cuda-oxide

cuda-oxide is a custom rustc backend for compiling GPU kernels in pure Rust. The workspace combines:

• single-source compilation -- host and device code live in the same file, built with one cargo oxide build
• a rustc codegen backend that compiles #[kernel] functions to CUDA PTX
• device-side abstractions (type-safe indexing, shared memory, scoped atomics, barriers, TMA, warp/cluster ops)
• a host-side runtime for memory management, pinned host transfers, and kernel launching (cuda-core, cuda-async)
• a rust-native compilation pipeline using Pliron, an MLIR-like IR framework in Rust (Rust → Rust MIR → Pliron IR → LLVM IR → PTX)

Project Status

cuda-oxide is an experimental compiler that demonstrates how CUDA SIMT kernels can be written natively in pure Rust -- no DSLs, no foreign language bindings -- and made available to the broader Rust community. The project is in an early stage (alpha) and under active development: you should expect bugs, incomplete features, and API breakage as we work to improve it. That said, we hope you'll try it in your own work and help shape its direction by sharing feedback on your experience.

Please see CONTRIBUTING.md if you're interested in contributing to the project.

Quick Start

use cuda_device::{cuda_module, kernel, thread, DisjointSlice};
use cuda_core::{CudaContext, DeviceBuffer, LaunchConfig};

// Device: generic kernel that applies any function to each element.
// F can be a closure with captures — rustc monomorphizes it to a concrete type.
#[cuda_module]
mod kernels {
    use super::*;

    #[kernel]
    pub fn map<T: Copy, F: Fn(T) -> T + Copy>(f: F, input: &[T], mut out: DisjointSlice<T>) {
        let idx = thread::index_1d();
        let i = idx.get();
        if let Some(out_elem) = out.get_mut(idx) {
            *out_elem = f(input[i]);
        }
    }
}

fn main() {
    let ctx = CudaContext::new(0).unwrap();
    let stream = ctx.default_stream();

    let data: Vec<f32> = (0..1024).map(|i| i as f32).collect();
    let input = DeviceBuffer::from_host(&stream, &data).unwrap();
    let mut output = DeviceBuffer::<f32>::zeroed(&stream, 1024).unwrap();

    let module = kernels::load(&ctx).unwrap();

    // Launch with a closure — factor is captured and passed to the GPU automatically
    let factor = 2.5f32;
    module
        .map::<f32, _>(
            &stream,
            LaunchConfig::for_num_elems(1024),
            move |x: f32| x * factor,
            &input,
            &mut output,
        )
        .unwrap();

    let result = output.to_host_vec(&stream).unwrap();
    assert!((result[1] - 2.5).abs() < 1e-5);
}

The above example defines a generic #[kernel] function map that accepts any Fn(T) -> T closure. #[cuda_module] embeds the generated device artifact into the host binary and generates a typed module.map::<f32, _>(...) launch method. The closure move |x| x * factor is captured, scalarized, and passed as kernel parameters automatically.

For composable async GPU work, stream: disappears, {kernel}_async returns a lazy DeviceOperation, and execution happens when you call .sync() or .await.

use cuda_async::device_operation::DeviceOperation;

// Assuming `module`, `input`, and `output` come from the cuda-async setup:
let factor = 2.5f32;
module
    .map_async::<f32, _>(
        LaunchConfig::for_num_elems(1024),
        move |x: f32| x * factor,
        &input,
        &mut output,
    )?
    .sync()?;
// or: .await?;

See the async_mlp example and crates/cuda-async/README.md for the full async setup.

# Build and run an example
cargo oxide run host_closure

# Show full compilation pipeline (Rust MIR → dialect-mir → mem2reg → LLVM dialect → LLVM IR → PTX)
cargo oxide pipeline vecadd

# Debug with cuda-gdb
cargo oxide debug vecadd --tui

Setup

Requirements

• cargo-oxide — cargo subcommand that drives the build pipeline (cargo oxide run, build, debug, etc.)
• Rust nightly with rust-src and rustc-dev and llvm-tools components (pinned in rust-toolchain.toml)
• CUDA Toolkit (12.x+)
• Clang + libclang dev headers (clang-21 / libclang-common-21-dev) — needed by bindgen when building the host cuda-bindings crate
• Linux (tested on Ubuntu 24.04)

Install

cargo-oxide

Inside the cuda-oxide repo, cargo oxide works out of the box via a workspace alias.

