bbport — a native Linux port of Bloodborne

English · Русский

bbport is the counterpart of Wine + DXVK for a single game: Bloodborne for PlayStation 4 (CUSA03173, game version 1.09) on an x86-64 Linux PC. The game's original executable runs directly on the PC:

• as in Wine, the game's x86-64 code runs on the CPU directly, and a runtime written for this one game replaces the PS4 system libraries;
• as in DXVK, the game's graphics are translated to Vulkan — by a renderer derived from shadPS4 and heavily extended for this game, including temporal upscaling with AMD FSR 3.1, FSR 4 and FSR 4.1.1;
• memory and the GPU's work are moving to the PC model: the launcher has an experimental New memory and translation model mode (AMD GPUs only); without it the game runs on the old memory model, as in 0.3.

Two steps remain to the full Wine + DXVK model: make the new mode the default, and move the reading of resource descriptors (textures, buffers) from the CPU to the GPU (see below).

No game files are included. You need your own dump of Bloodborne (CUSA03173, v1.09). This project is not affiliated with Sony Interactive Entertainment, FromSoftware or AMD.

Status: experimental, playable. The game boots, loads saves and plays (the Hunter's Dream and several areas of Yharnam were played with it) with sound, gamepad and saving. A full play-through has not been verified, and only one machine (Linux, AMD Radeon RX 7800 XT, Mesa/RADV) has been tested thoroughly.

Highlights

• Native execution. The eboot is converted offline into a flat memory image; PS4 libc and libSceFios2 are linked into it as native code. No CPU emulation and no per-instruction translation: the game code runs at full speed.

• Two modes (launcher → Mode):

  • Switch off (the default) — as in 0.3. The old memory model: VRAM copies of the game's memory, writes tracked through page protection. With every fix made since 0.3 (motion vectors and the upscaler, flicker with DoF on, a damaged shader cache).
  • New memory and translation model — experimental, AMD GPUs only. The game's memory lives in system RAM and the GPU reads it where it is, as a PC game's buffers; data it reads often is kept in VRAM and given back when unused (textures after 20 s, buffers after 60 s). No write tracking, no copies of the whole GPU-visible memory. The PS4 command processor's work is translated into Vulkan commands rather than emulated on the CPU: memory writes (WRITE_DATA, DMA) are done by the GPU in command-stream order, and fences are written once the GPU has really finished the work. Where the game is CPU-bound it runs 20–25% faster (measured standing in the Hunter's Dream), with fewer stutters. It may crash, and has been tested thoroughly only on the author's PC (RX 7800 XT). On NVIDIA and Intel the switch is unavailable: NVIDIA's driver cannot map the game's memory as needed, Intel is untested. Without the launcher: BB_PC_MODEL=1; to try it on another GPU: BB_PC_MODEL_ANY_GPU=1.

  Unused textures are freed in both modes, so VRAM no longer grows with every area visited.

• Unlocked frame rate. Community patches (patches/Bloodborne.xml) make the simulation use the real frame time; ~90 FPS at 4K with FSR 4 Balanced on an RX 7800 XT, ~150 FPS at 1440p with FSR 4 Quality. Also 30/60/90 FPS modes.

• Temporal upscaling built for this game. Bloodborne has no velocity buffer, so bbport computes motion vectors itself: camera motion from depth and the scene matrices, and object motion (characters, cloth, weapons) from the vertex positions of the previous frame. The scene is jittered sub-pixel (Halton) and rendered at a reduced resolution; the upscaler fills the output (720p for the Steam Deck, 1080p, 1440p or 2160p) and the UI is drawn natively at the output resolution.

  • FSR 3.1 (FireBurn/FSR-Vulkan).
  • FSR 4 (INT8, model v07) on GPUs exposing the required Vulkan shader features — RDNA2/3 included (see Requirements).
  • FSR 4.1.1: AMD's 4.1.1 DLL is recorded once under vkd3d-proton and its passes are replayed natively on Vulkan; the output is bit-exact with the DLL. Two variants, as in the DLL: INT8 on any GPU with the required shader features, and FP8 matrices on RDNA4 (RX 9000; picked automatically). The assets are built on your machine from one DLL of your own (4.1.x): the launcher's FSR 4.1.1 from your own AMD DLL → Choose DLL… button (2–5 minutes, twice that on RDNA4; needs a recent Proton), or tools/fsr4cap.
  • Faster than AMD's own shaders on RDNA3: the final passes of FSR 4 and 4.1.1 were rewritten to store through workgroup memory (3.5× and 2.3× faster, bit-exact); FSR 4 costs ~4 ms at 4K on an RX 7800 XT instead of ~6 ms.

