OpenFrame OSS Lib

OpenFrame OSS Lib is the core backend shared library collection of the OpenFrame platform — the AI-driven unified MSP (Managed Service Provider) infrastructure built by Flamingo.

This monorepo provides the reusable Spring Boot modules that power every OpenFrame service. It delivers multi-tenant authentication, reactive API routing, event-driven stream processing, agent lifecycle management, and more — all packaged as independently versionable Maven artifacts.

Note: This repository contains shared library modules, not a standalone deployable service. It is intended for use by openframe-oss-tenant and related OpenFrame services.

Features

Multi-Tenant by Design — Every module respects tenant isolation via TenantContext, scoped repositories, and JWT claims
OAuth2 / OIDC Authorization Server — Full Spring Authorization Server implementation with MongoDB persistence, SSO, and invitation-based registration
Reactive API Gateway — Spring Cloud Gateway (WebFlux + Netty) with JWT, API key authentication, rate limiting, and WebSocket proxying
GraphQL API Layer — Netflix DGS-based Relay-compliant API with cursor pagination and DataLoaders for N+1 elimination
External REST API — Versioned /api/v1/** endpoints for third-party integrations with OpenAPI documentation
Event-Driven Streaming — Kafka + Kafka Streams for real-time enrichment and state projection from integrated tools
Agent Lifecycle Management — Full agent registration, heartbeat (NATS), RMM script scheduling, execution watchdog, and Kafka publishing
MongoDB Domain Model — Rich document model covering devices, organizations, scripts, tickets, notifications, and more
Frontend Component Library — React/TypeScript component library for the OpenFrame UI (Storybook included)
Rust Device Agent — Cross-platform agent client (clients/openframe-client) built on the Tokio async runtime

Architecture

OpenFrame OSS Lib follows a layered, multi-tenant, event-driven architecture:

flowchart TD
    Client["Browser / Agent / External System"] --> Gateway["Gateway Service Core"]

    Gateway --> Authz["Authorization Service Core"]
    Gateway --> Api["API Service Core (REST + GraphQL)"]
    Gateway --> ExternalApi["External REST API Service"]
    Gateway --> ClientAgent["Client Agent Service Core"]

    Api --> Repos["Data Mongo Sync Repositories"]
    ExternalApi --> Repos
    ClientAgent --> Repos

    Repos --> Domain["Data Mongo Domain Model"]
    Domain --> Mongo[("MongoDB")]

    ClientAgent --> Kafka["Apache Kafka"]
    Gateway --> Kafka
    Kafka --> Stream["Stream Processing Core"]
    Stream --> Mongo

    ClientAgent --> NATS["NATS / JetStream"]
    NATS --> ClientAgent

Module Summary

Layer	Module	Purpose
Edge	`openframe-gateway-service-core`	Reactive JWT/API-key gateway
Identity	`openframe-authorization-service-core`	OAuth2 + OIDC authorization server
API	`openframe-api-service-core`	Internal GraphQL + REST API
External API	`openframe-external-api-service-core`	Public REST API surface
Agent	`openframe-client-core`	Agent registration + RMM
Domain	`openframe-data-mongo-common`	MongoDB document model
Repositories	`openframe-data-mongo-sync`	Sync MongoDB repositories
Streaming	`openframe-stream-service-core`	Kafka event processing

Quick Start

Prerequisites

JDK 21 (java -version)
Maven 3.9+ (mvn -version)
Docker 24+ (for integration tests)
Node.js 18+ (for frontend modules — optional)
Rust stable (for agent client — optional)

Clone and Build

# Clone the repository
git clone https://github.com/flamingo-stack/openframe-oss-lib.git
cd openframe-oss-lib

# Build all modules (skip tests for speed)
mvn clean install -DskipTests

# Verify the build succeeded
mvn dependency:resolve -DincludeArtifactIds=openframe-core

Use a Module in Your Project

After installing locally, add a dependency to your Spring Boot service's pom.xml:

<!-- Core data layer -->
<dependency>
    <groupId>com.openframe.oss</groupId>
    <artifactId>openframe-data-mongo-sync</artifactId>
    <version>999-SNAPSHOT</version>
</dependency>

