirage2025,
  title={YiRage: Yield Revolutionary AGile Engine for Multi-Backend LLM Inference},
  author={Chen, Xingqiang},
  year={2025},
  note={Multi-backend extension for LLM inference optimization},
  url={https://github.com/chenxingqiang/YiRage}
}

🙏 Acknowledgments

YiRage acknowledges CMU Mirage and the broader open-source systems and compiler communities whose work makes multi-backend optimization possible. Comprehensive third-party attribution details are maintained in NOTICE.

📞 Contact

Issues: GitHub Issues
Author: Chen Xingqiang
Email: joy6677@outlook.com

YiRage - Yielding Maximum Performance Across All Hardware 🚀
