three-html-render

Polyfill for the WICG HTML-in-Canvas proposal. Render live, interactive HTML as a WebGL / WebGPU / 2D texture — works in all browsers today.

Features

• HTML-in-Canvas polyfill — implements the WICG API in every browser (Safari, Firefox, iOS, Android); not just Chrome Canary.
• Fast path — uses native texElementImage2D / copyElementImageToTexture when available, falls back to SVG foreignObject rasterization otherwise.
• Pseudo-classes — :hover, :focus, :active, :focus-visible, :focus-within render correctly on 3D surfaces.
• CSS animations & transitions — spinners, keyframes, gradient shifts all render live into the texture.
• Scrollable content, caret, selection — measured from the live DOM and composited into the rasterized texture.
• Page-level text selection — drag across HTML on a 3D surface; the highlight shows up in the texture.
• Drop-in three.js classes — ships an HTMLTexture and InteractionManager that match upstream three.js API; works on any three >= 0.150.0.
• Raycast interaction manager — single-element overlay that works on every face of a box and on curved surfaces.
• Standalone overlay — same matrix3d math without a three.js dependency, for raw WebGL / WebGPU / 2D apps.
• Browser extension — Chrome & Safari extensions to polyfill any page.

Install

Drop-in script tag (zero config):

<script src="https://cdn.jsdelivr.net/npm/three-html-render/dist/polyfill.js"></script>

…or install from npm:

npm install three-html-render

Package exports

Canonical importmap for the CDN deployment:

{
  "imports": {
    "three": "https://cdn.jsdelivr.net/npm/three@0.184.0/build/three.module.js",
    "three/addons/": "https://cdn.jsdelivr.net/npm/three@0.184.0/examples/jsm/",
    "three-html-render/polyfill": "https://cdn.jsdelivr.net/npm/three-html-render/dist/polyfill.mjs",
    "three-html-render/html-texture": "https://cdn.jsdelivr.net/npm/three-html-render/dist/html-texture.js",
    "three-html-render/interaction-manager": "https://cdn.jsdelivr.net/npm/three-html-render/dist/interaction-manager.js",
    "three-html-render/raycast-interaction-manager": "https://cdn.jsdelivr.net/npm/three-html-render/dist/raycast-interaction-manager.js",
    "three-html-render/interaction-manager-standalone": "https://cdn.jsdelivr.net/npm/three-html-render/dist/interaction-manager-standalone.js"
  }
}

Usage

Polyfill only (no three.js)

The polyfill installs every WICG HTML-in-Canvas API onto the browser's own prototypes, so any <canvas layoutsubtree> works with the standard specification:

<canvas id="c" layoutsubtree>
  <div id="content" style="width:400px;height:300px">
    <h1>Hello from HTML</h1>
    <button>Click me</button>
  </div>
</canvas>

<script type="module">
  import { installHtmlInCanvasPolyfill } from 'three-html-render/polyfill'
  installHtmlInCanvasPolyfill()

  const canvas = document.getElementById('c')
  const content = document.getElementById('content')
  const ctx = canvas.getContext('2d')

  canvas.onpaint = () => ctx.drawElementImage(content, 0, 0)
  canvas.requestPaint()
</script>

With three.js

This mirrors the upstream three.js webgl_materials_texture_html example — on three >= 0.184 our HTMLTexture is the native class; on older three.js it's a fallback that captures the element as a canvas and rides three.js's standard texture pipeline. Your code is the same either way.

<canvas id="canvas" layoutsubtree>
  <div id="content" style="width:512px;height:512px;padding:20px;background:white;font-size:24px;">
    <h1>Hello from HTML</h1>
    <button onclick="this.textContent='Clicked!'">Click me</button>
    <input type="text" placeholder="Type here">
  </div>
</canvas>

