xc-soundfont-synth

简体中文 | English

A SoundFont (SF2) synthesis component for DIY electronic instruments, built on ESP-IDF.

For electronic wind instruments, guitars, and other projects that use sensors to control pitch and loudness, this component handles the path from note events to PCM audio. Your application reads sensors and determines the pitch; the component loads SoundFonts, renders audio, and passes it to your I2S, codec, or other output backend through a callback.

SF2 parsing and sample synthesis are provided by TinySoundFont. This repository adds ESP-IDF / FreeRTOS integration, command scheduling, expression control, legato transitions, lightweight reverb, and an output adapter interface.

Features

• Load uncompressed .sf2 files from a filesystem already mounted through ESP-IDF VFS; storage is not limited to SD cards.
• Render interleaved stereo PCM16, with defaults of 44.1 kHz and 128 frames per block.
• Serialize note-on, note-off, SoundFont loading, reverb, and silence commands through a FreeRTOS queue.
• Update a linear loudness target from 0 to 127 using the latest value, with approximately 5 ms smoothing and compensation for TinySoundFont's CC11 curve.
• Perform approximately 5 ms legato transitions by fading out the old note, switching at zero gain, and fading in the new note.
• Provide lightweight reverb using two feedback delay buffers, with optional render tracing and periodic diagnostic logging.
• Configure the SF2 bank/preset, file size budget, zone validation range, task priority, stack, queue, and core affinity.

The current implementation supports one instance and monophonic note control. max_voices sets the budget for internal SF2 voices, including sample layers; it is not the number of independent notes you can play simultaneously. note_on() ends the previous performance note, and note_off() stops all performance channels. Keyboard chords, multiple MIDI channels, and simultaneous instruments require further development.

Component boundaries

Application: sensors / buttons / MIDI parsing / instrument logic
                │ note / expression / legato
                ▼
xc-soundfont-synth
  FreeRTOS command queue → TinySoundFont → expression & legato → reverb
                │ PCM16, interleaved L/R
                ▼
Application-provided output_write() → I2S / codec / other output

The component does not initialize GPIO, I2C, I2S, codecs, amplifiers, or SD cards. It does not include fingering logic, breath sampling, a UI, Bluetooth, or Wi-Fi. Your application owns filesystem mounting, synchronization of SoundFont file access, and the output device's sample format and lifecycle.

Requirements and dependencies

The component does not depend on Arduino, GMF, or esp_codec_dev. Applications can still call esp_codec_dev_write() in their output callback, or use the ESP-IDF I2S driver directly.

The manifest's version range is not a complete compatibility matrix. Other ESP-IDF versions, chips, and output boards require their own builds and hardware validation. The render task is not pinned to a core by default; when pinning is enabled, initialization checks that the selected core exists.

Integrating into an existing project

Place this repository under your ESP-IDF project's components directory, keeping the directory name shown below:

your_project/
├── CMakeLists.txt
├── main/
│   ├── CMakeLists.txt
│   └── main.c
└── components/
    └── xc-soundfont-synth/
        ├── CMakeLists.txt
        ├── idf_component.yml
        ├── include/sampler_synth.h
        ├── sampler_synth.c
        └── tsf.h

Add the dependency to the calling component's CMakeLists.txt:

idf_component_register(
    SRCS "main.c"
    INCLUDE_DIRS "."
    PRIV_REQUIRES xc-soundfont-synth
)

If your application calls the I2S driver directly, also declare an esp_driver_i2s dependency for that application component. TinySoundFont source is included in this repository and does not need to be downloaded separately at build time.

Providing a PCM output callback

The following example assumes that your application has already initialized and enabled tx for 44.1 kHz, 16-bit stereo output:

#include "driver/i2s_std.h"
#include "sampler_synth.h"

static bool write_pcm(const int16_t *samples, size_t frames, void *ctx)
{
    size_t written = 0;
    const size_t bytes = frames * 2 * sizeof(int16_t);
    return i2s_channel_write((i2s_chan_handle_t)ctx, samples, bytes,
                            &written, 50) == ESP_OK && written == bytes;
}

/* Do not close or release tx until sampler_synth_deinit() has returned. */
static bool start_synth(i2s_chan_handle_t tx)
{
    const sampler_synth_cfg_t cfg = {
        .sample_rate = 44100,
        .output_write = write_pcm,
        .output_ctx = tx,
    };
    return sampler_synth_init(&cfg);
}

The callback runs in the render task. It must provide backpressure paced by the audio clock and return within a bounded time. A callback that discards data and immediately returns success will make the task spin at full speed and is not suitable for real-time operation as-is.

