ViPERFX_RE

A reverse-engineered, modernized port of ViPER4Android. The DSP has been re-implemented from a decompilation of the original libv4a_fx.so, with audio processed in float32, dead code removed, and dependencies refreshed.

If you want ViPER on desktop instead of Android, see:

• ViPER4Windows
• ViPER4Mac

Module Architecture

ViPERFX_RE ships as two separate Magisk modules, both built around the same DSP engine (ViPERDSP) but integrated through different Android audio HAL interfaces. They are not interchangeable: each module is designed for a specific generation of Android’s audio framework. Installing the wrong one may either do nothing or cause boot issues.

Non-AIDL (Legacy) Module

The non-AIDL module uses the classic Android audio effect plugin interface (often informally referred to as the “HIDL-based” path due to its association with the older audio HAL stack).

• Why it no longer works on Android 15+: Google has migrated the audio effect framework from the legacy C-based plugin model to a stable AIDL HAL implementation. Devices launching with Android 15 no longer support loading effect_handle_t plugins, as the old framework path has been removed entirely. See AIDL for HALs for more details.

AIDL Module

The AIDL module implements the modern audio effect HAL introduced in Android 13, which became the only officially supported audio effect path for devices launching with Android 15 and later.

Which module should you install?

Run the following command:

adb shell ps -A | grep "audio.*aidl"
adb shell su -c 'service list | grep -i IFactory'

If your see any process related to audio HAL with "aidl" and the following output, you need the AIDL module. If not, the non-AIDL module should work.

... android.hardware.audio.effect.IFactory/default: [android.hardware.audio.effect.IFactory]

Disclaimers

• Tested hardware is narrow. Non-AIDL is confirmed on Pixel 8 Pro / Android 14. AIDL is confirmed on Pixel 8 Pro / Android 16. Other devices may bootloop, may need vendor-specific shims (e.g. ShadoV's PIXAML for AIDL on some Pixels), or may simply do nothing. Make a backup before flashing.
• Audio fidelity is best-effort. The DSP is decompiled from libv4a_fx.so. Subtle deviations from the original ViPER4Android are expected. If you spot one, please open a PR — the source is here precisely so it can be improved.
• Not for commercial use. This is a reverse-engineering project and may carry legal restrictions in your jurisdiction. Use at your own risk.

Installation

1. Download the module zip matching your device (non-AIDL vs. AIDL — see Which module should you install?) from the Releases page, and the ViPER4Android app.
2. Flash the Magisk module. Do not flash both modules.
3. Install the app.
4. Reboot. Open the app and verify effects are applied (use any of the diagnostic commands below to confirm).

Troubleshooting

[!NOTE] Both modules mount the driver .so and the audio_effects*.xml config into /vendor (and /system where present). This is verified with MagiskSU. If you use KernelSU or APatch, you may need a metamodule that allows mounting files into /vendor and /system. And the AIDL module is confirmed not compatible with AudioModificationLibrary, so disable it if you want to use AIDL module.

[!IMPORTANT] When opening an issue, capture the relevant logs while reproducing the problem and attach them. The commands below are listed in the order you should run them when troubleshooting. Run the section that matches your module.

Log Tags

Both drivers (and the shared DSP) log under a single tag, ViPER4Android. The AHAL_* tags come from the AOSP AIDL effect framework and appear only on the AIDL path.

Non-AIDL (Legacy)

The non-AIDL driver is libv4a_re.so. It receives parameters over the classic effect_param_t command interface.

1. Check if the driver is loaded

adb logcat -d -s 'ViPER4Android:*' | grep -E 'Welcome|version|created'

Expected (the version line must match the module you flashed):

ViPER4Android: Welcome to ViPER FX
ViPER4Android: Current version is ...
ViPER4Android: ViperContext created

If missing, the audio framework never loaded the .so. Verify the config was patched (audio_effects.xml under /vendor/etc and/or /system/etc):

adb shell su -c 'grep -r v4a /vendor/etc /system/etc 2>/dev/null'

Expected:

/vendor/etc/audio_effects.xml:        <library name="v4a_re" path="libv4a_re.so"/>
/vendor/etc/audio_effects.xml:        <effect name="v4a_standard_re" library="v4a_re" uuid="90380da3-8536-4744-a6a3-5731970e640f"/>
/system/etc/audio_effects.xml:        <library name="v4a_re" path="libv4a_re.so"/>
/system/etc/audio_effects.xml:        <effect name="v4a_standard_re" library="v4a_re" uuid="90380da3-8536-4744-a6a3-5731970e640f"/>

Then verify the SELinux label on the library itself:

adb shell su -c 'ls -Z /vendor/lib*/soundfx/libv4a_re.so'

Expected:

u:object_r:vendor_file:s0 /vendor/lib/soundfx/libv4a_re.so
u:object_r:vendor_file:s0 /vendor/lib64/soundfx/libv4a_re.so

2. Dump the audioserver effect list

adb shell su -c 'dumpsys media.audio_flinger | grep -E -A5 -B7 "90380da3"'

Expected:

1 effects for session 0
    In buffer                         Out buffer                           Active tracks:
    0xb40000718d612da0 -> 0x72579a1000   0x72579a1000 -> 0xb40000718d612da0   0
    Effect ID 11:
        Session State Registered Internal Enabled Suspended:
        00000   002   y          n        y       n
        Descriptor:
        - UUID: 90380da3-8536-4744-a6a3-5731970e640f
        - TYPE: ec7178ec-e5e1-4432-a3f4-4657e6795210
        - apiVersion: 00000000
        - flags: 00005010 (conn. mode: insert, insert pref: last, volume mgmt: none, input mode: direct, output mode: direct)
        - name: ViPERDSP
        - implementor: viper.WYF, Martmists, Iscle, llsl

3. Check SELinux denials

adb logcat -d -s audit | grep v4a
# or, broader:
adb logcat -d | grep -E 'avc.*denied.*(v4a|soundfx)'

If you see avc: denied lines naming the audio process and the driver .so, the live policy injection from post-fs-data.sh did not stick. This is the single most common cause of "module installs cleanly but audio is unprocessed." The legacy effect runs inside audioserver (or the legacy audio HAL), not the AIDL service.

AIDL

The AIDL driver is libv4a_aidl.so. It publishes a binder service, viper.control, when the audio HAL loads it, the app sends all parameters, DDC/convolver data, and status requests over that service.

1. Check if the AIDL driver is loaded and the service is registered

adb logcat -d -s 'ViPER:*' | grep -E 'Welcome|version|AServiceManager|context created'

Expected (the version line must match the module you flashed; the addService -> 0 line must be present):

ViPER: Welcome to ViPER FX
ViPER: Current version is ...
ViPER: Ctrl: AServiceManager_addService viper.control -> 0
ViPER: ViPER (AIDL) context created, sample_rate=...

Confirm the service is published:

adb shell su -c 'service list | grep -i viper'

Expected:

... viper.control: [viper.fx.IViperControl]

If Welcome to ViPER FX is missing, the audio framework never loaded the .so. Verify the config was patched:

adb shell su -c 'grep v4a /vendor/etc/audio_effects_config.xml'

Expected:

<library name="v4a_aidl" path="libv4a_aidl.so"/>
<effect name="v4a_standard_aidl" library="v4a_aidl" uuid="90380da3-8536-4744-a6a3-5731970e640f" type="7261676f-6d75-7369-6364-28e2fd3ac39e"/>

Then verify the SELinux label on the library itself:

adb shell su -c 'ls -Z /vendor/lib*/soundfx/libv4a_aidl.so'

Expected:

u:object_r:vendor_file:s0 /vendor/lib/soundfx/libv4a_aidl.so
u:object_r:vendor_file:s0 /vendor/lib64/soundfx/libv4a_aidl.so

2. Dump the audioserver effect list

adb shell su -c 'dumpsys media.audio_flinger | grep -E -A5 -B7 "90380da3"'

Expected:

1 effects for session 0
    In buffer                               Out buffer                                 Active tracks:
    0xb40000778e915020 -> 0xb40000778e959220   0xb40000778e959220 -> 0xb40000778e915020   0
    Effect ID 1035:
        Session State Registered Internal Enabled Suspended:
        00000   003   y          n        y       n
        Descriptor:
        - UUID: 90380da3-8536-4744-a6a3-5731970e640f
        - TYPE: 7261676f-6d75-7369-6364-28e2fd3ac39e
        - apiVersion: 00020000
        - flags: 00410208 (conn. mode: insert, insert pref: first, volume mgmt: none, device indication: requires updates, input mode: not set, output mode: not set, hardware acceleration: non-tunneled, offloadable)
        - name: ViPER4Android
        - implementor: ViPER520 / RE Team

3. Check the binder service SELinux declaration

viper.control must be declared as a typed service and permitted by policy, otherwise registration or the app's find is silently denied.

adb shell su -c 'grep -i viper /vendor/etc/selinux/vendor_service_contexts'

Expected:

viper.control    u:object_r:viper_control_service:s0

Check for denials while toggling the master switch or dragging a slider in the app:

adb logcat -d -s audit | grep -iE 'viper.control|service_manager'
# or, broader:
adb shell su -c 'dmesg | grep -iE "avc.*viper.control"'

Expected: no output. Common denials and what they mean:

• denied { add } ... name=viper.control ... tclass=service_manager: the HAL could not register the service
• denied { find } ... name=viper.control scontext=u:r:untrusted_app ...: the app could not look up the service

4. Filter logcat by the audio HAL process

# Find the audio HAL process name (device-specific)
adb shell ps -A | grep audio

Expected (Pixel 8 Pro):

audioserver   ...  S android.hardware.audio.service-aidl.aoc
audioserver   ...  S audioserver

Then filter logcat by the HAL PID:

adb logcat --pid=$(adb shell pidof android.hardware.audio.service-aidl.aoc | tr -d '\r') -s 'ViPER:*' 'AHAL_EffectImpl:*'

The HAL process name is device-specific.

Building

Prerequisites: Android NDK, CMake, Make. Set ANDROID_NDK_HOME (or ANDROID_NDK_ROOT).

make libs   # build libv4a_re.so for arm64-v8a and armeabi-v7a
make zip    # build + package a flashable Magisk module zip

Credits

• Zhuhang and ViPER520 — original ViPER4Android.
• Martmists, Iscle, llsl — reverse-engineering of the DSP.
