Qwen3.8-Flash-Next on one DGX Spark

v5.3: NVIDIA's FP4-Local checkpoint on vLLM 0.32 — 9 of 12 gauntlet pages, 409,600-token context, 1.66M-token KV pool

One box, one model, three commands. The default checkpoint is nvidia/Qwen3.8-Flash-Next-FP4-Local, served as shipped. hibrid48 runs on the same image: swap the model: line in recipe.yaml, as do hibrid48-uncensored and INT4-AutoRound by @azampatti.

Side by side with v5.1 — every number, gauntlet page and quality verdict: myllmbox.com/?a=mbx-v53&b=mbx-v51

v5.3 (2026-10-20)

v5.2 stays available: git checkout v5.2.

New

1. vLLM 0.32.0, with our patches rebased: RecoverSSM (vllm#58863 by @jschmied, now with its exact replay of accepted tokens), the n-gram table on NVMe, the fused multi-step MTP draft, dynamic draft depth.
2. Default checkpoint: NVIDIA's FP4-Local, weights as shipped: NVFP4 experts with compressed scales (they stay compressed on the GPU), MXFP8 dense layers.
3. Full CUDA graphs for decode: table reads run off the critical path, so decode no longer leaves the graph.
4. Faster drafts: FP8 drafter projections, a two-stage draft head and draft-depth bookkeeping kept on the GPU — by @Alssndr0 (#8). All exact: every draft is verified. Draft depth now ranges 1–7.
5. 400k context by default (YaRN; config by @vr8vr8, 100 % needle retrieval at 407,552 tokens measured by @grau_marc). On vLLM 0.32 it needs the M-RoPE cache fix from vllm#62409 by @wtogami, built into the image (without it a request crashes the engine past 262,144 tokens). And an fp8 KV cache: 1,661,476 tokens in the same 27 GB.
6. One image for four checkpoints: FP4-Local (default), hibrid48, hibrid48-uncensored and INT4-AutoRound; run.sh applies each one's settings itself.

Measured (one DGX Spark, image v5.3, the shipped recipe.yaml)

Throughput (tok/s, one DGX Spark, image v5.3, the shipped recipe.yaml; thinking off, every stream kept busy, 300-s windows, 3 runs each)

v5.2 (2026-10-05)

v5.1 stays available: git checkout v5.1.

New

1. Default checkpoint: INT4-AutoRound by @azampatti, as published. Its 49 GB fp8 n-gram table is served from disk by the image's table reader like hibrid48's, so the memory goes to weights and KV; its fp8 side layers load through his vllm_fp8_hybrid module (MIT, after @Saren-Arterius's spark-dflash-hybrid-fp8).
2. Same stack as v5.1: RecoverSSM, dynamic draft depth up to 7, sampled drafts with block verification, 16 seats. With this checkpoint the draft uses its own MTP head routing 10 experts, and run.sh sets that up (cache/draft-k10).
3. One image for all three checkpoints. hibrid48 and hibrid48-uncensored run on the v5.2 image exactly as on v5.1 (same table map).

Measured (one DGX Spark, image v5.2, the shipped recipe.yaml; gauntlet and c=1–6 on one box, c=8–16 on a second)

v5.1 → v5.2 per prompt (side by side on myllmbox.com; thinking off, aggregate tok/s of all streams, averages of 3 runs; c=1 = one full answer, c≥2 = 300 s with every stream kept busy)

v5.1 (2026-10-02)

v5 stays available: git checkout v5.

New

1. RecoverSSM for the model's recurrent (GDN) layers and the PLE short conv — vllm-project/vllm#58863 by @jschmied, ported to 0.30. The drafts are verified from one saved state and only the accepted tokens are replayed: faster steps, and no per-draft state copies, so a deeper draft costs no memory. Pool 876,726 tokens at depth 7 (v5: 813,457 at depth 6).
2. Dynamic draft depth is the default, up to 7 (v5: opt-in, up to 6). Fixed K=5: mtp_depth.mode: off and the two commented K=5 lines in recipe.yaml.
3. Optional front proxy (proxy: section in recipe.yaml, absent = no proxy): keepalive pings during long prefill and thinking, a generic loop guard (any phrase repeated, or 2222… / ?!?!… runs), your own pattern list, and optional logging of every request and response to cache/requests/. A cut answer ends with <stopped reason="repetition"/> (or reason="pattern") and frees the seat. See Front proxy.
4. GB10 plan table for the model's small decode GEMMs, off by default (MBX_SKINNY_GEMM_SM12X: "1" in env:): faster kernels, neutral end to end on one Spark. Found and first tuned for two Sparks by @sethforprivacy (vllm-project/vllm#59605); the table here is tuned for one.

