pixels-spike
A cloud-native computing framework for serverless query processing.
1. How to get started
step1: Install Go
Requires Go version 1.22.7 or higher.
Some go plugins for protobuf and grpc are required to generate the go source files for the proto files:
# install protoc-gen-go to generate the go source code for protobuf messages
go install google.golang.org/protobuf/cmd/protoc-gen-go@latest
# install protoc-gen-go-grpc to generate the go source code for grpc services
go install google.golang.org/grpc/cmd/protoc-gen-go-grpc@latest
# install protoc-gen-grpc-gateway to transport HTTP to grpc
go install github.com/grpc-ecosystem/grpc-gateway/v2/protoc-gen-grpc-gateway@latest
# install protoc-gen-swagger to parse the swagger annotations in the proto files and generate OpenAPI docs
go install github.com/grpc-ecosystem/grpc-gateway/protoc-gen-swagger@lateststep2: Start MySQL
For example, start MySQL with Docker, and then create the spike database:
# Download the mysql:8.0.31 image
docker pull mysql:8.0.31
# Start the MySQL instance
docker run --name spike-mysql -e MYSQL_ROOT_PASSWORD=spikepassword -p 3306:3306 -d mysql:8.0.31
# After the MySQL instance starts, enter the MySQL container
docker exec -it spike-mysql mysql -uroot -pspikepassword -e "CREATE DATABASE spike;"step3: Initialize submodules
This project uses Git submodules. You need to initialize and update them:
# Initialize submodules
git submodule init
# Update submodules to their latest commits
git submodule updatestep4: Build spike
sh build.shstep5: Setup AWS credentials
To use AWS computing resources, you need to configure AWS credentials. You can use either environment variables or credential files.
step6: Modify spike config file
Edit spike.yaml, mainly modify the aws_config section to match your AWS cluster configuration.
Parameter description:
aws_cluster: AWS ECS cluster nameaws_subnets: List of AWS VPC subnet IDs for deploying function instancesaws_security_groups: List of AWS security group IDs for controlling network access permissionstask_role: AWS IAM role name for granting function instances access to AWS resourcesec2_provider: AWS EC2 capacity provider name for providing EC2 instance resources
aws_config:
aws_cluster: spike_cluster_mini
aws_subnets:
- subnet-01930cb57dbc12f7e
- subnet-0c77aae8c226d039c
- subnet-02bd39d1f8b337c22
aws_security_groups:
- sg-02221dbcd555d5277
task_role: PixelsFaaSRole
ec2_provider: Infra-ECS-Cluster-spikeclustermini-d985e674-EC2CapacityProvider-FufGynLGFE0qstep7: Run spike
cd build
./spike-server -f spike.yaml2. How to call function
step1: Create a function
Parameter description:
function_name: Function name, used to uniquely identify a functionimage_url: Container image URL for the functionresources: List of function resource configurations, multiple specifications can be configuredcpu: CPU resource size in millicores (1 core = 1000 millicores)memory: Memory resource size in MBmin_replica: Minimum number of replicas, i.e., minimum number of function instancesmax_replica: Maximum number of replicas, i.e., maximum number of function instances
curl --location 'http://127.0.0.1:8080/v1/create_function' \
--header 'Content-Type: application/json' \
--data '{
"function_name": "test",
"image_url": "013072238852.dkr.ecr.cn-north-1.amazonaws.com.cn/agentguo/test:1.1",
"resources": [
{
"cpu": 8192,
"memory": 32768,
"min_replica": 1,
"max_replica": 5
},
{
"cpu": 4096,
"memory": 16384,
"min_replica": 1,
"max_replica": 5
}
]
}'step2: Call function (test function will sleep for payload seconds)
Parameter description:
function_name: Name of the function to callpayload: Function input parameters, here representing sleep secondscpu: Required CPU resource size in millicores (1 core = 1000 millicores)memory: Required memory resource size in MB, set to 0 for default value
curl --location 'http://127.0.0.1:8080/v1/call_function' \
--header 'Content-Type: application/json' \
--data '{
"function_name": "test",
"payload": "3",
"cpu": 8192,
"memory": 0
}'
