OpenFrame OSS Frontend

OpenFrame OSS Frontend is the primary web application for the OpenFrame platform — a unified, AI-driven interface for Managed Service Providers (MSPs). It replaces expensive proprietary MSP software with intelligent open-source alternatives, bringing device management, ticketing, monitoring, scripts, and AI assistance into a single cohesive operational interface.

Built and maintained by Flamingo, this project is the human-facing layer of the OpenFrame ecosystem — connecting backend services into an AI-first MSP experience.

Features

Feature	Description
Device Management	Unified device model, remote shell, file manager, remote desktop via MeshCentral
Customer Management	Per-organization AI configuration, guardrails templates, aggregated device counts
Ticketing	Kanban boards, AI-assisted replies, approval workflows, assignment management
Knowledge Base	Article management, folder organization, attachment handling
Mingo AI (Technician)	Streaming AI assistant with tool execution, context awareness, and approval flows
Customer AI (Fae)	Embeddable AI for client-facing portals
Monitoring	Fleet MDM policies, osquery live query campaigns, query execution
Scripts	Script library, scheduling, execution history
Audit Logs	Organization and device-level log viewer with cursor-based pagination
Settings & Billing	Tenant config, SSO, API keys, subscription management
Onboarding	Step-by-step guided setup for new tenants
Feature Flags	Runtime-configurable feature toggles via Zustand

Technology Stack

flowchart TD
    FE["Next.js 16 App Router (React 19)"]
    FE --> TS["TypeScript 5.8"]
    FE --> GQL["GraphQL — graphql + Relay v20"]
    FE --> RQ["TanStack Query v5"]
    FE --> ZS["Zustand v5"]
    FE --> TW["Tailwind CSS v3"]
    FE --> FC["openframe-frontend-core"]
    FE --> API["API Service Core"]
    FE --> Chat["AI / Chat Service"]
    FE --> Auth["Authorization Service"]
    FE --> Fleet["Fleet MDM"]
    FE --> Mesh["MeshCentral"]

Core Dependencies

Package	Version	Purpose
`next`	^16.2.4	SSR + App Router framework
`react`	^19.2.0	UI library
`react-relay`	^20.1.1	GraphQL fragment system
`@tanstack/react-query`	^5.90.16	Server-state caching and pagination
`zustand`	^5.0.8	Client-side state management
`tailwindcss`	^3.4.17	Utility-first CSS
`@xterm/xterm`	^6.0.0	Terminal emulator for remote shell
`@monaco-editor/react`	^4.7.0	Script editor
`zod`	^4.3.6	Runtime schema validation
`@flamingo-stack/openframe-frontend-core`	^0.0.480	Shared UI component library

Architecture

OpenFrame OSS Frontend acts as the presentation and orchestration layer on top of OpenFrame backend services.

flowchart LR
    Browser["User Browser"] --> Frontend["OpenFrame OSS Frontend"]
    Frontend -->|"GraphQL /api/graphql"| ApiService["API Service Core"]
    Frontend -->|"REST /chat/api"| ChatService["AI / Chat Service"]
    Frontend -->|"OAuth 2.0"| AuthService["Authorization Service"]
    Frontend -->|"/tools/fleetmdm-server"| Fleet["Fleet MDM"]
    Frontend -->|"/tools/meshcentral"| Mesh["MeshCentral"]
    ApiService --> DataLayer["MongoDB / Cassandra / Apache Pinot"]
    ChatService --> StreamLayer["Kafka / NATS"]

Application Domain Structure

The application is organized by feature domain under src/app:

flowchart TD
    App["src/app"]
    App --> Customers["customers/"]
    App --> Devices["devices/"]
    App --> Tickets["tickets/"]
    App --> KnowledgeBase["knowledge-base/"]
    App --> Logs["logs-page/"]
    App --> Monitoring["monitoring/"]
    App --> Scripts["scripts/"]
    App --> Settings["settings/"]
    App --> Mingo["mingo/"]
    App --> Onboarding["onboarding/"]
    App --> Lib["src/lib/ — API, Auth, Relay, MeshCentral"]
    App --> Stores["src/stores/ — Zustand global state"]

State Management

The application uses three complementary state management approaches:

Pattern	Technology	Used For
Server state	TanStack Query v5	REST API calls, optimistic mutations, cursor pagination
GraphQL fragments	Relay v20	Logs, scripts, notifications (streaming + pagination)
Client UI state	Zustand v5	Feature flags, onboarding, Mingo chat, device filters

Quick Start

Prerequisites: Node.js 18+, npm 9+, Git. See the Prerequisites Guide for full details.

# 1. Clone the repository
git clone https://github.com/flamingo-stack/openframe-oss-frontend.git
cd openframe-oss-frontend

# 2. Install dependencies
npm install

# 3. Configure environment
cp .env.example .env.local
# Edit .env.local with your backend URLs

# 4. Start the development server
npm run dev

Open http://localhost:3000 in your browser.

Minimum Environment Variables

NEXT_PUBLIC_TENANT_HOST_URL=https://your-tenant.openframe.dev
NEXT_PUBLIC_SHARED_HOST_URL=https://api.openframe.dev
NEXT_PUBLIC_APP_MODE=oss-tenant
NEXT_PUBLIC_APP_URL=http://localhost:3000

Refer to your environment configuration for actual backend URLs.

Available Scripts

Script	Description
`npm run dev`	Start development server with hot reload
`npm run build`	Generate schema enums + Relay artifacts + Next.js production build
`npm run start`	Start production server (after build)
`npm run lint`	Run ESLint (the fast pass; rules come from the core library's shared config)
`npm run lint:fix`	ESLint autofix
`npm run lint:types`	ESLint type-aware pass (slow — needs an 8 GB heap)
`npm run format:fix`	Auto-fix formatting with Prettier
`npm run type-check`	TypeScript type checking without emitting
`npm run relay`	Compile Relay GraphQL fragments
`npm run relay:watch`	Watch and recompile Relay fragments on change
`npm run fetch-schema`	Fetch the latest GraphQL schema from the backend

Documentation

📚 See the Documentation for comprehensive guides including getting started tutorials, development workflows, architecture overviews, and API references.

Community & Support

OpenFrame OSS is supported through the OpenMSP Slack community — the primary channel for discussions, questions, and collaboration.

We do not use GitHub Issues or Discussions. All support and coordination happens in Slack.

Join Slack: https://join.slack.com/t/openmsp/shared_invite/zt-36bl7mx0h-3~U2nFH6nqHqoTPXMaHEHA
Community Hub: https://www.openmsp.ai/
OpenFrame Website: https://openframe.ai
Flamingo Platform: https://flamingo.run
GitHub Repository: https://github.com/flamingo-stack/openframe-oss-frontend

Contributing

We welcome contributions! Please read the Contributing Guidelines before opening a pull request.

Key points:

All code must be TypeScript with strict typing
Follow the Conventional Commits format
Run npm run type-check, npm run lint, and npm run relay before submitting
Coordinate in the OpenMSP Slack community before starting large features

Built with 💛 by the Flamingo team
