xarray_jax

This library supports using xarray datatypes together with the JAX library.

Installation

To install a specific tagged release:

pip install git+https://github.com/google-deepmind/xarray_jax.git@v0.1.0

What is xarray_jax?

JAX is a high-performance library designed for numerical computation and machine learning, operating primarily on arrays which can be contained in generic tree-like data structures known as PyTrees.

Standard xarray datatypes (DataArray, Dataset etc) are able to contain jax arrays, however they are not natively registered with jax as PyTree nodes, preventing their direct use within JAX's core transformations (jit, grad, vmap, etc.).

This library solves that problem. It registers xarray data structures as custom JAX PyTrees. This allows JAX to seamlessly flatten xarray objects into their raw arrays for accelerated computation and then unflatten the results back into fully labeled xarray objects, preserving critical metadata like dimension names and coordinates.

Quick Start

Here's a minimal example showing how to apply JAX's just-in-time (JIT) compilation to a function that operates directly on an xarray.DataArray containing jax.numpy data.

Example:

import jax
import jax.numpy as jnp
import xarray as xr
import numpy as np
import xarray_jax

# 1. Create a standard xarray.DataArray with JAX data
#   Use np.datetime64 for time coordinates as recommended practice
temperature = xr.DataArray(
    data=jnp.array([[20.5, 21.2, 22.1],
                   [18.3, 19.7, 20.8]]),
    dims=('time', 'location'),
    coords={
        'time': np.array(['2023-01-01', '2023-01-02'], dtype='datetime64[D]'),
        'location': ['NYC', 'LA', 'Chicago']
    }
)

# 2. Define a pure Python function that works with the DataArray
#    This function can use standard xarray methods like .mean()
def process_temperature(temp_data):
    fahrenheit = temp_data * 9/5 + 32
    return fahrenheit.mean(dim='location')

# 3. JIT-compile the function using jax.jit
#    This would fail without xarray_jax registering xarray objects as PyTrees
jitted_process = jax.jit(process_temperature)

# 4. Execute the compiled function with the xarray object
result = jitted_process(temperature)

print("JIT compilation successful!")
print(result)
# Expected Output:
# <xarray.DataArray (time: 2)>
# array([70.28    , 67.27999 ], dtype=float32)
# Coordinates:
#   * time     (time) datetime64[ns] 2023-01-01 2023-01-02

Using xarray in JAX Transformations

The primary use case for xarray_jax is enabling JAX transformations on functions that work with xarray data structures. Since JAX arrays are now directly supported by xarray, you can create xarray objects with JAX arrays and use them directly.

Computing Gradients with jax.grad

You can compute gradients through functions operating on xarray.DataArray objects, provided the function returns a raw JAX scalar. Use xarray_jax.jax_data to extract the underlying JAX array when needed.

Example :

# Assume 'temperature' DataArray exists from the Quick Start example

# Define a function that returns a scalar for gradient computation
def temperature_loss(temp_data):
    target = 20.0  # Simple loss: penalize deviation from 20°C
    # Note: The differentiable loss function must return a raw JAX scalar
    loss_xarray = ((temp_data - target) ** 2).sum()
    return loss_xarray.data  # Extract JAX scalar

# Compute gradients with respect to the temperature data
grad_fn = jax.grad(temperature_loss)
gradients = grad_fn(temperature)  # Pass the original xarray object

print(gradients)
# Expected Output:
# <xarray.DataArray (time: 2, location: 3)>
# array([[ 1.       ,  2.4000015,  4.200001 ],
#        [-3.4000015, -0.5999985,  1.5999985]], dtype=float32)
# Coordinates:
#   * time      (time) datetime64[ns] 2023-01-01 2023-01-02
#   * location  (location) <U7 'NYC' 'LA' 'Chicago'

Working with Datasets

---

JAX transformations also work seamlessly with xarray.Dataset objects.