<script type="module">
  import * as THREE from 'three'
  import { installHtmlInCanvasPolyfill } from 'three-html-render/polyfill'
  import { HTMLTexture } from 'three-html-render/html-texture'
  import { InteractionManager } from 'three-html-render/interaction-manager'

  installHtmlInCanvasPolyfill()

  const canvas = document.getElementById('canvas')
  const content = document.getElementById('content')
  const scene = new THREE.Scene()
  const camera = new THREE.PerspectiveCamera(75, innerWidth / innerHeight, 0.1, 100)
  camera.position.z = 2
  const renderer = new THREE.WebGLRenderer({ canvas })
  renderer.setSize(innerWidth, innerHeight)
  renderer.setAnimationLoop(animate)

  const material = new THREE.MeshBasicMaterial({ map: new HTMLTexture(content) })
  const mesh = new THREE.Mesh(new THREE.PlaneGeometry(2, 2), material)
  scene.add(mesh)

  const interactions = new InteractionManager()
  interactions.connect(renderer, camera)
  interactions.add(mesh)

  function animate() {
    interactions.update()
    renderer.render(scene, camera)
  }
</script>

Interaction on every face (raycast)

InteractionManager positions a DOM overlay on a single face using matrix3d — that matches upstream three.js behaviour but only covers one face of a box. For multi-face boxes and curved surfaces, use RaycastInteractionManager instead: on every pointer move / down it raycasts the scene, reads the hit UV, and translates the single HTML element so the sampled texture pixel sits exactly under the pointer. Clicks, selection, focus, :hover, image drag — all flow through native DOM semantics.

import { RaycastInteractionManager } from 'three-html-render/raycast-interaction-manager'

const interactions = new RaycastInteractionManager()
interactions.connect(renderer, camera)
interactions.add(mesh)
// no per-frame work — it's event-driven

Coexisting with OrbitControls: register a capture-phase pointerdown on the canvas that stops propagation when the pointer lands on the DOM element, so OrbitControls's setPointerCapture doesn't swallow clicks. See examples/three-html-raycast.html for the pattern.

Raw WebGL / WebGPU / 2D (no three.js)

InteractionManagerStandalone does the same matrix3d math without pulling in three.js. You hand it raw projection / view / world matrices (gl-matrix, DOMMatrix, anything that exposes the 16 floats), and it drives the CSS transform on the element.

import { InteractionManagerStandalone } from 'three-html-render/interaction-manager-standalone'

const overlay = new InteractionManagerStandalone()
overlay.connect(canvas, projectionMatrix, viewMatrix)
overlay.add(element, worldMatrix, { x: 2, y: 2, z: 2 }, 1 /* localMaxZ */)

// each frame:
overlay.setProjectionMatrix(projectionMatrix)
overlay.setViewMatrix(viewMatrix)
overlay.update()

Bonus over the three.js version: backface culling — when a face's normal points away from the camera the element is hidden (display: none, pointer-events: none).

Choosing an interaction manager

What gets polyfilled

The polyfill implements the full WICG HTML-in-Canvas API surface:

API

installHtmlInCanvasPolyfill(options?)

Installs the polyfill on all <canvas layoutsubtree> elements. Safe to call multiple times — it's idempotent.

uninstallHtmlInCanvasPolyfill()

Cleanly removes the polyfill, restoring all patched prototypes, tearing down canvas states, and disconnecting observers.

getHtmlRenderer()

Returns the internal HtmlRenderer instance used by the polyfill. Useful for advanced operations:

import { getHtmlRenderer } from 'three-html-render/polyfill'
getHtmlRenderer().invalidatePageStylesCss()  // re-collect page styles after a runtime change

HTMLTexture(element, …)

Drop-in replacement for THREE.HTMLTexture (three.js >= 0.184).

• three.js >= 0.184: this is the native class — re-exported unchanged. texture.image === element, and three.js's own WebGLTextures.setTexture2D handles the upload via texElementImage2D.
• three.js 0.150–0.183: a fallback subclass. On every paint event from the parent canvas it calls captureElementImage(element) and assigns the resulting 2D canvas to texture.image. three.js's standard upload path handles it from there — flipY, colour space, state tracking all correct. The original element is kept in texture._sourceElement so the interaction managers can find it.

Requirement on the fallback path: append the element to a <canvas layoutsubtree> before constructing the texture. (Native HTMLTexture auto-appends from inside three.js's upload branch; we can't hook that on older versions.)

