⬡ void

Void — grid-first terminal · Ghostty hard fork · N×M tiling as a core surface · beta: grid mode only

grid-mode · tiling-surface · terminal · pty · tool-call-stream · perf-first · zig · swift · gtk · metal · opengl

Void is a hard fork of Ghostty where an N×M pane grid is a first-class rendering surface — not a window-manager bolt-on, not a tmux-style multiplexer process. When cell count N changes the layout auto-rebalances (cols = ⌈√N⌉, rows = ⌈N/cols⌉, cols ≥ rows), each cell carries its own cwd/env, and input can broadcast to all cells. It inherits Ghostty's engine (SIMD parser, Metal/OpenGL, per-terminal threads) unchanged. Zig shared core, native Swift on macOS, GTK on Linux.

Beta status — grid mode is the only implemented direction. Two further directions are planned, not yet built: a structured agent I/O channel alongside PTY (roadmap P3) and a per-PR perf budget vs the Ghostty baseline (roadmap P4). They are described below as roadmap, not as shipped features.

[!NOTE] Part of the dancinlab n = 6 family — hexagonal icon, sibling to NEXUS, Anima, N6, and HEXA-LANG. Void is a UX divergence from Ghostty, not a drop-in replacement; upstream syncs are selective cherry-picks only and full Ghostty history/credit is preserved.

At a glance

   spawn a pane with cmd+ctrl+1..9 — the grid auto-rebalances

   N = 2          N = 4               N = 6                  N = 9
   ┌────┬────┐    ┌────┬────┐         ┌───┬───┬───┐          ┌───┬───┬───┐
   │ 1  │ 2  │    │ 1  │ 2  │         │ 1 │ 2 │ 3 │          │ 1 │ 2 │ 3 │
   │~/p │~/w │    ├────┼────┤         ├───┼───┼───┤          ├───┼───┼───┤
   └────┴────┘    │ 3  │ 4  │         │ 4 │ 5 │ 6 │          │ 4 │ 5 │ 6 │
                  │~/l │~/r │         │~/r│~/s│~/t│          ├───┼───┼───┤
   2 × 1          └────┴────┘         └───┴───┴───┘          │ 7 │ 8 │ 9 │
                  2 × 2               3 × 2                  └───┴───┴───┘
                                                             3 × 3

   cols = ⌈√N⌉   rows = ⌈N/cols⌉   cols ≥ rows   ·   per-cell cwd   ·   no manual resize handles   ·   no tmux

void                   # launch terminal
cmd+g                  # toggle grid mode <-> tab mode
cmd+ctrl+1..9          # spawn a tab in grid slot 1..9 (auto-rebalances)
cmd+ctrl+shift+1..9    # cycle tabs within a grid slot
cmd+ctrl+0             # broadcast input to all cells

Why void

Three things upstream Ghostty treats as explicit non-goals — Void forks to take exactly these bets.

1. Grid mode — a first-class tiling surface

   cells = N                              on add / remove the whole grid
   ──────────────────────────────         re-balances to equal splits:
   N = 2  →  2 × 1                        cols = ⌈√N⌉
   N = 4  →  2 × 2                        rows = ⌈N/cols⌉
   N = 6  →  3 × 2                        cols ≥ rows (wider before taller)
   N = 9  →  3 × 3                        (no manual resize handles)

The N×M grid is a new renderer path, not a patch on the single-surface renderer and not a multiplexer process. Per-cell cwd / env, shared input routing, broadcast. No tmux, no prefix key, no config DSL to learn. This is the headline — the other two directions sit on top of it.

2. Ghostty hard fork — performance inherited, not rebuilt

Void did not rebuild a terminal. It hard-forks a fast one and changes three things. The SIMD parser, Metal (macOS) / OpenGL (Linux) renderers, and per-terminal render/read/write threads come straight from Ghostty. 4698 files were renamed Ghostty → Void at commit 964c9e32e; upstream history and contributor credit are preserved (cherry-pick only, no clean merges).

