pi-subagents

Pi extension for delegating tasks to subagents with chains, parallel execution, TUI clarification, and async support.

https://github.com/user-attachments/assets/702554ec-faaf-4635-80aa-fb5d6e292fd1

Installation

pi install npm:pi-subagents

To remove:

npx pi-subagents --remove

If you use pi-prompt-template-model, you can wrap subagent delegation in a slash command:

---
description: Take a screenshot
model: claude-sonnet-4-20250514
subagent: browser-screenshoter
cwd: /tmp/screenshots
---
Use url in the prompt to take screenshot: $@

Then /take-screenshot https://example.com switches to Sonnet, delegates to the browser-screenshoter agent with /tmp/screenshots as the working directory, and restores your model when done. Runtime overrides like --cwd=<path> and --subagent=<name> work too.

pi-prompt-template-model is entirely optional — pi-subagents works standalone through the subagent tool and slash commands. If you want reusable prompt-template workflows on top of subagents, including /chain-prompts and compare-style prompts like pi-prompt-template-model's /best-of-n example, install pi-prompt-template-model separately and copy any example prompts you want from its examples/ directory into ~/.pi/agent/prompts/.

Agents

Agents are markdown files with YAML frontmatter that define specialized subagent configurations.

Agent file locations:

Scope	Path	Priority
Builtin	`~/.pi/agent/extensions/subagent/agents/`	Lowest
User	`~/.pi/agent/agents/{name}.md`	Medium
Project	`.pi/agents/{name}.md` (searches up directory tree)	Highest

Use agentScope parameter to control discovery: "user", "project", or "both" (default; project takes priority).

Builtin agents: The extension ships with ready-to-use agents — scout, planner, worker, reviewer, context-builder, researcher, and delegate. They load at lowest priority so any user or project agent with the same name overrides them. Builtin agents appear with a [builtin] badge in listings and cannot be modified through management actions (create a same-named user agent to override instead).

Note: The researcher agent uses web_search, fetch_content, and get_search_content tools which require the pi-web-access extension. Install it with pi install npm:pi-web-access.

Agent frontmatter:

---
name: scout
description: Fast codebase recon
tools: read, grep, find, ls, bash, mcp:chrome-devtools  # mcp: requires pi-mcp-adapter
extensions:                 # absent=all, empty=none, csv=allowlist
model: claude-haiku-4-5
thinking: high               # off, minimal, low, medium, high, xhigh
skill: safe-bash, chrome-devtools  # comma-separated skills to inject
output: context.md           # writes to {chain_dir}/context.md
defaultReads: context.md     # comma-separated files to read
defaultProgress: true        # maintain progress.md
interactive: true            # (parsed but not enforced in v1)
maxSubagentDepth: 1          # tighten nested delegation for this agent's children
---

Your system prompt goes here (the markdown body after frontmatter).

The thinking field sets a default extended thinking level for the agent. At runtime it's appended as a :level suffix to the model string (e.g., claude-sonnet-4-5:high). If the model already has a thinking suffix (from a chain-clarify override), the agent's default is not double-applied.

Extension sandboxing

Use extensions in frontmatter to control which extensions a subagent can access:

# Field absent: all extensions load (default behavior)

# Empty field: no extensions
extensions:

# Allowlist specific extensions
extensions: /abs/path/to/ext-a.ts, /abs/path/to/ext-b.ts

Semantics:

extensions absent → all extensions load
extensions: empty → --no-extensions
extensions: a,b → --no-extensions --extension a --extension b

When extensions is present, it takes precedence over extension paths implied by tools entries.

MCP Tools (optional)

If you have the pi-mcp-adapter extension installed, subagents can use MCP server tools directly. Without that extension, everything below is ignored — MCP integration is entirely optional.

Add mcp: prefixed entries to the tools field in agent frontmatter:

# All tools from a server
tools: read, bash, mcp:chrome-devtools

# Specific tools from a server
tools: read, bash, mcp:github/search_repositories, mcp:github/get_file_contents

Syntax	Effect
`mcp:server-name`	All tools from that MCP server
`mcp:server-name/tool_name`	One specific tool

The mcp: items are additive — they don't affect which builtins the agent gets. tools: mcp:chrome-devtools (with no regular tools listed) gives the agent all default builtins plus chrome-devtools tools. To restrict builtins, list them explicitly: tools: read, bash, mcp:chrome-devtools.

Subagents only get direct MCP tools when mcp: items are explicitly listed. Even if your mcp.json has directTools: true globally, a subagent without mcp: in its frontmatter won't get any direct tools — keeping it lean. The mcp proxy tool is still available for discovery if needed.

First-run caveat: The MCP adapter caches tool metadata at startup. The first time you connect to a new MCP server, that cache is empty, so tools are only available through the generic mcp proxy. After that first session, restart pi and direct tools become available.