• Multi-threaded GPU command processing. The PS4 command stream is decoded on one thread and draws are bound and recorded on another (two-stage pipeline), with a Vulkan recording thread and helper threads for memory copies. Early on the single GPU thread capped the game at ~26 FPS; now it runs at 90–150 FPS depending on resolution and scene.

• In-game menu (Insert or L3+R3): upscaler, preset, sharpness, output resolution, game effects (chromatic aberration, DoF, motion blur, SSAO, the game's own AA, SSR, model LOD). It opens where it was left, with the mouse cursor shown over it.

• GTK4 launcher and an AppImage for the Steam Deck.

How it differs from shadPS4

Without shadPS4 there would be no bbport: its renderer and shader recompiler are the base of the graphics side.

Wine + DXVK for one game

• CPU. The PS4 CPU is x86-64, so the game's code runs directly on the PC's CPU, with no emulation and no instruction translation.
• System libraries. As Wine replaces the Windows API, the bbport runtime (src/runtime_*.c) implements exactly the PS4 OS functions Bloodborne calls: memory, threads, files, audio, pad, saves.
• Memory. In the new mode, as in a PC game: the game's data in system RAM, VRAM used the way a PC game uses it. The mode is still experimental and runs on AMD GPUs only.
• Graphics. The PS4 GPU's command stream (PM4) is a recording of the game's graphics API calls: it is written by 99 functions of the statically linked libGnm, so decoding the stream and translating the calls themselves come to the same thing. GCN shaders are translated to SPIR-V. In the new mode the command processor's work (memory writes, DMA, fences) is translated into Vulkan commands as well. One part still works the old way: the translator reads resource descriptors (textures, buffers) from the game's memory on the CPU, and recognises textures by address. The next big step is the GPU reading the descriptors itself (bindless), with textures as objects created at load time.

"Port" here means a build for this one game, not a rewrite of its source code, which the project neither has nor includes.

Requirements

• Linux x86-64, a Vulkan 1.3 GPU. Tested: AMD RX 7800 XT with Mesa 26 (RADV). The New memory and translation model mode needs an AMD GPU. FSR 4 / 4.1.1 require shader Float16, Int8/Int16, integer dot products, linear compute derivatives and extended storage image formats; FSR 4.1.1 additionally requires VK_VALVE_shader_mixed_float_dot_product. Unsupported choices fall back to FSR 3.1 before the first frame and are disabled in the in-game menu.
• Your decrypted game dump: the CUSA03173 folder (eboot.bin, sce_module, ...), version 1.09. A dumped update is a separate folder: copy it over the base game, replacing files. The base game alone (1.00) crashes at start (guest offset 0x20348b8); the launcher and run.sh check the executable and say what is missing (BB_SKIP_GAME_CHECK=1 skips the check).
• To build: GCC, CMake, Ninja, Python 3, glslang, SDL3, Vulkan headers and the libraries in shell.nix. With Nix everything comes from shell.nix automatically.

Build and run

git clone --recursive https://github.com/deadinside28/bloodborne_pc.git bbport && cd bbport
bash build.sh                        # builds out/bb-probe and out/gpu/libbbgpu.so
BB_GAME_DIR=/path/to/CUSA03173 bash run.sh

or the launcher (pick the game folder, settings, Start):

bash launcher/bb-launcher.sh         # launcher/install-desktop.sh adds it to the app menu

By default the game folder is expected next to the repository (../CUSA03173). Saves and the shader cache go to user/ (the launcher lets you choose another folder); settings to bbport.ini. A gamepad is used through SDL3 (the launcher's Controls → Controller picks one when several are connected; BB_GAMEPAD=<GUID or part of the name>). The keyboard works too, also next to a connected gamepad (the Steam Deck always has one); both are remapped in the launcher (Controls). The character name is typed on the keyboard in a box over the game. The touchpad: its left half (Tab, Back/Select) opens the gestures, the right half (Backspace) the key items.