3. AI-native I/O and a perf budget (roadmap — not yet implemented)

   shell process     ┌──── PTY ────────▶  traditional byte stream
        │            │
        ▼            ├──── AGENT ──────▶  structured tool-call events
   libvoid layer ────┤                    token stream w/ boundaries
        ▲            └──── META ───────▶  cwd, exit-code, span marks
        │
   agent process      (no wrapper process required)

Neither of these is built yet — the beta is grid-only. The plan: a structured agent channel alongside PTY (tool-call events and token-stream boundaries as a data model, not heuristic-parsed from stdout) — roadmap P3, deliberately not the headline since Void is grid-first, not an "AI overlay" terminal. And a perf budget where every PR reports a delta against the Ghostty baseline with a ≥ 2 % regression blocking merge — roadmap P4, the harness is not wired yet. Both are described here as intent, not as shipped behaviour.

Highlights

Architecture

       ┌──────────────────────────────────────────┐
       │            macOS App (Swift)             │
       │    SwiftUI · AppIntents · CoreText       │
       │        Metal renderer · native menu      │
       └──────────────┬───────────────────────────┘
                      │
       ┌──────────────▼───────────────────────────┐
       │          libvoid (Zig) — core            │
       │   parser · terminal state · renderer     │
       │   grid engine   (agent I/O: roadmap)     │
       └──────────────┬───────────────────────────┘
                      │
       ┌──────────────▼───────────────────────────┐
       │            Linux App (GTK)               │
       │      systemd · OpenGL · FreeType         │
       └──────────────────────────────────────────┘

Zig-based shared core with platform-native shells. Core is C-ABI-compatible so it can be embedded in third-party projects (Ghostty's libghostty pattern — renamed to libvoid in this fork).

Install

# 1. Install hexa-lang (gives you `hexa` + `hx` package manager)
/bin/bash -c "$(curl -fsSL https://raw.githubusercontent.com/dancinlab/hexa-lang/main/install.sh)"

# 2. Install void
hx install void

Or build from source — see HACKING.md. Default branch on the fork is void/main, not main.

Run

void                   # launch terminal
void +show-config      # print active config
void +list-keybinds    # list keybindings
void +crash-report     # list crash reports

Keybindings (default)

All keys are rebindable via config — nothing is hardcoded.

Fork status

See VOID_FORK.md for the full fork rationale, non-goals, and upstream policy.

Roadmap

Checkpoints (done):

Phases:

P1 (grid mode) is complete: surface rendering, N×M auto-layout (cols = ⌈√N⌉), cmd+ctrl+1..9 slot-spawn, broadcast, and per-cell cwd all landed. P4 (perf baseline) is next — capturing the Ghostty-baseline benches before further divergence accumulates.

Non-goals

• Not a drop-in Ghostty replacement — Void will diverge in UX.
• Not a shell — Void drives shells, it does not replace them.
• Not an "AI terminal" — grid mode is the headline and the only thing built; agent I/O is an unimplemented roadmap direction, never an overlay.

Crash reports

Void inherits Ghostty's crash reporter. Reports are saved to $XDG_STATE_HOME/void/crash (default ~/.local/state/void/crash) and are not sent off your machine. Use void +crash-report to list. Reports use the Sentry envelope format with extension .voidcrash.

[!WARNING] Crash reports contain full stack memory per thread at the time of the crash and can include sensitive data.

Session restore — survive abnormal termination

When void or macOS dies abnormally, void re-opens with the previous terminal contents (scrollback, colors, cursor) restored — not just the window layout. The mechanism is fork-only (no upstream Ghostty equivalent); see docs/design/sighup-resistant-session.md for the full design.

Two failure modes, one experience

How it works

       ┌──────────────────────────────────────────┐
       │  macOS NSWindowRestoration (existing)    │  ← grid topology + per-surface UUID
       │  TerminalRestorable.swift                │    survive force-quit / crash
       └──────────────┬───────────────────────────┘
                      │  uuid round-trips via Codable
       ┌──────────────▼───────────────────────────┐
       │  PersistRing (mmap, 4 MB / pane)         │  ← raw PTY byte stream → disk
       │  ~/.void/sessions/by-uuid/<uuid>.ring    │    memcpy + msync(MS_ASYNC) every 1s
       └──────────────┬───────────────────────────┘
                      │  on relaunch
       ┌──────────────▼───────────────────────────┐
       │  Termio.init replay → processOutput      │  ← bytes (ANSI + colors + cursor)
       │  BEFORE io read thread starts            │    fed back through SIMD parser
       └──────────────────────────────────────────┘

• Write side — Termio.processOutput appends every PTY byte to an mmap'd ring (memcpy, ~0µs, lock-free per pane). msync(MS_ASYNC) fires every 1s → kernel page cache + dirty-page flush bound Scenario B loss to ≤ 1 second. Scenario A loses nothing because mmap MAP_SHARED page cache survives process death.
• Read side — at surface init, if a ring exists at the UUID-keyed path, PersistRing.replay() extracts up to 4 MB of most-recent bytes, and Termio.processOutputLocked feeds them through the parser before the io read thread spawns. The new shell still starts fresh underneath; the visual scrollback is reconstructed via ANSI replay.