Resolution priority: step override > agent frontmatter > disabled

Quick Commands

Command	Description
`/run <agent> <task>`	Run a single agent with a task
`/chain agent1 "task1" -> agent2 "task2"`	Run agents in sequence with per-step tasks
`/parallel agent1 "task1" -> agent2 "task2"`	Run agents in parallel with per-step tasks
`/subagents-status`	Open the async status overlay for active and recent runs
`/agents`	Open the Agents Manager overlay

All commands validate agent names locally and tab-complete them, then route through the tool framework for full live progress rendering. Results are sent to the conversation for the LLM to discuss.

Per-Step Tasks

Use -> to separate steps and give each step its own task with quotes or --:

/chain scout "scan the codebase" -> planner "create implementation plan"
/parallel scanner "find security issues" -> reviewer "check code style"

Both double and single quotes work. The -- delimiter also works: /chain scout -- scan code -> planner -- analyze auth.

Steps without a task inherit behavior from the execution mode: chain steps get {previous} (output from the prior step), parallel steps get the first available task as a fallback.

/chain scout "analyze auth" -> planner -> implementer
# scout: "analyze auth", planner: gets scout's output, implementer: gets planner's output

Shared task (no ->): Space-separated agents with a single -- task:

/chain scout planner -- analyze the auth system
/parallel scout reviewer -- check for security issues

Inline Per-Step Config

Append [key=value,...] to any agent name to override its defaults:

/chain scout[output=context.md] "scan code" -> planner[reads=context.md] "analyze auth"
/run scout[model=anthropic/claude-sonnet-4] summarize this codebase
/parallel scanner[output=scan.md] "find issues" -> reviewer[output=review.md] "check style"

Key	Example	Description
`output`	`output=context.md`	Write results to file (relative to chain dir for `/chain`/`/parallel`; for `/run`, absolute paths are used as-is and relative paths resolve against cwd)
`reads`	`reads=a.md+b.md`	Read files before executing (`+` separates multiple)
`model`	`model=anthropic/claude-sonnet-4`	Override model for this step
`skills`	`skills=planning+review`	Override skills (`+` separates multiple)
`progress`	`progress`	Enable progress tracking

Set output=false, reads=false, or skills=false to explicitly disable.

Background Execution

Add --bg at the end of any slash command to run in the background:

/run scout "full security audit of the codebase" --bg
/chain scout "analyze auth system" -> planner "design refactor plan" -> worker --bg
/parallel scout "scan frontend" -> scout "scan backend" -> scout "scan infra" --bg

Without --bg, the run is foreground: the tool call stays active and streams progress until completion. With --bg, the run is launched asynchronously: control returns immediately, and completion arrives later via notification. In both cases subagents run as separate processes. Check status with the subagent_status tool, or open the /subagents-status slash command for a read-only overlay listing active runs and recent completions.

Forked Context Execution

Add --fork at the end of /run, /chain, or /parallel to run with context: "fork":

/run reviewer "review this diff" --fork
/chain scout "analyze this branch" -> planner "plan next steps" --fork
/parallel scout "audit frontend" -> reviewer "audit backend" --fork

You can combine --fork and --bg in any order:

/run reviewer "review this diff" --fork --bg
/run reviewer "review this diff" --bg --fork

Agents Manager

Press Ctrl+Shift+A or type /agents to open the Agents Manager overlay — a TUI for browsing, viewing, editing, creating, and launching agents and chains.

Screens:

Screen	Description
List	Browse all agents and chains with search/filter, scope badges, chain badges
Detail	View resolved prompt, frontmatter fields, recent run history
Edit	Edit fields with specialized pickers (model, thinking, skills, prompt editor)
Chain Detail	View chain steps with flow visualization and dependency map
Parallel Builder	Build parallel execution slots, add same agent multiple times, per-slot task overrides
Task Input	Enter task and launch with optional skip-clarify toggle
New Agent	Create from templates (Blank, Scout, Planner, Implementer, Code Reviewer, Blank Chain)

List screen keybindings:

↑↓ — navigate agents/chains
Enter — view detail
Type any character — search/filter
Tab — toggle selection (agents only)
Ctrl+N — new agent from template
Ctrl+K — clone current item
Ctrl+D or Del — delete current item
Ctrl+R — run selected (1 agent: launch, 2+: sequential chain)
Ctrl+P — open parallel builder (from selection or cursor agent)
Esc — clear query, then selection, then close overlay

Parallel builder keybindings:

↑↓ — navigate slots
Ctrl+A — add agent (opens search picker)
Del or Ctrl+D — remove slot
Enter — edit per-slot task override
Ctrl+R — continue to task input (requires 2+ slots)
Esc — back to list

Task input keybindings:

Enter — launch (or quick run if skip-clarify is on)
Tab — toggle skip-clarify (defaults to on for all manager launches)
Esc — back

Multi-select workflow: Select agents with Tab, then press Ctrl+R for a sequential chain or Ctrl+P to open the parallel builder. The parallel builder lets you add the same agent multiple times, set per-slot task overrides, and launch N agents in parallel. Slots without a custom task use the shared task entered on the next screen.