Measured (one DGX Spark, image v5.1, the shipped recipe.yaml, one bench/full.py run)

v5 → v5.1 per prompt (same box, thinking off, v5 = the dynamic-depth runs below, average tok/s of all streams together, averages of 3 runs; c=1 = one full answer, c≥2 = 300 s with every stream kept busy)

Dynamic draft depth

How the dynamic depth works. Speculative decoding drafts several tokens ahead and the model checks them in one step; how many of them survive depends on what is being written. Long prose keeps about the first three, code and JSON often all six. A fixed depth is therefore too deep for prose (every rejected draft is wasted work) and too shallow for code. With mode: dynamic every request keeps its own depth between min and num_speculative_tokens: it watches, over its last window steps, how often its deepest drafted position was accepted, and moves one or two steps deeper when that rate is above promote and shallower when it is below demote. Requests that are batched together draft their average depth. Prose settles at 3, code and JSON at 5–6, and a thinking-on request changes depth between its reasoning and its answer.

v5 vs every fixed depth on one full thinking-on request (the pasture prompt: reasoning, then an HTML/JS scene), each phase on its own, because answers think for different lengths (averages of 3 runs, tok/s):

v5 and v5.1 vs fixed K=3 and K=5 at every concurrency, aggregate tok/s (same box and image, thinking off, averages of 3 runs; c=1 = one full answer, c≥2 = 300 s with every stream kept busy; fixed K=3 / K=5 = mode: dynamic with min pinned and promotion off). The best value of each row is bold; the mixed prompt is in the table above.

Long prose (7,000-word story)

Code (TypeScript)

Structured output (JSON schema)

On by default since v5.1 (deepest depth 7; the tables above are v5, deepest 6). Fixed K=5 instead, in recipe.yaml: mtp_depth.mode: off and swap in the two commented K=5 lines next to speculative-config and compilation-config.

Knobs (mtp_depth in recipe.yaml; run.sh writes them to cache/mbx-depth.json, and the serve re-reads that file while it runs — edit it to change them live):

The deepest depth is num_speculative_tokens; the capture sizes must cover every depth × seats (the shipped list covers 3 … 7 × 16).

Front proxy (v5.1, optional)

Uncomment the proxy: section in recipe.yaml. run.sh then starts a second container (qwen38-flash-next-proxy) on the public port and moves vLLM to 127.0.0.1:<port+1>; ./stop.sh removes both.

Measured performance (v5, one DGX Spark, vm.compaction_proactiveness=0)

2026-10-01, vLLM 0.30, image v5, hibrid48, bf16 KV, 16 seats, Marlin MoE. Mixed prompt (a code task plus its prose explanation), thinking off, averages of 3 runs per row. c=1 is one full answer; c≥2 is 300 s with every stream kept busy, so a finished request is replaced at once and its new prompt's prefill is part of the average.

Single-stream peak: 86.4 tok/s — the best 10-second window, while a thinking-on request writes its code. Prefill: 1,988 tok/s on a 128k-token prompt, first token in 0.71 s on a 1k prompt. The KV pool is 830,582 tokens with mode: off (K=5) and 813,457 with mode: dynamic (K=6 graphs); the v4 and v3 ladders are in their tags (git checkout v4).

Quality (measured on this model, thinking on)

All three checkpoints, lm-evaluation-harness against a running serve, thinking on, temperature 0.6 / top-p 0.95 / top-k 20, a 32k-token budget per answer, HumanEval complete and a fixed 200-question subset (seed 123123123) of the others — the same 763 questions for every column. Qwen publishes no numbers for these four tests (its card reports LiveCodeBench v6 91.9, GPQA Diamond 91.7, IFBench 81.3, SWE-bench Pro 62.5). The v4 changes are output-exact (speculative decoding keeps the model's own distribution), so the scores carry over.

The IFEval gain is the one difference larger than the subsets' sampling error (about ±3 points); the other deltas are one to four questions each. The abliterated body thinks shorter (median reasoning −8 %, 90th percentile −27 %) and runs away half as often. Published leaderboard numbers use other prompts, few-shot counts and full sets — a sanity band, not a column.

What changed

v5.2 (2026-10-05): the INT4-AutoRound checkpoint is the default — +13 to +40 % over v5.1; hibrid48 and its uncensored twin stay one line away. See v5.2. v5.1 stays available: git checkout v5.1.

v5.1 (2026-10-02): RecoverSSM, dynamic depth up to 7 by default, optional front proxy. See v5.1. v5 stays available: git checkout v5.

v5 (2026-10-01): dynamic draft depth, opt-in. Per-request draft depth from measured acceptance, live-tunable knobs, +12 to +19 % on long prose at every concurrency, level on mixed text, JSON and code (Dynamic draft depth). With mode: off (the default) the serve is v4. v4 stays available: git checkout v4.

v4 (2026-09-25): vLLM 0.30, five sampled draft tokens, an 830k-token pool and 16 seats.