Example :

# Create a Dataset with multiple variables
weather_data = xr.Dataset(
    {
        'temperature': (['time', 'location'],
                       jnp.array([[20.5, 21.2], [18.3, 19.7]])),
        'humidity': (['time', 'location'],
                    jnp.array([[0.65, 0.72], [0.58, 0.69]]))
    },
    coords={
        'time': ['morning', 'evening'],
        'location': ['NYC', 'LA']
    }
)

@jax.jit
def weather_model(data):
    # Compute heat index approximation
    temp_f = data.temperature * 9/5 + 32
    heat_index = temp_f + 0.5 * (data.humidity * 100 - 10)
    # Use standard xarray method to assign a new variable
    return data.assign(heat_index=heat_index)

result_dataset = weather_model(weather_data)
print(result_dataset.heat_index)
# Expected Output:
# <xarray.DataArray 'heat_index' (time: 2, location: 2)>
# array([[96.15     , 99.7      ],
#        [92.44     , 96.9600067]], dtype=float32)
# Coordinates:
#   * time      (time) <U7 'morning' 'evening'
#   * location  (location) <U3 'NYC' 'LA'

Advanced JAX Operations with Named Dimensions

xarray_jax provides specialized wrappers for certain JAX operations to work directly with xarray's named dimensions.

Vectorized Mapping with xarray_jax.vmap

Note: While xarray_jax.vmap exists, it is generally not needed for standard xarray usage due to xarray's built-in broadcasting. Furthermore, vmap is not the canonical method for SPMD or sharding in modern JAX (see the Sharding section below). This function is mainly for niche use cases, such as compatibility with legacy code requiring named axes for collectives or when vectorizing specific non-broadcastable JAX primitives.

vmap vectorizes a function along a named xarray dimension, acting as a thin, dimension-name-aware wrapper around jax.vmap.

Constraints:

• The mapped dimension dim must be the leading axis for all relevant xarray variables and JAX arrays passed to the function.
• Uses in_axes=0, out_axes=0 strictly (no broadcasting of non-mapped leaves).
• Static coordinates along dim are not available inside the function; prefer jax_coords if per-example coordinates are needed.
• Optional axis_name, axis_size, and spmd_axis_name are forwarded to jax.vmap for advanced use cases like collectives or legacy sharding interop (see jax.vmap docs).

Example:

import xarray
import jax
import jax.numpy as jnp
import xarray_jax

batch = 5
ds = xarray.Dataset(
    {
        'foo': (('batch', 'lat', 'lon'), jnp.zeros((batch, 3, 4), dtype=jnp.float32)),
        'bar': (('batch', 'time', 'lat', 'lon'), jnp.zeros((batch, 2, 3, 4), dtype=jnp.float32)),
    },
    coords={'lat': jnp.arange(3), 'lon': jnp.arange(4)}
)

def step(d):  # 'batch' dimension is removed inside the vmapped function
  assert 'batch' not in d.dims
  return d + 1

# Vectorize the 'step' function along the 'batch' dimension
vmapped_step = xarray_jax.vmap(step, dim='batch')
result = vmapped_step(ds)
print(result.dims) # {'batch': 5, 'lat': 3, 'lon': 4, 'time': 2}

Parallel Mapping with xarray_jax.pmap

Note: Similar to vmap, jax.pmap is no longer the main or most flexible way to achieve sharding in JAX. Modern approaches involve directly specifying sharding on arrays (see the Sharding section below). xarray_jax.pmap is provided primarily for compatibility with legacy code.

The pmap function allows you to parallelize computation across multiple devices (e.g., GPUs or TPUs) using a named dimension:

Example:

# Create data with a 'device' dimension matching the number of local devices
devices_count = jax.local_device_count()
parallel_data = xr.DataArray(
    data=jnp.ones((devices_count, 10, 5)),
    dims=('device', 'time', 'location'),
    coords={
        'time': range(10),
        'location': range(5)
    }
)

def process_chunk(data_chunk):
    # This function operates on a slice of data on a single device.
    # The 'device' dimension is not present here.
    assert 'device' not in data_chunk.dims
    return data_chunk * 2

# Parallelize the function across devices using the named dimension
parallel_fn = xarray_jax.pmap(process_chunk, dim='device')
result = parallel_fn(parallel_data)

print(result.dims)  # ('device', 'time', 'location')

Sharding (Modern Approach)

The canonical way to perform parallel computation and distribute data across multiple devices (SPMD/sharding) in modern JAX involves using device meshes and attaching sharding information directly to arrays. This approach is generally preferred over legacy methods like pmap for sharding. xarray_jax facilitates this by integrating well with jax.sharding primitives, particularly through the tree_map_with_dims utility.

