Workflow Escrow Refund Protocol

Automate escrow-backed freelance agreements with AI-powered work validation using USDC on Arc testnet. This sample application uses Next.js, Supabase, Circle Developer Controlled Wallets, and OpenAI to demonstrate an end-to-end escrow workflow — from contract creation and deposit, through AI-validated deliverable submission, to fund release or refund.

Table of Contents

• Prerequisites
• Getting Started
• How It Works
• Environment Variables
• User Accounts

Prerequisites

• Node.js v22+ — Install via nvm
• Supabase CLI — Install via npm install -g supabase or see Supabase CLI docs
• Docker Desktop (only if using the local Supabase path) — Install Docker Desktop
• ngrok — For local webhook testing
• Circle Developer Controlled Wallets API key and Entity Secret
• OpenAI API key — Used for AI-powered work validation

Getting Started

1. Clone the repository and install dependencies:

   git clone git@github.com:akelani-circle/workflow-escrow-refund-protocol.git
   cd workflow-escrow-refund-protocol
   npm install

2. Set up environment variables:

   cp .env.example .env.local

   Then edit .env.local and fill in all required values (see Environment Variables section below). Leave NEXT_PUBLIC_AGENT_WALLET_ID, NEXT_PUBLIC_AGENT_WALLET_ADDRESS, and CIRCLE_BLOCKCHAIN blank — they will be auto-generated in the next step.

3. Generate the agent wallet:

   npm run generate-wallet

   This creates a Circle developer-controlled wallet and writes the wallet ID, address, and blockchain values into your .env.local.

4. Set up the database — Choose one of the two paths below:

   Path 1: Local Supabase (Docker)

   Requires Docker Desktop installed and running.

   npx supabase start
   npx supabase migration up

   The output of npx supabase start will display the Supabase URL and API keys needed for your .env.local.

   Path 2: Remote Supabase (Cloud)

   Requires a Supabase account and project.

   npx supabase link --project-ref <your-project-ref>
   npx supabase db push

   Retrieve your project URL and API keys from the Supabase dashboard under Settings → API.

5. Start the development server:

   npm run dev

   The app will be available at http://localhost:3000.

6. Set up Circle Webhooks (for local development):

   In a separate terminal, expose your local server:

   ngrok http 3000

   Copy the HTTPS URL from ngrok and configure a webhook in the Circle Console:

   • Navigate to Circle Console → Webhooks
   • Add a new webhook endpoint: https://your-ngrok-url.ngrok.io/api/webhooks/circle
   • Keep ngrok running while developing to receive webhook events

How It Works

• Built with Next.js and Supabase
• Uses Circle Developer Controlled Wallets for USDC escrow transactions on Arc testnet
• Smart contracts (EIP-712 Refund Protocol) deployed and managed via @circle-fin/smart-contract-platform
• OpenAI validates submitted work deliverables against agreement criteria using vision models
• Webhook signature verification ensures secure transaction notifications
• Agent wallet automatically initialized via the generate-wallet script
• Real-time UI updates powered by Supabase Realtime subscriptions

Environment Variables

Copy .env.example to .env.local and fill in the required values:

# Deployment URL
VERCEL_URL=http://localhost:3000
NEXT_PUBLIC_VERCEL_URL=http://localhost:3000

# Supabase
NEXT_PUBLIC_SUPABASE_URL=
NEXT_PUBLIC_SUPABASE_ANON_KEY=

# USDC Smart Contract
NEXT_PUBLIC_USDC_CONTRACT_ADDRESS=

# Agent Wallet (auto-generated by npm run generate-wallet)
NEXT_PUBLIC_AGENT_WALLET_ID=
NEXT_PUBLIC_AGENT_WALLET_ADDRESS=

# Circle
CIRCLE_API_KEY=
CIRCLE_ENTITY_SECRET=
CIRCLE_BLOCKCHAIN=

# OpenAI
OPENAI_API_KEY=

User Accounts

Default Account

On first visit, sign up with any email and password. The first user created can act as both a depositor (client) and a beneficiary (freelancer) across different agreements.

Signup Rate Limits

Supabase limits email signups to 2 per hour by default (unless custom SMTP is configured). If you hit an "email rate limit exceeded" error during testing:

• Local Supabase (Docker): Email verification is handled by the built-in Inbucket mail server — check it to confirm signups. The rate limit can be adjusted in supabase/config.toml under [auth.rate_limit].
• Remote Supabase (Cloud): Use real email addresses (disposable emails may fail verification). If you hit the limit, you can manually add users via the Supabase dashboard under Authentication → Users.

Security & Usage Model

This sample application:

• Assumes testnet usage only
• Handles secrets via environment variables
• Verifies webhook signatures for security
• Is not intended for production use without modification