<!-- API service infrastructure -->
<dependency>
    <groupId>com.openframe.oss</groupId>
    <artifactId>openframe-api-service-core</artifactId>
    <version>999-SNAPSHOT</version>
</dependency>

<!-- Gateway module -->
<dependency>
    <groupId>com.openframe.oss</groupId>
    <artifactId>openframe-gateway-service-core</artifactId>
    <version>999-SNAPSHOT</version>
</dependency>

Build a Specific Module

# Build only one module and its upstream dependencies
mvn clean install -pl openframe-data-mongo-sync -am -DskipTests

Build the Frontend Library (Optional)

cd openframe-frontend-core
npm install
npm run build

Build the Rust Agent Client (Optional)

cd clients/openframe-client
cargo build --release
# Binary: target/release/openframe-client

Technology Stack

Layer	Technology
Java framework	Spring Boot 3.3, Spring Cloud 2023
Authorization	Spring Authorization Server 1.3.1
API (GraphQL)	Netflix DGS 9.0.3
Gateway	Spring Cloud Gateway (WebFlux + Netty)
Messaging	NATS / JetStream, Apache Kafka, Kafka Streams
Database	MongoDB, Redis
Testing	JUnit 5, Testcontainers 1.21.4, Mockito
Frontend	React, TypeScript, Tailwind CSS, Storybook
Agent	Rust (stable), Tokio async runtime
Build	Maven 3.9+, Node.js 18+, Cargo

Repository Structure

openframe-oss-lib/
├── openframe-exception/              # Exception hierarchy
├── openframe-core/                   # Core utilities and validation
├── openframe-core-crypto/            # Encryption service
├── openframe-security-core/          # JWT security config
├── openframe-security-oauth/         # OAuth BFF service
├── openframe-authorization-service-core/  # OAuth2/OIDC server
├── openframe-gateway-service-core/   # Reactive API gateway
├── openframe-api-service-core/       # Internal GraphQL + REST API
├── openframe-api-lib/                # API contracts & DTO library
├── openframe-external-api-service-core/  # External REST API
├── openframe-client-core/            # Agent service core
├── openframe-data-mongo-common/      # MongoDB domain documents
├── openframe-data-mongo-sync/        # Synchronous repositories
├── openframe-data-mongo-reactive/    # Reactive repositories
├── openframe-data-redis/             # Redis caching
├── openframe-data-kafka/             # Kafka producer utilities
├── openframe-data-nats/              # NATS messaging
├── openframe-stream-service-core/    # Kafka Streams processing
├── openframe-notification-mail/      # Email notifications
├── openframe-notification-push/      # Push notifications
├── openframe-frontend-core/          # React/TypeScript UI library
├── clients/openframe-client/         # Rust agent client
└── sdk/fleetmdm/                     # Fleet MDM SDK

GitHub Package Registry

Published artifacts are available from GitHub Packages. Configure your Maven ~/.m2/settings.xml:

<servers>
  <server>
    <id>github</id>
    <username>YOUR_GITHUB_USERNAME</username>
    <password>YOUR_GITHUB_TOKEN</password>
  </server>
</servers>

Replace YOUR_GITHUB_TOKEN with a GitHub Personal Access Token with the read:packages scope.

Related Projects

Project	Description
openframe-oss-tenant	Main OpenFrame platform application
openframe-cli	CLI tool for self-hosted deployment
Flamingo	Commercial MSP platform powered by OpenFrame
OpenFrame	Unified AI-driven MSP platform

Documentation

📚 See the Documentation for comprehensive guides including getting started tutorials, development setup, architecture reference, and security best practices.

Community & Support

OpenFrame is developed in the open. Questions, ideas, and contributions are welcome on the OpenMSP Slack community:

https://join.slack.com/t/openmsp/shared_invite/zt-36bl7mx0h-3~U2nFH6nqHqoTPXMaHEHA

We do not use GitHub Issues or GitHub Discussions — all coordination happens on Slack.

Contributing

Contributions are welcome! Please read the Contributing Guidelines before submitting a pull request. Discuss your idea on Slack first for non-trivial changes.