Chain Files

Chains are .chain.md files stored alongside agent files. They define reusable multi-step pipelines.

Chain file locations:

Scope	Path
User	`~/.pi/agent/agents/{name}.chain.md`
Project	`.pi/agents/{name}.chain.md`

Format:

---
name: scout-planner
description: Gather context then plan implementation
---

## scout
output: context.md

Analyze the codebase for {task}

## planner
reads: context.md
model: anthropic/claude-sonnet-4-5:high
progress: true

Create an implementation plan based on {previous}

Each ## agent-name section defines a step. Config lines (output, reads, model, skills, progress) go immediately after the header. A blank line separates config from the task text. Chains support the same three-state semantics as tool params: omitted (inherit from agent), value (override), false (disable).

Chains can be created from the Agents Manager template picker ("Blank Chain"), or saved from the chain-clarify TUI during execution.

Features (beyond base)

Slash Commands: /run, /chain, /parallel with tab-completion and live progress
Agents Manager Overlay: Browse, view, edit, create, delete, and launch agents/chains from a TUI (Ctrl+Shift+A)
Management Actions: LLM can list, inspect, create, update, and delete agent/chain definitions via action field
Chain Files: Reusable .chain.md files with per-step config, saveable from the clarify TUI
Multi-select & Parallel: Select agents in the overlay, launch as chain or parallel
Run History: Per-agent JSONL recording of task, exit code, duration; shown on detail screen
Thinking Level: First-class thinking frontmatter field with picker UI and runtime suffix application
Agent Templates: Create agents from presets (Scout, Planner, Implementer, Code Reviewer, Blank Chain)
Skill Injection: Agents declare skills in frontmatter; skills get injected into system prompts
Parallel-in-Chain: Fan-out/fan-in patterns with { parallel: [...] } steps within chains
Worktree Isolation: worktree: true gives each parallel agent its own git worktree, preventing filesystem conflicts during concurrent execution
Chain Clarification TUI: Interactive preview/edit of chain templates and behaviors before execution
Agent Frontmatter Extensions: Agents declare default chain behavior (output, defaultReads, defaultProgress, skill) plus optional recursion limits via maxSubagentDepth
Chain Artifacts: Shared directory at <tmpdir>/pi-chain-runs/{runId}/ for inter-step files
Solo Agent Output: Agents with output write to temp dir and return path to caller
Live Progress Display: Real-time visibility during sync execution showing current tool, recent output, tokens, and duration
Output Truncation: Configurable byte/line limits via maxOutput
Debug Artifacts: Input/output/JSONL/metadata files per task
Session Logs: JSONL session files with paths shown in output
Async Status Files: Durable status.json, events.jsonl, and markdown logs for async runs
Async Widget: Lightweight TUI widget shows background run progress
Session-scoped Notifications: Async completions only notify the originating session

Modes

Mode	Async Support	Notes
Single	Yes	`{ agent, task }` - agents with `output` write to temp dir
Chain	Yes	`{ chain: [{agent, task}...] }` with `{task}`, `{previous}`, `{chain_dir}` variables
Parallel	Yes	`{ tasks: [{agent, task}...] }` - via TUI toggle or converted to chain for async

Execution context defaults to context: "fresh", which starts each child run from a clean session. Set context: "fork" to start each child from a real branched session created from the parent's current leaf.

All modes support foreground and background execution. Foreground is the default (the call waits and streams progress). For programmatic background launch, use clarify: false, async: true. For interactive background launch, use clarify: true and press b in the TUI before running. Chains with parallel steps ({ parallel: [...] }) run concurrently with configurable concurrency and failFast options.

Clarify TUI for single/parallel:

Single and parallel modes also support the clarify TUI for previewing/editing parameters before execution. Unlike chains, they default to no TUI - use clarify: true to enable:

// Single agent with clarify TUI
{ agent: "scout", task: "Analyze the codebase", clarify: true }

// Parallel tasks with clarify TUI
{ tasks: [{agent: "scout", task: "Analyze frontend"}, ...], clarify: true }

Clarification TUI keybindings:

Navigation mode:

Enter - Run (foreground) or launch in background if b is toggled on
Esc - Cancel
↑↓ - Navigate between steps/tasks (parallel, chain)
e - Edit task/template (all modes)
m - Select model (all modes)
t - Select thinking level (all modes)
s - Select skills (all modes)
b - Toggle background/async execution (all modes) — shows [b]g:ON when enabled
w - Edit writes/output file (single, chain only)
r - Edit reads list (chain only)
p - Toggle progress tracking (chain only)
S - Save current overrides to agent's frontmatter file (all modes)
W - Save chain configuration to a .chain.md file (chain only)

Model selector mode:

↑↓ - Navigate model list
Enter - Select model
Esc - Cancel (keep current model)
Type to filter (fuzzy search by model name or provider)

Thinking level selector mode:

↑↓ - Navigate level list
Enter - Select level
Esc - Cancel (keep current level)

Skill selector mode:

↑↓ - Navigate skill list
Space - Toggle skill selection
Enter - Confirm selection
Esc - Cancel (keep current skills)
Type to filter (fuzzy search by name or description)

Edit mode (full-screen editor with word wrapping):

Esc - Save changes and exit
Ctrl+C - Discard changes and exit
←→ - Move cursor left/right
Alt+←→ - Move cursor by word
↑↓ - Move cursor up/down by display line (auto-scrolls)
Page Up/Down or Shift+↑↓ - Move cursor by viewport (12 lines)
Home/End - Start/end of current display line
Ctrl+Home/End - Start/end of text
Alt+Backspace - Delete word backward
Paste supported (multi-line in multi-line editors)

Skills

Skills are specialized instructions loaded from SKILL.md files and injected into the agent's system prompt.

Skill locations (project-first precedence):

Project: .pi/skills/{name}/SKILL.md
Project packages: .pi/npm/node_modules/* via package.json -> pi.skills
Project settings: .pi/settings.json -> skills
User: ~/.pi/agent/skills/{name}/SKILL.md
User packages: ~/.pi/agent/npm/node_modules/* via package.json -> pi.skills
User settings: ~/.pi/agent/settings.json -> skills

Usage:

// Agent with skills from frontmatter
{ agent: "scout", task: "..." }  // uses agent's default skills

// Override skills at runtime
{ agent: "scout", task: "...", skill: "tmux, safe-bash" }

// Disable all skills (including agent defaults)
{ agent: "scout", task: "...", skill: false }

// Chain with chain-level skills (additive to agent skills)
{ chain: [...], skill: "code-review" }

// Chain step with skill override
{ chain: [
  { agent: "scout", skill: "safe-bash" },  // only safe-bash
  { agent: "worker", skill: false }        // no skills at all
]}

Skill injection format:

<skill name="safe-bash">
[skill content from SKILL.md, frontmatter stripped]
</skill>

Missing skills: If a skill cannot be found, execution continues with a warning shown in the result summary.

Usage

These are the parameters the LLM agent passes when it calls the subagent tool — not something you type directly. The agent decides to use these based on your conversation. For user-facing commands, see Quick Commands above.

subagent tool parameters:

// Single agent
{ agent: "worker", task: "refactor auth" }
{ agent: "scout", task: "find todos", maxOutput: { lines: 1000 } }
{ agent: "scout", task: "investigate", output: false }  // disable file output

// Single agent from parent-session fork (real branched session at current leaf)
{ agent: "worker", task: "continue this thread", context: "fork" }

// Parallel
{ tasks: [{ agent: "scout", task: "a" }, { agent: "scout", task: "b" }] }

// Parallel with count shorthand (run the same task 3 times)
{ tasks: [{ agent: "scout", task: "audit auth", count: 3 }] }

// Parallel with forked context (each task gets its own isolated fork)
{ tasks: [{ agent: "scout", task: "audit frontend" }, { agent: "reviewer", task: "audit backend" }], context: "fork" }

// Chain with TUI clarification (default)
{ chain: [
  { agent: "scout", task: "Gather context for auth refactor" },
  { agent: "planner" },  // task defaults to {previous}
  { agent: "worker" },   // uses agent defaults for reads/progress
  { agent: "reviewer" }
]}

// Chain with forked context (each step gets its own isolated fork of the same parent leaf)
{ chain: [
  { agent: "scout", task: "Analyze current branch decisions" },
  { agent: "planner", task: "Plan from {previous}" }
], context: "fork" }

// Chain without TUI (enables async)
{ chain: [...], clarify: false, async: true }

// Chain with behavior overrides
{ chain: [
  { agent: "scout", task: "find issues", output: false },  // text-only, no file
  { agent: "worker", progress: false }  // disable progress tracking
]}

// Chain with parallel step (fan-out/fan-in)
{ chain: [
  { agent: "scout", task: "Gather context for the codebase" },
  { parallel: [
    { agent: "worker", task: "Implement auth based on {previous}", count: 2 },
    { agent: "worker", task: "Implement API based on {previous}" }
  ]},
  { agent: "reviewer", task: "Review all changes from {previous}" }
]}

// Parallel step with options
{ chain: [
  { agent: "scout", task: "Find all modules" },
  { parallel: [
    { agent: "worker", task: "Refactor module A" },
    { agent: "worker", task: "Refactor module B" },
    { agent: "worker", task: "Refactor module C" }
  ], concurrency: 2, failFast: true }  // limit concurrency, stop on first failure
]}

// Worktree isolation — each parallel agent gets its own git worktree
{ tasks: [
  { agent: "worker", task: "Implement auth" },
  { agent: "worker", task: "Implement API" }
], worktree: true }

