SplatTransform - 3D Gaussian Splat Converter

npm install -g @playcanvas/splat-transform

npm install @playcanvas/splat-transform

splat-transform [GLOBAL] input [ACTIONS]  ...  output [ACTIONS]

-t, --translate        <x,y,z>          Translate Gaussians by (x, y, z)
-r, --rotate           <x,y,z>          Rotate Gaussians by Euler angles (x, y, z), in degrees
-s, --scale            <factor>         Uniformly scale Gaussians by factor
-H, --filter-harmonics <0|1|2|3>        Remove spherical harmonic bands > n
-N, --filter-nan                        Remove Gaussians with NaN values and most Inf values;
                                          retains +Infinity in opacity and -Infinity in scale_*
-B, --filter-box       <x,y,z,X,Y,Z>    Remove Gaussians outside box (min, max corners)
-S, --filter-sphere    <x,y,z,radius>   Remove Gaussians outside sphere (center, radius)
-V, --filter-value     <name,cmp,value> Keep Gaussians where <name> <cmp> <value>
                                          cmp ∈ {lt,lte,gt,gte,eq,neq}
                                          opacity, scale_*, f_dc_* use transformed values
                                          (linear opacity 0-1, linear scale, linear color 0-1).
                                          Append _raw for raw PLY values (e.g. opacity_raw).
-d, --decimate         <n|n%>           Simplify to n Gaussians via merge-based decimation
                                          Use n% to keep a percentage of Gaussians.
                                          Memory-bounded and streaming: scales to scenes of 100M+
                                          Gaussians. Must be the final action, and the output must
                                          be .ply (write a decimated PLY first, then convert in a
                                          second invocation). Deep targets on huge scenes spill
                                          temporary files to --scratch-dir (default: the output
                                          file's directory).
    --scratch-dir      <path>           Directory for decimation spill files
-F, --filter-floaters  [size,op,min]    Remove Gaussians not contributing to any solid voxel.
                                          Evaluates each Gaussian at occupied voxel centers.
                                          Default: size=0.05, opacity=0.1, min=0.004 (1/255).
                                          Bare flag (no value) uses all defaults.
-C, --filter-cluster   [res,op,min]     Keep only the connected cluster at --seed-pos.
                                          GPU-voxelizes at coarse resolution (res world units/voxel).
                                          Default: res=1.0, opacity=0.999, min=0.1.
                                          Bare flag (no value) uses all defaults.
-p, --params           <key=val,...>    Pass parameters to .mjs generator script
-l, --tag-lod          <n>              Tag the Gaussians with LOD level n (n >= 0, or -1 for environment)
    --stats            [text|json]      Print file info and per-column statistics to stdout. Default: text
    --info             [text|json]      Print structural metadata (per-LOD counts, columns) to stdout. Default: text
-m, --morton-order                      Reorder Gaussians by Morton code (Z-order curve)

-h, --help                              Show this help and exit
-v, --version                           Show version and exit
-q, --quiet                             Suppress non-error output
    --verbose                           Show debug-level diagnostics
    --memory                            Show peak memory in progress output
    --tty                               Interactive bar rendering (default on a TTY; --no-tty to disable)
-w, --overwrite                         Overwrite output file if it exists

    --list-gpus                         List available GPU adapters and exit
-g, --gpu              <n|cpu>          Device for GPU operations: GPU adapter index | 'cpu'
                                          ('cpu' disables GPU and is incompatible with
                                          GPU-only features like --filter-cluster)

-i, --sh-iterations    <n>              Iterations for SH compression (more=better). Default: 10
    --max-workers      <n>              Worker threads for SOG encoding (0 = inline/serial). Default: 4

    --spz-version      <3|4>            The SPZ format version to write. Default: 4

    --viewer-settings  <settings.json>  HTML viewer settings JSON file
    --unbundled                         Generate unbundled HTML viewer with separate files

-L, --select-lod       <n,n,...>        Comma-separated LOD levels to read from LCC / LCC2 input