Here's an example demonstrating how to shard an xarray.Dataset along the 'batch' dimension using jax.sharding.NamedSharding.

Example:

import jax
import jax.numpy as jnp
import xarray as xr
from jax.sharding import Mesh, PartitionSpec as P
import xarray_jax

ds = xr.Dataset(
    {'foo': (('batch', 'lat', 'lon'), jnp.zeros((16, 3, 4)))},
    coords={'lat': jnp.arange(3), 'lon': jnp.arange(4)}
)

# 1. Create a device mesh.
mesh = Mesh(jax.devices(), axis_names=('batch',))

# 2. Define a function to apply shardings based on dimension names,
# and apply it using `tree_map_with_dims`.
def apply_sharding(arr, dims):
  if dims:
    # Shard any 'batch' dimensions across the 'batch' mesh axis:
    mesh_axes = ['batch' if d == 'batch' else None for d in dims]
    sharding = jax.sharding.NamedSharding(mesh, P(*mesh_axes))
  else:
    # Fully-replicate any jax arrays occurring outside xarray datatypes:
    sharding = jax.sharding.NamedSharding(mesh, P())

  return jax.device_put(arr, sharding)

sharded_ds = xarray_jax.tree_map_with_dims(apply_sharding, ds)
print(f"Sharding applied to 'foo': {sharded_ds.foo.data.sharding}")

# 3. Pass sharded data directly to a jitted function. No pmap needed! JAX
# handles the SPMD computation.
@jax.jit
def process_sharded_data(data):
    # Your computation here operates directly on the sharded data
    return data * 2 + 1

result = process_sharded_data(sharded_ds)

print(f"Output sharding of 'foo': {result.foo.data.sharding}")

Accessing jax array data

You can access jax array data held within an xarray.DataArray or xarray.Variable directly using the standard xarray API:

# Assume 'temperature' is an xarray.DataArray with JAX data
jax_array = temperature.data

Helpers (unwrap_data, jax_data etc) used to be required for this in an older version of xarray_jax, and are still provided for backwards compatibility, but are no longer a necessary or recommended way to access array data. (They are still needed to access non-array leaf data, although this is a relatively niche scenario, see the section on it below.)

Treatment of xarray coordinates under JAX

Standard xarray coordinates (coords) are treated by JAX as static, compile-time constants. In particular this means that if the coordinates provided as input to a jax.jit'd function change, jax will re-trace and re-compile the function.

For scenarios requiring coordinates that are dynamic, traceable JAX arrays (e.g., coordinates that change during an optimization process), xarray_jax provides the jax_coords parameter in its custom DataArray and Dataset constructors.

This feature should currently be considered experimental. While relied upon by some DeepMind research models (like GenCast), it may be replaced in the future with a different approach (e.g., automatically treating all non-index coordinates as dynamic).

Therefore, it is recommended that most users prefer the standard xarray.DataArray and xarray.Dataset constructors and use standard coords, unless there is a specific need for dynamic, traceable coordinates.

Example:

import xarray
import jax
import jax.numpy as jnp
import xarray_jax

batch = 5
# Dynamic time values computed with JAX
time_values = jnp.linspace(0.0, 1.0, batch)

# Use xarray_jax.Dataset to define 'time' as a jax_coord
ds_dynamic = xarray_jax.Dataset(
    {'data': (('batch', 'x'), jnp.ones((batch, 3)))},
    coords={'x': [0, 1, 2]},
    # 'time' is now a traceable JAX array associated with the 'batch' dimension
    jax_coords={'time': xarray.Variable(('batch',), time_values)}
)