// Worktree isolation in a chain (fan-out with isolation, fan-in for review)
{ chain: [
  { agent: "scout", task: "Gather context" },
  { parallel: [
    { agent: "worker", task: "Implement feature A based on {previous}" },
    { agent: "worker", task: "Implement feature B based on {previous}" }
  ], worktree: true },
  { agent: "reviewer", task: "Review changes from {previous}" }
]}

// Async chain with parallel step (runs in background)
{ chain: [
  { agent: "scout", task: "Gather context" },
  { parallel: [
    { agent: "worker", task: "Implement feature A based on {previous}" },
    { agent: "worker", task: "Implement feature B based on {previous}" }
  ]},
  { agent: "reviewer", task: "Review all changes from {previous}" }
], clarify: false, async: true }

subagent_status tool:

{ action: "list" }                    // active async runs only
{ id: "a53ebe46" }                    // inspect one run
{ dir: "<tmpdir>/pi-async-subagent-runs/a53ebe46-..." }

/subagents-status slash command:

Opens a small read-only overlay that shows active async runs plus recent completed/failed runs. It auto-refreshes every 2 seconds while open, keeps the current run selected when possible, and uses ↑↓ to select a run plus Esc to close.

Management Actions

Agent definitions are not loaded into LLM context by default. Management actions let the LLM discover, inspect, create, and modify agent and chain definitions at runtime through the subagent tool — no manual file editing or restart required. Newly created agents are immediately usable in the same session. Set action and omit execution payloads (task, chain, tasks).

// Discover all agents and chains (management defaults to both scopes)
{ action: "list" }
{ action: "list", agentScope: "project" }

// Inspect one agent or chain (searches both scopes)
{ action: "get", agent: "scout" }
{ action: "get", chainName: "review-pipeline" }

// Create agent
{ action: "create", config: {
  name: "Code Scout",
  description: "Scans codebases for patterns and issues",
  scope: "user",
  systemPrompt: "You are a code scout...",
  model: "anthropic/claude-sonnet-4",
  tools: "read, bash, mcp:github/search_repositories",
  extensions: "", // empty = no extensions
  skills: "parallel-scout",
  thinking: "high",
  output: "context.md",
  reads: "shared-context.md",
  progress: true
}}

// Create chain (presence of steps creates .chain.md)
{ action: "create", config: {
  name: "review-pipeline",
  description: "Scout then review",
  scope: "project",
  steps: [
    { agent: "scout", task: "Scan {task}", output: "context.md" },
    { agent: "reviewer", task: "Review {previous}", reads: ["context.md"] }
  ]
}}

// Update agent fields (merge semantics)
{ action: "update", agent: "scout", config: { model: "openai/gpt-4o" } }
{ action: "update", agent: "scout", config: { output: false, skills: "" } } // clear optional fields
{ action: "update", chainName: "review-pipeline", config: {
  steps: [
    { agent: "scout", task: "Scan {task}", output: "context.md" },
    { agent: "reviewer", task: "Improved review of {previous}", reads: ["context.md"] }
  ]
}}

// Delete definitions
{ action: "delete", agent: "scout" }
{ action: "delete", chainName: "review-pipeline" }

Notes:

create uses config.scope ("user" or "project"), not agentScope.
update/delete use agentScope only for scope disambiguation when the same name exists in both scopes.
Agent config mapping: reads -> defaultReads, progress -> defaultProgress, extensions controls extension sandboxing, maxSubagentDepth maps directly to agent frontmatter, and tools supports mcp: entries that map to direct MCP tools.
To clear any optional field, set it to false or "" (e.g., { model: false } or { skills: "" }). Both work for all string-typed fields.

Parameters

Param	Type	Default	Description
`agent`	string	-	Agent name (single mode) or target for management get/update/delete
`task`	string	-	Task string (single mode)
`action`	string	-	Management action: `list`, `get`, `create`, `update`, `delete`
`chainName`	string	-	Chain name for management get/update/delete
`config`	object	-	Agent or chain config for management create/update
`output`	`string \| false`	agent default	Override output file for single agent (absolute path as-is, relative path resolved against cwd)
`skill`	`string \| string[] \| false`	agent default	Override skills (comma-separated string, array, or false to disable)
`model`	string	agent default	Override model for single agent
`tasks`	`{agent, task, cwd?, count?, skill?}[]`	-	Parallel tasks. Foreground runs directly; background requests are converted to an equivalent chain. `count` repeats one task entry N times with the same settings.
`worktree`	boolean	false	Create isolated git worktrees for each parallel task. Requires clean git state. Per-worktree diffs included in output.
`chain`	ChainItem[]	-	Sequential steps with behavior overrides (see below)
`context`	`"fresh" \| "fork"`	`fresh`	Execution context mode. `fork` uses a real branched session from the parent's current leaf for each child run
`chainDir`	string	`<tmpdir>/pi-chain-runs/`	Persistent directory for chain artifacts (default auto-cleaned after 24h)
`clarify`	boolean	true (chains)	Show TUI to preview/edit chain; implies sync mode
`agentScope`	`"user" \| "project" \| "both"`	`both`	Agent discovery scope (project wins on name collisions)
`async`	boolean	false	Background execution (requires `clarify: false` for chains)
`cwd`	string	-	Override working directory
`maxOutput`	`{bytes?, lines?}`	200KB, 5000 lines	Truncation limits for final output
`artifacts`	boolean	true	Write debug artifacts
`includeProgress`	boolean	false	Include full progress in result
`share`	boolean	false	Upload session to GitHub Gist (see Session Sharing)
`sessionDir`	string	-	Override session log directory (takes precedence over `defaultSessionDir` and parent-session-derived path)

