FluentIcons

A multi-framework control library of fluentui-system-icons. Browse the icons in the online gallery.

Packages

Package	Platform
	meta package
	Avalonia 12
	FluentAvalonia 3 (Avalonia 12)
	MAUI 10
	UWP 10.0.10773 Uno.UI 5.4
	Windows App SDK 1.8.5 Uno.WinUI 6.0
	.NET Framework 4.6.2 .NET 6

Version 2.x

Starting with version 2.0, the underlying fonts have been migrated from TTF to CFF.

Package	Version	Platform
FluentIcons.WinUI	2.1	Windows App SDK 1.6.3 Uno.WinUI 5.4
FluentIcons.Avalonia	2.0	Avalonia 11
FluentIcons.Avalonia.Fluent	2.0	FluentAvalonia 2 (Avalonia 11)
FluentIcons.WinUI	2.0	Windows App SDK 1.6

Version 1.3

Version 1.3 is a backports release for legacy platforms which are no longer supported by version 2.0.

Package	Platform
FluentIcons.Avalonia	Avalonia 0.10
FluentIcons.Avalonia.Fluent	FluentAvalonia 1.3 (Avalonia 0.10)
FluentIcons.Maui	MAUI 8
FluentIcons.Uwp	Uno.UI 5.0
FluentIcons.WinUI	Uno.WinUI 5.0
FluentIcons.WinUI	Windows App SDK 1.2

Usage

<Page xmlns:ic="using:FluentIcons.WinUI">
<!-- or FluentIcons.Avalonia / FluentIcons.Avalonia.Fluent / FluentIcons.Maui / FluentIcons.Wpf -->
    <ic:FluentIcon Icon="ArrowLeft" IconVariant="Regular" IconSize="Size32" />
    <ic:SymbolIcon Symbol="Calendar" IconVariant="Color" />
</Page>

This package features <FluentIcon>/<SymbolIcon> element, and <FluentIconSource>/<SymbolIconSource> on platforms with <IconSource>, which generally provide following properties:

• Icon (for Fluent...) / Symbol (for Symbol...) : Icon / Symbol
• IconVariant : IconVariant
  • New in version 1.1.278: Color variant added along with COLRv1 migration.
• IconSize (for Fluent...) : IconSize
• FlowDirection : FlowDirection
  • Switch between LTR/RTL icon variant.
• FontSize : double
• Foreground : Brush

The Fluent variant provides all sizes of icons untouched compared to upstream, while the Symbol variant mimics the APIs and appearances of SymbolIcon and Segoe Fluent Icons from WinUI, which is powered by a derived version from the child project Seagull Icons.

<Page xmlns:icx="using:FluentIcons.WinUI.Markup">
    <Expander Header="{icx:SymbolIcon Symbol=ArrowLeft}" />
</Page>

Markup extension classes have been added since version 1.1.242. These extensions will bind their FlowDirection to that of the parent control, except FluentIconSourceExtension/SymbolIconSourceExtension on (non-Uno) UWP where IXamlServiceProvider is not available. They are moved to a child namespace since version 1.3.

<Page xmlns:ic="using:FluentIcons.WinUI">
    <ic:FluentIcon Icon="Trophy"
                   IconVariant="Filled"
                   Foreground="Gold"
                   ic:Outline.Foreground="Goldenrod" />
    <ic:SymbolIcon Symbol="InkingToolAccent"
                   IconVariant="Filled"
                   Foreground="Gold"
                   ic:Outline.Symbol="InkingTool"
                   ic:Outline.Foreground="Goldenrod" />
</Page>

The new feature Outline is implemented for experiment since version 2.0.317. The static class include following attached properties which could be applied to FluentIcon or SymbolIcon elements:

• Icon (for FluentIcon) / Symbol (for SymbolIcon) : Icon? / Symbol?
  • Default to null, where the value will be inherited from the host control.
• IconVariant : IconVariant
  • Default to Regular.
• Foreground : Brush

Please note that due to limitations in rendering precision, unexpected color leakage may occur at the edges of the icons. To achieve a good display effect, you may need to avoid using combinations of fill and stroke colors with large hue differences.

MAUI

⚠️ The extension method UseFluentIcons(this MauiAppBuilder builder) must be called to register fonts properly.

<SymbolImageSource> and SymbolImageSourceExtension are provided on MAUI as stand-ins.

All properties of type Brush are defined as Color instead, with the Color suffix added to the name.

UWP / WinUI

The Win2D package is referenced by this library for the “Outline” feature, but with a relatively old version. While this brings you more flexibility, it is still recommended to override with the latest version of the package.

Known issues

Color icons are broken on WPF, because of the lack of COLR rendering support. It also stops working in environments like macOS and WebAssembly when rendering with SkiaSharp 2, possibly affecting Avalonia and Uno.
