GraphRAG - Powered by LangChain
This is an implementation of GraphRAG as described in
https://arxiv.org/pdf/2404.16130
From Local to Global: A Graph RAG Approach to Query-Focused Summarization
Official implementation by the authors of the paper is available at:
https://github.com/microsoft/graphrag/
Guides
Why re-implementation 🤔?
Personal Preference
While I generally prefer utilizing and refining existing implementations, as re-implementation often isn't optimal, I decided to take a different approach after encountering several challenges with the official version.
Issues with the Official Implementation
- Lacks integration with popular frameworks like LangChain, LlamaIndex, etc.
- Limited to OpenAI and AzureOpenAI models, with no support for other providers.
Why rely on established frameworks like LangChain?
Using an established foundation like LangChain offers numerous benefits. It abstracts various providers, whether related to LLMs, embeddings, vector stores, etc., allowing for easy component swapping without altering core logic or adding complex support. More importantly, a solid foundation like this lets you focus on the problem's core logic rather than reinventing the wheel.
LangChain also supports advanced features like batching and streaming, provided your components align with the framework’s guidelines. For instance, using chains (LCEL) allows you to take full advantage of these capabilities.
Modularity & Extensibility-focused design
The APIs are designed to be modular and extensible. You can replace any component with your own implementation as long as it implements the required interface.
Given the nature of the domain, this is important for conducting experiments by swapping out various components.
Install
pip install langchain-graphrag
Projects
There are 2 projects in the repo:
langchain_graphrag
This is the core library that implements the GraphRAG paper. It is built on top of the langchain library.
An example code for local search using the API
Below is a snippet taken from the simple-app to show the style of API
and extensibility offered by the library.
Almost all the components (classes/functions) can be replaced by your own implementations. The library is designed to be modular and extensible.
# Reload the vector Store that stores # the entity name & description embeddings entities_vector_store = ChromaVectorStore( collection_name="entity_name_description", persist_directory=str(vector_store_dir), embedding_function=make_embedding_instance( embedding_type=embedding_type, model=embedding_model, cache_dir=cache_dir, ), ) # Build the Context Selector using the default # components; You can supply the various components # and achieve as much extensibility as you want # Below builds the one using default components. context_selector = ContextSelector.build_default( entities_vector_store=entities_vector_store, entities_top_k=10, community_level=cast(CommunityLevel, level), ) # Context Builder is responsible for taking the # result of Context Selector & building the # actual context to be inserted into the prompt # Keeping these two separate further increases # extensibility & maintainability context_builder = ContextBuilder.build_default( token_counter=TiktokenCounter(), ) # load the artifacts artifacts = load_artifacts(artifacts_dir) # Make a langchain retriever that relies on # context selection & builder retriever = LocalSearchRetriever( context_selector=context_selector, context_builder=context_builder, artifacts=artifacts, ) # Build the LocalSearch object local_search = LocalSearch( prompt_builder=LocalSearchPromptBuilder(), llm=make_llm_instance(llm_type, llm_model, cache_dir), retriever=retriever, ) # it's a callable that returns the chain search_chain = local_search() # you could invoke # print(search_chain.invoke(query)) # or, you could stream for chunk in search_chain.stream(query): print(chunk, end="", flush=True)
Clone the repo
git clone https://github.com/ksachdeva/langchain-graphrag.git
Open in VSCode devcontainer (Recommended)
Devcontainer will install all the dependencies
If not using devcontainer
- Clone the repository
git clone https://github.com/ksachdeva/langchain-graphrag.git cd langchain-graphrag
- Install dependencies (requires Python 3.10+ and uv)
Installation
You can install uv using the standalone installers or from PyPI:
Standalone installers
# On macOS and Linux curl -LsSf https://astral.sh/uv/install.sh | sh # On Windows powershell -ExecutionPolicy ByPass -c "irm https://astral.sh/uv/install.ps1 | iex"
From PyPI
# With pip pip install uv # Or pipx pipx install uv
If installed via the standalone installer, you can update uv to the latest version:
uv self update
Setting up the environment and dependencies installation
uv sync
examples/simple-app
This is a simple typer based CLI app.
In terms of configuration it is limited by the number of command line options exposed.
That said, the way core library is written you can easily replace any component by your own implementation i.e. your choice of LLM, embedding models etc. Even some of the classes as long as they implement the required interface.
Note:
Make sure to rename .env.example to .env if you are using OpenAI or AzureOpenAI
and fill in the necessary environment variables.
Indexing
# Step 1 - Index using convenient aliases uv run poe simple-app-indexer-azure # Uses Azure OpenAI uv run poe simple-app-indexer-openai # Uses OpenAI uv run poe simple-app-indexer-ollama # Uses Ollama # Or run the base command with custom parameters uv run poe simple-app indexer index --input-file examples/input-data/book.txt --output-dir tmp --cache-dir tmp/cache --llm-type azure_openai --llm-model gpt-4o --embedding-type azure_openai --embedding-model text-embedding-3-large
# To see more options $ uv run poe simple-app-indexer-help Usage: main.py indexer index [OPTIONS] ╭─ Options ───────────────────────────────────────────────────────────────────────────────────────────────────────────────────────╮ │ * --input-file FILE [default: None] [required] │ │ * --output-dir DIRECTORY [default: None] [required] │ │ * --cache-dir DIRECTORY [default: None] [required] │ │ * --llm-type [openai|azure_openai|ollama] [default: None] [required] │ │ * --llm-model TEXT [default: None] [required] │ │ * --embedding-type [openai|azure_openai|ollama] [default: None] [required] │ │ * --embedding-model TEXT [default: None] [required] │ │ --chunk-size INTEGER Chunk size for text splitting [default: 1200] │ │ --chunk-overlap INTEGER Chunk overlap for text splitting │ │ [default: 100] │ │ --ollama-num-context INTEGER Context window size for ollama model │ │ [default: None] │ │ --enable-langsmith --no-enable-langsmith Enable Langsmith │ │ [default: no-enable-langsmith] │ │ --help Show this message and exit. │ ╰─────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────╯
Global Search
# Global search using provider-specific aliases (add --query "your question") uv run poe simple-app-global-search-azure --query "What are the top themes in this story?" uv run poe simple-app-global-search-openai --query "What are the top themes in this story?" uv run poe simple-app-global-search-ollama --query "What are the top themes in this story?" # Or use the base command for custom configurations uv run poe simple-app-global-search --llm-type azure_openai --llm-model gpt-4o --query "What are the top themes in this story?"
