SuperSplat Viewer
| User Manual | Blog | Forum |
This is the official viewer for SuperSplat.
The web app compiles to a simple, self-contained static website.
URL Parameters
The app supports a number of URL parameters (these are subject to change):
Content
| Parameter | Description | Default |
|---|---|---|
settings | URL of the settings.json file | ./settings.json |
content | URL of the scene file (.ply, .sog, .compressed.ply, .meta.json, .lod-meta.json) | ./scene.compressed.ply |
skybox | URL of an equirectangular skybox image | |
poster | URL of an image to show while loading | |
collision | URL of a collision asset (.glb mesh, or voxel data). voxel is accepted as an alias. |
UI
| Parameter | Description |
|---|---|
noui | Hide the UI overlay |
noanim | Start with animation paused |
ministats | Show runtime CPU/GPU performance graphs |
lang | Override the UI language (de, en, es, fr, ja, ko, pt-BR, ru, zh-CN; default: detect from browser) |
Renderer
By default the viewer uses WebGPU when available (falling back automatically when not). The flag below forces the WebGL renderer (also required for WebXR / AR / VR):
| Parameter | Description |
|---|---|
webgl | Force the WebGL renderer (required for AR/VR) |
aa | Enable antialiasing (WebGL only) |
nofx | Disable post effects |
hpr | Override highPrecisionRendering from settings (?hpr, ?hpr=1, ?hpr=true, ?hpr=enable to enable) |
budget | Override the splat budget, in millions of splats |
colorize | Render with LOD colorization |
fullload | Load all streaming LOD data before the first frame |
heatmap | Render the heatmap debug overlay (WebGPU only) |
debug | Open the developer debug panel on load (Ctrl+Shift+D to toggle) |
NPM Package
The web app source files are available as strings for templating when you import the package from npm:
import { html, css, js } from '@playcanvas/supersplat-viewer';
// logs the source of index.html
console.log(html);
// logs the source of index.css
console.log(css);
// logs the source of index.js
console.log(js);The package also exports the settings schema types and helpers via the /settings subpath, which is useful for generating, validating or migrating a settings.json file:
import {
importSettings,
validateSettings,
type ExperienceSettings
} from '@playcanvas/supersplat-viewer/settings';
// throws on invalid input
validateSettings(json);
// migrates a v1 settings object to the latest schema
const settings: ExperienceSettings = importSettings(json);Local Development
To initialize a local development environment for SuperSplat Viewer, ensure you have Node.js 18 or later installed. Follow these steps:
-
Clone the repository:
git clone https://github.com/playcanvas/supersplat-viewer.git cd supersplat-viewer -
Install dependencies:
npm install -
Start the development build and local web server:
npm run develop -
Open your browser at http://localhost:3000.
Debug engine build
By default the viewer links against the release build of the PlayCanvas engine. Set ENGINE=debug to link against the engine's debug build instead, which includes runtime assertions and unminified, readable source for easier debugging:
ENGINE=debug npm run developThis also works with npm run build and npm run watch.
Settings Schema
The settings.json file uses the schema below (defined in TypeScript and exported from @playcanvas/supersplat-viewer/settings). Legacy v1 settings produced by older SuperSplat releases are automatically migrated to v2 on load.
type AnimTrack = {
name: string,
duration: number,
frameRate: number,
loopMode: 'none' | 'repeat' | 'pingpong',
interpolation: 'step' | 'spline',
smoothness: number,
keyframes: {
times: number[],
values: {
position: number[],
target: number[],
fov: number[],
}
}
};
type CameraPose = {
position: [number, number, number],
target: [number, number, number],
fov: number
};
type Camera = {
initial: CameraPose
};
type Annotation = {
position: [number, number, number],
title: string,
text: string,
extras?: any,
camera: Camera
};
type PostEffectSettings = {
sharpness: { enabled: boolean, amount: number },
bloom: { enabled: boolean, intensity: number, blurLevel: number },
grading: { enabled: boolean, brightness: number, contrast: number, saturation: number, tint: [number, number, number] },
vignette: { enabled: boolean, intensity: number, inner: number, outer: number, curvature: number },
fringing: { enabled: boolean, intensity: number }
};
type ExperienceSettings = {
version: 2,
tonemapping: 'none' | 'linear' | 'filmic' | 'hejl' | 'aces' | 'aces2' | 'neutral',
highPrecisionRendering: boolean,
soundUrl?: string,
background: {
color: [number, number, number],
skyboxUrl?: string
},
postEffectSettings: PostEffectSettings,
animTracks: AnimTrack[],
cameras: Camera[],
annotations: Annotation[],
startMode: 'default' | 'animTrack' | 'annotation'
};Example settings.json
{
"version": 2,
"tonemapping": "none",
"highPrecisionRendering": false,
"background": {
"color": [0, 0, 0]
},
"postEffectSettings": {
"sharpness": { "enabled": false, "amount": 0 },
"bloom": { "enabled": false, "intensity": 1, "blurLevel": 2 },
"grading": { "enabled": false, "brightness": 0, "contrast": 1, "saturation": 1, "tint": [1, 1, 1] },
"vignette": { "enabled": false, "intensity": 0.5, "inner": 0.3, "outer": 0.75, "curvature": 1 },
"fringing": { "enabled": false, "intensity": 0.5 }
},
"animTracks": [],
"cameras": [
{
"initial": {
"position": [0, 1, -1],
"target": [0, 0, 0],
"fov": 60
}
}
],
"annotations": [],
"startMode": "default"
}
