Gradient Bang

Gradient Bang is an online multiplayer universe where you explore, trade, battle, and collaborate with other players and with LLMs. Everything in the game is an AI agent, including the ship you command.

The projects demonstrates the full capabilities of realtime agentic workflows, such as multi-tasking, advanced tool calling and low latency voice.

➡️ Join the play test

Quick start (Claude Code)

If you have Claude Code installed, the fastest way to get set up from a fresh clone is:

/init

This single command installs dependencies, starts Supabase, generates environment files, creates universe data, and walks you through providing API keys. See Initial setup below for the manual equivalent.

Many of the steps described in this README also have corresponding Claude Code skills — look for the /skill-name callouts. See the full Claude Code skills reference at the bottom.

Table of Contents

• Initial setup
• Running locally
• Event delivery modes
• Deployment
• Environment variables
• Auth & secrets quick guide
• Claude Code skills reference

Initial setup

If you want to work on Gradient Bang, the first step is getting the entire app running locally. There are four components to run:

• Supabase is the "game server". We use its PostgreSQL database (with some important PL/pgSQL functions) for storage, and Supabase Edge Functions for the API. Supabase provides a CLI tool to run their stack locally for development.
• The edge functions dev server serves the functions in the deployment/supabase/functions folder.
• The client is the game UI, built in React and deployed to Vercel using turbo.
• The bot is a Pipecat bot, deployed to Pipecat Cloud.

Prerequisites

• uv: Python package manager
• Supabase Account: Game server functions, auth and database
• Docker: Required for local Supabase stack and agent deployment
• Node.js 18+: For edge function deployment and client
• (Optional) Pipecat Cloud Account: Production agent hosting
• (Optional) - Supabase CLI: If you cannot use npx, install the CLI globally instead

Step 1: Set up Supabase

First, run supabase start. Supabase is several services in a trenchcoat. This command downloads and runs all of the various Docker images. When you run this, you'll see a bunch of services listening on different ports that we'll use later.

npx supabase start --workdir deployment/

Next, grab the required API keys to create an .env.supabase file for your local Supabase stack configuration:

tok=$(openssl rand -hex 32)
npx supabase status -o env --workdir deployment | awk -F= -v tok="$tok" '
  $1=="API_URL"           {v=$2; gsub(/"/,"",v); print "SUPABASE_URL=" v}
  $1=="ANON_KEY"          {v=$2; gsub(/"/,"",v); print "SUPABASE_ANON_KEY=" v}
  $1=="SERVICE_ROLE_KEY"  {v=$2; gsub(/"/,"",v); print "SUPABASE_SERVICE_ROLE_KEY=" v}
  END {
    print "POSTGRES_POOLER_URL=postgresql://postgres:postgres@db:5432/postgres"
    print "EDGE_API_TOKEN=" tok
  }
'  > .env.supabase

Next, run this helper after supabase start (and after any manual database reset). It sets up some important PL/pgSQL functions to keep combat rounds auto-resolving:

scripts/supabase-reset-with-cron.sh

Next, generate a universe and load it into your local database. universe-bang writes tmp/world-data/universe.json and validates the generated graph before saving it.

uv run universe-bang 5000 1234

# Load .env.supabase to env (if not done already)
set -a && source .env.supabase && set +a

uv run -m gradientbang.scripts.load_universe_to_supabase --from-json tmp/world-data/ --dry-run
uv run -m gradientbang.scripts.load_universe_to_supabase --from-json tmp/world-data/

Step 2: Edge functions

Claude Code: /character-create can handle user registration and character creation interactively.

From here forward, you'll need the Supabase edge functions process running:

npx supabase functions serve --workdir deployment --no-verify-jwt --env-file .env.supabase

# or shorthand (Python wrapper around the about)

uv run functions

You'll need to create a user account in your database in order log in. We don't have a UI for that right now, so you can do it one of two ways.

Option 1: Your local Supabase has a Studio dashboard: http://127.0.0.1:54323/project/default/auth/users

Click the "Add user" green button on the right, then click "Create new user". Type a username and password, and leave "Auto Confirm User?" checked.