Resolution and preset changes: for outputs other than 1080p (720p on the Steam Deck, 1440p, 4K) the whole game renders at the preset's resolution, set by a patch at start — the fastest path. Changing the output or the preset in the in-game menu then needs Apply and restart the game. The Live resolution changes setting (launcher, in-game menu, bbport.ini live_resolution=0|1|auto; off by default) instead keeps the game at 1080p internally and scales its render targets at run time, so 720p/1080p/1440p/4K and the presets switch without a restart. It costs more: the game then believes it renders 1080p and draws more (e.g. ~8× more small lights), and some targets are copied between sizes — use it on strong desktop GPUs only (auto turns it on for discrete GPUs with 8+ GB that are not pre-Turing NVIDIA). 1080p output and TAA always use the live path.

TAA: a separate native-resolution temporal AA mode in the launcher and overlay, switchable live without an FSR model. The saved FSR preset is restored when returning to FSR. FSR Native AA adds reconstruction on top of full-resolution rendering and can be slower than disabling AA. TAA also adds work compared with no temporal AA. The RCAS switch and the 0–2 sharpness control also work with TAA. Sharpening runs after temporal accumulation and leaves its history and HUD unchanged.

Mods: the launcher accepts separate loose-file mod folders (with dvdroot_ps4/, an extra wrapper folder, or the game folders such as chr/ directly; file name case does not matter), with enable switches and load order. A sibling CUSA03173-mods/ overlay also works. The original game is preserved; later mods override conflicting files. Third-party patches: shadPS4-format XML patch files in the data directory's patches/, switched on and off in the launcher. See mods and patches.

Launcher language: Russian, English or Brazilian Portuguese (follows the system language by default).

Free camera and game debug menu (v1.09): enable the corresponding switches in the launcher or in-game menu and restart. Free camera uses Lance McDonald's GoldHEN patch: hold Cross and press L3 to cycle modes (keyboard: hold Space and press Z). It needs no fonts and conflicts with Enemy Control. For the game debug menu, install DbgFont14h.ccm and DbgFont14h.tpf from Debug Menu and XML Patch into the game's dvdroot_ps4/font/ first. Startup rejects missing or empty font files instead of launching the unsafe patch. Open it with the left touchpad / Tab (with the debug menu on, the left half no longer opens the gestures); Backspace is the right touchpad. Touch coordinates are forwarded from SDL gamepads; Back/Select emulates a left click on pads without a touch surface. The port's settings menu remains Insert / L3+R3.

GPU occlusion queries still use synthetic pixel counters (PixelPipeStatDump), and IT_SET_PREDICATION is unimplemented. Free camera allows visual investigation; it does not implement GPU occlusion culling.

Upscaler assets (not included; FSR 3.1 needs none):

bash tools/fetch_fsr4_assets.sh      # FSR 4 v07 (MIT, built from AMD's source by Q2RTX)
# FSR 4.1.1, from your own AMD DLLs (e.g. OptiScaler's FSR4_LATEST), needs GE-Proton 10 or newer:
bash tools/fsr4cap/build_assets.sh <amd_fidelityfx_upscaler_dx12.dll>

FSR 4.1.1 from your own DLL. The easiest way is the launcher: Upscaler → FSR 4.1.1 from your own AMD DLL → Choose DLL…, then pick amd_fidelityfx_upscaler_dx12.dll version 4.1.x: from OptiScaler's FSR4_LATEST folder or from a game with FSR 4.1. That one file is enough: AMD's DLL exports the FidelityFX API itself, so no loader is needed (only a DLL without these exports would be recorded through amd_fidelityfx_loader_dx12.dll, and the launcher would ask for it). The DLL is checked at once, without a long capture; these do not fit: AMD's official FSR 4.0.x (e.g. Pragmata's 4.0.3 — AMD enables it on RDNA4 only, and under Proton it does not start on other GPUs) and community builds (4.0.2b, 4.1.1b and similar OptiScaler INT8 builds: another model and pass count). Then the DLL runs under Proton and is recorded at 20 sizes (progress in the row and in the Log tab; on RDNA4 a second time, for the FP8 variant), the passes are translated to SPIR-V, and FSR 4.1.1 is selected. The Proton build is picked automatically — the first under which the DLL enables FSR 4.1: GE-Proton 10 or newer, Proton-CachyOS, Proton Experimental (tested: GE-Proton 11, Proton-CachyOS 11, Experimental of October 2026; Steam's Proton 11.0 and GE-Proton 9 do not). It runs in the Steam runtime it requires (Steam installs it the first time any game runs with that Proton), or through umu-launcher when installed. On NixOS umu-launcher comes from nix-shell (downloaded the first time, ~1.7 GB); the AppImage runs the recording on the system itself, through the user's systemd (systemd-run --user), since the system's /nix is out of its sight. Recording on the Steam Deck is not verified yet; if the DLL does not enable FSR 4.1 there, build on a PC and copy the fsr4_411 folder. The same from the command line: the launcher's (and the AppImage's) --build-fsr411 <DLL>.