    --lod-chunk-count  <n>              Approximate number of Gaussians per LOD chunk in K. Default: 512
    --lod-chunk-extent <n>              Approximate size of an LOD chunk in world units (m). Default: 16

    --voxel-size       <n>              Voxel size for .voxel.json. Default: 0.05
    --voxel-opacity    <n>              Voxel opacity threshold for .voxel.json. Default: 0.1
    --voxel-external-fill [size]        Seal exterior voxels via boundary flood fill (interior scenes).
                                          [size] (world units) is the dilation distance applied
                                          before the flood fill to bridge small wall gaps.
                                          --seed-pos is used to verify the volume is enclosed at
                                          the seed; the fill is skipped if the seed is reachable
                                          from outside.
                                          Default size: 1.6
    --voxel-floor-fill [size]           Fill each column upward from bottom until hitting solid (exterior scenes).
                                          Optional size (world units): only patch XZ areas surrounded by floor
                                          within 2*size; large empty exterior areas are left alone.
                                          Default size: 1.6
    --voxel-carve      [h,r]            Carve navigable space using capsule flood fill from seed.
                                          Default: height=1.6, radius=0.2
    --seed-pos         <x,y,z>          Seed position for voxel fill/carve and --filter-cluster.
                                          Default: 0,0,0
    --collision-mesh   [smooth|faces]   Generate collision mesh (.collision.glb). Default: smooth

    --projection       <pinhole|equirect>  Camera projection. Default: pinhole.
                                        equirect = 360°×180° panorama from --camera-pos; --camera-fov must be
                                        omitted; --resolution must be 2:1 (default 2048x1024).
    --camera-pos       <x,y,z>          Camera position in world space. Default: 2,1,-2
    --camera-target    <x,y,z>          Camera target point. Default: 0,0,0
    --camera-up        <x,y,z>          World up vector. Default: 0,1,0
    --camera-fov       <degrees>        Vertical field of view in degrees. Default: 60. Rejected with --projection equirect.
    --resolution       <WxH>            Output resolution, e.g. 1920x1080. Default: 1280x720 (pinhole) or 2048x1024 (equirect)
    --camera-near      <n>              Near clip distance. Default: 0.2 (matches reference 3DGS)
    --background       <r,g,b[,a]>      Background color in [0,1]. Default: 0,0,0,1
    --f-stop           <N>              Aperture as a photographic f-stop (e.g. 2.8, 5.6, 11). Enables defocus blur;
                                        smaller = more blur. Pinhole only. Default: disabled (no defocus).
    --focus-distance   <n>              Camera-space Z of the focus plane (world units). Default: distance to --camera-target.
                                        Pinhole only; only meaningful with --f-stop.
    --sensor-size      <n>              Vertical sensor height in world units. Gives --f-stop a physical meaning.
                                        Default: 0.024 (35mm full-frame, world units = meters). Scale to your world:
                                        world unit = decimeter → 0.24, world unit = millimeter → 24.
    --camera-pos-end   <x,y,z>          End camera position. When set, enables camera motion blur: the renderer
                                        averages sub-frames with the camera interpolated from --camera-pos (shutter open)
                                        to --camera-pos-end (shutter close). Default: disabled (no motion blur).
    --camera-target-end <x,y,z>         End camera target. Default: same as --camera-target. Only with --camera-pos-end.
    --camera-up-end    <x,y,z>          End up vector. Default: same as --camera-up. Only with --camera-pos-end.
    --shutter          <0..1>           Fraction of the start→end segment integrated, centered on the midpoint
                                        (1.0 = full motion; 0.5 = 180° shutter). Default: 1. Only with --camera-pos-end.
    --motion-samples   <n>              Sub-frames to accumulate for motion blur. Cost is N× a single render.
                                        Default: 16. Only with --camera-pos-end.