1. Engine: upstream vLLM 0.30 (was 0.29), with the fused multi-step MTP draft for this model's attention (proposed upstream as vllm-project/vllm#58449).
2. Five draft tokens, sampled. The drafter proposes 5 tokens instead of 3 and samples them from its own distribution (draft_sample_method: probabilistic); the model checks them with the exact probability-ratio test and block verification. Output quality cannot change — the text follows the model's distribution either way — but more drafts survive: 5.1 accepted per step on code (v3: 3.4 of 4).
3. The n-gram table no longer takes memory. On the first boot the image prepares a table map in ./cache (~31G, a few minutes, once; it works for both checkpoints) and serves from it. The memory that frees goes to the KV pool: 8G fp8 → 27G bf16 = 830,582 tokens (3.17 full 262K requests), and 16 seats instead of 8.
4. Boots in about four minutes instead of about twelve (load-format: fastsafetensors, and no per-boot compilation on 0.30).

v3 stays available: git checkout v3 (image …-vllm:v3, vLLM 0.29, K=3, fp8 KV 8G, 8 seats).

v3 (2026-09-14): vLLM 0.29 and a 4-bit output head. The engine moved from the vendor SM121 pin to vLLM 0.29, and the checkpoint's 1.18 GB bf16 output head became 0.33 GB of NVFP4 (hibrid48) — it was 27 % of every decode step: 60 tok/s single-stream at 17.7 engine steps/s (v2: 50 at 14.4). v2 stays available: git checkout v2.

Quick start

git clone https://github.com/myllmbox/qwen38-flash-next-recipe.git
cd qwen38-flash-next-recipe
./run.sh        # downloads ~102G from HF on first run, serves the OpenAI API on :8000

./stop.sh stops it. ./view.sh shows live stats (throughput, KV usage, speculative-decoding acceptance). Requirements: a DGX Spark with docker + the NVIDIA container runtime, and free disk under ./cache for the table map (~31G for FP4-Local and hibrid48, ~52G for INT4-AutoRound). A boot reaches healthy in about seven minutes (weights ~2 min); the very first boot on a box also prepares the map and compiles kernels (~15 min, once).

All configuration lives in recipe.yaml — one file: image, weights repo, port, context length, KV budget, every vLLM flag. Nothing else to edit.

curl http://127.0.0.1:8000/v1/chat/completions -H 'Content-Type: application/json' -d '{
  "model": "Qwen/Qwen3.8-Flash-Next",
  "messages": [{"role": "user", "content": "hello"}]
}'

Hugging Face token. Anonymous downloads are rate-limited, and gated models (license-agreement repos, e.g. uncensored variants) refuse anonymous access. run.sh looks for HF_TOKEN, then ~/.cache/huggingface/token (hf auth login), and asks for one when the repo is gated — after you accepted its agreement on the model page. Nothing is stored by the kit.

Which checkpoint

Four checkpoints run on this image; recipe.yaml ships with the first active and the others commented out under it. Switching is comment one line, uncomment another, ./run.sh; run.sh applies each checkpoint's settings itself:

The uncensored repo is gated: open its Hugging Face page, accept the agreement, then hf auth login (or export HF_TOKEN=…) before ./run.sh — the kit checks both and tells you what is missing. Running several checkpoints at different times? Set served-model-name to something distinct so clients and logs can tell them apart. FP4-Local weighs ~102 GB, the two hibrid48 checkpoints 98 GB each; INT4-AutoRound is ~120 GB and prepares its own table map in cache/ (~52G) on its first boot.

Memory on a Spark: what the kit does about it

Unified memory means the GPU driver, the page cache and the kernel share one pool, and this serve uses most of it on purpose: the weights + the 27G KV pool + graphs and host processes. The kit never asks for your password; it stabilises memory with what a user may do:

• waits after removing the old container until the box reports ≥ 100G available (unified memory takes 30–60 s to come back after a container dies; launching earlier gives a phantom "CUDA out of memory"),
• evicts its own checkpoint files from the page cache before launch (dd iflag=nocache, no privileges),
• the image's loader reads each weight file once and drops it from the page cache as it goes.

Measured on v5.3: about 1.5–2 GB free at its lowest during 16-stream runs. If you run other things on the box, set kv-cache-memory to 26G.

One thing you can do, with root, and it is worth ~10 % on a serve that runs this close to the memory edge:

./tune-host.sh      # sets vm.compaction_proactiveness=0; shows the command, asks, then sudo prompts; persisted

run.sh reads the value before every launch (no privilege needed) and warns while it is not 0; it never applies the change itself. The kernel's background page compactor migrates pages to build large contiguous blocks; on a Spark the GPU's memory is those pages, so every migration first unmaps them from the GPU — measured as a 4–5 s slowdown every ~37 s. A serving box allocates once at boot and gains nothing from the upkeep.