@jax.jit
def process_dynamic(d):
    # This JITted function can perform calculations
    # using the dynamic 'time' coordinate because it's a JAX array.
    return d.data * d.coords['time']

result_dynamic = process_dynamic(ds_dynamic)
print(result_dynamic.dims) # ('batch', 'x')
# Verify that the 'time' coordinate data is still a JAX array
print(f"Type of time coord data: {type(result_dynamic.coords['time'].data)}")

Storing non-array data within xarray objects in PyTrees

A core design goal of xarray_jax is to ensure robust compatibility with the broader JAX ecosystem, including higher-level neural network libraries like Flax which perform complex manipulations on PyTrees.

A key challenge arises because the JAX PyTree contract allows any data type to be a leaf node, not just arrays. Transformations can introduce non-array leaves such as None, integers, booleans, or internal JAX metadata objects like jax.ShapeDtypeStruct. However, standard xarray constructors expect array-like data.

To bridge this gap and prevent errors, xarray_jax internally uses a NonArrayLeafWrapper. This utility class is used internally to wrap any non-array leaf value encountered during PyTree unflattening. It implements the minimal interface required to "quack like" an array (duck typing), satisfying xarray's expectations without actually converting the leaf into an array.

The wrapper is removed automatically in the corresponding PyTree flatten step, and so is largely an implementation detail of xarray_jax; if you only manipulate PyTrees using the generic jax.tree and jax.tree_util APIs then you should not typically have to deal with NonArrayLeafWrappers yourself. You would only need to work with them yourself in the following relatively niche situations:

• If manually constructing a PyTree with non-array leaves inside an xarray object, e.g. to provide to a public API which requires a PyTree of ints or booleans, where you aren't able to construct it using e.g. jax.tree.map on an existing PyTree. In this case you can wrap the leaf values manually with NonArrayLeafWrapper.

• When a PyTree with non-array leaves is returned from a public API and you need to access specific leaves of it that occur wrapped inside an xarray object. In this case you can use e.g. xarray_jax.unwrap_data(data_array) or xarray_jax.unwrap_vars(dataset).

Scan

jax.lax.scan is a powerful primitive for efficiently executing loops with carry-over state, commonly used in recurrent neural networks or time-series simulations. xarray_jax provides a wrapper, xarray_jax.scan, that allows you to use this functionality directly with xarray objects, scanning along a named dimension.

The xarray_jax.scan wrapper behaves like jax.lax.scan but automatically handles named dimensions and reconstructs the xarray structure on output.

This wrapper handles the details of transposing the specified dimension (dim) to the leading axis before passing it to jax.lax.scan and correctly reconstructing the xarray object with the scanned dimension afterwards.

Constraints:

• The scanned dimension dim must exist in all xarray objects within the input xs.
• Static coordinates along dim in the input xs will not be available inside the scan function f and are not automatically restored on the output ys.

Example:

import jax
import jax.numpy as jnp
import xarray as xr
import xarray_jax

# Initial state (carry)
initial_state = jnp.float32(0.0)

# Input data with a 'time' dimension to scan over
input_data = xr.DataArray(
    data=jnp.arange(1, 6, dtype=jnp.float32),
    dims=('time',),
    coords={'time': jnp.arange(5)}
)

# Define the function to apply at each step
# Takes (carry, x_slice) and returns (new_carry, y_slice)
def scan_body(carry, x_slice):
    # x_slice is the data for the current time step (no 'time' dim)
    new_carry = carry + x_slice.data # Access raw JAX array
    y_slice = new_carry * 2 # Example output for this step
    return new_carry, y_slice

# Perform the scan along the 'time' dimension
final_state, output_y = xarray_jax.scan(scan_body, initial_state, dim='time', xs=input_data)

print("Final State (Carry):", final_state)
print("\nOutput (ys):")
print(output_y)
# Expected Output:
# Final State (Carry): 15.0
#
# Output (ys):
# <xarray.DataArray (time: 5)>
# array([ 2.,  6., 12., 20., 30.], dtype=float32)
# Coordinates:
#   * time     (time) int32 0 1 2 3 4