For use outside the repo (your own projects), install it with the pinned nightly toolchain:

cargo +nightly-2026-04-03 install --git https://github.com/NVlabs/cuda-oxide.git cargo-oxide

On first run, cargo-oxide will automatically fetch and build the codegen backend.

Nix (alternative)

If you have Nix with flakes enabled, nix develop in the repo gives you a reproducible shell with CUDA 13, LLVM 22, Clang, and the pinned Rust nightly — no manual apt installs. The shellHook auto-discovers host NVIDIA drivers on NixOS and non-NixOS systems.

nix develop                                       # full dev shell in this repo
nix run github:NVlabs/cuda-oxide#new my-project   # bootstrap a project

Rust

# Toolchain installed automatically via rust-toolchain.toml
# Manual install if needed:
rustup toolchain install nightly-2026-04-03
rustup component add rust-src rustc-dev --toolchain nightly-2026-04-03

CUDA

export PATH="/usr/local/cuda/bin:$PATH"
nvcc --version

LLVM (optional)

# Ubuntu/Debian
sudo apt install llvm-21

If your distro packages do not provide llvm-21, use LLVM's apt helper:

sudo apt-get install -y lsb-release wget software-properties-common gnupg
wget https://apt.llvm.org/llvm.sh && chmod +x llvm.sh
sudo ./llvm.sh 21

# Verify NVPTX support
llc-21 --version | grep nvptx

The pipeline prefers llc in Rust toolchain, and auto-discovers llc-22 and llc-21 on PATH (in that order). To pin a specific binary, set CUDA_OXIDE_LLC=/usr/bin/llc-21.

We emit TMA / tcgen05 / WGMMA intrinsics that llc from LLVM 20 and earlier can't handle. Simple kernels might still work with an older llc, but anything Hopper / Blackwell needs 21+.

Clang (host cuda-bindings)

The host cuda-bindings crate runs bindgen, which loads libclang and needs clang's own resource-dir stddef.h — a bare libclang1-* runtime is not enough.

sudo apt install clang-21   # or libclang-common-21-dev

cargo oxide doctor catches this up front; the symptom otherwise is a cryptic 'stddef.h' file not found during the host build.

Dev Container

The repository includes a standard devcontainer setup in .devcontainer/ for a reproducible CUDA, LLVM, Clang, and Rust environment. See the installation chapter for editor and CLI usage.

Verifying Installation

# Check that all prerequisites are in place
cargo oxide doctor

# Build and run an example end-to-end
cargo oxide run vecadd

cargo oxide doctor validates your Rust toolchain, CUDA toolkit, LLVM, and codegen backend. If everything is configured correctly, cargo oxide run vecadd compiles a Rust kernel to PTX, launches it on the GPU, and prints ✓ SUCCESS: All 1024 elements correct!.

Examples

60+ examples in crates/rustc-codegen-cuda/examples/. Highlights:

Example	Description
vecadd	Vector addition -- canonical first example
host_closure	Generic kernels with closures passed from host
generic	Generic kernels with monomorphization (scale<T>)
ord_cmp	Device-side Ord::cmp lowering for signed and unsigned integers
gemm_sol	GEMM SoL: 868 TFLOPS, 58% cublasLt SoL on B200 (148 SMs); 8 kernels
tcgen05	Blackwell tensor cores (sm_100a): TMEM, MMA, cta_group::2
atomics	GPU atomics: 6 types x 3 scopes x 5 orderings (20 tests)
cluster	Thread Block Clusters + DSMEM ring exchange (Hopper+)
async_mlp	Async MLP pipeline: GEMM → MatVec → ReLU across concurrent streams
mathdx_ffi_test	cuFFTDx thread-level FFT + cuBLASDx block-level GEMM
device_ffi_test	Device FFI: Rust kernels calling C++ CCCL warp-level reductions via LTOIR
async_vecadd	Async GPU execution with cuda-async and DeviceOperation
cross_crate_kernel	Library crates defining kernels, bundled into binaries

