robot_self_filter

A ROS 2 package that filters robot body parts from point cloud data, enabling sensors to ignore the robot's own geometry during perception tasks.

Overview

The robot_self_filter package removes points from sensor data that correspond to the robot's body, preventing self-occlusion issues in perception pipelines. It uses the robot's URDF model to create collision shapes and filters out points that fall within these shapes.

Key Features

• Multi-sensor support: Compatible with various LiDAR sensors (Ouster, Hesai, Robosense, Pandar)
• Dynamic filtering: Updates collision shapes based on robot joint states
• Configurable shapes: Supports spheres, boxes, and cylinders with customizable padding and scaling
• Visualization: Publishes collision shapes for debugging and tuning
• Performance optimized: Efficient point cloud processing using PCL

Installation

Prerequisites

• ROS 2 (tested on Humble/Iron)
• Dependencies:
  • rclcpp
  • tf2_ros
  • sensor_msgs
  • geometry_msgs
  • visualization_msgs
  • urdf
  • resource_retriever
  • pcl_ros
  • filters
  • bullet
  • assimp

Build

cd ~/ros2_ws
colcon build --packages-select robot_self_filter
source install/setup.bash

Usage

Quick Start

Launch the self filter node with your robot configuration:

ros2 launch robot_self_filter self_filter.launch.py \
    robot_description:="$(xacro /path/to/robot.urdf.xacro)" \
    filter_config:=/path/to/filter_config.yaml \
    in_pointcloud_topic:=/lidar/points \
    out_pointcloud_topic:=/lidar/points_filtered

Launch Parameters

Parameter	Type	Default	Description
robot_description	string	-	Robot URDF/XACRO description
filter_config	string	-	Path to YAML configuration file
in_pointcloud_topic	string	/cloud_in	Input point cloud topic
out_pointcloud_topic	string	/cloud_out	Filtered point cloud topic
lidar_sensor_type	int	2	Sensor type (0: XYZ, 1: XYZRGB, 2: Ouster, 3: Hesai, 4: Robosense, 5: Pandar)
zero_for_removed_points	bool	true	Set filtered points to zero instead of removing
use_sim_time	bool	true	Use simulation time
description_name	string	/robot_description	Robot description parameter namespace

Configuration

YAML Configuration File

The filter configuration is defined in a YAML file. See params/example.yaml for a complete example.

Basic Structure

self_filter_node:
  ros__parameters:
    sensor_frame: "lidar_frame"  # Frame of the sensor

    # Default shape parameters
    default_sphere_scale: 1.0
    default_sphere_padding: 0.01

    default_box_scale: [1.0, 1.0, 1.0]  # [x, y, z]
    default_box_padding: [0.01, 0.01, 0.01]  # [x, y, z]

    default_cylinder_scale: [1.0, 1.0]  # [radial, vertical]
    default_cylinder_padding: [0.01, 0.01]  # [radial, vertical]

    # Filtering parameters
    keep_organized: false  # Maintain organized point cloud structure
    zero_for_removed_points: false  # Zero points instead of removing
    invert: false  # Invert filter (keep only robot points)
    min_sensor_dist: 0.5  # Minimum distance from sensor to filter

    # Links to filter
    self_see_links:
      names:
        - base_link
        - arm_link_1
        - arm_link_2
        # ... add all robot links to filter

      # Per-link custom parameters (optional)
      arm_link_1:
        box_scale: [1.1, 1.1, 1.0]
        box_padding: [0.05, 0.05, 0.02]

Shape Types

The filter automatically determines shape types from the robot's URDF collision geometry:

• Sphere: Single scale and padding value
• Box: 3D scale and padding values [x, y, z]
• Cylinder: 2D scale and padding [radial, vertical]

Tuning Guidelines

1. Start with default values: Use scale=1.0 and small padding (0.01-0.05)
2. Visualize collision shapes: Check /collision_shapes topic in RViz
3. Adjust per-link parameters: Fine-tune problematic links individually
4. Consider sensor noise: Increase padding for noisy sensors
5. Monitor performance: Larger padding values may filter valid points

Topics

Subscribed Topics

• <in_pointcloud_topic> (sensor_msgs/PointCloud2): Raw point cloud from sensor
• /tf (tf2_msgs/TFMessage): Transform data
• /tf_static (tf2_msgs/TFMessage): Static transforms
• /joint_states (sensor_msgs/JointState): Robot joint positions

Published Topics

• <out_pointcloud_topic> (sensor_msgs/PointCloud2): Filtered point cloud
• /collision_shapes (visualization_msgs/MarkerArray): Visualization of filter shapes

Visualization

To visualize the collision shapes in RViz:

1. Add a MarkerArray display
2. Set topic to /collision_shapes
3. Collision shapes will appear as semi-transparent geometries

Sensor Types

The package supports multiple sensor types through the lidar_sensor_type parameter:

Value	Sensor Type	Point Type
0	Generic XYZ	pcl::PointXYZ
1	Generic XYZRGB	pcl::PointXYZRGB
2	Ouster	Custom Ouster point type
3	Hesai	Custom Hesai point type
4	Robosense	Custom Robosense point type
5	Pandar	Custom Pandar point type

Examples

Example 1: Mobile Robot with Arm

self_filter_mobile_robot:
  ros__parameters:
    sensor_frame: "lidar_link"
    min_sensor_dist: 0.3

    self_see_links:
      names:
        - base_link
        - wheel_left
        - wheel_right
        - arm_base
        - arm_link_1
        - arm_link_2
        - gripper

      # Wheels need extra padding for suspension movement
      wheel_left:
        cylinder_scale: [1.0, 1.0]
        cylinder_padding: [0.05, 0.1]

      wheel_right:
        cylinder_scale: [1.0, 1.0]
        cylinder_padding: [0.05, 0.1]

Example 2: Construction Equipment

See params/example.yaml for a complete configuration example for construction equipment with multiple moving parts.

Troubleshooting

Common Issues

1. Points not being filtered

   • Check sensor frame matches configuration
   • Verify TF tree is complete
   • Increase padding values
   • Check URDF collision geometries

2. Too many points filtered

   • Reduce padding values
   • Check scale factors (should typically be 1.0)
   • Verify min_sensor_dist setting

3. Performance issues

   • Reduce number of filtered links
   • Simplify collision geometries in URDF
   • Consider using zero_for_removed_points for organized clouds

4. No output point cloud

   • Verify input topic is publishing
   • Check remappings in launch file
   • Ensure robot_description is loaded

Contributing

Contributions are welcome! Please ensure your code follows ROS 2 coding standards and includes appropriate documentation.

License

BSD License - See package.xml for details

Maintainer

Lorenzo Terenzi lterenzi@ethz.ch

Author

ROS 2 version by Lorenzo Terenzi Original ROS 1 version by Eitan Marder-Eppstein