context: "fork" fails fast when the parent session is not persisted, the current leaf is missing, or a branched child session cannot be created. It never silently downgrades to fresh.

ChainItem can be either a sequential step or a parallel step:

Sequential step fields:

Field	Type	Default	Description
`agent`	string	required	Agent name
`task`	string	`{task}` or `{previous}`	Task template (required for first step)
`cwd`	string	-	Override working directory
`output`	`string \| false`	agent default	Override output filename or disable
`reads`	`string[] \| false`	agent default	Override files to read from chain dir
`progress`	boolean	agent default	Override progress.md tracking
`skill`	`string \| string[] \| false`	agent default	Override skills or disable all
`model`	string	agent default	Override model for this step

Parallel step fields:

Field	Type	Default	Description
`parallel`	ParallelTask[]	required	Array of tasks to run concurrently
`concurrency`	number	4	Max concurrent tasks
`failFast`	boolean	false	Stop remaining tasks on first failure
`worktree`	boolean	false	Create isolated git worktrees for each parallel task

ParallelTask fields: (same as sequential step)

Field	Type	Default	Description
`agent`	string	required	Agent name
`task`	string	`{previous}`	Task template
`cwd`	string	-	Override working directory
`count`	number	1	Repeat this parallel task N times with the same settings
`output`	`string \| false`	agent default	Override output (namespaced to parallel-N/M-agent/)
`reads`	`string[] \| false`	agent default	Override files to read
`progress`	boolean	agent default	Override progress tracking
`skill`	`string \| string[] \| false`	agent default	Override skills or disable all
`model`	string	agent default	Override model for this task

Status tool:

Tool	Description
`subagent_status`	List active async runs or inspect one run by id or dir

Worktree Isolation

When multiple agents run in parallel against the same repo, they can clobber each other's file changes. Pass worktree: true to give each parallel agent its own git worktree branched from HEAD.

// Top-level parallel with worktree isolation
{ tasks: [
  { agent: "worker", task: "Implement auth", count: 2 },
  { agent: "worker", task: "Implement API" }
], worktree: true }

// Chain with worktree-isolated parallel step
{ chain: [
  { agent: "scout", task: "Gather context" },
  { parallel: [
    { agent: "worker", task: "Implement feature A based on {previous}" },
    { agent: "worker", task: "Implement feature B based on {previous}" }
  ], worktree: true },
  { agent: "reviewer", task: "Review all changes from {previous}" }
]}

After the parallel step completes, per-agent diff stats are appended to the output (and become {previous} for the next chain step). Full patch files are written to disk. The caller or next step can decide what to keep.

Requirements:

Must be inside a git repository
Working tree must be clean (no uncommitted changes) — commit or stash first
node_modules/ is symlinked into each worktree to avoid reinstalling
Worktree runs use the shared parallel/step cwd. Task-level cwd overrides must be omitted or match that shared cwd; if you need different working directories, disable worktree or split the run.
If worktreeSetupHook is configured, it must return valid JSON and complete before timeout

What happens under the hood:

git worktree add creates a temporary worktree per agent in <tmpdir>/pi-worktree-*
Optional worktreeSetupHook runs once per worktree (JSON in on stdin, JSON out on stdout)
Each agent runs in its worktree's cwd (preserving subdirectory context)
Before diff capture, declared synthetic helper paths (for example .venv or copied local config files) are removed
After execution, git add -A && git diff --cached captures all real changes (committed, modified, and new files)
Diff stats appear in the aggregated output; full .patch files are written to the artifacts directory
Worktrees and temp branches are cleaned up in a finally block

If you use pi-prompt-template-model, worktree isolation is also available via worktree: true in chain template frontmatter or the --worktree CLI flag on chain-prompts. pi-prompt-template-model compare-style prompts can route through the same worktree machinery too; see the pi-prompt-template-model README and examples/ directory for the installable prompt templates.