Before returning true, the callback must write or copy the entire block. Asynchronous DMA must not retain a reference to the component's temporary buffer. Return false on a write failure; the component records SAMPLER_SYNTH_ERROR_OUTPUT, yields for one tick, and then continues trying to submit audio.

Loading and playing

1. Mount storage and initialize the output hardware in your application, then call sampler_synth_init().
2. Submit sampler_synth_load_soundfont(0, "/sdcard/instrument.sf2") and check the return value.
3. Poll the state from your application's control task with a finite timeout. Play only after READY; read the error if the state becomes ERROR.
4. Set a nonzero expression value, for example sampler_synth_set_expression(80). The initial loudness is zero.
5. Start a note with sampler_synth_note_on(60, 100, 0, 0). Use legato_transition() to transition to another note.
6. Stop the note with sampler_synth_note_off(60, 0, 0) and handle any queue submission failure.

A true result from load_soundfont(), note_on(), note_off(), legato_transition(), or set_reverb() only means that the command was queued successfully. Parsing, voice creation, or audio output can still fail; a successful queue submission does not mean that audio has already played.

See the I2S + SD card example for a complete timeout, error-handling, and cleanup sequence.

Running the example

examples/i2s_sdcard is a standalone ESP-IDF project. It mounts a FAT SD card over SPI, loads an SF2 file into memory, and plays four successive notes through standard Philips I2S to an external DAC. It does not configure codec I2C registers, MCLK, or amplifier enable signals, so it is intended for I2S DACs that do not require those controls. Add the appropriate hardware initialization for other boards.

cd examples/i2s_sdcard
idf.py set-target esp32
idf.py menuconfig
idf.py build

Configure the I2S pins, SD SPI pins, and SF2 path under XC SoundFont example. All GPIO settings default to -1; until configured, the example reports an error instead of driving preset pins.

Place an SF2 file that you are authorized to use on the SD card. It must contain bank 0 / preset 0 and cover the example notes 60, 62, 64, and 67. The example does not format the card if mounting fails. After wiring the hardware and checking the pins and electrical requirements, run:

idf.py -p <PORT> flash monitor

The example does not require PSRAM by default. Before using a larger SoundFont, enable and verify PSRAM using settings appropriate for your board, allow ordinary malloc() allocations to use external RAM, and choose a resource budget based on the available heap. Do not copy another board's PSRAM, power, or codec configuration without checking it against your hardware.

Configuration

The configuration structure can be zero-initialized, but output_write is required.

Any available SF2 preset can be selected. By default, the component does not enforce the original OFLU requirements of MIDI notes 36–71 and at most two layers per note. To preserve those validation requirements, use:

cfg.validate_zones = true;
cfg.note_min = 36;
cfg.note_max = 71;
cfg.zone_velocity = 100;
cfg.max_zones_per_note = 2;
cfg.min_free_psram_bytes = 1152U * 1024U;

Move codec/SD initialization from the original firmware into your application and connect the output through output_write. The old SAMPLER_SYNTH_ERROR_CODEC value is retained as a compatibility alias for SAMPLER_SYNTH_ERROR_OUTPUT.

This extraction changes the configuration structure and initialization requirements. Existing callers must provide an output callback and recompile; this is not a binary-compatible replacement.