Option 2: Via terminal:

curl -X POST http://127.0.0.1:54321/functions/v1/register \
  -H "Content-Type: application/json" \
  -d '{
    "email": "test@example.com",
    "password": "secret123"
  }'

Step 3: Run the Pipecat bot and game client

Install Python dependencies:

uv sync

Copy the env.bot.example file and add your keys (see Bot environment variables for the full list):

Note: Keep BOT_USE_KRISP to 0 in local dev (see here)

cp env.bot.example .env.bot

Finally, run the bot process:

# The simple way for local dev and SmallWebRTCTransport
uv run bot
# Add "-t daily --host 0.0.0.0" to use the Daily transport and listen on all interfaces (for use with Tailscale, for example)
uv run bot -t daily --host 0.0.0.0

Local pooler mode

By default the bot calls Supabase Edge Functions over HTTP for all game server operations. This adds latency (500ms avg, up to 10s on cold starts). If you set LOCAL_API_POSTGRES_URL in .env.bot to a Supabase session pooler connection string, the bot runs the equivalent function logic locally against Postgres directly, bypassing the edge function network hop entirely. This is especially useful in production where the bot container and database are co-located.

Step 4: Run web client

If you're running everything else, the client should run out of the box without an env.

cd client/
pnpm i
pnpm run dev

You can create a .env in the client/app directory to configure the client:

cd client/app/
cp env.example .env.local

That should be everything you need. You should be able to open http://localhost:5173, sign in with the username and password you set up, create a character, and start talking!

On my Linux box running the ufw firewall, I had to add a firewall rule to allow Supabase's docker containers to talk to themselves:

# Run one of these to fix it:
# Allow from all Docker networks
sudo ufw allow from 172.16.0.0/12 to any port 7860 proto tcp

# Or more restrictive — just the Supabase bridge network
sudo ufw allow from 172.18.0.0/16 to any port 7860 proto tcp

Running locally

To review, in order to run the full stack locally, you need to be running Supabase, edge functions, the client, and the bot.

# to start Supabase (this runs in the background, so you don't have the leave the terminal open)
npx supabase start --workdir deployment # and don't forget to "npx supabase stop --workdir deployment" when you're done!)

# Keep these open in different terminal windows:
npx supabase functions serve --workdir deployment --no-verify-jwt --env-file .env.supabase
uv run bot
cd client && pnpm run dev

Running the NPC task agent

Claude Code: /npc <character_name> resolves the name and launches the agent in the background.

Run autonomous tasks with a character using the text-based task agent:

set -a && source .env.supabase && set +a
uv run npc-run <character-id> "Explore and find 5 new sectors"

Database reset that preserves user accounts

Claude Code: /reset-world handles this interactively with environment, sector count, and seed options.

# local
scripts/reset-world.sh --env .env.supabase 1000 42
# live
scripts/reset-world.sh --env .env.cloud 1000 42

Local resets also create/update the restricted BYOA bus login used by uv run byoa: postgresql://byoa_login:byoa_dev_password@127.0.0.1:54322/postgres.

Event delivery modes

The bot's AsyncGameClient receives game events via one of two Supabase event-delivery adapters, picked when event delivery starts based on EVENT_TRANSPORT.

pubsub (default)

Direct Postgres reads against a temporary pgmq queue created for the live bot session. The bot calls SECURITY DEFINER functions (event_session_register / event_session_subscribe / event_session_archive / event_session_unregister) that:

1. Verify the trusted bot's EDGE_API_TOKEN against public.app_runtime_config.edge_api_token.
2. Create one random evs_* queue before bootstrap RPCs run.
3. Keep the session alive with heartbeat while the bot is online.
4. Return up to N pending messages from that session queue via pgmq.read.

The pubsub hot path does not call an edge function per poll. record_event_with_recipients still writes durable rows to events, then fans out only to active, non-expired event_sessions. Offline characters do not receive pgmq copies.

Cleanup is database-owned. A clean bot shutdown calls event_session_unregister() and drops the queue immediately. If the bot crashes or is left dangling, heartbeats stop, the session expires, publish ignores it, and the scheduled event-session-cleanup pg_cron job drops the queue in bounded batches.