Chain Variables

Templates support three variables:

Variable	Description
`{task}`	Original task from first step (use in subsequent steps)
`{previous}`	Output from prior step (or aggregated outputs from parallel step)
`{chain_dir}`	Path to chain artifacts directory

Parallel output aggregation: When a parallel step completes, all outputs are concatenated with clear separators:

=== Parallel Task 1 (worker) ===
[output from first task]

=== Parallel Task 2 (worker) ===
[output from second task]

This aggregated output becomes {previous} for the next step.

Extension Configuration

pi-subagents reads optional JSON config from ~/.pi/agent/extensions/subagent/config.json.

`defaultSessionDir`

defaultSessionDir sets the fallback directory used for session logs. Eg:

{
  "defaultSessionDir": "~/.pi/agent/sessions/subagent/"
}

Session root resolution follows this precedence:

params.sessionDir from the subagent tool call
config.defaultSessionDir
Derived from parent session (stored alongside parent session file)

Sessions are always enabled — every subagent run gets a session directory for tracking.

`maxSubagentDepth`

maxSubagentDepth sets the default recursion limit for nested delegation when no inherited PI_SUBAGENT_MAX_DEPTH is already in effect. Eg:

{
  "maxSubagentDepth": 1
}

Per-agent maxSubagentDepth can tighten that limit further for child runs, but it does not relax an already inherited stricter limit.

`worktreeSetupHook`

worktreeSetupHook configures an optional setup hook for worktree-isolated parallel runs. The hook runs once per created worktree, after git worktree add succeeds and before the agent starts.

{
  "worktreeSetupHook": "./scripts/setup-worktree.mjs"
}

Path rules:

Must be an absolute path or a repo-relative path
Bare command names from PATH are rejected
~/... is supported for home-directory hooks

Hook I/O contract (JSON only):

stdin: one JSON object with repoRoot, worktreePath, agentCwd, branch, index, runId, and baseCommit
stdout: one JSON object, e.g. { "syntheticPaths": [".venv", ".env.local"] }

syntheticPaths must be relative to the worktree root. These paths are removed before diff capture so helper files/symlinks do not pollute generated patches.

Tracked-file edits are never excluded. If the hook tries to mark tracked paths as synthetic, setup fails.

`worktreeSetupHookTimeoutMs`

Optional timeout (milliseconds) for each worktree hook invocation.

{
  "worktreeSetupHook": "./scripts/setup-worktree.mjs",
  "worktreeSetupHookTimeoutMs": 45000
}

Default: 30000 ms.

Chain Directory

Each chain run creates <tmpdir>/pi-chain-runs/{runId}/ containing:

context.md - Scout/context-builder output
plan.md - Planner output
progress.md - Worker/reviewer shared progress
parallel-{stepIndex}/ - Subdirectories for parallel step outputs
- 0-{agent}/output.md - First parallel task output
- 1-{agent}/output.md - Second parallel task output
Additional files as written by agents

Directories older than 24 hours are cleaned up on extension startup.

Artifacts

Location: {sessionDir}/subagent-artifacts/ or <tmpdir>/pi-subagent-artifacts/

Files per task:

{runId}_{agent}_input.md - Task prompt
{runId}_{agent}_output.md - Full output (untruncated)
{runId}_{agent}.jsonl - Event stream (sync only)
{runId}_{agent}_meta.json - Timing, usage, exit code

Session Logs

Session files (JSONL) are stored under a per-run session directory. Directory selection follows the same precedence as session root resolution: explicit sessionDir > config.defaultSessionDir > parent-session-derived path. The session file path is shown in output.

When context: "fork" is used, each child run starts with --session <branched-session-file> produced from the parent's current leaf. This is a real session fork, not injected summary text.

Session Sharing

When share: true is passed, the extension will:

Export the full session (all tool calls, file contents, outputs) to an HTML file
Upload it to a GitHub Gist using your gh CLI credentials
Return a shareable URL (https://shittycodingagent.ai/session/?<gistId>)

This is disabled by default. Session data may contain sensitive information like source code, file paths, environment variables, or credentials that appear in tool outputs.

To enable sharing for a specific run:

{ agent: "scout", task: "...", share: true }

Requirements:

GitHub CLI (gh) must be installed and authenticated (gh auth login)
Gists are created as "secret" (unlisted but accessible to anyone with the URL)

Live progress (sync mode)

During sync execution, the collapsed view shows real-time progress for single, chain, and parallel modes.

Chains:

Header: ... chain 1/2 | 8 tools, 1.4k tok, 38s
Chain visualization with status: ✓scout → ●planner (✓=done, ●=running, ○=pending, ✗=failed)
Current tool: > read: packages/tui/src/...
Recent output lines (last 2-3 lines)

Parallel:

Header: ... parallel 2/4 | 12 tools, 2.1k tok, 15s
Per-task step cards showing status icon, agent name, model, tool count, and duration
Current tool and recent output for each running task

Press Ctrl+O to expand the full streaming view with complete output per step.

Note: Chain visualization (the ✓scout → ●planner line) is only shown for sequential chains. Chains with parallel steps show per-step cards instead.