Memory, threading, and timing

• Use uncompressed SF2 files; compressed SF3 files are not supported. TinySoundFont does not yet implement SF2 modulators, chorus send, or reverb send. This component's lightweight reverb is independent of the effect-send settings inside the SF2 file, so playback is not guaranteed to sound the same as a desktop synthesizer.
• SF2 files are loaded in full, and TinySoundFont converts PCM16 samples to floating point. Runtime memory usage is usually considerably larger than the file size. Presets, zones, voices, stacks, and output buffers also consume memory; passing the file size check does not guarantee successful allocation.
• At 44.1 kHz, the two floating-point reverb delay buffers use approximately 58.6 KiB. Initialization attempts to allocate them. Basic synthesis remains available if allocation fails, but enabling reverb will return false.
• The original component's monophonic note-transition algorithm and local TinySoundFont gain extensions are retained. Layered SoundFonts can still use multiple voices; one note does not necessarily mean one voice.
• Only the render task accesses TinySoundFont. Ordinary control commands are processed in queue order, while expression retains the latest value. During a legato transition, only the latest pending target is retained, so rapidly traversed intermediate notes may not sound.
• Control APIs are task-context APIs and cannot be called from an ISR. The application must serialize init(), shutdown(), and deinit(). Stop all event producers before deinitialization; do not release queues or buffers concurrently with other API calls.
• Output and trace callbacks must not block on UI, file, or wireless operations. Set the trace callback only while the synthesizer is not initialized.
• SoundFont reading and parsing run in the render task and pause new PCM submissions, potentially causing an underrun. Stop notes or mute output in the application before loading, and switch SoundFonts outside active performance. Background preloading and seamless switching are not provided.
• At 44.1 kHz, the default 128-frame block represents approximately 2.90 ms of audio. This is a block duration, not sensor-to-speaker latency. The approximately 5 ms expression and legato settings are not end-to-end latency measurements either.

Stopping and shutting down

Recommended order: stop event producers → sampler_synth_shutdown() → sampler_synth_deinit() → drain the output backend, mute the codec/amplifier, and shut down hardware in the application.

shutdown() waits for approximately one second at most. Success means that the output callback has accepted a block of zero PCM; it does not mean that DMA has finished playing through that block. If it fails, the application must still ensure hardware mute. deinit() waits for an in-progress callback or file operation to finish, so output writes must use finite timeouts, and the application must prevent concurrent changes to an SF2 file being loaded.

Repository layout

include/sampler_synth.h       Public API, configuration, and callback contracts
sampler_synth.c               Task, commands, SF2 loading, performance control, and reverb
tsf.h                        TinySoundFont with local extensions
TINYSOUNDFONT_VERSION.md      Upstream commit, actual hashes, and local modifications
THIRD_PARTY_NOTICES.md        Third-party projects and license notices
LICENSE                      MIT license for this project
LICENSES/                    Full copies of bundled third-party licenses
examples/i2s_sdcard/          Standalone integration example
tests/                       Host regression checks and validation notes

Validation and contributing

Automated validation results are recorded in the validation notes (Chinese). A successful firmware build demonstrates compilation and linking; it does not establish audio behavior on a particular DAC, codec, or board.

When integrating the component, verify cold startup, weak/strong expression, rapid note transitions, note-on/off behavior, failed SoundFont loads, queue pressure, output timeouts, and shutdown silence. Also check for stuck notes, clicks, or watchdog resets while other application tasks are running.

Issues and pull requests are welcome. For bug reports, include the ESP-IDF version, chip, output backend, relevant configuration, error codes, and reproduction steps. Confirm that you have distribution rights before submitting SoundFonts or recordings. For performance results, describe the measurement endpoints, sampling method, and hardware conditions.

License and acknowledgments

Original code and documentation in this project are licensed under the MIT License. Use, modification, redistribution, and commercial use are permitted subject to retaining the required copyright and license notices. The software is provided as-is; the full license text governs the terms.

• TinySoundFont, maintained by Bernhard Schelling and based on Steve Folta's SFZero, is licensed under MIT. It provides SF2 parsing, sample playback, envelopes, filtering, and basic synthesis. This repository's tsf.h includes local mixer-gain and voice-reclamation extensions and retains the original copyright and license notices. It is not an unmodified upstream file; see the version notes (Chinese).
• ESP-IDF provides the runtime environment and driver interfaces. The framework is primarily licensed under Apache-2.0, with bundled third-party components distributed under their respective licenses. FreeRTOS is supplied through ESP-IDF, and its kernel is MIT-licensed. This repository does not redistribute the SDK source code.

See THIRD_PARTY_NOTICES.md (Chinese) for sources, copyrights, and license scope. No SF2 SoundFonts are bundled. The component's MIT license does not cover external SoundFonts, samples, trademarks, or other libraries used by your application. Follow the SoundFont author's license when using or redistributing a SoundFont.