Tuning (recipe.yaml)

• max-model-len: 409600 + hf-overrides: YaRN, 400k context (default). For the native 262,144: set max-model-len: 262144 and remove the hf-overrides line.
• kv-cache-memory (bytes): 27G fp8 = 1,661,476 tokens (26G for more headroom); with INT4-AutoRound run.sh uses 24G = 1,476,867 tokens.
• max-num-seqs 16: with RecoverSSM each request holds one recurrent state (no per-draft copies).
• speculative-config up to 7 sampled draft tokens with block verification, depth chosen per request (mtp_depth).
• use-replayssm: true: RecoverSSM. Remove it for the stock GDN verify path (more memory per seat, slower steps).
• compilation-config: full CUDA graphs for decode; the capture sizes cover every draft depth × seats (16 × 8 = 128). Shorten them only together with max-num-seqs, or the upper rungs decode without CUDA graphs.
• block-size: 3312: the model's attention ring (12 at K=7) must divide the attention block; vLLM raises it to 6624.
• docker_args: --security-opt seccomp=unconfined: required by the image's table reader; the container still runs unprivileged otherwise.
• load-format: mbx: the image's loader. Keep it: FP4-Local's compressed expert scales go through it.
• max-num-batched-tokens: also the image-input encoder budget — 8192 fits one max-resolution image (~4.1k tokens).
• async-scheduling on. Thinking is ON by default (model native); disable per request with "chat_template_kwargs": {"enable_thinking": false} for max speed on structured output.
• mtp_depth: dynamic draft depth, on by default — see Dynamic draft depth.
• proxy: optional front proxy, absent by default — see Front proxy.
• patches (server): vLLM patches from patches/, applied at launch over the image's files; the image itself is unchanged. A patch made for an older image stops run.sh if it does not fit. The QSA logits-workspace fix (vllm-project/vllm#57105 by Thien Tran, reported for this kit by @anzax, #5) is part of vLLM 0.32.

What's in the image

myllmbox/qwen38-flash-next-vllm:v5.3 — upstream vllm/vllm-openai:v0.32.0 plus patches, each an anchored or sha256-checked edit that refuses to apply twice and fails the build if its target moved:

1. RecoverSSM (vllm-project/vllm#58863 by @jschmied, with its exact replay of accepted tokens), base files sha256-checked,
2. the n-gram tables (NVFP4, and INT4-AutoRound's fp8) on the image's table library (binary), read from NVMe off the critical path,
3. fused multi-step draft metadata — the code proposed upstream as vllm-project/vllm#58449,
4. dynamic draft depth in full CUDA graphs, with the depth library (binary),
5. the image's loader and the Marlin MoE kernel for compressed NVFP4 expert scales (binaries),
6. faster drafts by @Alssndr0 (Apache-2.0): FP8 drafter projections and the two-stage draft head, with its bases for FP4-Local and hibrid48,
7. the output-head and hyper-connection quantization configs, the draft scale, and GB10 small-batch kernels for the bf16 output head and the MXFP8 layers,
8. INT4-AutoRound support: its fp8 side layers (azampatti's vllm_fp8_hybrid, MIT) and its fp8 n-gram table,
9. the M-RoPE cache fix for YaRN: backport of vllm-project/vllm#62409 by @wtogami,
10. the front proxy (mbx_proxy), started only with a proxy: section.

Digest: sha256:cf52ff577851827110b34958bb21ced187369c2851f7de798eecd2de45ffa1de.

v5.2 (…-vllm:v5.2, vLLM 0.30, digest sha256:76eda2f6c0e51fd2a9913d97b6f36abd829965ca8cad661195fd70ec763ee7a3), v5.1 (…-vllm:v5.1, digest sha256:733f1a576e7e5a4192b0475ac4c3c53b5e5f27a182e92de0972ce88853ce1edd), v5 (…-vllm:v5, digest sha256:695882cca3c64ff49d538fd37d72ae7db4537d039ff633da67909648b5ba4676), v4 (…-vllm:v4, digest sha256:51629f438f5ba3f7a96db110826c783d69b91a6851c43fb07d447644f157dcc4), v3 (…-vllm:v3, vLLM 0.29, digest sha256:61d2bc6ba5977024895734d0ef94918ac806d936c4e17a263906e246599f9862), v2 and v1 stay available: git checkout v5.2 / v5.1 / v5 / v4 / v3 / v2 / v1.

The full box

This kit serves one model, plain. The same model also runs under myllmbox with a public HTTPS tunnel, keepalive and multi-model management — same image, same weights.

License

Weights: Qwen Community License 1.0 (permissive incl. commercial; >100M MAU/$20M-revenue products must display the model name; Model-as-a-Service businesses need a separate Qwen license). Kit scripts and image patches: MIT. The table library is distributed in binary form inside the image.
