Stylized Components

A growing collection of real-time, anime-inspired rendering systems for the web, built with Next.js, Three.js and React Three Fiber. Each one is a self-contained, reusable component written in custom GLSL — drop it into your own scene and drive it from Leva. No baked textures, no black boxes.

The index page (/) lists the demos.

📽 Demos

🌊 Water — Anime Style

https://github.com/user-attachments/assets/ed8cb44d-d290-493c-b0d2-8f48d6580571

🌿 Stylized Grass

https://github.com/user-attachments/assets/57236730-37cc-46cb-bc11-69474fad6fd1

Both clips live in the repo under public/assets/demos — the same footage the landing page plays behind its cards.

🌊 WaterFloor System

The core of this project is the WaterFloor component — a modular, layered water rendering system composed of several independent passes that work together to produce the final anime water look.

Architecture

src/components/waterFloor/
├── index.tsx                        # Main water surface (Voronoi cel-shading + ripple rings)
├── useWaterRipple.ts                # Hook — attach to any object to emit water ripples
├── shaders/                         # WaterFloor GLSL shaders
├── utils/controls.ts                # Leva GUI controls
├── stores/
│   ├── rippleStore.ts               # Singleton — ripple event bus between components
│   └── dragonBallsStore.ts          # Singleton — shared transform state
├── models/
│   ├── DragonBalls/                 # Glass sphere model with custom water-line shader
│   └── Feather/                     # Feather model with bobbing animation + ripples
└── components/
    ├── SeabedFloor/                 # Animated Voronoi seabed (parallax depth layer)
    ├── ShadowCatcher/               # Receives shadows on the seabed plane
    ├── WaterSparkles/               # Procedural 4-pointed star particles on the surface
    ├── WaterDepthIntersection/      # Screen-space depth intersection glow
    └── WaterWaveSimulation/         # PDE-based ping-pong wave simulation

Rendering Passes

1. Seabed Floor (SeabedFloor)

An animated Voronoi pattern rendered below the water surface, visible through the transparent deep-color areas of the water. Slower cell movement than the surface creates a parallax depth illusion.

2. Water Surface (WaterFloor)

Cel-shaded water using a Voronoi F1 − SmoothF1 subtraction, replicating the Blender node graph approach in GLSL. World-space XZ coordinates keep the pattern anchored regardless of camera movement.

Features:

• 3-stop color ramp (deep → mid → highlight)
• Animated cell positions with noise-based UV distortion
• Hard-edged anime ripple rings driven by rippleStore
• Distance fade for infinite-floor look

3. Water Depth Intersection (WaterDepthIntersection)

Screen-space depth comparison technique. The DragonBalls geometry is rendered into a depth-only render target each frame. A fullscreen plane at the water surface compares its own depth against the scene depth to detect geometry crossing the water plane, drawing:

• A sharp white silhouette line at the exact intersection
• A soft blue halo glow around it

DPR-aware: uses physical pixel dimensions so the effect stays aligned at any device pixel ratio.

4. Wave Simulation (WaterWaveSimulation)

A three-pass GPU wave simulation per frame:

1. Injection pass — top-down orthographic render of the DragonBalls geometry clipped to a thin band around the water surface. Produces the exact waterline shape in simulation UV space.
2. Wave update pass (ping-pong) — runs the 2D wave PDE each frame: h_next = 2·h_cur − h_prev + c²·∇²h Absorbing boundaries prevent edge reflections.
3. Display pass — computes gradient magnitude of the height map; high gradient = ring edge, rendered as an additive overlay.

5. Water Sparkles (WaterSparkles)

GPU particle system using gl_PointCoord to draw procedural 4-pointed star shapes — no textures required. Each particle fades in/out over its lifetime using a sine curve.

6. Ripple System (useWaterRipple)

A composable hook that can be attached to any R3F object. Emits ripple events to rippleStore when the object enters the water (entry splash) and periodically while submerged. The water surface shader reads these events and renders concentric anime-style rings.