Nested subagent recursion guard

Subagents can themselves call the subagent tool, which risks unbounded recursive spawning (slow, expensive, hard to observe). A depth guard prevents this.

By default nesting is limited to 2 levels: main session → subagent → sub-subagent. Any deeper subagent calls are blocked and return an error with guidance to the calling agent.

You can configure the limit in three places:

PI_SUBAGENT_MAX_DEPTH in the environment before starting pi
config.maxSubagentDepth in ~/.pi/agent/extensions/subagent/config.json
maxSubagentDepth in an agent's frontmatter to tighten the limit for that agent's child runs

Environment inherits downward and wins for the current process. Per-agent limits can tighten child delegation but do not relax an already inherited stricter limit.

Override the limit with PI_SUBAGENT_MAX_DEPTH set before starting pi:

export PI_SUBAGENT_MAX_DEPTH=3   # allow one more level (use with caution)
export PI_SUBAGENT_MAX_DEPTH=1   # only allow direct subagents, no nesting
export PI_SUBAGENT_MAX_DEPTH=0   # disable the subagent tool entirely

PI_SUBAGENT_DEPTH is an internal variable propagated automatically to child processes -- don't set it manually.

Async observability

Async runs write a dedicated observability folder:

<tmpdir>/pi-async-subagent-runs/<id>/
  status.json
  events.jsonl
  subagent-log-<id>.md

status.json is the source of truth for async progress and powers both the TUI widget and /subagents-status. Async status and result files are written atomically, so readers do not observe partial JSON during background updates.

For programmatic access:

subagent_status({ action: "list" })
subagent_status({ id: "<id>" })
subagent_status({ dir: "<tmpdir>/pi-async-subagent-runs/<id>" })

For an interactive overview, run the /subagents-status slash command to open the overlay listing active runs and recent completed/failed runs. The overlay auto-refreshes every 2 seconds while it is open.

Events

Async events:

subagent:started
subagent:complete

notify.ts consumes subagent:complete as the canonical completion channel.

Files

├── index.ts                      # Main extension, tool registration, overlay dispatch
├── agents.ts                     # Agent + chain discovery, frontmatter parsing
├── skills.ts                     # Skill resolution, caching, and discovery
├── settings.ts                   # Chain behavior resolution, templates, chain dir
├── chain-clarify.ts              # TUI for chain/single/parallel clarification
├── chain-execution.ts            # Chain orchestration (sequential + parallel)
├── chain-serializer.ts           # Parse/serialize .chain.md files
├── async-execution.ts            # Async/background execution support
├── async-status.ts               # Async run discovery, listing, and formatting
├── execution.ts                  # Core runSync, applyThinkingSuffix
├── render.ts                     # TUI rendering (widget, tool result display)
├── subagents-status.ts           # Async status overlay component
├── artifacts.ts                  # Artifact management
├── formatters.ts                 # Output formatting utilities
├── schemas.ts                    # TypeBox parameter schemas
├── utils.ts                      # Shared utility functions (mapConcurrent, readStatus, etc.)
├── types.ts                      # Shared types and constants
├── subagent-runner.ts            # Async runner (detached process)
├── parallel-utils.ts             # Parallel execution utilities for async runner
├── worktree.ts                   # Git worktree isolation for parallel execution
├── pi-spawn.ts                   # Cross-platform pi CLI spawning
├── single-output.ts              # Solo agent output file handling
├── notify.ts                     # Async completion notifications
├── completion-dedupe.ts          # Completion deduplication for notifications
├── file-coalescer.ts             # Debounced file write coalescing
├── jsonl-writer.ts               # JSONL event stream writer
├── agent-manager.ts              # Overlay orchestrator, screen routing, CRUD
├── agent-manager-list.ts         # List screen (search, multi-select, progressive footer)
├── agent-manager-detail.ts       # Detail screen (resolved prompt, runs, fields)
├── agent-manager-edit.ts         # Edit screen (pickers, prompt editor)
├── agent-manager-parallel.ts     # Parallel builder screen (slot management, agent picker)
├── agent-manager-chain-detail.ts # Chain detail screen (flow visualization)
├── agent-management.ts           # Management action handlers (list, get, create, update, delete)
├── agent-serializer.ts           # Serialize agents to markdown frontmatter
├── agent-scope.ts                # Agent scope resolution utilities
├── agent-selection.ts            # Agent selection state management
├── agent-templates.ts            # Agent/chain creation templates
├── render-helpers.ts             # Shared pad/row/header/footer helpers
├── run-history.ts                # Per-agent run recording (JSONL)
├── test/unit/                    # Fast unit tests for pure modules
├── test/integration/             # Loader-based execution/integration tests
├── test/e2e/                     # End-to-end sandbox tests
├── test/support/                 # Shared test loader, helpers, and mock pi harness
└── text-editor.ts                # Shared text editor (word nav, paste)
