GPIOnext+

Pardon Our Dust!

While the base code works, I am currently testing the installer/updater and various system configurations (Pi3/4/5, Buster/Bullseye/Bookworm, 32bit/64bit). This takes a bit of time, but I'm working hard to get through all of the testing as quickly as possible. In the meantime, the legacy code is still available. If you have problems with the installer, you should be able to clone the Legacy-Code branch to /opt/gpionext, then run the setup.sh script.

Thank you for your patience!

This is a fully featured GPIO to HID controller Daemon that is fully compatible with RetroPie (and PiPlay, RIP). It includes an intuitive config utility and an easy to use CLI wrapper in order to quickly make changes on the fly. In this long overdue revamp, we have migrated to a core handler written in Rust. This lower level language gets us closer to the metal reducing the lag induced by the Python interpreter.

What's New?

Precompiled Rust Core for lower latency
Support for popular I2C expanders (MCP23017 & PCF8574) adds virtual GPIO pins for all of your arcade needs
Audio HAT auto detection - automatically detect audio HAT and keep GPIOnext from using those pins
Improved terminal configuration tool allows configuration even on "lite" OS's or over SSH/Xterm
supports matrix pin combinations for additional configurable buttons
It supports system commands! (you can map volume/shutdown/etc to buttons)

Coming Soon

Support for ADS1115 I2C analog → digital converter for high resolution joysticks

1. Installation

The easiest way to install GPIOnext is to use our bootstrap installer. This will download the latest release and handle all dependencies automatically.

Latest Version (Recommended)

(root required):

curl -fL https://raw.githubusercontent.com/mholgatem/GPIOnext/main/manage | bash

Specific Version

If you need to install a specific version (root required):

curl -fL https://raw.githubusercontent.com/mholgatem/GPIOnext/main/install.sh | bash -s -- install --version v0.1.0

Legacy Version (not compatible with recalBox/batocera)

To install the original Python-only implementation:

curl -fL https://raw.githubusercontent.com/mholgatem/GPIOnext/refs/heads/Legacy-Code/install.sh | sudo bash

2. Configuration

Once installed, you should run the configuration tool to map your buttons and joysticks.

Basic Setup

gpionext config

This interactive tool will guide you through:

Detecting pressed pins.
Mapping pins to "Commands", "Keys", or "Joypad Buttons/Axes".
Setting up multi-button combos.

Peripheral Types

Button: Triggers a standard joystick button (e.g., Button A, Start).
Key: Triggers a keyboard key with auto-repeat.
Axis: Maps pins to analog joystick directions (Up/Down/Left/Right).
Command: Executes a shell command when the button is pressed.

3. CLI Commands & Settings

GPIOnext provides a powerful CLI wrapper via the gpionext command.

Daemon Management

gpionext start: Enable and start the background daemon.
gpionext stop: Stop the daemon.
gpionext reload: Send SIGHUP to the daemon to hot-reload the configuration without a full restart.
gpionext disable: Stop and disable the auto-start service.

Updates & Removal

gpionext update: Pull the latest source and binary from GitHub.
gpionext update --version <version>: Update to a specific version.
gpionext remove: Completely remove GPIOnext from the system, including /opt/gpionext, the systemd service, and udev rules.

Diagnostics

gpionext journal: Stream live log output from the daemon (Press Ctrl+C to exit).
gpionext test [1-4]: Run jstest on one of the four virtual joypads created by GPIOnext.

Global Settings

Settings are applied immediately and will restart the daemon:

gpionext set combo_delay <ms>: The window (default 50ms) to detect multi-button combos.
gpionext set key_hold_delay <ms>: The delay (default 350ms) before keyboard auto-repeat starts.
gpionext set debounce <ms>: Button debounce time (default 1ms).
gpionext set pulldown <true|false>: Use internal pulldown resistors (default: false/pullup).
gpionext set use_i2c <true|false>: Enable support for MCP23017 or ADS1115 hardware.
gpionext set dev <true|false>: Enable verbose logging to the system journal.

4. Running GPIOnext

Systemd Service: GPIOnext runs as a systemd service (gpionext.service). It starts automatically on boot if enabled.
Physical Pins: GPIOnext uses physical BOARD numbering (1-40) rather than BCM numbering.
I2C Safety: If use_i2c is enabled, GPIOnext will automatically avoid claiming pins 3 and 5 (SDA/SCL) as standard GPIOs.
Conflicts: GPIOnext will check for and offer to disable competing drivers like retrogame.
Hot-Reload: You can modify your configuration using gpionext config while the daemon is running, and then run gpionext reload to apply the changes instantly.
