Kimera-Semantics

Release News

Dec 1st 2019: Kimera-Semantics got a complete revamp:
- Leaner code: no more code dedicated to meshing, we fully re-use Voxblox/OpenChisel instead.
- New fast method: an order of magnitude faster (took approx 1s before, 0.1s now) than using merged, with minimal accuracy loss for small voxels (it leverages Voxblox' fast approach): you can play with both methods by changing the parameter semantic_tsdf_integrator_type in the launch file. High-res video here.

Publications

We kindly ask to cite our paper if you find this library useful:

A. Rosinol, M. Abate, Y. Chang, L. Carlone, Kimera: an Open-Source Library for Real-Time Metric-Semantic Localization and Mapping. IEEE Intl. Conf. on Robotics and Automation (ICRA), 2020. arXiv:1910.02490.

@InProceedings{Rosinol20icra-Kimera,
  title = {Kimera: an Open-Source Library for Real-Time Metric-Semantic Localization and Mapping},
  author = {Rosinol, Antoni and Abate, Marcus and Chang, Yun and Carlone, Luca},
  year = {2020},
  booktitle = {IEEE Intl. Conf. on Robotics and Automation (ICRA)},
  url = {https://github.com/MIT-SPARK/Kimera},
  pdf = {https://arxiv.org/pdf/1910.02490.pdf}
}

Related publications

Our work is built using Voxblox, an amazing framework to build your own 3D voxelized world:

Helen Oleynikova, Zachary Taylor, Marius Fehr, Juan Nieto, and Roland Siegwart, Voxblox: Incremental 3D Euclidean Signed Distance Fields for On-Board MAV Planning, in IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS), 2016.

Which was originally inspired by OpenChisel:

Matthew Klingensmith, Ivan Dryanovski, Siddhartha Srinivasa, and Jizhong Xiao, Chisel: Real Time Large Scale 3D Reconstruction Onboard a Mobile Device using Spatially Hashed Signed Distance Fields.. Robotics: science and systems (RSS), 2015.

A related work to ours is Voxblox++ which also uses Voxblox for geometric and instance-aware segmentation, differently from our dense scene segmentation, check it out as well!:

Margarita Grinvald, Fadri Furrer, Tonci Novkovic, Jen Jen Chung, Cesar Cadena, Roland Siegwart, and Juan Nieto, Volumetric Instance-Aware Semantic Mapping and 3D Object Discovery, in IEEE Robotics and Automation Letters, July 2019.

1. Installation

A. Prerequisities

Install ROS by following our reference, or the official ROS website.
Install system dependencies:

sudo apt-get install python-wstool python-catkin-tools  protobuf-compiler autoconf
# Change `melodic` below for your own ROS distro
sudo apt-get install ros-melodic-cmake-modules

B. Kimera-Semantics Installation

Using catkin:

# Setup catkin workspace
mkdir -p ~/catkin_ws/src
cd ~/catkin_ws/
catkin init
catkin config --extend /opt/ros/melodic # Change `melodic` to your ROS distro
catkin config --cmake-args -DCMAKE_BUILD_TYPE=Release
catkin config --merge-devel

# Add workspace to bashrc.
echo 'source ~/catkin_ws/devel/setup.bash' >> ~/.bashrc

# Clone repo
cd ~/catkin_ws/src
git clone git@github.com:MIT-SPARK/Kimera-Semantics.git

# Install dependencies from rosinstall file using wstool
wstool init # Use unless wstool is already initialized

# Optionally add Kimera-Semantics to the rosinstall file
# wstool scrape

# For ssh:
wstool merge Kimera-Semantics/install/kimera_semantics_ssh.rosinstall
# For https:
#wstool merge Kimera-Semantics/install/kimera_semantics_https.rosinstall

# Download and update all dependencies
wstool update

Finally, compile:

# Compile code
catkin build kimera_semantics_ros

# Refresh workspace
source ~/catkin_ws/devel/setup.bash

2. Usage

First, install Kimera-Semantics, see instructions above.

In Simulation (with semantics)

Download the demo rosbag (click here to download) and save it in: ./kimera_semantics_ros/rosbag/kimera_semantics_demo.bag.
As a general good practice, open a new terminal and run: roscore
In another terminal, launch Kimera-Semantics:

roslaunch kimera_semantics_ros kimera_semantics.launch play_bag:=true

This will launch the rosbag that was downloaded in step 0 and will launch Kimera-Semantics.

In another terminal, launch rviz for visualization:

rviz -d $(rospack find kimera_semantics_ros)/rviz/kimera_semantics_gt.rviz

Note: you will need to source your catkin_ws for each new terminal unless you added the following line to your ~/.bashrc file: source ~/catkin_ws/devel/setup.bash # Change bash to the shell you use.

Note 2: you might need to check/uncheck once the Kimera Semantic 3D Mesh left pane topic in rviz to visualize the mesh.

In Euroc dataset (without semantics)

With Kimera-VIO

Download a Euroc rosbag: for example V1_01_easy
Install Kimera-VIO-ROS.
Open a new terminal, run: roscore
In another terminal, launch Kimera-VIO-ROS:

roslaunch kimera_vio_ros kimera_vio_ros_euroc.launch run_stereo_dense:=true

The flag run_stereo_dense:=true will do stereo dense reconstruction (using OpenCV's StereoBM algorithm).

In another terminal, launch Kimera-Semantics:

roslaunch kimera_semantics_ros kimera_semantics_euroc.launch

In yet another terminal, run the Euroc rosbag downloaded in step 0:

rosbag play V1_01_easy.bag --clock

Note 1: Don't forget the --clock flag!

Note 2: Kimera is so fast that you could also increase the rosbag rate by 3 --rate 3 and still see a good performance (results depend on available compute power).

Finally, in another terminal, run Rviz for visualization:

rviz -d $(rospack find kimera_semantics_ros)/rviz/kimera_semantics_euroc.rviz

3. FAQ

Minkindr doesn't compile:

Catkin ignore the minkindr_python catkin package: touch ~/catkin_ws/src/minkindr/minkindr_python/CATKIN_IGNORE
How to run Kimera-Semantics without Semantics?

We are using Voxblox as our 3D reconstruction library, therefore, to run without semantics, simply do:
```
roslaunch kimera_semantics_ros kimera_semantics.launch play_bag:=true metric_semantic_reconstruction:=false
```
How to enable Dense Depth Stereo estimation

This will run OpenCV's StereoBM algorithm, more info can be found here (also checkout this to choose good parameters):

roslaunch kimera_semantics_ros kimera_semantics.launch run_stereo_dense:=1

This will publish a /points2 topic, which you can visualize in Rviz as a 3D pointcloud. Alternatively, if you want to visualize the depth image, since Rviz does not provide a plugin to visualize a disparity image, we also run a disparity_image_proc nodelet that will publish the depth image to /depth_image.