$ uv run poe simple-app-query-help $ uv run poe simple-app query global-search --help Usage: main.py query global-search [OPTIONS] ╭─ Options ─────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────╮ │ * --output-dir DIRECTORY [default: None] [required] │ │ * --cache-dir DIRECTORY [default: None] [required] │ │ * --llm-type [openai|azure_openai|ollama] [default: None] [required] │ │ * --llm-model TEXT [default: None] [required] │ │ * --query TEXT [default: None] [required] │ │ --level INTEGER Community level to search [default: 2] │ │ --ollama-num-context INTEGER Context window size for ollama model [default: None] │ │ --enable-langsmith --no-enable-langsmith Enable Langsmith [default: no-enable-langsmith] │ │ --help Show this message and exit. │ ╰───────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────╯
Local Search
# Local search using provider-specific aliases (add --query "your question") uv run poe simple-app-local-search-azure --query "Who is Scrooge, and what are his main relationships?" uv run poe simple-app-local-search-openai --query "Who is Scrooge, and what are his main relationships?" uv run poe simple-app-local-search-ollama --query "Who is Scrooge, and what are his main relationships?" # Or use the base command for custom configurations uv run poe simple-app-local-search --llm-type azure_openai --llm-model gpt-4o --embedding-type azure_openai --embedding-model text-embedding-3-large --query "Who is Scrooge, and what are his main relationships?"
$ uv run poe simple-app query local-search --help Usage: main.py query local-search [OPTIONS] ╭─ Options ─────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────╮ │ * --output-dir DIRECTORY [default: None] [required] │ │ * --cache-dir DIRECTORY [default: None] [required] │ │ * --llm-type [openai|azure_openai|ollama] [default: None] [required] │ │ * --llm-model TEXT [default: None] [required] │ │ * --query TEXT [default: None] [required] │ │ --level INTEGER Community level to search [default: 2] │ │ * --embedding-type [openai|azure_openai|ollama] [default: None] [required] │ │ * --embedding-model TEXT [default: None] [required] │ │ --ollama-num-context INTEGER Context window size for ollama model [default: None] │ │ --enable-langsmith --no-enable-langsmith Enable Langsmith [default: no-enable-langsmith] │ │ --help Show this message and exit. │ ╰───────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────╯
See examples/simple-app/README.md for more details.
Available poe tasks
The project includes several convenient poe tasks (see pyproject.toml for complete list):
# Base command (for custom usage) uv run poe simple-app # Base: python examples/simple-app/app/main.py # Help commands uv run poe simple-app-help # General help uv run poe simple-app-indexer-help # Indexer help uv run poe simple-app-query-help # Query help # Development uv run poe test # Run tests uv run poe lint # Check code quality uv run poe format # Format code uv run poe typecheck # Type checking uv run poe docs-serve # Serve documentation locally # Indexing (with preconfigured provider settings) uv run poe simple-app-indexer-azure # Index with Azure OpenAI uv run poe simple-app-indexer-openai # Index with OpenAI uv run poe simple-app-indexer-ollama # Index with Ollama uv run poe simple-app-indexer # Basic indexer (requires additional parameters) # Reports uv run poe simple-app-report # Generate reports (requires prior indexing) # Global search (add --query "your question") uv run poe simple-app-global-search-azure --query "your question" # Azure OpenAI uv run poe simple-app-global-search-openai --query "your question" # OpenAI uv run poe simple-app-global-search-ollama --query "your question" # Ollama uv run poe simple-app-global-search --query "your question" # Basic (needs provider params) # Local search (add --query "your question") uv run poe simple-app-local-search-azure --query "your question" # Azure OpenAI uv run poe simple-app-local-search-openai --query "your question" # OpenAI uv run poe simple-app-local-search-ollama --query "your question" # Ollama uv run poe simple-app-local-search --query "your question" # Basic (needs provider params)
Development workflow
# 1. Setup uv sync # 2. Create a .env file (if not already present) and fill in your API keys and other configuration values. # 3. Quick start with aliases uv run poe simple-app-indexer-azure # Index with Azure OpenAI uv run poe simple-app-global-search-azure --query "What are the themes?" # Search with Azure OpenAI # 4. Or try different providers uv run poe simple-app-indexer-openai # Index with OpenAI uv run poe simple-app-local-search-openai --query "Who is the main character?" # Search with OpenAI # 5. For custom configurations, use the base command uv run poe simple-app indexer index --input-file your-file.txt --output-dir custom-output --llm-type azure_openai --llm-model gpt-4o # 6. Development (optional) uv run poe test && uv run poe lint # Test and check code
Roadmap / Things to do
The state of the library is far from complete.
Here are some of the things that need to be done to make it more useful:
- Add more guides
- Document the APIs
- Add more tests