Setup for local pubsub:

1. Apply the pubsub migrations; record_event_with_recipients writes to active session queues automatically.

2. In .env.bot:

   EVENT_TRANSPORT=pubsub
   PGMQ_URL=postgresql://postgres:postgres@127.0.0.1:54322/postgres
   EVENT_SESSION_EMPTY_POLL_INTERVAL_SECONDS=1.0
   EVENT_SESSION_HEARTBEAT_SECONDS=15
   EVENT_SESSION_TTL_SECONDS=60


   Use a session-mode admin Postgres URL. Local Supabase uses postgresql://postgres:postgres@127.0.0.1:54322/postgres.

3. Make sure EDGE_API_TOKEN is present in the bot environment and matches public.app_runtime_config.edge_api_token in the target database.

Migration 20260515020000_session_scoped_event_pubsub.sql adds event_sessions, session read/archive/heartbeat wrappers, scheduled cleanup, and session-scoped gameplay event fanout.

polling

HTTP polling against the events_since edge function, authenticated by EDGE_API_TOKEN. Works in any environment without per-character credentials. Set EVENT_TRANSPORT=polling to opt out of pubsub.

Why two modes?

Polling remains the fallback. Pubsub is the default direct-Postgres path for online sessions. Both modes deliver events through the same client sinks.

Subagent bus transport

Independent of EVENT_TRANSPORT: the bot's internal subagent bus (how the player runtime, Orchestrator, and TaskAgent talk to each other) is also transport-pluggable, chosen at startup by SUBAGENT_BUS_TRANSPORT. This is the wire BYOA agents ride on; see docs/byoa.md for the operator-facing guide.

local (default)

In-process AsyncQueueBus from pipecat.bus. No env changes needed.

pgmq

Distributed bus over Postgres via upstream PgmqBus + IsolatedPgmqBackend. The bot mints a fresh UUID-128 channel (gb_<32hex>) per voice session and forwards it to BYOA over HTTPS at wake time. Required for BYOA.

# .env.bot
SUBAGENT_BUS_TRANSPORT=pgmq
SUBAGENT_BUS_DATABASE_URL=postgresql://postgres:postgres@127.0.0.1:54322/postgres

On managed Postgres, prefer the session-mode pooler (port 5432 on Supabase).

BYOA processes never see this DSN. They use the restricted BYOA_BUS_DATABASE_URL injected by wake_agent, which can only call public.bus_* SECURITY DEFINER wrappers gated by per-channel peer registration. Channels are unguessable UUIDs transported wake → BYOA over HTTPS; knowledge of the channel name is the bus capability.

Cleanup is database-owned. A clean bus shutdown calls bus_leave() and drops the peer queue immediately. If a bot or BYOA process crashes, the old gb_<32hex> channel is abandoned and future sessions mint a fresh channel; the scheduled subagent-bus-cleanup pg_cron job drops any remaining q_* peer queues older than 48 hours in bounded batches.

Running tests

Edge function tests (Deno)

Integration tests for the game server (edge functions) live in deployment/supabase/functions/tests/.

Dependencies: Docker, Node.js / npx (Deno is installed automatically by the Supabase CLI).

No .env file is needed — the test runner creates its own isolated Supabase stack on ephemeral ports and extracts credentials automatically.

bash deployment/supabase/functions/tests/run_tests.sh

The runner starts an isolated Supabase instance, runs the tests with coverage, prints a coverage report, and tears everything down automatically.

Python tests (pytest)

Python tests live in tests/ and use pytest markers to categorize them.

# Run all unit tests (no server needed)
uv run pytest -m unit -v

# Run only LLM behavior tests (context summarization, etc.)
uv run pytest -m llm -v

Available markers: unit, llm, integration, stress, live_api.

Unit tests

The tests/unit/ directory includes unit tests for the bot's agent layer — EventRelay routing, voice runtime tool registration, TaskAgent construction, and runtime integration tests that wire real objects together with mock external boundaries.

# Run all unit tests
uv run pytest -m unit -v

# Run only the relay↔voice integration tests
uv run pytest tests/unit/test_voice_relay_integration.py -v

Python integration tests (requires DB)

Python integration tests need a seeded Supabase database. An all-in-one script handles the lifecycle: it spins up an isolated Supabase instance on different ports (54421+), seeds it via test_reset, runs pytest -m integration, and tears everything down. The dev database is never touched.

# Run all integration tests
bash scripts/run-integration-tests.sh

# Pass extra pytest args
bash scripts/run-integration-tests.sh -v -k "test_movement"

Integration tests are automatically skipped when running uv run pytest directly (without the script).