cargo oxide run vecadd
cargo oxide run gemm_sol

Crate Overview

User-Facing Crates

Crate	Description
cuda-device	Device intrinsics (thread::*, warp::*, barriers)
cuda-host	Typed module loading, launch helpers, LTOIR loader
cuda-macros	Proc macros (#[cuda_module], #[kernel], gpu_printf!)
cuda-bindings	Raw bindgen FFI bindings to cuda.h
cuda-core	Safe RAII wrappers (CudaContext, CudaStream, DeviceBuffer<T>, ...)
cuda-async	Async execution layer (DeviceOperation, DeviceFuture, DeviceBox<T>)
libnvvm-sys	dlopen bindings to libNVVM (used by cuda-host::ltoir)
nvjitlink-sys	dlopen bindings to nvJitLink (used by cuda-host::ltoir)

Compiler Crates

Crate	Description
rustc-codegen-cuda	Custom rustc backend
mir-importer	Rust MIR -> dialect-mir translation + pipeline
mir-lower	dialect-mir -> LLVM dialect lowering
dialect-mir	pliron dialect modelling Rust MIR
llvm-export	pliron-llvm shim + textual .ll exporter
dialect-nvvm	pliron dialect modelling NVVM intrinsics

Build Tooling

Crate	Description
cargo-oxide	Cargo subcommand (cargo oxide run, etc.)

Documentation

Directory	Description
cuda-oxide-book	Project book (Sphinx + MyST) — guides, compiler internals, API ref

Status

Highlights:

• End-to-end Rust -> PTX compilation
• Unified single-source compilation (host + device in one file)
• Generic functions with monomorphization
• Closures with captures (move and non-move via HMM)
• User-defined structs, enums, pattern matching
• Full GPU intrinsic support (thread, warp, shared memory, barriers, TMA, clusters, atomics)
• Cross-crate kernels
• LTOIR generation for Blackwell+ (device-side LTO)
• Device FFI: Rust <-> C++/CCCL interop via LTOIR
• MathDx integration: cuFFTDx thread-level FFT, cuBLASDx block-level GEMM
• Tile interop (experimental): cutile_inter_kernel chains a cutile-rs Tile kernel and a cuda-oxide SIMT PTX kernel on the same CUDA stream over shared device tensors. Intra-kernel Tile interop is work in progress and tracked in #96.
• Host runtime: cuda-core (explicit control, pinned host transfers) and cuda-async (composable async operations)
• GEMM SoL: 868 TFLOPS (58% of cublasLt FP16 SoL) on B200 (148 SMs) with cta_group::2 + CLC + 4-stage pipeline (gemm_sol example measures the cublasLt baseline live via bench/cublaslt_bench — absolute TFLOPS scale with SM count on smaller Blackwell DC SKUs; per-phase tables for both 148-SM and 80-SM variants are in crates/rustc-codegen-cuda/examples/gemm_sol/README.md)

Documentation

WIP: 🚧 The cuda-oxide book is the primary reference for the project. It covers SIMT kernel authoring in Rust, synchronous and asynchronous GPU programming, the compiler architecture, and more.

To build and serve the book locally, see cuda-oxide-book/README.md.

Ecosystem

cuda-oxide is one of several Rust + GPU efforts under active development. Projects in this space address different parts of the problem — Vulkan/SPIR-V for graphics, implicit offload via LLVM, third-party CUDA backends, safe driver bindings — and we've been working with maintainers across the broader Rust GPU community on how to move GPU computing in Rust forward together. For where cuda-oxide fits relative to other projects, see the Ecosystem appendix of the book.

License

The cuda-bindings crate is licensed under the NVIDIA Software License: LICENSE-NVIDIA. All other crates are licensed under the Apache License, Version 2.0: LICENSE-APACHE.