From source the script takes its tools from the system (MinGW GCC, CMake, Ninja, Python 3, SPIRV-Tools, Git) or from Nix; the AppImage has them prebuilt.

FP8 on RDNA4. When vkd3d-proton offers FP8 cooperative matrices (RDNA4), the DLL runs another variant of its passes: other shaders and weights, other dispatch sizes. The build records both, INT8 into fsr4_411/ and FP8 into fsr4_411/fp8/, and the game picks FP8 itself when the GPU has FP8 matrices (VK_EXT_shader_float8); the log says Upscaler: FSR 4.1.1 replay, FP8 …. BB_FSR411_VARIANT=int8 forces INT8. Checked on an RX 7800 XT through vkd3d-proton's FP16 emulation of FP8 (BB_FSR4CAP_FP8=1 records it there too, fp8emu/): bit-exact with the DLL; not yet run on RDNA4 hardware.

AppImage (Steam Deck): bash build.sh && bash packaging/appimage.sh → dist/Bloodborne-bbport-x86_64.AppImage; data in ~/.local/share/bbport, --play starts the game without the launcher window (Game Mode). FSR 4.1.1 models are not packaged: build them with the launcher's button (see above); they go to ~/.local/share/bbport/fsr4_411 (BB_PACKAGE_FSR411=1 bundles a local fsr4_411 into an AppImage for your own devices). On the Steam Deck pick the 1280×720 output (the game is 16:9; on the 1280×800 screen it gets thin bars).

Adding the AppImage to Steam (Add a Non-Steam Game) needs no options; the compatibility tool does not matter. (Steam preloads its overlay into every non-Steam game; the AppImage removes it before its own programs start, so the Steam overlay is not shown in the game.) Where Steam runs games without FUSE (NixOS: Steam's FHS sandbox; the AppImage then exits with Cannot mount AppImage), set the launch options to

TMPDIR=$HOME/.cache APPIMAGE_EXTRACT_AND_RUN=1 NO_CLEANUP=1 %command%

The AppImage then unpacks itself (~2 GB, ~/.cache/appimage_extracted_*) on the first start (~10 s) and reuses that copy afterwards; a new AppImage version gets a new copy, the old one can be deleted. Without TMPDIR it would unpack into Steam's /tmp, which is in RAM there. Add --play after %command% to skip the launcher.

NVIDIA in the AppImage: startup discovers the host's installed 64-bit NVIDIA Vulkan ICD and exposes its vendor libraries alongside the bundled AMD/Intel drivers. This keeps the NVIDIA userspace driver matched to the host kernel module. Standard Linux distributions keep these libraries under /usr/lib*; on NixOS the AppImage's internal /nix/store may hide them. In that case copy the NVIDIA libraries into an accessible directory and set BB_NVIDIA_LIB_DIR=/path/to/libraries (the NVIDIA manifest must also be accessible). Explicit VK_DRIVER_FILES/VK_ICD_FILENAMES overrides are preserved. Diagnose drivers inside the package with:

./Bloodborne-bbport-x86_64.AppImage --vulkan-info 2>&1 | tee bbport-vulkan.log

A user reported successful startup with FSR 3 on a GTX 1060 6GB (Fedora 44, NVIDIA 580.178.04); selecting FSR 4 caused a black window. Use FSR 3 on this configuration.

