openlore

[!NOTE] spec-gen has been renamed to OpenLore. The npm package is now openlore and the CLI command is openlore. Existing projects: rename your .spec-gen/ directory to .openlore/ and reinstall (npm i -g openlore). See docs/RENAME-TO-OPENLORE.md for the full migration checklist.

Persistent architectural memory and structural cognition for AI coding agents.

openlore turns any evolving codebase into a navigable knowledge graph backed by OpenSpec living specifications. It maintains persistent architectural context across agent sessions: graph structure, specs, decisions, drift state, and semantic retrieval — so agents start each task already oriented instead of re-discovering the system from file reads.

Why It Exists

AI agents are powerful but amnesiac. On every new task:

• They re-read the same source files to understand structure
• They forget architectural decisions made two sessions ago
• They have no link between specs and code — drift is invisible
• File-by-file navigation often burns 15,000–50,000 tokens per orientation pass, before a single line of useful code is written

openlore closes this loop. Run a full analysis once, then keep the graph incrementally updated as the codebase evolves. Even greenfield projects become cognitively "brownfield" after only a few agent sessions — architectural context fragments, decisions disappear, and agents repeatedly reconstruct the same understanding from scratch.

openlore persists that context continuously: structure, specs, decisions, drift state, and graph relationships remain queryable across sessions.

How It Works

Three layers, each usable independently:

You can use layer 1 alone to give agents structural context. Add layer 2 for semantic intent and architectural governance through OpenSpec-compatible living specifications. Layer 3 keeps that context continuously accessible through graph-native MCP tools once openlore mcp is running.

openlore vs. Alternatives

Traditional coding agents reconstruct architecture from repeated file reads every session. openlore persists it as a queryable graph.

5-Minute Quickstart

Minimum to see value — no API key needed:

npm install -g openlore
cd /path/to/your-project

openlore analyze          # build call graph, clusters, CODEBASE.md
openlore mcp              # start MCP server

Then ask your agent: orient("add a new payment method")

That single call returns the relevant functions, their call neighbours, matching spec sections, and insertion-point candidates — preserving architectural continuity across sessions instead of forcing the agent to repeatedly reconstruct context from raw file reads. In practice, this often reduces orientation cost from ~30,000 exploratory tokens to ~1,000 targeted tokens.

Full pipeline (specs + decisions — optional and additive):

openlore generate         # generate living specs (requires API key)
openlore drift            # detect spec/code drift
openlore decisions        # manage architectural decisions

git clone https://github.com/clay-good/openlore
cd openlore
npm install && npm run build && npm link

nix run github:clay-good/openlore -- analyze
nix shell github:clay-good/openlore

environment.systemPackages = [ openlore.packages.x86_64-linux.default ];

See It In Action

{
  "functions": [
    {
      "name": "processPayment",
      "file": "src/payments/processor.ts",
      "risk": "medium",
      "fanIn": 4,
      "callers": ["handleCheckout", "retryFailedCharge"],
      "callType": "direct"
    },
    {
      "name": "validateCard",
      "file": "src/payments/validator.ts",
      "risk": "low",
      "fanIn": 1,
      "testedBy": [{ "name": "validateCard.test.ts", "confidence": "called" }]
    }
  ],
  "specDomains": ["payments — §CardValidation, §PaymentFlow"],
  "insertionPoints": [
    "src/payments/processor.ts:87 — after existing charge logic"
  ],
  "callPath": "POST /charge → handleCheckout → processPayment → validateCard → stripeClient.charge"
}

Core Features

Analyze (no API key)

Continuously maintains a structural representation of your codebase using pure static analysis. Builds a full call graph persisted to SQLite, runs label-propagation community detection to cluster tightly coupled functions, computes McCabe cyclomatic complexity for every function, and extracts DB schemas, HTTP routes, UI components, middleware chains, and environment variables. Outputs .openlore/analysis/CODEBASE.md — a ~600-token structural digest that compresses the equivalent of tens of thousands of exploratory tokens into a small, queryable summary.

With --watch-auto, the call graph updates incrementally on every file save: changed file and its direct callers are re-parsed and the graph is atomically swapped. Orient and BFS queries remain live between full analyze runs.