# Simple format conversion
splat-transform input.ply output.csv

# Convert from .splat format
splat-transform input.splat output.ply

# Convert from .ksplat format
splat-transform input.ksplat output.ply

# Convert to compressed PLY
splat-transform input.ply output.compressed.ply

# Uncompress a compressed PLY back to standard PLY
# (compressed .ply is detected automatically on read)
splat-transform input.compressed.ply output.ply

# Convert to SOG bundled format
splat-transform input.ply output.sog

# Convert to SOG unbundled format
splat-transform input.ply output/meta.json

# Convert from SOG (bundled) back to PLY
splat-transform scene.sog restored.ply

# Convert from SOG (unbundled folder) back to PLY
splat-transform output/meta.json restored.ply

# Convert to standalone HTML viewer (bundled, single file)
splat-transform input.ply output.html

# Convert to unbundled HTML viewer (separate CSS, JS, and SOG files)
splat-transform --unbundled input.ply output.html

# Convert to HTML viewer with custom settings
splat-transform --viewer-settings settings.json input.ply output.html

# Scale and translate
splat-transform bunny.ply -s 0.5 -t 0,0,10 bunny_scaled.ply

# Rotate by 90 degrees around Y axis
splat-transform input.ply -r 0,90,0 output.ply

# Chain multiple transformations
splat-transform input.ply -s 2 -t 1,0,0 -r 0,0,45 output.ply

# Remove entries containing NaN and Inf
splat-transform input.ply --filter-nan output.ply

# Filter by opacity values (keep only splats with opacity > 0.5)
splat-transform input.ply -V opacity,gt,0.5 output.ply

# Strip spherical harmonic bands higher than 2
splat-transform input.ply --filter-harmonics 2 output.ply

# Simplify to 50000 splats via progressive pairwise merging
splat-transform input.ply --decimate 50000 output.ply

# Simplify to 25% of original splat count
splat-transform input.ply -d 25% output.ply

# Combine multiple files with different transforms
splat-transform -w cloudA.ply -r 0,90,0 cloudB.ply -s 2 merged.compressed.ply

# Apply final transformations to combined result
splat-transform input1.ply input2.ply output.ply -t 0,0,10 -s 0.5

# Print stats, then write output
splat-transform input.ply --stats output.ply

# Print stats without writing a file (discard output)
splat-transform input.ply --stats null

# Print stats as JSON for scripting
splat-transform input.ply --stats json null

# Print stats before and after a transform
splat-transform input.ply --stats -s 0.5 --stats output.ply

splat-transform gen-grid.mjs -p width=10,height=10,scale=10,color=0.1 scenes/grid.ply -w

splat-transform input.ply \
    --filter-cluster --seed-pos x,y,z \
    [--voxel-external-fill | --voxel-floor-fill] [--voxel-carve] \
    [--collision-mesh [smooth|faces]] \
    output.voxel.json

splat-transform room.ply \
    --filter-cluster --seed-pos 0,1,0 \
    --voxel-external-fill --voxel-carve \
    --collision-mesh room.voxel.json

splat-transform terrain.ply \
    --filter-cluster --seed-pos 0,0,0 \
    --voxel-floor-fill \
    --collision-mesh terrain.voxel.json

# Voxelize with custom resolution and opacity threshold
splat-transform --voxel-size 0.1 --voxel-opacity 0.3 input.ply output.voxel.json

# Custom carve capsule (height, radius)
splat-transform --seed-pos 1,0,0 --voxel-carve 2.0,0.3 input.ply output.voxel.json

# Watertight voxel-face collision mesh
splat-transform --collision-mesh faces input.ply output.voxel.json

# Default 1280x720 render
splat-transform input.ply view.webp

# Custom camera and resolution
splat-transform input.ply view.webp \
    --camera-pos 2,1,-2 --camera-target 0,0,0 \
    --camera-fov 50 --resolution 1920x1080

# Transparent background
splat-transform input.ply view.webp --background 0,0,0,0

# Defocus blur (focus on camera-target, f/2.8 aperture)
splat-transform input.ply view.webp --f-stop 2.8

# Defocus with explicit focus distance and a smaller world scale
splat-transform input.ply view.webp \
    --f-stop 2.8 --focus-distance 3 --sensor-size 0.1