InteractionManager

Port of three/addons/interaction/InteractionManager.js. Positions the HTML element of each registered mesh's HTMLTexture using a single CSS matrix3d transform per frame, so the browser dispatches pointer events natively to the real HTML.

const im = new InteractionManager()
im.connect(renderer, camera)
im.add(mesh)
// in your animate loop:
im.update()

Math is viewport × projection × view × world × pixelToLocal, identical to upstream. Only change: looks up the element as texture._sourceElement ?? texture.image so it works both with native HTMLTexture and the fallback.

RaycastInteractionManager

Alternative to InteractionManager that supports every face of a box and any curved surface with a single DOM element. Event-driven, not frame-driven.

const im = new RaycastInteractionManager()
im.connect(renderer, camera)
im.add(mesh)
// no update() call required

On each pointermove / pointerdown on the canvas it raycasts registered meshes, reads intersects[0].uv, and translates the mesh's element so its (uv.x * w, (1 - uv.y) * h) pixel lands on the pointer. Other managed elements are parked off-screen so stale hover / misrouted clicks don't happen. Clicks, focus, text selection, image drag — all native DOM.

Based on Jake Archibald's curved-markup demo.

InteractionManagerStandalone

The InteractionManager math without the three.js dependency. Works with any renderer — raw WebGL, WebGPU, Canvas 2D.

const overlay = new InteractionManagerStandalone()
overlay.connect(canvas, projectionMatrix, viewMatrix)  // raw Float32Arrays
overlay.add(element, worldMatrix, { x, y, z }, localMaxZ)

// per frame:
overlay.setProjectionMatrix(projectionMatrix)
overlay.setViewMatrix(viewMatrix)
overlay.update()

Accepts Float32Array or number[] for every matrix. localSize is the mesh's local-space size; localMaxZ is boundingBox.max.z for the face you want the element to land on.

Extra over the three.js version: backface culling — when a face's normal points away from the camera the element is given display: none and pointer-events: none.

Browser support

The HTML-in-Canvas API is a WICG proposal currently in developer trial in Chrome Canary, with an origin trial planned for Chrome M148–M151. This polyfill ensures your code works today and transparently uses the native fast-path the moment a browser ships it.

Known limitations

• Textarea internal scroll isn't reflected in the texture (content renders at scroll offset 0).
• contenteditable elements don't get caret / selection rendering.
• Dynamic stylesheets added after the polyfill installs need getHtmlRenderer().invalidatePageStylesCss() to be picked up.
• :visited cannot be polyfilled (browser privacy restriction).
• Some CSS features render slightly differently inside SVG foreignObject (form-control appearance, color-scheme).
• The polyfill floors fractional vertical dimensions on canvas children to prevent sub-pixel drift between texture and DOM overlay. Set window.__HIC_MUTATE_DOM__ = false before installing to disable this if it interferes with CSS animations on element heights.

How it works

1. The polyfill moves <canvas> children into an off-screen host div, and rasterises them via <svg><foreignObject> → <img> → 2D canvas.
2. CSS pseudo-classes (:hover, :focus, :active, :focus-visible, :focus-within) are rewritten to real classes (.pseudo-hover, …) and injected into the SVG stylesheet. Mouse / focus / pointer events on the host overlay toggle those classes.
3. Input caret and text selection are measured from the live DOM and injected as positioned <div> elements into the SVG clone.
4. requestPaint / onpaint let the consumer control when rasterisation happens (rAF-coalesced).
5. An interaction manager (matrix3d or raycast) positions the DOM overlay so the browser handles hit-testing natively.
6. Each frame the texture is uploaded through the best available WebGL / WebGPU path.

Examples

Integration

Works with vanilla three.js (>= 0.150.0). The functionality is also built into threepipe (GitHub) and kite3d as plugins — manual integration isn't needed when using those frameworks.

For React Three Fiber or another three.js framework, refer to their documentation.

Browser extension

Chrome and Safari extensions are included to polyfill any page. See extension/README.md for build and installation instructions.

Development

npm run dev              # dev server (demos at localhost:5173)
npm run build            # library build (ESM + IIFE + .d.ts)
npm run build:demo       # demo site build (for GitHub Pages)
npm run build:extension  # browser extension build
npm run typecheck        # TypeScript check

License

MIT

Contributing

Contributions welcome. See CONTRIBUTING.md for development setup and guidelines.