🌿 GrassField System

The /grass route showcases GrassField — a stylized grass system that takes a GLB and turns it into a wind-animated field. It rewires the model by mesh/material name, so using your own model means passing names, not editing code.

import GrassField from "@/components/grassField";

<Canvas shadows={{ type: PCFSoftShadowMap }}>
  <directionalLight castShadow position={[-9, 4, -0.5]} />
  <GrassField />
</Canvas>

Architecture

src/components/grassField/
├── index.tsx              # Loads the GLB, rewires it, syncs uniforms each frame
├── uniforms.ts            # Every uniform in the field, in a single shared bag
├── presets.ts             # Named looks (Spring, Autumn…) — pushed into the Leva panel
├── shaders/               # Raw GLSL, injected via onBeforeCompile
│   ├── groundMask.ts      # Procedural dirt mask — the shared source of truth
│   ├── grassBlade.ts      # Wind, dirt shortening, rock trampling, soft shadow
│   ├── flower.ts          # Wind + palette lookup + dirt culling
│   └── debug.ts           # Breakdown "Debug View" — paints intermediate values
├── materials/             # One factory per material
│   ├── bladeMaterial.ts   # Blades (Lambert + injected GLSL)
│   ├── groundMaterial.ts  # Ground: grass tint, dirt patches, fake relief
│   ├── flowerMaterial.ts  # Flowers + their custom depth material for shadows
│   ├── pineLeafMaterial.ts# Repaints foliage RGB, keeps the texture's alpha
│   └── barkMaterial.ts    # Bark color + AO + height, tint-able
├── utils/
│   ├── scatter.ts         # Area-weighted placement of blades and flowers
│   └── controls.ts        # Leva panels
└── debug/                 # Breakdown visualisers — off by default, deletable
    ├── GrassBreakdown.tsx # Wires the visualisers + their Leva toggles
    ├── DebugScatter.tsx   # How blades are placed (area-weighted sampling)
    ├── DebugBlade.tsx     # A single blade, blown up
    ├── DebugMaskPlane.tsx # The dirt mask as grayscale
    └── DebugWind.tsx      # The wind field, painted on the ground

Features

Instanced blades & flowers

Both are scattered by area-weighted sampling of the ground mesh's triangles: pick a triangle proportional to its area, then a uniform point inside it. Every instance lands on the surface, so density means exactly what it says — instances per world unit². Placement is seeded, so the field is identical on every reload.

Flowers are cross-billboards (two quads 90° apart) with the petal shape cut out of an alpha mask.

Ground colormap blending

A procedural dirt mask in world XZ, sampled by the ground, the blades and the flowers through the very same groundDirt() function. That shared source of truth is the whole trick: the ground paints the earth, the blades standing on it shrink and take its color, and the flowers are culled from it — so the grass thins out into bare earth instead of ending at a hard line.

Rock trampling

Rocks are handed to the blade shader as world-space spheres. Blades inside one are pressed flat and splayed outward — bending on top of flattening is what makes it read as trampled rather than merely mown.

Translucency (subsurface back-light)

An additive back-scatter lobe: blades glow when the camera looks into the sun through them, strongest at the thin tips and on blades edge-on to the light. Shadowed blades transmit nothing, so the glow never leaks into shadow.

Per-blade shadows

Three resolves shadows per fragment, which leaves a blade half-lit wherever a shadow edge crosses it — drawing a hard straight line across the field. The blade shader instead resolves one shadow sample per blade, so each blade is entirely in or out of shadow and the shadow's edge becomes the grass's own jagged silhouette.

Shadow-casting flowers

A flower is a quad with its shape cut out by a mask, and Three's shadow pass knows nothing about that mask or about the wind. Without a customDepthMaterial each flower would cast the shadow of a static rectangle; the depth material repeats both the discard and the wind, so the shadow has a flower's shape and sways with it.

Season presets

Named looks (Spring, Autumn, …) live in presets.ts and are switchable from the overlay. A preset names only the values it changes and pushes them into the Leva panel, so it's a starting point, not a lock — everything stays editable afterwards.

Sky presets

The scene ships with a SkyDome (procedural gradient, sun/moon, FBM clouds, stars, aurora). Switching Sky Mode drives the scene's lighting and a full-screen color filter, so the whole field takes on the mood of the selected sky.

🛠 Tech Stack

🚀 Getting Started

# Clone the repository
git clone https://github.com/cortiz2894/stylized-components.git

cd stylized-components

pnpm install

pnpm dev

• http://localhost:3000 — the demo index
• http://localhost:3000/water — the water scene
• http://localhost:3000/grass — the grass scene

Each scene exposes its full parameter set through Leva (toggle the panel with the sliders button, bottom right).

📄 License

Released under the MIT License — free to use, modify and ship, in personal or commercial projects.

The only ask: keep the attribution. If you use these components (or build on them), a credit to Christian Ortiz (Cortiz) with a link back to this repo is required by the license and genuinely appreciated. A shout-out on socials is always welcome too. 🌿