# 360° equirectangular panorama from camera position
splat-transform input.ply pano.webp \
    --projection equirect --camera-pos 0,1,0 --camera-target 0,1,1

# Camera motion blur (dolly from start to end pose over the shutter)
splat-transform input.ply view.webp \
    --camera-pos 2,1,-2 --camera-pos-end 3,1,-2 \
    --motion-samples 16 --shutter 1

# List available GPU adapters
splat-transform --list-gpus

# Let WebGPU automatically choose the best GPU (default behavior)
splat-transform input.ply output.sog

# Explicitly select a GPU adapter by index
splat-transform -g 0 input.ply output.sog  # Use first listed adapter
splat-transform -g 1 input.ply output.sog  # Use second listed adapter

# Use CPU for compression instead (much slower but always available)
splat-transform -g cpu input.ply output.sog

# Show version
splat-transform --version

# Show help
splat-transform --help

import {
    readFile,
    writeSource,
    getInputFormat,
    getOutputFormat,
    createChunkDataPool,
    processSourceBridged
} from '@playcanvas/splat-transform';

import { Vec3 } from 'playcanvas';
import {
    readFile,
    writeSource,
    getInputFormat,
    getOutputFormat,
    createChunkDataPool,
    processSourceBridged,
    UrlReadFileSystem,
    MemoryFileSystem
} from '@playcanvas/splat-transform';

// Read a PLY file from a URL as a lazy, chunked source
const fileSystem = new UrlReadFileSystem('https://example.com/');
const [source] = await readFile({
    filename: 'scene.ply',
    inputFormat: getInputFormat('scene.ply'),
    fileSystem
});

// Apply actions: transforms compose lazily, filters stream chunk-by-chunk
const pool = createChunkDataPool();
const processed = await processSourceBridged(source, [
    { kind: 'scale', value: 0.5 },
    { kind: 'translate', value: new Vec3(0, 1, 0) },
    { kind: 'filterNaN' }
], pool);

// Stream the result to an in-memory PLY
const memFs = new MemoryFileSystem();
await writeSource({
    filename: 'output.ply',
    outputFormat: getOutputFormat('output.ply', {}),
    source: processed,
    pool,
    options: {}
}, memFs);
await processed.close();

// Get the output data
const outputBuffer = memFs.results.get('output.ply');

type ProcessAction =
    | { kind: 'translate'; value: Vec3 }
    | { kind: 'rotate'; value: Vec3 }       // Euler angles in degrees
    | { kind: 'scale'; value: number }
    | { kind: 'filterNaN' }
    | { kind: 'filterByValue'; columnName: string; comparator: 'lt'|'lte'|'gt'|'gte'|'eq'|'neq'; value: number }
    | { kind: 'filterBands'; value: 0|1|2|3 }
    | { kind: 'filterBox'; min: Vec3; max: Vec3 }
    | { kind: 'filterSphere'; center: Vec3; radius: number }
    | { kind: 'filterFloaters'; voxelResolution?: number; opacityCutoff?: number; minContribution?: number } // GPU
    | { kind: 'filterCluster'; voxelResolution?: number; seed?: Vec3; opacityCutoff?: number; minContribution?: number } // GPU
    | { kind: 'decimate'; count: number | null; percent: number | null }
    | { kind: 'param'; name: string; value: string }
    | { kind: 'stats'; format?: 'text' | 'json' }
    | { kind: 'info'; format?: 'text' | 'json' }
    | { kind: 'mortonOrder' };

import { logger, TextRenderer } from '@playcanvas/splat-transform';

// Route status output (scopes, progress bars, messages) to stderr and
// pipeable output (e.g. JSON stats) to stdout
logger.setRenderer(new TextRenderer({
    write: process.stderr.write.bind(process.stderr),
    output: process.stdout.write.bind(process.stdout)
}));

logger.setVerbosity('quiet'); // 'quiet' | 'normal' | 'verbose'