Enable

# void config
window-save-state    = always     # macOS NSWindowRestoration (already documented)
persist-bytes-mmap   = true       # opt-in: enable per-pane ring buffer

What's restored / what isn't

Apple Terminal.app's "Tab Contents v2" mechanism is plain-text-only (no colors); void's ring is raw bytes including ANSI sequences, so attributes round-trip.

Manual recovery

If auto-replay doesn't trigger (e.g. UUID lost, ring schema changed), the byte stream is still on disk:

tool/void-session-replay.sh --list           # enumerate ring files
tool/void-session-replay.sh --latest         # dump most recent ring to stdout
tool/void-session-replay.sh --all            # dump every ring
tool/void-session-replay.sh <path-to-ring>   # dump a specific ring

Pipe to less -R, cat, or save to a file.

Storage layout

~/.void/sessions/by-uuid/
    <uuid>.ring   # 4 MB mmap'd ring buffer per pane
    ...

Ring files are not garbage-collected automatically — rm -rf ~/.void/sessions/by-uuid is safe between sessions when you want to start fresh.

Status

• Beta — grid mode is the only implemented direction. P1 (grid mode + new-tab keybinding) complete (2026-05-18): surface rendering, N×M auto-layout, slot-spawn, broadcast, per-cell cwd
• Inherited from Ghostty (not Void-built): SIMD parser, Metal/OpenGL renderers, per-terminal threads, native Swift/GTK shells, crash reporter
• Void-only support infra (shipped, not a "direction"): session-restore via per-pane mmap byte ring — see Session restore
• Not yet implemented: AI-native I/O (roadmap P3) · perf-budget harness (roadmap P4) — described in this README as intent, not shipped behaviour
• Fork date: 2026-04-21 (from upstream commit c3c8572f7); default branch void/main (not main)
• L3 rename complete — 4698 files renamed Ghostty → Void at commit 964c9e32e
• Next: P4 perf baseline (capture Ghostty-baseline benches), then Show HN / r/commandline launch
• CI: .github/workflows/build-fork.yml on GitHub-hosted macos-15 runners (ad-hoc codesign)

Repo layout

void/
├── README.md
├── AGENTS.md / AGENTS.tape         project ops manual + machine-readable companion
├── VOID_FORK.md                    fork rationale + non-goals + upstream policy
├── HACKING.md / CONTRIBUTING.md    dev + contribution guides
├── LICENSE                         MIT
├── build.zig / build.zig.zon       Zig build entry + manifest
├── src/                            libvoid (Zig core) — parser · terminal state · renderer · grid  (agent I/O: roadmap)
├── macos/                          Swift app (SwiftUI · AppIntents · Metal · CoreText)
├── linux/ + gtk/                   GTK app (systemd · OpenGL · FreeType)
├── pkg/                            vendored package wrappers
├── include/                        C-ABI headers for libvoid embedders
├── images/                         icon + brand assets (hexagon n=6 family)
├── docs/                           reference docs + logo.svg
├── conformance/                    terminal protocol conformance tests
├── bench/                          perf budget harness — roadmap P4 (Δ vs Ghostty baseline)
├── nix/ + flake.nix                Nix build entry
└── .github/workflows/              CI (build-fork.yml on macos-15 runners)

Contributing

• Contributing to Void — CONTRIBUTING.md
• Developing Void — HACKING.md
• Fork rationale & upstream policy — VOID_FORK.md

Credits

Void is a hard fork of Ghostty by Mitchell Hashimoto and the Ghostty team. All Ghostty contributors are credited in upstream history, which is preserved in this repo. Divergent work — grid mode (implemented), plus the planned AI-native I/O and perf-harness directions — is Void-only.

License

MIT — same license as upstream Ghostty. All Ghostty contributors are credited in upstream history (preserved in this repo); divergent work (grid mode implemented; AI-native I/O and perf-harness planned) is Void-only.

_{⬡ Terminal as substrate. Grid as primitive. · Based on Ghostty · dancinlab}