MangoHud is bundled in the AppImage; enable its checkbox in the launcher. If MangoHud is also installed system-wide, or Steam's performance overlay is on (Steam Deck game mode), only one overlay is drawn (two drew doubled, offset text). When running from source, install MangoHud separately. A diagnostic launch with VK_LOADER_LAYERS_DISABLE=~implicit~ also disables MangoHud.

Useful variables: BB_FRAME_STATS=1 (frame statistics, including a Memory: line: VRAM, GTT, RSS, images and guest blocks in VRAM), BB_PC_MODEL=1 (the new memory and translation model, AMD only; 0, the old model as in 0.3, is the default), BB_ANISO=N (anisotropic filtering of scene textures; 16 by default, 0 = the game's own), BB_GC_IDLE_SECONDS=N / BB_VRAM_IDLE_SECONDS=N (how long unused textures / buffers stay in VRAM; 20 / 60), BB_BREADCRUMBS=0 (no GPU breadcrumbs; with them a GPU hang names the draw or dispatch it is stuck in), BB_GPU_PROFILE=1 (GPU time per pass), BB_FSR4_PROFILE=1 (GPU time per FSR 4 pass), BB_UPSCALER=taa|fsr3|fsr4|fsr411|off|none, BB_FRAMES_AHEAD=N (how many frames the GPU command thread may run ahead of the GPU; 1 by default, 0 = unbounded), BB_PRESENT_THREAD=0 (present on the vblank thread, as before), BB_LIVE_RES=1 (live resolution changes instead of the startup patch for outputs other than 1080p), BB_PAD_RECORD=file / BB_PAD_REPLAY=file (record a route with F9, replay it in scripted tests), BB_GC_BUDGET_MB=N (texture cache budget, as on integrated GPUs), BB_PRESENT_DUMP_TRIGGER=file with BB_PRESENT_DUMP_COUNT=N (dump N consecutive presented frames), BB_FSR411_VARIANT=int8|fp8|fp8emu (FSR 4.1.1 variant; by default FP8 where the GPU has FP8 matrices), BB_READBACKS=0|1|2 (reads of GPU-written memory by the game: 1 by default, 2 precise and slow, 0 off). More in docs/; recent changes: docs/CHANGES_0.4.md (in Russian), docs/CHANGES_2026-10-06.md.

Repository layout

Tests: bash build.sh --test, python3 -m unittest discover -s tests, and ninja -C out/gpu motion-history-test ui-composition-test scene-resolution-test motion-shader-test settings-test.

Roadmap

• The new memory and translation model on by default once it is stable, NVIDIA included; the old model is removed after that.
• The GPU reads resource descriptors itself (bindless), textures are objects created at load time: no shader code or constant engine executed on the CPU, no texture cache keyed by address.
• Shaders translated ahead of time, at install, not during play.
• More CPU parallelism in GPU command processing (split the draw-recording stage further), scaling to all hardware threads — most important for the Steam Deck.
• Async compute for the upscaler (the frame is GPU-bound at 4K).
• XeSS (super resolution) and XeFG frame generation through a Wine helper sharing Vulkan memory (a memory-bridge prototype is in tools/bridge_helper); DLSS for NVIDIA users; inputs exposed so that OptiScaler-style mapping works.
• Frame generation (FSR 3.1 FG first), reactive and transparency masks for particles and fog.
• Fix the races in AMD's FSR 4.1.1 shaders at output widths that are not multiples of 64 (e.g. 1600×900), as already done for the left-edge race in FSR 4 v07 at 1080p.
• Steam Deck validation of the AppImage; HDR output.

Credits and licenses

bbport is licensed under the GNU GPL v2 or later (LICENSE) — it contains code from shadPS4 (GPL-2.0-or-later). Third-party components keep their licenses: shadPS4 video core and shader recompiler (GPL-2.0+), sirit, half, FSR-Vulkan by FireBurn (MIT; FSR 3.1 on Vulkan and the FSR 4 v07 provider), AMD FidelityFX SDK (MIT), LibAtrac9 (MIT), Dear ImGui (MIT), DejaVu fonts, dxil-spirv (MIT, used to build the FSR 4.1.1 assets). Game patches by Kyo, Lance McDonald, auser1337, illusion, emoose and other community members (patches/Bloodborne.xml). AMD's FSR 4 DLLs and model data are not distributed here.