Generate (API key required)

Sends the analysis to an LLM in 6 structured stages: project survey → entity extraction → service analysis → API extraction → architecture synthesis → ADR enrichment. Produces openspec/specs/ living specifications in RFC 2119 format with Given/When/Then scenarios.

Drift (no API key)

Compares git changes against spec mappings in milliseconds. Detects: Gap (code changed, spec not updated), Uncovered (new file, no spec), Stale (spec references deleted files), ADR gap (code changed in an ADR-referenced domain). Installs as a pre-commit hook.

MCP (no API key)

45 graph-native tools exposed over stdio. Together they act as a persistent architectural runtime for coding agents: orientation, graph traversal, semantic retrieval, drift awareness, decision context, and structural risk analysis. orient() is the main entry point — one call replaces 10+ file reads. detect_changes risk-scores changed functions using call graph centrality × change type multiplier. See docs/mcp-tools.md.

orient() runs in ~430µs p50 against a 15k-node codebase (TypeScript compiler, ~79k edges). Full benchmark results: scripts/BENCHMARKS.md.

Decisions (API key for consolidation)

Agents call record_decision before writing code. Consolidation runs immediately in the background. At commit time, a pre-commit hook gates the commit until all verified decisions are reviewed and written back as requirements in spec.md files. Decisions are classified by scope (local / component / cross-domain / system); only cross-domain and system decisions produce ADR files, keeping the decision log signal-dense.

Architecture

OpenSpec provides semantic intent and workflow structure. openlore maintains the evolving implementation as a continuously queryable architectural graph for agents.

Codebase
   │
   ▼
openlore analyze ──► SQLite graph store (.openlore/analysis/call-graph.db)
                          │                      │
                          │              MCP tools (orient, BFS, search…)
                          │                      │
                     Artifact Generator        Agent
                          │
                    ┌─────┴──────┐
                    ▼            ▼
              CODEBASE.md   (optional)
                         openlore generate ──► openspec/specs/*.md
                         openlore drift   ──► drift report
                         openlore decisions ► ADR gates

The graph and the OpenSpec spec layer are co-equal: the graph makes orientation fast, the specs make it semantically grounded. Drift detection and decision gates connect both. See docs/ARCHITECTURE.md for the full pipeline diagram.

Documentation

Known Limitations

• Incremental call graph updates are depth-1 only: --watch-auto re-indexes signatures and edges on save for the changed file and its direct callers. Transitive callers (A→B→C, C changes, A stays stale) are only refreshed by the next analyze --force. For hub files with 100+ callerFiles, re-parse may take several seconds.
• Static analysis only: dynamic dispatch, runtime metaprogramming, and eval-based patterns are not captured in the call graph.
• LLM spec quality varies: generated specs reflect the model's understanding. Review sections covering complex business logic before treating them as authoritative.
• Embedding is optional: without an embedding endpoint, orient and search_code fall back to BM25 keyword search (still useful, less accurate for semantic queries).
• Large monorepos: openlore analyze on large codebases may take several minutes. Graph storage itself has no practical limit — the pipeline (AST parsing, symbol extraction) is the bottleneck.
• node:sqlite experimental warning on Node 22: Node.js 22 prints ExperimentalWarning: SQLite is an experimental feature to stderr. The warning is gone on Node 24+. Suppress on Node 22 with NODE_NO_WARNINGS=1 openlore analyze.

Requirements

• Node.js 22.5+
• API key for generate, verify, and drift --use-llm:

  export ANTHROPIC_API_KEY=sk-ant-...    # default provider
  export OPENAI_API_KEY=sk-...           # OpenAI
  export GEMINI_API_KEY=...              # Google Gemini

  Or use a CLI-based provider (claude-code, gemini-cli, mistral-vibe, cursor-agent) — no API key, just the CLI on your PATH.
• analyze, drift, mcp, and init require no API key

Languages supported: TypeScript · JavaScript · Python · Go · Rust · Ruby · Java · C++ · Swift

Development

npm install
npm run build
npm test          # 2660+ unit tests
npm run typecheck