Deployment

If you want to run your own game world in the cloud, you will need a Supabase project.

Create a new Supabase project

[!NOTE] You can create a Supabase project via the Supabase Dashboard or using the command line below.

npx supabase login

npx supabase projects create gb-game-server \
  --db-password <some-secure-password> \
  --region us-west-1 \
  --org-id <my-supabase-org-slug> \
  --size small

Push config from /deployment/supabase template:

npx supabase link --workdir deployment
npx supabase config push --workdir deployment

Create .env.cloud environment

Generate it in one step (prompts for project ref and DB password).

Note, this will create a POSTGRES_POOLER_URL that requires IPv6 routing from your machine. If you cannot use IPv6, you will need to click on the "" button that's in the top bar of your Supabase project dashboard and look up the "Method: Session Pooler" connection string. Change your POSTGRES_POOLER_URL to the Session Pooler format.

printf "Project ref (from Supabase dashboard URL): "; read PROJECT_REF
printf "DB password (from Settings → Database): "; read -s DB_PASS; echo
EDGE_API_TOKEN=$(openssl rand -hex 32)
npx supabase projects api-keys --project-ref "$PROJECT_REF" --workdir deployment \
| awk -v tok="$EDGE_API_TOKEN" -v pw="$DB_PASS" -v pr="$PROJECT_REF" '
  /anon[[:space:]]*\|/         {anon=$3}
  /service_role[[:space:]]*\|/ {srv=$3}
  END {
    print "SUPABASE_URL=https://" pr ".supabase.co";
    print "SUPABASE_ANON_KEY=" anon;
    print "SUPABASE_SERVICE_ROLE_KEY=" srv;
    print "POSTGRES_POOLER_URL=postgres://postgres:" pw "@db." pr ".supabase.co:6543/postgres";
    print "EDGE_API_TOKEN=" tok;
  }' > .env.cloud

Load environment variables, so the next steps will work:

set -a && source .env.cloud && set +a

Push database structure

Claude Code: /migrate applies pending migrations safely with review and confirmation steps.

Optional: reset remote database

npx supabase link --workdir deployment
npx supabase db reset --linked --workdir deployment
npx supabase db push --workdir deployment

Apply all SQL migrations to the linked project

npx supabase migration up --workdir deployment/ --db-url "$POSTGRES_POOLER_URL"

Combat round resolution cron config (cloud)

Populate app_runtime_config with the Supabase URL and edge token (run after migrations). The script requires --env <file>; production additionally requires --allow-production.

# dev
scripts/setup-production-combat-tick.sh --env .env.cloud.dev

# production (manual; will prompt to type 'MODIFY PRODUCTION')
scripts/setup-production-combat-tick.sh --env .env.cloud --allow-production

Verify:

psql "$POSTGRES_POOLER_URL" -c "SELECT key, updated_at FROM app_runtime_config WHERE key IN ('supabase_url','edge_api_token');"

Deploy edge functions

Claude Code: /deploy-functions deploys all edge functions to production or local.

Deploy edge functions to your Supabase project. You will see warnings about decorator flags. You can ignore them.

npx supabase functions deploy --workdir deployment/ --no-verify-jwt

Add required secrets. Ignore the warnings about the SUPABASE_ variables. They are set automatically in the project.

npx supabase secrets set --env-file .env.cloud

Note: we will need to add BOT_START_URL and BOT_START_API_KEY later.

Add Universe Data

Generate the universe JSON locally. The output path is tmp/world-data/universe.json.

uv run universe-bang 5000 1234

Validate and load it into the Supabase project referenced by your current environment:

uv run -m gradientbang.scripts.load_universe_to_supabase --from-json tmp/world-data/ --dry-run
uv run -m gradientbang.scripts.load_universe_to_supabase --from-json tmp/world-data/

Load quest definitions (or use /load-quests):

uv run -m gradientbang.scripts.load_quests_to_supabase

Deploy bot to Pipecat Cloud

Claude Code: /deploy-bot handles the full build, push, and deploy flow interactively.

Create .env.bot for Pipecat Cloud (see Bot environment variables for the full list):

cp env.bot.example .env.bot
# Fill in your API keys and Supabase credentials

Create a new secret set on Pipecat Cloud:

pipecat cloud secrets set gb-bot-secrets --file .env.bot

Build and deploy bot:

docker build -f deployment/Dockerfile.bot -t gb-bot:latest .
docker push gb-bot:latest

cd deployment/
pipecat cloud deploy
# ... or if public
# pipecat cloud deploy --no-credentials

Update edge functions with bot start URL

Create and note down a Public API Key:

pipecat cloud organizations keys create

Add bot integration vars to .env.cloud:

BOT_START_URL=https://api.pipecat.daily.co/v1/public/{AGENT_NAME}/start
BOT_START_API_KEY=...

Apply to edge functions:

npx supabase secrets set --env-file .env.cloud

Point client to your production environment

# client/app/.env
VITE_SERVER_URL=https://{SUPABASE_PROJECT_ID}.supabase.co/functions/v1
VITE_PIPECAT_TRANSPORT=daily

cd client/
pnpm run dev

Environment variables

Edge functions (.env.supabase / .env.cloud)

Bot (.env.bot)

API keys

*Exactly one TTS key is required for the selected TTS_PROVIDER; Gradium is the default.

Supabase & connectivity

TTS configuration

LLM configuration

UI agent tuning

Testing & debug

Optional integrations

Auth & secrets quick guide

• Gateway check (Supabase): default verify_jwt=true requires Authorization: Bearer $SUPABASE_ANON_KEY (or a user access token). Keep this on in production; optional --no-verify-jwt only for local.
• App gate (gameplay): every gameplay edge function expects X-Edge-Auth: $EDGE_API_TOKEN, except explicit local auth-bypass test/dev setups. X-API-Token: <user-access-token> is optional user context for bot sessions.
  • Bot context: X-Edge-Auth plus a Supabase Auth access_token in X-API-Token. Edge functions use canActOnCharacter() so the caller can only operate on characters they own directly or via corp membership.
  • Admin context: X-Edge-Auth only. Used by NPCs, the combat-tick cron job, internal pg_net invocations, and dev tooling. Bypasses per-character checks by design.
• BYOA configuration: ship_byoa_configure is authenticated by the caller's Supabase Auth JWT, not EDGE_API_TOKEN. Ship lookups for claim/unclaim flows must happen inside that JWT security boundary so operators only see and mutate ships their character is allowed to access.
• Bot/client calls: send apikey: $SUPABASE_ANON_KEY, Authorization: Bearer $SUPABASE_ANON_KEY (gateway), X-Edge-Auth: $EDGE_API_TOKEN, and, for user-bound bot sessions, X-API-Token: <user-access-token>.
• Production secrets to set: SUPABASE_URL, SUPABASE_ANON_KEY, SUPABASE_SERVICE_ROLE_KEY, POSTGRES_POOLER_URL, EDGE_API_TOKEN (required on every bot, NPC, and cron caller — the trusted-backend gate verifies it on every gameplay edge call).
• Combat cron: ensure app_runtime_config has supabase_url and edge_api_token set to the live values (use scripts/setup-production-combat-tick.sh --env <env-file>; prod requires --allow-production).

Claude Code skills reference

This project includes a set of Claude Code skills (slash commands) that automate common development and testing workflows. Run them inside Claude Code with /skill-name.

/newspaper — generating newspaper assets

The newspaper system uses a shared retro-digital aesthetic across multiple asset types. /newspaper is the single entry point that routes to the right underlying script. All outputs land under artifacts/ (gitignored).

Banners — single wide masthead-style image (e.g. recruitment header, special-edition broadside):

/newspaper banner Call to arms recruiting pilots to test the combat rework. CTA: #gradient-bang

The skill drafts kicker / headline / subhead / body / CTA in the newspaper's voice, confirms the copy with you, then renders a 2048×1024 PNG via news-banner (~2 minutes per render). Override the shape with --size 2880x1024 for a Discord-style banner.

Front pages — full ten-section newspaper from real game events:

/news-front-page 24h

/newspaper front-page simply forwards to /news-front-page — use that directly. It pulls events from the configured Supabase environment, mines storylines, writes the front-page Markdown, and renders a 2160×3840 PNG.

Prompt experiments — sweep prompt variants for front-page rendering. See news-front-page-prompt-experiment --help.
